March 22, 20215 yr I am seeing this on my cache drive: Mar 21 22:26:12 Tower emhttpd: read SMART /dev/nvme0n1 Mar 21 22:52:12 Tower emhttpd: shcmd (1683): mount -t xfs -o noatime /dev/nvme0n1p1 /mnt/cache Mar 21 22:52:12 Tower kernel: XFS (nvme0n1p1): Mounting V5 Filesystem Mar 21 22:52:12 Tower kernel: XFS (nvme0n1p1): Ending clean mount Mar 22 03:01:36 Tower root: /mnt/cache: 190.3 GiB (204309774336 bytes) trimmed on /dev/nvme0n1p1 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): metadata I/O error in "xfs_imap_to_bp+0x5c/0xa2 [xfs]" at daddr 0xf4afae0 len 32 error 5 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): metadata I/O error in "xfs_imap_to_bp+0x5c/0xa2 [xfs]" at daddr 0x2cf0d200 len 32 error 5 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): metadata I/O error in "xfs_da_read_buf+0x9e/0xfe [xfs]" at daddr 0x2cf8c7b0 len 8 error 5 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 42077208 op 0x1:(WRITE) flags 0x800 phys_seg 3 prio class 0 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 0 op 0x1:(WRITE) flags 0x800 phys_seg 0 prio class 0 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 88096136 op 0x1:(WRITE) flags 0x8800 phys_seg 1 prio class 0 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 809978401, offset 0, sector 754835864 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 500518589 op 0x1:(WRITE) flags 0x29800 phys_seg 1 prio class 0 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 12732352 op 0x0:(READ) flags 0x1000 phys_seg 4 prio class 0 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 256356112 op 0x1:(WRITE) flags 0x800 phys_seg 1 prio class 0 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 16747910, offset 37883904, sector 42077232 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 502525672 op 0x0:(READ) flags 0x0 phys_seg 4 prio class 0 Mar 22 19:40:33 Tower kernel: blk_update_request: I/O error, dev nvme0n1, sector 0 op 0x1:(WRITE) flags 0x800 phys_seg 0 prio class 0 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): log I/O error -5 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 274737869, offset 32768, sector 256356120 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 274737869, offset 36864, sector 256356136 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 4573547, offset 24576, sector 4572576 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 4573547, offset 16384, sector 4572552 Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 4573547, offset 0, sector 4572520 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): xfs_do_force_shutdown(0x2) called from line 1196 of file fs/xfs/xfs_log.c. Return address = 000000007f16e358 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): Log I/O Error Detected. Shutting down filesystem Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): Please unmount the filesystem and rectify the problem(s) Mar 22 19:40:33 Tower kernel: nvme0n1p1: writeback error on inode 277207800, offset 528384, sector 258101072 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): log I/O error -5 Mar 22 19:40:33 Tower kernel: XFS (nvme0n1p1): log I/O error -5 It is full of all these errors. See attach screenshot. Edited March 22, 20215 yr by CyberMew set title
March 22, 20215 yr Community Expert Cache device dropped offline: Mar 22 19:37:30 Tower kernel: nvme nvme0: I/O 393 QID 6 timeout, aborting Mar 22 19:37:30 Tower kernel: nvme nvme0: I/O 394 QID 6 timeout, aborting Mar 22 19:37:30 Tower kernel: nvme nvme0: I/O 395 QID 6 timeout, aborting Mar 22 19:37:30 Tower kernel: nvme nvme0: I/O 396 QID 6 timeout, aborting Mar 22 19:37:33 Tower kernel: nvme nvme0: I/O 397 QID 6 timeout, aborting Mar 22 19:37:33 Tower kernel: nvme nvme0: I/O 398 QID 6 timeout, aborting Mar 22 19:37:35 Tower kernel: nvme nvme0: I/O 1007 QID 2 timeout, aborting Mar 22 19:37:41 Tower kernel: nvme nvme0: I/O 675 QID 11 timeout, aborting Mar 22 19:38:00 Tower kernel: nvme nvme0: I/O 393 QID 6 timeout, reset controller Mar 22 19:38:31 Tower kernel: nvme nvme0: I/O 16 QID 0 timeout, reset controller Mar 22 19:39:32 Tower kernel: nvme nvme0: Device not ready; aborting reset, CSTS=0x1 Mar 22 19:39:32 Tower kernel: nvme nvme0: Abort status: 0x371 ### [PREVIOUS LINE REPEATED 7 TIMES] ### Mar 22 19:40:03 Tower kernel: nvme nvme0: Device not ready; aborting reset, CSTS=0x1 Mar 22 19:40:03 Tower kernel: nvme nvme0: Removing after probe failure status: -19 Mar 22 19:40:33 Tower kernel: nvme nvme0: Device not ready; aborting reset, CSTS=0x1 A power cycle should bring it back, but look for a BIOS update for your board to see if it doesn't happen again, sometimes disabling NVMe power states also helps.
March 22, 20215 yr Author Thanks, weird how it just dropped off. It didn't happened on the past few months until I updated the software and restarted the computer. Will restart and see if it makes any difference. I don't think the bios have any NVMe power states (I am using https://www.msi.com/Motherboard/support/x470-gaming-pro-carbon). Restarting now, will report back soon
March 22, 20215 yr Author Seems like the cache drive is no longer detected tower-diagnostics-20210322-2139.zip
March 22, 20215 yr Community Expert Did you power cycle? Just rebooting might not be enough, if a power cycle didn't help it's possibly a failed NVMe device.
March 22, 20215 yr Author Ok it's back after shutdown, but it is under unassigned, and if I select it as a cache drive, it says New device. Will my cache drive data still be there? How can I fix or restore it without causing further issues?
March 22, 20215 yr Community Expert 8 minutes ago, CyberMew said: and if I select it as a cache drive, it says New device As long as there's no "all data on this device will be deleted" warning on the right side of the SSD it's fine.
March 22, 20215 yr Author Thank you for the reassurance! Only seeing these yellow warnings: Mar 22 22:19:24 Tower kernel: tsc: Fast TSC calibration failed Mar 22 22:19:24 Tower kernel: ACPI: Early table checksum verification disabled Mar 22 22:19:24 Tower kernel: pci 0000:27:00.0: BAR 9: failed to assign [mem size 0x00400000 64bit] Mar 22 22:19:24 Tower kernel: pci 0000:27:00.0: BAR 7: failed to assign [mem size 0x00040000 64bit] Mar 22 22:19:24 Tower kernel: floppy0: no floppy controllers found Mar 22 22:19:24 Tower kernel: random: 6 urandom warning(s) missed due to ratelimiting Mar 22 22:19:27 Tower rpc.statd[1933]: Failed to read /var/lib/nfs/state: Success But so far so good, hope it stays that way.. thanks a lot!
