Jarsky Posted August 15, 2022 Share Posted August 15, 2022 (edited) Hi all, I just logged into my UnRAID and noticed a popup about checksum issues from file integrity. On looking at the log, I realised there are ongoing BTRFS error notifications for my NVMe drives Im running UnRAID 6.10.3. ASRock X570 Taichi with 4.60 BIOS (November 2021). 2 x 1TB Crucial P1 M.2 NVMe's on the board. The drives are in a "cache pool" that are a Mirror, used for holding my Dockers & VM's I'm seeing these errors in the Log Aug 13 06:46:20 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 752, gen 0 Aug 13 06:46:20 TOWER kernel: BTRFS info (device nvme0n1p1): read error corrected: ino 819355 off 11784499200 (dev /dev/nvme0n1p1 sector 1268009080) Aug 13 06:46:31 TOWER kernel: BTRFS warning (device nvme0n1p1): csum failed root 5 ino 819355 off 49962971136 csum 0x53014952 expected csum 0x26cf4179 mirror 2 Aug 13 06:46:31 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 753, gen 0 Aug 13 06:46:31 TOWER kernel: BTRFS info (device nvme0n1p1): read error corrected: ino 819355 off 49962971136 (dev /dev/nvme0n1p1 sector 1671624720) Aug 13 07:52:39 TOWER kernel: BTRFS warning (device nvme0n1p1): csum failed root 5 ino 819355 off 50563215360 csum 0x4fe4c983 expected csum 0x7c3f67e3 mirror 1 Aug 13 07:52:39 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 754, gen 0 Aug 13 07:52:40 TOWER kernel: BTRFS info (device nvme0n1p1): read error corrected: ino 819355 off 50563215360 (dev /dev/nvme0n1p1 sector 1019641256) Aug 14 02:06:16 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 755, gen 0 Aug 14 02:07:54 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 516561707008 on dev /dev/nvme1n1p1, physical 469262540800, root 5, inode 819355, offset 1276887040, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 14 02:07:54 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 756, gen 0 Aug 14 02:07:59 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 757, gen 0 The NVMe drives look physically healthy from smartctl root@TOWER:~# smartctl --all -H /dev/nvme0n1 Spoiler smartctl 7.3 2022-02-28 r5338 [x86_64-linux-5.15.46-Unraid] (local build) Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org === START OF INFORMATION SECTION === Model Number: CT1000P1SSD8 Serial Number: 1942E22465EB Firmware Version: P3CR013 PCI Vendor/Subsystem ID: 0xc0a9 IEEE OUI Identifier: 0x00a075 Controller ID: 1 NVMe Version: 1.3 Number of Namespaces: 1 Namespace 1 Size/Capacity: 1,000,204,886,016 [1.00 TB] Namespace 1 Formatted LBA Size: 512 Namespace 1 IEEE EUI-64: 00a075 19e22465eb Local Time is: Mon Aug 15 17:20:18 2022 NZST Firmware Updates (0x14): 2 Slots, no Reset required Optional Admin Commands (0x0016): Format Frmw_DL Self_Test Optional NVM Commands (0x005e): Wr_Unc DS_Mngmt Wr_Zero Sav/Sel_Feat Timestmp Log Page Attributes (0x0f): S/H_per_NS Cmd_Eff_Lg Ext_Get_Lg Telmtry_Lg Maximum Data Transfer Size: 32 Pages Warning Comp. Temp. Threshold: 70 Celsius Critical Comp. Temp. Threshold: 80 Celsius Supported Power States St Op Max Active Idle RL RT WL WT Ent_Lat Ex_Lat 0 + 9.00W - - 0 0 0 0 5 5 1 + 4.60W - - 1 1 1 1 30 30 2 + 3.80W - - 2 2 2 2 30 30 3 - 0.0500W - - 3 3 3 3 1000 1000 4 - 0.0040W - - 4 4 4 4 6000 8000 Supported LBA Sizes (NSID 0x1) Id Fmt Data Metadt Rel_Perf 0 + 512 0 0 === START OF SMART DATA SECTION === SMART overall-health self-assessment test result: FAILED! - NVM subsystem reliability has been degraded SMART/Health Information (NVMe Log 0x02) Critical Warning: 0x04 Temperature: 46 Celsius Available Spare: 100% Available Spare Threshold: 10% Percentage Used: 99% Data Units Read: 24,395,362 [12.4 TB] Data Units Written: 279,765,903 [143 TB] Host Read Commands: 272,087,789 Host Write Commands: 5,433,505,136 Controller Busy Time: 69,775 Power Cycles: 82 Power On Hours: 22,735 Unsafe Shutdowns: 37 Media and Data Integrity Errors: 0 Error Information Log Entries: 0 Warning Comp. Temperature Time: 66 Critical Comp. Temperature Time: 0 Temperature Sensor 1: 46 Celsius Temperature Sensor 2: 47 Celsius Temperature Sensor 5: 55 Celsius Thermal Temp. 1 Transition Count: 21217 Thermal Temp. 2 Transition Count: 795 Thermal Temp. 1 Total Time: 28233845 