Hello, I changed my server about 3 months ago, and since then I've always had problems with my boot USB key. I've changed it 3 times since, so the problem is not with the USB keys.



This morning I reformatted my key twice and after 2 hours my web interface no longer responds and I have a message that my key is corrupted. When I plug it into my PC, I get a message saying that my key needs to be checked. I've tried all the USB ports and even bought a header to connect directly to my motherboard. I did a 24-hour test of my RAM and had 4 complete passes. I have no more ideas about the origin of the problem, does anyone have an idea?



I have included the diagnostic file in the post.



tower-diagnostics-20231213-1255.zip

Dec 13 12:52:46 Tower kernel: xhci_hcd 0000:23:00.3: xHCI host not responding to stop endpoint command
Dec 13 12:52:46 Tower kernel: xhci_hcd 0000:23:00.3: xHCI host controller not responding, assume dead
Dec 13 12:52:46 Tower kernel: xhci_hcd 0000:23:00.3: HC died; cleaning up
Dec 13 12:52:46 Tower kernel: usb 3-1: USB disconnect, device number 2
Dec 13 12:52:46 Tower kernel: usb 3-1.2: USB disconnect, device number 4
Dec 13 12:52:46 Tower kernel: device offline error, dev sda, sector 1773416 op 0x1:(WRITE) flags 0x4800 phys_seg 3 prio class 2



Flash drive is dropping offline, this can be the USB controller or a flash drive issue.

Just now, JorgeB said:

xHCI host controller not responding, assume dead

This part looks more like a controller problem.

23 minutes ago, JorgeB said:

This part looks more like a controller problem.

It would make sense because my UPS is also connected via USB and I often get messages that it's losing communication. Could I update the USB drivers of Unraid?

6 minutes ago, nicecube said:

Could I update the USB drivers of Unraid?

No that I know off, they should come with the kernel, but a newer kernel may have newer drivers.

2 minutes ago, JorgeB said:

No that I know off, they should come with the kernel, but a newer kernel may have newer drivers.

I would like to buy a USB PCIe card but I don't have any available ports on my motherboard. I have a built in micro SD card reader on the mb, do you think I could use that? Does it share the same USB bus?

Edited December 13, 20232 yr by nicecube

7 minutes ago, nicecube said:

I have a built in micro SD card reader on the mb, do you think I could use that?

You need to see if the GUID is unique, if not someone else may already be using it.
