[Hardware error] CPU, Memory, PCIe

Featured Replies

Good evening



I've been getting these errors below after upgrading from 6.8.3 to 6.9.2 recently. The server appears to be running fine but I'm worried as these errors were not noticed before the upgrade.



I have a AMD Radeon R7 passed through to a Windows 10 VM. I recently added more ECC Kingston RAM (Total 16GBx4).



MB: Asrock X570 Steel Legend

CPU: AMD Ryzen 7 3700X



Recent diagnostics attached. Any help is much appreciated.



Thanks





dhaka-diagnostics-20210813-2049.zip

Are there any symptoms you are noticing or just errors in logs?

Aug 13 06:05:24 Dhaka kernel: [Hardware Error]: Unified Memory Controller Ext. Error Code: 0, DRAM ECC error.
Aug 13 06:05:24 Dhaka kernel: EDAC MC0: 1 CE on mc#0csrow#3channel#0 (csrow:3 channel:0 page:0x5b7962 offset:0x880 grain:64 syndrome:0x1000)

Looks like a bad stick

  • Author
4 hours ago, jonp said:

Are there any symptoms you are noticing or just errors in logs?

I haven't noticed any symptoms - just errors in the logs.

  • Author
4 hours ago, Squid said:
Aug 13 06:05:24 Dhaka kernel: [Hardware Error]: Unified Memory Controller Ext. Error Code: 0, DRAM ECC error.
Aug 13 06:05:24 Dhaka kernel: EDAC MC0: 1 CE on mc#0csrow#3channel#0 (csrow:3 channel:0 page:0x5b7962 offset:0x880 grain:64 syndrome:0x1000)

Looks like a bad stick

I'll remove the new sticks and see. Could there be any long term consequences if I leave them there do you think? As the server appears to be running fine.

  • Author

Looks like it was bad DRAM sticks. I've removed them and errors have disappeared. Thanks for your help.

On 8/16/2021 at 6:54 PM, sfaruque said:

Could there be any long term consequences if I leave them there do you think? As the server appears to be running fine.

My opinion:



You purchased ECC memory and are using it so that if/when one starts going bad you can replace it.  Sure the errors are currently being corrected, but that is simply the stick telling you "replace me".  If you have ECC memory and chose to not replace the memory when errors begin to happen then I'd question why you even bought ECC memory and a compatible CPU / motherboard in the first place.


  • Author
8 hours ago, Squid said:

My opinion:



You purchased ECC memory and are using it so that if/when one starts going bad you can replace it.  Sure the errors are currently being corrected, but that is simply the stick telling you "replace me".  If you have ECC memory and chose to not replace the memory when errors begin to happen then I'd question why you even bought ECC memory and a compatible CPU / motherboard in the first place.

Very valid point. Noted. Thanks.