Thermal Temp. 2 Total Time: 4910317 Error Information (NVMe Log 0x01, 16 of 256 entries) No Errors Logged root@TOWER:~# smartctl --all -H /dev/nvme1n1 Spoiler smartctl 7.3 2022-02-28 r5338 [x86_64-linux-5.15.46-Unraid] (local build) Copyright (C) 2002-22, Bruce Allen, Christian Franke, www.smartmontools.org === START OF INFORMATION SECTION === Model Number: CT1000P1SSD8 Serial Number: 1934E21B2513 Firmware Version: P3CR013 PCI Vendor/Subsystem ID: 0xc0a9 IEEE OUI Identifier: 0x00a075 Controller ID: 1 NVMe Version: 1.3 Number of Namespaces: 1 Namespace 1 Size/Capacity: 1,000,204,886,016 [1.00 TB] Namespace 1 Formatted LBA Size: 512 Namespace 1 IEEE EUI-64: 00a075 19e21b2513 Local Time is: Mon Aug 15 17:20:23 2022 NZST Firmware Updates (0x14): 2 Slots, no Reset required Optional Admin Commands (0x0016): Format Frmw_DL Self_Test Optional NVM Commands (0x005e): Wr_Unc DS_Mngmt Wr_Zero Sav/Sel_Feat Timestmp Log Page Attributes (0x0f): S/H_per_NS Cmd_Eff_Lg Ext_Get_Lg Telmtry_Lg Maximum Data Transfer Size: 32 Pages Warning Comp. Temp. Threshold: 70 Celsius Critical Comp. Temp. Threshold: 80 Celsius Supported Power States St Op Max Active Idle RL RT WL WT Ent_Lat Ex_Lat 0 + 9.00W - - 0 0 0 0 5 5 1 + 4.60W - - 1 1 1 1 30 30 2 + 3.80W - - 2 2 2 2 30 30 3 - 0.0500W - - 3 3 3 3 1000 1000 4 - 0.0040W - - 4 4 4 4 6000 8000 Supported LBA Sizes (NSID 0x1) Id Fmt Data Metadt Rel_Perf 0 + 512 0 0 === START OF SMART DATA SECTION === SMART overall-health self-assessment test result: PASSED SMART/Health Information (NVMe Log 0x02) Critical Warning: 0x00 Temperature: 45 Celsius Available Spare: 100% Available Spare Threshold: 10% Percentage Used: 89% Data Units Read: 26,242,139 [13.4 TB] Data Units Written: 278,143,832 [142 TB] Host Read Commands: 280,790,435 Host Write Commands: 5,490,535,695 Controller Busy Time: 64,057 Power Cycles: 79 Power On Hours: 22,622 Unsafe Shutdowns: 34 Media and Data Integrity Errors: 0 Error Information Log Entries: 0 Warning Comp. Temperature Time: 0 Critical Comp. Temperature Time: 0 Temperature Sensor 1: 46 Celsius Temperature Sensor 2: 45 Celsius Temperature Sensor 5: 54 Celsius Thermal Temp. 1 Transition Count: 318 Thermal Temp. 1 Total Time: 1965751 Error Information (NVMe Log 0x01, 16 of 256 entries) No Errors Logged I ran a check on the file system with BTRFS, and im getting errors with nvme0n1p1 root@TOWER:~# btrfs check --force /dev/nvme0n1p1 Spoiler root 5 inode 8752743 errors 2001, no inode item, link count wrong unresolved ref dir 8749677 index 366 namelen 10 name _00365.wal filetype 1 errors 4, no inode ref root 5 inode 8752744 errors 2001, no inode item, link count wrong unresolved ref dir 8749678 index 211 namelen 23 name 000000091-000000001.tsm filetype 1 errors 4, no inode ref root 5 inode 8752745 errors 2001, no inode item, link count wrong unresolved ref dir 3480794 index 196000 namelen 45 name 8e6baa014e0c6025c722620f6b38c16c550e0892.json filetype 1 errors 4, no inode ref root 5 inode 8752746 errors 2001, no inode item, link count wrong unresolved ref dir 8749677 index 367 namelen 10 name _00366.wal filetype 1 errors 4, no inode ref root 5 inode 8752747 errors 2001, no inode item, link count wrong unresolved ref dir 3480794 index 196002 namelen 45 name 823ae318b4984e81a0759b9ca9f73f9ea0c4c759.json filetype 1 errors 4, no inode ref ERROR: errors found in fs roots found 215344644096 bytes used, error(s) found total csum bytes: 0 total tree bytes: 89866240 total fs tree bytes: 0 total extent tree bytes: 89686016 btree space waste bytes: 22181978 file data blocks allocated: 0 referenced 0 root@TOWER:~# btrfs check --force /dev/nvme1n1p1 Spoiler Opening filesystem to check... WARNING: filesystem mounted, continuing because of --force Checking filesystem on /dev/nvme1n1p1 UUID: f7f0ec9a-281c-4352-8557-336143708cd1 [1/7] checking root items [2/7] checking extents [3/7] checking free space tree [4/7] checking fs roots [5/7] checking only csums items (without verifying data) [6/7] checking root refs [7/7] checking quota groups skipped (not enabled on this FS) found 916449837056 bytes used, no error found total csum bytes: 881724912 total tree bytes: 2476294144 total fs tree bytes: 834617344 total extent tree bytes: 523468800 btree space waste bytes: 472071382 file data blocks allocated: 15728413237248 referenced 736101736448 Is this an issue from space? I have 80GB total free left of the 1TB Do i need to delete/move data? Do i need to unmount it and run a repair? e.g btrfs check —repair /dev/nvme0n1p1 Some help would be appreciated jarskynas-diagnostics-20220815-1745.zip Edited August 15, 2022 by Jarsky Quote Link to comment
