February 11, 20242 yr Hi all. I'd like to try unRAID, because it seems more user-friendly in comparison to TrueNAS. I'm already running an array of 5 drives in RAIDZ1 in TrueNAS core. How do I migrate in such a way that if I dislike unRAID I can move back to TrueNAS Core without remaking my array?
February 11, 20242 yr Community Expert A TrueNAS pool may not yet be importable by Unraid, and if it was created using default TrueNAS settings, which uses partition #1 for swap, it won't be, at least not for now, it should be once v6.13 is out, post the partition list for the pool members, IIRC with FreeBSD it's: gpart show
February 11, 20242 yr Author => 40 15628053088 ada0 GPT (7.3T) 40 88 - free - (44K) 128 4194304 1 freebsd-swap (2.0G) 4194432 15623858696 2 freebsd-zfs (7.3T) => 40 15628053088 ada1 GPT (7.3T) 40 88 - free - (44K) 128 4194304 1 freebsd-swap (2.0G) 4194432 15623858696 2 freebsd-zfs (7.3T) => 40 15628053088 ada2 GPT (7.3T) 40 88 - free - (44K) 128 4194304 1 freebsd-swap (2.0G) 4194432 15623858696 2 freebsd-zfs (7.3T) => 40 15628053088 ada3 GPT (7.3T) 40 88 - free - (44K) 128 4194304 1 freebsd-swap (2.0G) 4194432 15623858696 2 freebsd-zfs (7.3T) => 40 15628053088 ada4 GPT (7.3T) 40 88 - free - (44K) 128 4194304 1 freebsd-swap (2.0G) 4194432 15623858696 2 freebsd-zfs (7.3T) => 40 30031792 da0 GPT (14G) 40 532480 1 efi (260M) 532520 29491200 2 freebsd-zfs (14G) 30023720 8112 - free - (4.0M) => 40 30031792 da1 GPT (14G) 40 532480 1 efi (260M) 532520 29491200 2 freebsd-zfs (14G) 30023720 8112 - free - (4.0M) The last two are boot drives. What's ETA for 6.13? Is there any beta available?
February 11, 20242 yr Community Expert Zfs is on partition #2, this is currently not supported. 57 minutes ago, VasiliiNorris said: What's ETA for 6.13? Is there any beta available? A beta should be available soon, but don't know if it's going to take a couple of weeks or a couple of months, also don't know if TrueNAS pool import will work at that time. P.S. you should have no issues going form Unraid back to TrueNAS if needed.
February 11, 20242 yr Author 1 hour ago, JorgeB said: Zfs is on partition #2, this is currently not supported. A beta should be available soon, but don't know if it's going to take a couple of weeks or a couple of months, also don't know if TrueNAS pool import will work at that time. P.S. you should have no issues going form Unraid back to TrueNAS if needed. Do you mean that if I backup my pool, create a ZFS RAIDZ1 pool in unRAID and, in case I don't like unRAID, I can just continue with a newly created unRAID ZFS pool in the TrueNAS? By the way, if I remove the swap partition on all of the drives and move the ZFS partition to sector 128 (or even without moving it), will unRAID be able to handle my pool? And why does these swaps get created by default anyway?
February 12, 20242 yr Community Expert Solution 10 hours ago, VasiliiNorris said: I can just continue with a newly created unRAID ZFS pool in the TrueNAS? Correct, TrueNAS should have no issues importing that pool. 10 hours ago, VasiliiNorris said: By the way, if I remove the swap partition on all of the drives and move the ZFS partition to sector 128 (or even without moving it), will unRAID be able to handle my pool? Starting sector is not really important, as long as zfs is on partition #1 it should work.
