ontheroad Posted April 7, 2022 Share Posted April 7, 2022 Hello, Evey one, What is the Linux kernel version of UNRAID? Can GUC/NUC be enabled?Thank you for your help https://jellyfin.org/docs/general/administration/hardware-acceleration.html#intel-gen9-and-gen11-igpus https://github.com/intel/media-driver#known-issues-and-limitations Quote Link to comment
astronax Posted April 7, 2022 Share Posted April 7, 2022 (edited) u can open the unraid bash from the webgui or use ssh to connect and enter uname –r which returns me for unraid 6.9.2 5.10.28 6.10.x rc seems to have 5.15.30 https://forums.unraid.net/bug-reports/prereleases/unraid-os-version-6100-rc4-available-r1774 for the second part, i guess u are asking for a Media Center Application in relation to hardware de/encoding, this is not as simple We have the great Intel Plugin from the community Apps, i already used handbrake with this hardware acceleration from my intel 10 series GPU But it is not possible to use onboard Intel GPU as output source for your television so far. to ouput via hdmi u need a dedicated GPU. if you only want to use this inside a docker or VM, with not HDMi /Displayport output you might be fine. Edited April 7, 2022 by astronax Quote Link to comment
ich777 Posted April 7, 2022 Share Posted April 7, 2022 56 minutes ago, astronax said: We have the great Intel Plugin from the community Apps, i already used handbrake with this hardware acceleration from my intel 10 series GPU Keep in mind that GVT-g is only supported up to 10th Gen Intel CPUs, please see this post: Click 11 hours ago, ontheroad said: Hello, Evey one, What is the Linux kernel version of UNRAID? Can GUC/NUC be enabled?Thank you for your help From what I know HW transcoding is working fine in my Jellyfin container with 11th Gen. Intel CPUs (just be sure to also try VAAPI if QuickSync isn't working for you). 1 Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 On 4/8/2022 at 1:49 AM, ich777 said: Keep in mind that GVT-g is only supported up to 10th Gen Intel CPUs, please see this post: Click From what I know HW transcoding is working fine in my Jellyfin container with 11th Gen. Intel CPUs (just be sure to also try VAAPI if QuickSync isn't working for you). Hi @ich777 what is your unraid version？ on 6.9.2 my N6005 HW transcoding well with both Plex and emby，when I upgrade to 6.10 （rc2，3，4），it just broken.I have tried many method，incloud ‘echo "blacklist i915" > /boot/config/modprobe.d/i915.conf’，'install Intel_gpu_top', 'options i915 force_probe=4e71 options i915 enable_guc=2'，I can see /dev/dri shows card0 and renderD128,but all of these did not work. someone uses 11gen core cpu like 1135G7, 11500 can use HW transcoding without any code,but my 11gen Pentium CPU cant. is there any other steps for Jasper Laker ? sorry about my poor English. Quote Link to comment
ich777 Posted April 20, 2022 Share Posted April 20, 2022 20 minutes ago, always67 said: options i915 force_probe=4e71 options i915 enable_guc=2 Do you have those options put somewhere? Please post your Diagnostics. 20 minutes ago, always67 said: @ich777 what is your unraid version？ I have no issues with my 10th gen i5-10600 on 6.8.3, 6.9.0, 6.9.1, 6.9.2, 6.10.0-RC series. Also my test system with a Asrock J3160-ITX has no issue on those versions using the iGPU for transcoding. Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 24 minutes ago, ich777 said: Do you have those options put somewhere? Please post your Diagnostics. I have no issues with my 10th gen i5-10600 on 6.8.3, 6.9.0, 6.9.1, 6.9.2, 6.10.0-RC series. Also my test system with a Asrock J3160-ITX has no issue on those versions using the iGPU for transcoding. here is my Diagnostics unraid-diagnostics-with blacklist i915 and intel_gpu_top.zip unraid-diagnostics-with force_probe=4e71 enable_guc=2 in boot config modprobe.di915.conf.zip unraid-diagnostics-without any config.zip Quote Link to comment