Jarsky Posted August 15, 2022 Author Share Posted August 15, 2022 Looks like from a scrub, the corruption is in a VM disk image. I have a backup from a few months ago, but is there any other repair activities I can do, short of restoring from a backup? Aug 15 18:48:14 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 795, gen 0 Aug 15 18:48:14 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 566991183872 on dev /dev/nvme0n1p1 Aug 15 18:48:14 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 796, gen 0 Aug 15 18:48:14 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 567391494144 on dev /dev/nvme0n1p1 Aug 15 18:48:21 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 797, gen 0 Aug 15 18:48:21 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 573802946560 on dev /dev/nvme0n1p1 Aug 15 18:50:44 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 824454868992 on dev /dev/nvme1n1p1, physical 729911062528, root 5, inode 819355, offset 12810076160, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:50:44 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 797, gen 0 Aug 15 18:50:44 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 824454868992 on dev /dev/nvme1n1p1 Aug 15 18:50:51 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 817108246528 on dev /dev/nvme1n1p1, physical 736523083776, root 5, inode 819355, offset 1667567616, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:50:51 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 798, gen 0 Aug 15 18:50:52 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 817108246528 on dev /dev/nvme1n1p1 Aug 15 18:51:01 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 835594616832 on dev /dev/nvme1n1p1, physical 745345777664, root 5, inode 819355, offset 7420325888, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:51:01 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 799, gen 0 Aug 15 18:51:02 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 835594616832 on dev /dev/nvme1n1p1 Aug 15 18:51:11 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 1063512186880 on dev /dev/nvme0n1p1, physical 666227712000, root 5, inode 819355, offset 9483952128, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:51:11 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 798, gen 0 Aug 15 18:51:11 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 1063512186880 on dev /dev/nvme0n1p1 Aug 15 18:53:36 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 800, gen 0 Aug 15 18:53:36 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme1n1p1 Aug 15 18:53:42 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 799, gen 0 Aug 15 18:53:42 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 967017721856 on dev /dev/nvme0n1p1 Aug 15 18:54:11 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 1234893328384 on dev /dev/nvme1n1p1, physical 940633542656, root 5, inode 819355, offset 6063378432, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:54:11 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 801, gen 0 Aug 15 18:54:11 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 1234893328384 on dev /dev/nvme1n1p1 Aug 15 18:54:23 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 802, gen 0 Aug 15 18:54:23 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme1n1p1 Aug 15 18:54:41 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 1145505271808 on dev /dev/nvme0n1p1, physical 868479881216, root 5, inode 819355, offset 9617289216, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:54:41 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 800, gen 0 Aug 15 18:54:41 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 1145505271808 on dev /dev/nvme0n1p1 Aug 15 18:54:42 TOWER kernel: BTRFS warning (device nvme0n1p1): checksum error at logical 1147382370304 on dev /dev/nvme0n1p1, physical 870356979712, root 5, inode 819355, offset 7115976704, length 4096, links 1 (path: VM/Windows Server 2022/vdisk1.img) Aug 15 18:54:42 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 801, gen 0 Aug 15 18:54:43 TOWER kernel: BTRFS error (device nvme0n1p1): fixed up error at logical 1147382370304 on dev /dev/nvme0n1p1 Aug 15 18:54:43 TOWER kernel: BTRFS info (device nvme0n1p1): scrub: finished on devid 2 with status: 0 Aug 15 18:55:26 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 802, gen 0 Aug 15 18:55:26 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme0n1p1 Aug 15 18:56:53 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 803, gen 0 Aug 15 18:56:53 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme0n1p1 Aug 15 18:57:17 TOWER kernel: BTRFS info (device nvme0n1p1): scrub: finished on devid 1 with status: 0 Quote Link to comment
JorgeB Posted August 15, 2022 Share Posted August 15, 2022 Btrfs is detecting data corruption, Ryzen with overclocked RAM like you have is known to in some cases corrupt data, so start there, then also a good idea to run memtest. Quote Link to comment
Jarsky Posted August 15, 2022 Author Share Posted August 15, 2022 I don't think theres an issue with my Ram. It's a Zen2 and has been running @ 3000Mhz for 2.5 years. Its only the single pool that has corruption. The array and cache have no errors. I already repaired the file that didnt pass checksum from my main array. I'm pretty confident the corruption occured when electricians switched off the power abruptly several times, and I dont currently have it on a UPS (since the last battery died). I've restored my VM from backup and updated it so no longer receiving checksum errors with the vdisk for that. However I still have uncorrectable errors on the pool. It's a mirrored pool, so what is the best way to resolve this? Can I break the pool, format the drive and resync? Or do I need to copy everything off that pool to somewhere else and reformat the pool? Spoiler Aug 15 23:01:21 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 1, gen 0 Aug 15 23:01:21 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 513608630272 on dev /dev/nvme1n1p1 Aug 15 23:02:08 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 2, gen 0 Aug 15 23:02:08 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 189270196224 on dev /dev/nvme1n1p1 Aug 15 23:02:27 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 1, gen 0 Aug 15 23:02:27 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 513608630272 on dev /dev/nvme0n1p1 Aug 15 23:03:09 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 2, gen 0 Aug 15 23:03:09 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 189270196224 on dev /dev/nvme0n1p1 Aug 15 23:06:16 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 3, gen 0 Aug 15 23:06:16 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 380153503744 on dev /dev/nvme1n1p1 Aug 15 23:08:23 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 4, gen 0 Aug 15 23:08:23 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1217718784000 on dev /dev/nvme1n1p1 Aug 15 23:09:18 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 3, gen 0 Aug 15 23:09:18 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 380153503744 on dev /dev/nvme0n1p1 Aug 15 23:09:34 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Aug 15 23:09:34 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 567391494144 on dev /dev/nvme1n1p1 Aug 15 23:09:42 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 6, gen 0 Aug 15 23:09:42 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 573802946560 on dev /dev/nvme1n1p1 Aug 15 23:11:45 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 4, gen 0 Aug 15 23:11:45 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1217718784000 on dev /dev/nvme0n1p1 Aug 15 23:13:47 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Aug 15 23:13:47 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 567391494144 on dev /dev/nvme0n1p1 Aug 15 23:14:04 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 6, gen 0 Aug 15 23:14:04 