Greetings,
I am new to Unraid and I have ran into an issue with getting hard drives to register to the OS.
I have 10 Hotswap bays (not using the hotswap feature, just using them as basic mount points for the server).
They are connected to a 6 Port and a 4 Port Back Plane that then connects to a Broadcom LSI MegaRAID SAS 2108 Raid controller (it should have Passthrough mode though I'm not sure if it is configured as such, I cant seem to be able to identify any way to access it's configuration).
At this moment I am trying to add my two 6TB data drives that hold my Plex Media to the server. However, as I have stated, they will not register to the OS as unassigned drives (Although I only want to use them as standalone drives for now).
After several restarts, I managed to get 1 of the HDDs to register, but Unraid was saying it was actually a 5TB HDD instead of 6TB.
The actual capacity that Unraid was saying it had was 4.99TB, however, when I insert the drive into my Windows 10 PC it registers with 5.5TB capacity. Any idea why I am losing .5TB of capacity on Unraid?
To make the issue worse, the moment I attempted to interact with the HDD in the GUI it dropped off the listing and disappeared. I have not been able to get it to register again since then.
Below is a listing of my System Devices from my server. Could someone provide some insight on what I may be missing or overlooking? I would appreciate it. Please let me know if you need any more information.
[8086:3406] 00:00.0 Host bridge: Intel Corporation 5520 I/O Hub to ESI Port (rev 13)
[8086:3408] 00:01.0 PCI bridge: Intel Corporation 5520/5500/X58 I/O Hub PCI Express Root Port 1 (rev 13)
[8086:340a] 00:03.0 PCI bridge: Intel Corporation 5520/5500/X58 I/O Hub PCI Express Root Port 3 (rev 13)
[8086:340c] 00:05.0 PCI bridge: Intel Corporation 5520/X58 I/O Hub PCI Express Root Port 5 (rev 13)
[8086:340e] 00:07.0 PCI bridge: Intel Corporation 5520/5500/X58 I/O Hub PCI Express Root Port 7 (rev 13)
[8086:3410] 00:09.0 PCI bridge: Intel Corporation 7500/5520/5500/X58 I/O Hub PCI Express Root Port 9 (rev 13)
[8086:3425] 00:10.0 PIC: Intel Corporation 7500/5520/5500/X58 Physical and Link Layer Registers Port 0 (rev 13)
[8086:3426] 00:10.1 PIC: Intel Corporation 7500/5520/5500/X58 Routing and Protocol Layer Registers Port 0 (rev 13)
[8086:3427] 00:11.0 PIC: Intel Corporation 7500/5520/5500 Physical and Link Layer Registers Port 1 (rev 13)
[8086:3428] 00:11.1 PIC: Intel Corporation 7500/5520/5500 Routing & Protocol Layer Register Port 1 (rev 13)
[8086:342d] 00:13.0 PIC: Intel Corporation 7500/5520/5500/X58 I/O Hub I/OxAPIC Interrupt Controller (rev 13)
[8086:342e] 00:14.0 PIC: Intel Corporation 7500/5520/5500/X58 I/O Hub System Management Registers (rev 13)
[8086:3422] 00:14.1 PIC: Intel Corporation 7500/5520/5500/X58 I/O Hub GPIO and Scratch Pad Registers (rev 13)
[8086:3423] 00:14.2 PIC: Intel Corporation 7500/5520/5500/X58 I/O Hub Control Status and RAS Registers (rev 13)
[8086:3438] 00:14.3 PIC: Intel Corporation 7500/5520/5500/X58 I/O Hub Throttle Registers (rev 13)
[8086:342f] 00:15.0 PIC: Intel Corporation 7500/5520/5500/X58 Trusted Execution Technology Registers (rev 13)
[8086:3430] 00:16.0 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:3431] 00:16.1 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:3432] 00:16.2 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:3433] 00:16.3 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:3429] 00:16.4 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:342a] 00:16.5 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:342b] 00:16.6 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:342c] 00:16.7 System peripheral: Intel Corporation 5520/5500/X58 Chipset QuickData Technology Device (rev 13)
[8086:3a37] 00:1a.0 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #4
[8086:3a38] 00:1a.1 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #5
[8086:3a39] 00:1a.2 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #6
[8086:3a3c] 00:1a.7 USB controller: Intel Corporation 82801JI (ICH10 Family) USB2 EHCI Controller #2
[8086:3a40] 00:1c.0 PCI bridge: Intel Corporation 82801JI (ICH10 Family) PCI Express Root Port 1
[8086:3a48] 00:1c.4 PCI bridge: Intel Corporation 82801JI (ICH10 Family) PCI Express Root Port 5
[8086:3a34] 00:1d.0 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #1
[8086:3a35] 00:1d.1 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #2
[8086:3a36] 00:1d.2 USB controller: Intel Corporation 82801JI (ICH10 Family) USB UHCI Controller #3
[8086:3a3a] 00:1d.7 USB controller: Intel Corporation 82801JI (ICH10 Family) USB2 EHCI Controller #1
[8086:244e] 00:1e.0 PCI bridge: Intel Corporation 82801 PCI Bridge (rev 90)
[8086:3a16] 00:1f.0 ISA bridge: Intel Corporation 82801JIR (ICH10R) LPC Interface Controller
[8086:3a20] 00:1f.2 IDE interface: Intel Corporation 82801JI (ICH10 Family) 4 port SATA IDE Controller #1
[8086:3a30] 00:1f.3 SMBus: Intel Corporation 82801JI (ICH10 Family) SMBus Controller
[8086:3a26] 00:1f.5 IDE interface: Intel Corporation 82801JI (ICH10 Family) 2 port SATA IDE Controller #2