ich777 Posted April 20, 2022 Share Posted April 20, 2022 5 minutes ago, always67 said: here is my Diagnostics Please remove any option or better speaking force_probe, blacklist the i915 module, install only the Intel GPU TOP plugin, the plugin will handle everything for you including the force_probe and reboot. Do you have a monitor connected to the iGPU? If not temporarily connect a monitor to it and try it again. 1 Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 11 minutes ago, ich777 said: 请删除任何选项或更好地说 force_probe，将 i915 模块列入黑名单，仅安装 Intel GPU TOP 插件，该插件将为您处理所有事情，包括 force_probe 和重启。 你有连接到 iGPU 的显示器吗？如果没有暂时将显示器连接到它，然后再试一次。 thanks for your help, now I have only Intel GPU TOP installed，but still not work. I will try connect my monitor later. unraid-diagnostics-20220420-1530.zip Quote Link to comment
ich777 Posted April 20, 2022 Share Posted April 20, 2022 27 minutes ago, always67 said: thanks for your help, now I have only Intel GPU TOP installed，but still not work. I will try connect my monitor later. Oh, I forgot that you have to blacklist the iGPU first because you are on 6.10.0-rc4, please execute this from the command line and reboot afterwards: echo "blacklist i915" > /boot/config/modprobe.d/i915.conf Do you've mounted the transcoding directory from Emby to your /tmp directory? If so please don't do this, this can cause OOM errors, I would rather recommend doing it like this: Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 32 minutes ago, ich777 said: Oh, I forgot that you have to blacklist the iGPU first because you are on 6.10.0-rc4, please execute this from the command line and reboot afterwards: echo "blacklist i915" > /boot/config/modprobe.d/i915.conf Do you've mounted the transcoding directory from Emby to your /tmp directory? If so please don't do this, this can cause OOM errors, I would rather recommend doing it like this: with echo "blacklist i915" > /boot/config/modprobe.d/i915.conf and reboot ,still with no luck unraid-diagnostics-20220420-1637.zip Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 What confuses me is that it works fine on 6.9.2 Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 9 minutes ago, always67 said: with echo "blacklist i915" > /boot/config/modprobe.d/i915.conf and reboot ,still with no luck unraid-diagnostics-20220420-1637.zip 76.25 kB · 0 downloads here is my emby logs ffmpeg-transcode-23cdae61-17c8-4cd4-950f-e7be3bbcadbd_1.txt embyserver.txt ffmpeg-transcode-23cdae61-17c8-4cd4-950f-e7be3bbcadbd_1graph.txt Quote Link to comment
ich777 Posted April 20, 2022 Share Posted April 20, 2022 18 minutes ago, always67 said: here is my emby logs Please try to connect a monitor to the iGPU before turning on the server and see if it solves the issue. Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 2 minutes ago, ich777 said: Please try to connect a monitor to the iGPU before turning on the server and see if it solves the issue. thank you for your advice i will try it later Quote Link to comment