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 573802946560 on dev /dev/nvme0n1p1 Aug 15 23:17:45 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 7, gen 0 Aug 15 23:17:45 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme1n1p1 Aug 15 23:18:44 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 8, gen 0 Aug 15 23:18:44 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme1n1p1 Aug 15 23:25:39 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 7, gen 0 Aug 15 23:25:39 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme0n1p1 Aug 15 23:28:13 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 8, gen 0 Aug 15 23:28:13 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme0n1p1 Quote Link to comment
JorgeB Posted August 15, 2022 Share Posted August 15, 2022 2 minutes ago, Jarsky said: I'm pretty confident the corruption occured when electricians switched off the power abruptly several times, and I dont currently have it on a UPS (since the last battery died). That should not cause data corruption, it might cause filesystem corruption. 3 minutes ago, Jarsky said: It's a mirrored pool, so what is the best way to resolve this? Delete the corrupt file(s) and restore from backup if available. Quote Link to comment
Jarsky Posted August 15, 2022 Author Share Posted August 15, 2022 22 minutes ago, JorgeB said: That should not cause data corruption, it might cause filesystem corruption. Delete the corrupt file(s) and restore from backup if available. How can I identify the files though? Using inspect-internal its giving me nothing root@TOWER:/mnt/nvme_mirror# btrfs inspect-internal logical-resolve -v -P 513608630272 /mnt/nvme_mirror ioctl ret=0, total_size=65536, bytes_left=65520, bytes_missing=0, cnt=0, missed=0 root@TOWER:/mnt/nvme_mirror# echo $? 0 I thought from the remaining errors, they were a filesystem issue on nvme0n1p1? Quote Link to comment
JorgeB Posted August 15, 2022 Share Posted August 15, 2022 Run a scrub, it should list the affect file(s) in the syslog. Quote Link to comment
Jarsky Posted August 15, 2022 Author Share Posted August 15, 2022 31 minutes ago, JorgeB said: Run a scrub, it should list the affect file(s) in the syslog. I already showed the syslog after a scrub above Aug 15 23:01:21 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 1, gen 0 Aug 15 23:01:21 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 513608630272 on dev /dev/nvme1n1p1 Aug 15 23:02:08 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 2, gen 0 Aug 15 23:02:08 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 189270196224 on dev /dev/nvme1n1p1 Aug 15 23:02:27 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 1, gen 0 Aug 15 23:02:27 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 513608630272 on dev /dev/nvme0n1p1 Aug 15 23:03:09 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 2, gen 0 Aug 15 23:03:09 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 189270196224 on dev /dev/nvme0n1p1 Aug 15 23:06:16 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 3, gen 0 Aug 15 23:06:16 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 380153503744 on dev /dev/nvme1n1p1 Aug 15 23:08:23 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 4, gen 0 Aug 15 23:08:23 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1217718784000 on dev /dev/nvme1n1p1 Aug 15 23:09:18 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 3, gen 0 Aug 15 23:09:18 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 380153503744 on dev /dev/nvme0n1p1 Aug 15 23:09:34 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Aug 15 23:09:34 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 567391494144 on dev /dev/nvme1n1p1 Aug 15 23:09:42 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 6, gen 0 Aug 15 23:09:42 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 573802946560 on dev /dev/nvme1n1p1 Aug 15 23:11:45 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 4, gen 0 Aug 15 23:11:45 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1217718784000 on dev /dev/nvme0n1p1 Aug 15 23:13:47 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Aug 15 23:13:47 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 