[8086:10a7] 01:00.0 Ethernet controller: Intel Corporation 82575EB Gigabit Network Connection (rev 02)
[8086:10a7] 01:00.1 Ethernet controller: Intel Corporation 82575EB Gigabit Network Connection (rev 02)
[1000:0079] 03:00.0 RAID bus controller: Broadcom / LSI MegaRAID SAS 2108 [Liberator] (rev 05)
[102b:0522] 07:00.0 VGA compatible controller: Matrox Electronics Systems Ltd. MGA G200e [Pilot] ServerEngines (SEP1) (rev 02)
[8086:1010] 08:00.0 Ethernet controller: Intel Corporation 82546EB Gigabit Ethernet Controller (Copper) (rev 01)
[8086:1010] 08:00.1 Ethernet controller: Intel Corporation 82546EB Gigabit Ethernet Controller (Copper) (rev 01)
[8086:2c40] fe:00.0 Host bridge: Intel Corporation Xeon 5500/Core i7 QuickPath Architecture Generic Non-Core Registers (rev 05)
[8086:2c01] fe:00.1 Host bridge: Intel Corporation Xeon 5500/Core i7 QuickPath Architecture System Address Decoder (rev 05)
[8086:2c10] fe:02.0 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Link 0 (rev 05)
[8086:2c11] fe:02.1 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Physical 0 (rev 05)
[8086:2c14] fe:02.4 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Link 1 (rev 05)
[8086:2c15] fe:02.5 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Physical 1 (rev 05)
[8086:2c18] fe:03.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller (rev 05)
[8086:2c19] fe:03.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Target Address Decoder (rev 05)
[8086:2c1a] fe:03.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller RAS Registers (rev 05)
[8086:2c1c] fe:03.4 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Test Registers (rev 05)
[8086:2c20] fe:04.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Control Registers (rev 05)
[8086:2c21] fe:04.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Address Registers (rev 05)
[8086:2c22] fe:04.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Rank Registers (rev 05)
[8086:2c23] fe:04.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Thermal Control Registers (rev 05)
[8086:2c28] fe:05.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Control Registers (rev 05)
[8086:2c29] fe:05.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Address Registers (rev 05)
[8086:2c2a] fe:05.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Rank Registers (rev 05)
[8086:2c2b] fe:05.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Thermal Control Registers (rev 05)
[8086:2c30] fe:06.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Control Registers (rev 05)
[8086:2c31] fe:06.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Address Registers (rev 05)
[8086:2c32] fe:06.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Rank Registers (rev 05)
[8086:2c33] fe:06.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Thermal Control Registers (rev 05)
[8086:2c40] ff:00.0 Host bridge: Intel Corporation Xeon 5500/Core i7 QuickPath Architecture Generic Non-Core Registers (rev 05)
[8086:2c01] ff:00.1 Host bridge: Intel Corporation Xeon 5500/Core i7 QuickPath Architecture System Address Decoder (rev 05)
[8086:2c10] ff:02.0 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Link 0 (rev 05)
[8086:2c11] ff:02.1 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Physical 0 (rev 05)
[8086:2c14] ff:02.4 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Link 1 (rev 05)
[8086:2c15] ff:02.5 Host bridge: Intel Corporation Xeon 5500/Core i7 QPI Physical 1 (rev 05)
[8086:2c18] ff:03.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller (rev 05)
[8086:2c19] ff:03.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Target Address Decoder (rev 05)
[8086:2c1a] ff:03.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller RAS Registers (rev 05)
[8086:2c1c] ff:03.4 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Test Registers (rev 05)
[8086:2c20] ff:04.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Control Registers (rev 05)
[8086:2c21] ff:04.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Address Registers (rev 05)
[8086:2c22] ff:04.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Rank Registers (rev 05)
[8086:2c23] ff:04.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 0 Thermal Control Registers (rev 05)
[8086:2c28] ff:05.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Control Registers (rev 05)
[8086:2c29] ff:05.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Address Registers (rev 05)
[8086:2c2a] ff:05.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Rank Registers (rev 05)
[8086:2c2b] ff:05.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 1 Thermal Control Registers (rev 05)
[8086:2c30] ff:06.0 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Control Registers (rev 05)
[8086:2c31] ff:06.1 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Address Registers (rev 05)
[8086:2c32] ff:06.2 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Rank Registers (rev 05)
[8086:2c33] ff:06.3 Host bridge: Intel Corporation Xeon 5500/Core i7 Integrated Memory Controller Channel 2 Thermal Control Registers (rev 05)