ich777 Posted April 20, 2022 Share Posted April 20, 2022 1 hour ago, always67 said: thank you for your advice i will try it later I would also recommend to enable GUC/HUC on your CPU by adding this to your syslinux.conf: i915.enable_guc=3 Quote Link to comment
always67 Posted April 20, 2022 Share Posted April 20, 2022 2 hours ago, ich777 said: I would also recommend to enable GUC/HUC on your CPU by adding this to your syslinux.conf: i915.enable_guc=3 FYI: I have HW transcoding working on 6.9.2 by vi /boot/config/modprobe.d/i915.conf options i915 force_probe=4e71 options i915 enable_guc=2 modprobe i915 if I only use intel_gpu_top,it wont have HW Transcoding. And on 6.10 rc4,by echo "blacklist i915" > /boot/config/modprobe.d/i915.conf i915.enable_guc=3 in syslinux.conf the system cant initialize GPU (emby does the same) I have read the system logs 'Apr 20 06:43:24 unraid kernel: i915 0000:00:02.0: GuC initialization failed -110 Apr 20 06:43:24 unraid kernel: i915 0000:00:02.0: Enabling uc failed (-5) Apr 20 06:43:24 unraid kernel: i915 0000:00:02.0: Failed to initialize GPU, declaring it wedged! Apr 20 06:43:24 unraid kernel: i915 0000:00:02.0: [drm:add_taint_for_CI [i915]] CI tainted:0x9 by intel_gt_init+0x22a/0x242 [i915]' sorry for taking up so much of your time If it is a kernel problem I will go back to 6.9.2 after many tries unraid-diagnostics-20220420-2146.zip unraid-diagnostics-20220420-2139.zip Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 On 4/20/2022 at 6:50 PM, ich777 said: I would also recommend to enable GUC/HUC on your CPU by adding this to your syslinux.conf: i915.enable_guc=3 Hi @ich777 After many attempts and analysis, I think the reason why 6.10 rc cannot hardware decode is that HUC cannot be enabled. Whether adding i915.enable_guc=2/3 in syslinux.cfg or adding options i915 enable_guc=2 in modprobe.d/i915.conf, the system log always showed ‘Apr 20 06:35:26 unraid kernel: i915 0000:00:02.0: GuC initialization failed -110 Apr 20 06:35:26 unraid kernel: i915 0000:00:02.0: Enabling uc failed (-5) Apr 20 06:35:26 unraid kernel: i915 0000:00:02.0: Failed to initialize GPU, declaring it wedged! Apr 20 06:35:26 unraid kernel: i915 0000:00:02.0: [drm:add_taint_for_CI [i915]] CI tainted:0x9 by intel_gt_init+0x22a/0x242 [i915]’ However，when I came back to 6.9.2, I can see ‘Apr 21 05:18:12 unraid kernel: i915 0000:00:02.0: [drm] GuC firmware i915/ehl_guc_33.0.4.bin version 33.0 submission:disabled’ ’Apr 21 05:18:12 unraid kernel: i915 0000:00:02.0: [drm] HuC firmware i915/ehl_huc_9.0.0.bin version 9.0 authenticated:yes‘ then，the HW decode works fine Quote Link to comment
ich777 Posted April 21, 2022 Share Posted April 21, 2022 2 minutes ago, always67 said: After many attempts and analysis, I think the reason why 6.10 rc cannot hardware decode is that HUC cannot be enabled. Can you pleas give me the output from: ls /lib/firmware/i915 when you are on 6.10.0-rc4? Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 3 minutes ago, ich777 said: Can you pleas give me the output from: ls /lib/firmware/i915 when you are on 6.10.0-rc4? Please wait a moment, I will upgrade the system right away. I have to say that the unraid upgrade/downgrade system is very convenient Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 10 minutes ago, ich777 said: Can you pleas give me the output from: ls /lib/firmware/i915 when you are on 6.10.0-rc4? root@unraid:~# ls /lib/firmware/i915 (RC 4) adlp_dmc_ver2_10.bin cml_huc_4.0.0.bin icl_dmc_ver1_09.bin skl_dmc_ver1_27.bin adlp_guc_62.0.3.bin dg1_dmc_ver2_02.bin icl_guc_62.0.0.bin skl_guc_62.0.0.bin adls_dmc_ver2_01.bin ehl_guc_62.0.0.bin icl_huc_9.0.0.bin skl_huc_2.0.0.bin bxt_dmc_ver1_07.bin ehl_huc_9.0.0.bin kbl_dmc_ver1_04.bin tgl_dmc_ver2_12.bin bxt_guc_62.0.0.bin glk_dmc_ver1_04.bin kbl_guc_62.0.0.bin tgl_guc_62.0.0.bin bxt_huc_2.0.0.bin glk_guc_62.0.0.bin kbl_huc_4.0.0.bin tgl_huc_7.9.3.bin cml_guc_62.0.0.bin glk_huc_4.0.0.bin rkl_dmc_ver2_03.bin root@unraid:~# ls /lib/firmware/i915 (6.9.2) bxt_dmc_ver1_07.bin cml_huc_4.0.0.bin glk_dmc_ver1_04.bin icl_guc_33.0.0.bin kbl_huc_4.0.0.bin skl_huc_2.0.0.bin bxt_guc_33.0.0.bin cnl_dmc_ver1_07.bin glk_guc_33.0.0.bin icl_huc_9.0.0.bin rkl_dmc_ver2_02.bin tgl_dmc_ver2_08.bin bxt_huc_2.0.0.bin ehl_guc_33.0.4.bin glk_huc_4.0.0.bin kbl_dmc_ver1_04.bin skl_dmc_ver1_27.bin tgl_guc_35.2.0.bin cml_guc_33.0.0.bin ehl_huc_9.0.0.bin icl_dmc_ver1_09.bin kbl_guc_33.0.0.bin skl_guc_33.0.0.bin tgl_huc_7.5.0.bin Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 7 minutes ago, always67 said: root@unraid:~# ls /lib/firmware/i915 (RC 4) adlp_dmc_ver2_10.bin cml_huc_4.0.0.bin icl_dmc_ver1_09.bin skl_dmc_ver1_27.bin adlp_guc_62.0.3.bin dg1_dmc_ver2_02.bin icl_guc_62.0.0.bin skl_guc_62.0.0.bin adls_dmc_ver2_01.bin ehl_guc_62.0.0.bin icl_huc_9.0.0.bin skl_huc_2.0.0.bin bxt_dmc_ver1_07.bin ehl_huc_9.0.0.bin kbl_dmc_ver1_04.bin tgl_dmc_ver2_12.bin bxt_guc_62.0.0.bin glk_dmc_ver1_04.bin kbl_guc_62.0.0.bin tgl_guc_62.0.0.bin bxt_huc_2.0.0.bin glk_guc_62.0.0.bin kbl_huc_4.0.0.bin tgl_huc_7.9.3.bin cml_guc_62.0.0.bin glk_huc_4.0.0.bin rkl_dmc_ver2_03.bin root@unraid:~# ls /lib/firmware/i915 (6.9.2) bxt_dmc_ver1_07.bin cml_huc_4.0.0.bin glk_dmc_ver1_04.bin icl_guc_33.0.0.bin kbl_huc_4.0.0.bin skl_huc_2.0.0.bin bxt_guc_33.0.0.bin cnl_dmc_ver1_07.bin glk_guc_33.0.0.bin icl_huc_9.0.0.bin rkl_dmc_ver2_02.bin tgl_dmc_ver2_08.bin bxt_huc_2.0.0.bin ehl_guc_33.0.4.bin glk_huc_4.0.0.bin kbl_dmc_ver1_04.bin skl_dmc_ver1_27.bin tgl_guc_35.2.0.bin cml_guc_33.0.0.bin ehl_huc_9.0.0.bin icl_dmc_ver1_09.bin kbl_guc_33.0.0.bin skl_guc_33.0.0.bin tgl_huc_7.5.0.bin Maybe I can simply replace the 6.9.2 driver with the 6.10 RC？ Quote Link to comment
ich777 Posted April 21, 2022 Share Posted April 21, 2022 13 minutes ago, always67 said: Maybe I can simply replace the 6.9.2 driver with the 6.10 RC？ No, that is not possible… Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 12 minutes ago, always67 said: Maybe I can simply replace the 6.9.2 driver with the 6.10 RC？ oh,every driver I replaced was restored. Quote Link to comment
ich777 Posted April 21, 2022 Share Posted April 21, 2022 Just now, always67 said: oh,every driver I replaced was restored. Don‘t do that, this is not like on Windows, each driver version has to be compiled for the appropriate Kernel version. Quote Link to comment
always67 Posted April 21, 2022 Share Posted April 21, 2022 Just now, ich777 said: Don‘t do that, this is not like on Windows, each driver version has to be compiled for the appropriate Kernel version. forgive my ignorance.Too many people pay attention to the 12th generation,I can't find information about the 11th generation. And Jasperlake's GPU is actually same as Comet Lake Quote Link to comment