567391494144 on dev /dev/nvme0n1p1 Aug 15 23:14:04 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 6, gen 0 Aug 15 23:14:04 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 573802946560 on dev /dev/nvme0n1p1 Aug 15 23:17:45 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 7, gen 0 Aug 15 23:17:45 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme1n1p1 Aug 15 23:18:44 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 8, gen 0 Aug 15 23:18:44 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme1n1p1 Aug 15 23:25:39 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 7, gen 0 Aug 15 23:25:39 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1173223571456 on dev /dev/nvme0n1p1 Aug 15 23:28:13 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 8, gen 0 Aug 15 23:28:13 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 1263566585856 on dev /dev/nvme0n1p1 Quote Link to comment
Solution Jarsky Posted August 15, 2022 Author Solution Share Posted August 15, 2022 Since it's late hours I decided to shut everything down and put the array into maintenance. The NVMe drives showed they were doing a bunch of read/write for about a minute. It seemed to correct the remaining BTRFS errors with the pool. Scrub started: Tue Aug 16 01:06:35 2022 Status: finished Duration: 0:23:17 Total to scrub: 1.53TiB Rate: 1.12GiB/s Error summary: no errors found Quote Link to comment
Jarsky Posted 12 hours ago Author Share Posted 12 hours ago This is an old thread, but i've seen others having the same issue of being able to find the file associated. I just ran into it again yesterday after a power outage rebooted my server several times. So for records sake.... Select your pool, tick to "Repair Corrupted Blocks" and click "SCRUB"; you should see an error log like below: Apr 18 19:57:42 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme0n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Apr 18 19:57:42 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 5507816349696 on dev /dev/nvme0n1p1 Apr 18 19:57:46 TOWER kernel: BTRFS error (device nvme0n1p1): bdev /dev/nvme1n1p1 errs: wr 0, rd 0, flush 0, corrupt 5, gen 0 Apr 18 19:57:46 TOWER kernel: BTRFS error (device nvme0n1p1): unable to fixup (regular) error at logical 5507816349696 on dev /dev/nvme1n1p1 This gives you the device; if you have a lot of mounts you can check the mount point running this: root@TOWER:/var/log# cat /proc/mounts | grep '/mnt/' | grep -v -E 'tmpfs|shfs' /dev/md1p1 /mnt/disk1 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md2p1 /mnt/disk2 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md3p1 /mnt/disk3 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md4p1 /mnt/disk4 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md5p1 /mnt/disk5 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md6p1 /mnt/disk6 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md7p1 /mnt/disk7 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md8p1 /mnt/disk8 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md9p1 /mnt/disk9 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md10p1 /mnt/disk10 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/md11p1 /mnt/disk11 xfs rw,noatime,nouuid,attr2,inode64,logbufs=8,logbsize=32k,noquota 0 0 /dev/nvme2n1p1 /mnt/cache btrfs rw,noatime,ssd,discard=async,space_cache=v2,subvolid=5,subvol=/ 0 0 /dev/nvme0n1p1 /mnt/nvme_mirror btrfs rw,noatime,ssd,discard=async,space_cache=v2,subvolid=5,subvol=/ 0 0 The one we're looking for here is /mnt/nvme_mirror We can then run an inspect-internal like below to find the culprit file that occupies that block root@TOWER:/var/log# btrfs inspect-internal logical-resolve -o 5507816349696 /mnt/nvme_mirror/ /mnt/nvme_mirror//VM/VM1/vm1.img So we can see that our offending file is /mnt/nvme_mirror/VM/VM1/vm1.img We can move this offending file somewhere else e.g mv /mnt/nvme_mirror/VM/VM1 /mnt/user0/share Repeat for any other offending logical block numbers reported. We can then re-run the scrub and should find no errors. Move the files back to their original directories Re-run the scrub one more time; and should still come back with no errors. Quote Link to comment
