  1. I did see that Areca has a "Driver" for 6.10. Does this drive differ from what is in the main distro?
  2. I have two 1882i cards Latest firmware. Both cards are identical except for IP and S/N. I will d/l the cli tool today and try to spin down the 4 TB drive which is not part of the array. I use it as a stand alone backup drive to some data. the 6 TB drive is drive passed thru to a BlueIRIS windows VM for my security system. Again is can not thank you enough for spending cycle on this. IOMMU group 29:[17d3:1880] 03:00.0 RAID bus controller: Areca Technology Corp. ARC-188x series PCIe 2.0/3.0 to SAS/SATA 6/12Gb RAID Controller (rev 05) [1:0:0:0] disk Seagate ST6000NM0024-1HT R001 /dev/sdb 6.00TB [1:0:0:1] disk Seagate ST14000NM001G-2K R001 /dev/sdc 14.0TB [1:0:0:2] disk Seagate ST12000NM0008-2H R001 /dev/sdd 12.0TB [1:0:0:3] disk Seagate ST12000NM001G-2M R001 /dev/sde 12.0TB [1:0:0:4] disk Seagate ST10000NM0016-1T R001 /dev/sdf 10.0TB [1:0:0:5] disk Seagate ST10000NM0016-1T R001 /dev/sdh 10.0TB [1:0:0:6] disk Seagate ST10000NM0086-2A R001 /dev/sdi 10.0TB [1:0:0:7] disk Seagate ST10000NM0086-2A R001 /dev/sdj 10.0TB IOMMU group 30:[17d3:1880] 02:00.0 RAID bus controller: Areca Technology Corp. ARC-188x series PCIe 2.0/3.0 to SAS/SATA 6/12Gb RAID Controller (rev 05) [8:0:0:0] disk Seagate ST10000NM0016-1T R001 /dev/sdm 10.0TB [8:0:0:1] disk Seagate ST10000NM0016-1T R001 /dev/sdn 10.0TB [8:0:0:2] disk Seagate ST10000NM0016-1T R001 /dev/sdo 10.0TB [8:0:0:3] disk Seagate ST10000NM0016-1T R001 /dev/sdp 10.0TB [8:0:0:5] disk WDC WD4002FYYZ-01B7C R001 /dev/sdq 4.00TB [8:0:0:7] disk Seagate ST6000VN0041-2EL R001 /dev/sdr 6.00TB
  3. One of the main reason I went to unraid was for the spin down feature. I have been running QNAP's for years and those drives would spin all day. Now i can not live without it. I have turned so many people on to it. unfortunately i am their tech support arm whenever they want to do something new with their systems
  4. i have an extra ARC-1280 ML V2. I would of shipped it to you. thank you for going the extra mile on this.
  5. Just wanted to report. I upgraded to the last RC version (Version: 6.10.0-rc7) still no change in spin down behavior. i do get this in the logs. looks like the system is issuing commands to spin down but the drives are not listening except for the parity which are connected to the main board. May 10 14:54:59 STORAGE2 kernel: sdb: sdb1 May 10 14:54:59 STORAGE2 kernel: sdp: sdp1 May 10 14:57:03 STORAGE2 emhttpd: spinning down /dev/sdq May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdm May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdh May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdg May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdd May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdb May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdf May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdn May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdo May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdi May 10 15:07:02 STORAGE2 emhttpd: spinning down /dev/sdp May 10 15:07:32 STORAGE2 emhttpd: spinning down /dev/sdk May 10 15:07:32 STORAGE2 emhttpd: spinning down /dev/sdl May 10 15:09:51 STORAGE2 emhttpd: spinning down /dev/sdr May 10 15:12:04 STORAGE2 emhttpd: spinning down /dev/sdq May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdm May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdh May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdg May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdd May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdb May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdf May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdn May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdo May 10 15:22:03 STORAGE2 emhttpd: spinning down /dev/sdi May 10 15:24:52 STORAGE2 emhttpd: spinning down /dev/sdr May 10 15:25:37 STORAGE2 kernel: sdb: sdb1 May 10 15:25:37 STORAGE2 kernel: sdp: sdp1 May 10 15:27:05 STORAGE2 emhttpd: spinning down /dev/sdq May 10 15:29:46 STORAGE2 emhttpd: read SMART /dev/sdk May 10 15:29:46 STORAGE2 emhttpd: read SMART /dev/sdl May 10 15:39:53 STORAGE2 emhttpd: spinning down /dev/sdr May 10 15:42:06 STORAGE2 emhttpd: spinning down /dev/sd
  6. Something odd happened. Drives 9 & 10 went X on me. Thank the lord for 2 parity drives. System is rebuilding. I will try and issue more commands once rebuilt and 100%. Again, thank you for all the help and suggestions. I am trying to avoid buying a new adapter and there is nothing working with the ones I have. Something changed in 6.9.2 that broke spin down or compatibility for Areca adapters. I even logged into the adapter web UI and both have the same config …
  7. root@STORAGE2:~# lsscsi -g|grep "Areca" [1:0:16:0] process Areca RAID controller R001 - /dev/sg10 [8:0:16:0] process Areca RAID controller R001 - /dev/sg19 root@STORAGE2:~# sg_map /dev/sg0 /dev/sda /dev/sg1 /dev/sdb /dev/sg2 /dev/sdc /dev/sg3 /dev/sdd /dev/sg4 /dev/sde /dev/sg5 /dev/sdf /dev/sg6 /dev/sdg /dev/sg7 /dev/sdh /dev/sg8 /dev/sdi /dev/sg9 /dev/sdj /dev/sg10 /dev/sg11 /dev/sdk /dev/sg12 /dev/sdl /dev/sg13 /dev/sdm /dev/sg14 /dev/sdn /dev/sg15 /dev/sdo /dev/sg16 /dev/sdp /dev/sg17 /dev/sdq /dev/sg18 /dev/sdr /dev/sg19 root@STORAGE2:~# hdparm -y /dev/sg9 /dev/sg9: issuing standby command SG_IO: bad/missing sense data, sb[]: f0 00 05 00 00 00 00 0b 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 root@STORAGE2:~# hdparm -C /dev/sg9 /dev/sg9: SG_IO: bad/missing sense data, sb[]: f0 00 05 00 00 00 00 0b 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 drive state is: standby root@STORAGE2:~# smartctl -n never /dev/sg9 smartctl 7.3 2022-02-28 r5338 [x86_64-linux-5.15.35-Unraid] (local build) Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org Device is in ACTIVE mode SCSI device successfully opened Use 'smartctl -a' (or '-x') to print SMART (and more) information root@STORAGE2:~#
  8. Thank you for all help ! root@STORAGE2:~# smartctl -s standby,now /dev/sdj smartctl 7.3 2022-02-28 r5338 [x86_64-linux-5.15.35-Unraid] (local build) Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org SCSI STANDBY command failed: SCSI device successfully opened Use 'smartctl -a' (or '-x') to print SMART (and more) information root@STORAGE2:~# smartctl -n stanby /dev/sdj smartctl 7.3 2022-02-28 r5338 [x86_64-linux-5.15.35-Unraid] (local build) Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org =======> INVALID ARGUMENT TO -n: stanby =======> VALID ARGUMENTS ARE: never, sleep[,STATUS[,STATUS2]], standby[,STATUS[,STATUS2]], idle[,STATUS[,STATUS2]] <======= Use smartctl -h to get a usage summary root@STORAGE2:~# hdparm -C /dev/sdj /dev/sdj: SG_IO: bad/missing sense data, sb[]: f0 00 05 00 00 00 00 0b 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 drive state is: standby root@STORAGE2:~# hdparm -y /dev/sdj /dev/sdj: issuing standby command SG_IO: bad/missing sense data, sb[]: f0 00 05 00 00 00 00 0b 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 root@STORAGE2:~# lsscsi -g|grep "Areca" [1:0:16:0] process Areca RAID controller R001 - /dev/sg10 < Arcea 1881i drives 1 - 8 (sdb > sdi) > [8:0:16:0] process Areca RAID controller R001 - /dev/sg19 < Arcea 1881i drives 1 - 8 (sdj > sdq) > root@STORAGE2:~# smartctl -a -d areca,1,2 /dev/sg19 < device 1 on controller 2 > Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org === START OF INFORMATION SECTION === Model Family: Seagate Enterprise Capacity 3.5 HDD Device Model: ST10000NM0016-1TT101 Serial Number: ZA24S56L LU WWN Device Id: 5 000c50 0afaeae7f Firmware Version: SND0 User Capacity: 10,000,831,348,736 bytes [10.0 TB] Sector Sizes: 512 bytes logical, 4096 bytes physical Rotation Rate: 7200 rpm Form Factor: 3.5 inches Device is: In smartctl database 7.3/5360 ATA Version is: ACS-3 T13/2161-D revision 5 SATA Version is: SATA 3.1, 6.0 Gb/s (current: 6.0 Gb/s) Local Time is: Sat May 7 17:28:13 2022 EDT SMART support is: Available - device has SMART capability. SMART support is: Enabled Warning! SMART Attribute Data Structure error: invalid SMART checksum.
  9. 6.9.1 Was the last version of unRAID that the drives spun down properly.
  10. Thanks for assisting with this issue. Drive spin down always worked until a UNraid OS update. The config of the system has not changed since the system was built years ago. Something changed in the OS. Party drives and other drives not connected drives pin down as they should.
  11. Party Drives are connected to the onboard controller and the data drives are on Arcea 1882 Controllers. This config has not changed since the day the system was built. root@STORAGE2:~# hdparm -y /dev/sdh /dev/sdh: issuing standby command SG_IO: bad/missing sense data, sb[]: f0 00 05 00 00 00 00 0b 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
  12. Absolutely . Diags attached. Whatever you need from me to help diagnose the issue I am willing to put the time and effort in to resolving. storage2-diagnostics-20220506-1508.zip
  13. I know this issue is specifically for the Party drives not spinning down. But my system, is still suffering from my data drives not spinning down. It is very frustrating. Has there been any progress made on this issue. Everything was working just fine with spin down until a unRAID OS update that is now preventing them.
  14. BC thanks for the update. Glad your issue have been resolved. I have a bit of hope that maybe there is a fix out there for me . Would prefer not to buy a new card / cards to get this to work.
  15. Are there any updates on the Spindown issue. I have upgraded to the latest RC and my drives still continue to spin all day every day..