February 12, 20242 yr Community Expert On 2/11/2024 at 10:12 PM, VasiliiNorris said: By the way, if I remove the swap partition on all of the drives and move the ZFS partition to sector 128 (or even without moving it), will unRAID be able to handle my pool? I've been meaning to take a look at this, since you are not the first to ask about it, just did a quick test and everything worked correctly, in case you want to try, this should be perfectly safe to do but cannot guarantee an unforeseen issue. This would need to be done with Unraid (Linux), list partitions of one of the pool devices: root@Tower15:~# fdisk -l /dev/sde Disk /dev/sde: 223.57 GiB, 240057409536 bytes, 468862128 sectors Disk model: KINGSTON SA400S3 Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: gpt Disk identifier: 22B20B36-C9D0-11EE-A9A9-F079595F9D0F Device Start End Sectors Size Type /dev/sde1 128 4194431 4194304 2G FreeBSD swap /dev/sde2 4194432 468862087 464667656 221.6G FreeBSD ZFS Use fdisk to delete partition 1 and make partition 2 > partition 1 Commands used: d - to delete a partition 1 - to delete partition 1 x - to enter expert mode f - to fix order, in this case make part2 > part1 r - go back to main menu w - to write changes (any mistakes abort before w) root@Tower15:~# fdisk /dev/sde Welcome to fdisk (util-linux 2.38.1). Changes will remain in memory only, until you decide to write them. Be careful before using the write command. Command (m for help): d Partition number (1,2, default 2): 1 Partition 1 has been deleted. Command (m for help): x Expert command (m for help): f Partitions order fixed. Expert command (m for help): r Command (m for help): w The partition table has been altered. Calling ioctl() to re-read partition table. Syncing disks. Confirm new partition layout: root@Tower15:~# fdisk -l /dev/sde Disk /dev/sde: 223.57 GiB, 240057409536 bytes, 468862128 sectors Disk model: KINGSTON SA400S3 Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: gpt Disk identifier: 22B20B36-C9D0-11EE-A9A9-F079595F9D0F Device Start End Sectors Size Type /dev/sde1 4194432 468862087 464667656 221.6G FreeBSD ZFS Repeat the procedure for the other pool devices, after all layouts are corrected Unraid can import the pool, to do that create a new pool with the number of slots needed, leave the filesystem set to auto, assign all pool devices in the same order as the zpool status output and start the array. P.S. once v6.12.7 is out, this last step will no longer be needed, but it is with 6.12.6 or earlier v6.12 releases, the pool will fail to import the first time with a similar error to this: Feb 12 18:15:05 Tower15 root: cannot import 'tank': pool was previously in use from another system. Feb 12 18:15:05 Tower15 root: Last accessed by (hostid=46c5a671) at Mon Feb 12 18:10:11 2024 Feb 12 18:15:05 Tower15 root: The pool can be imported, use 'zpool import -f' to import the pool. Type: root@Tower15:~# zpool import -f tank root@Tower15:~# zpool export tank Replace tank with correct pool name, after that restart the array and Unraid will now be able to import the pool. If at any point you want to go back to TrueNAS you just need to boot it with the devices attached and the pool will automatically be imported, at least it was for me, note that depending on the zfs version running on TrueNAS, the pool can show that some new features are available on Unraid, if that is the case don't upgrade the pool, or it will then fail to import with TrueNAS, currently the only way to upgrade a pool with Unraid is by typing the command manually, so not something that can happen by accident. Edit to add an example: I did it with my TrueNAS CORE pool, just for testing, since I want to keep TrueNAS on this server, booted with an Unraid flash drive, pool before the changes: pool: tank id: 11986576849467638030 state: ONLINE status: The pool was last accessed by another system. action: The pool can be imported using its name or numeric identifier and the '-f' flag. see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-EY config: tank ONLINE raidz3-0 ONLINE sdk2 ONLINE sdg2 ONLINE sdc2 ONLINE sdd2 ONLINE sdf2 ONLINE sdi2 ONLINE sde2 ONLINE sdh2 ONLINE sdm2 ONLINE sdj2 ONLINE sdl2 ONLINE After running fdisk on each device to delete parttion1 and make partition2 > partition1: pool: tank id: 11986576849467638030 state: ONLINE status: The pool was last accessed by another system. action: The pool can be imported using its name or numeric identifier and the '-f' flag. see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-EY config: tank ONLINE raidz3-0 ONLINE sdk1 ONLINE sdg1 ONLINE sdc1 ONLINE sdd1 ONLINE sdf1 ONLINE sdi1 ONLINE sde1 ONLINE sdh1 ONLINE sdm1 ONLINE sdj1 ONLINE sdl1 ONLINE After doing this, the pool imported normally with Unraid 6.12.8: Rebooted the server and booted TrueNAS, pool imported as if nothing changed:
March 12, 20242 yr On 2/12/2024 at 7:33 PM, JorgeB said: P.S. once v6.12.7 is out, this last step will no longer be needed What is the current status of this? I am considering trying unraid by installing it on a usb drive on my current truenas machine, but I would need a safe and sound way of importing my current pools.
March 12, 20242 yr Community Expert 5 minutes ago, studjohey said: What is the current status of this? If the disks have a swap partition you'd need to do the above to remove it.
March 12, 20242 yr Thanks for prompt answer to my first post in this forum! 😀 It looks like I only have one partition for each drive in my two pools. admin@truenas[/mnt/nas]$ sudo fdisk -l /dev/sd[a-e]|grep dev Disk /dev/sda: 14.55 TiB, 16000900661248 bytes, 31251759104 sectors /dev/sda1 4096 31251757056 31251752961 14.6T Solaris /usr & Apple ZFS Disk /dev/sdb: 14.55 TiB, 16000900661248 bytes, 31251759104 sectors /dev/sdb1 4096 31251757056 31251752961 14.6T Solaris /usr & Apple ZFS Disk /dev/sdc: 14.55 TiB, 16000900661248 bytes, 31251759104 sectors /dev/sdc1 4096 31251757056 31251752961 14.6T Solaris /usr & Apple ZFS Disk /dev/sdd: 14.55 TiB, 16000900661248 bytes, 31251759104 sectors /dev/sdd1 4096 31251757056 31251752961 14.6T Solaris /usr & Apple ZFS Disk /dev/sde: 14.55 TiB, 16000900661248 bytes, 31251759104 sectors /dev/sde1 4096 31251757056 31251752961 14.6T Solaris /usr & Apple ZFS admin@truenas[/mnt/nas]$ sudo fdisk -l /dev/nvme[1-4]n1|grep dev Disk /dev/nvme1n1: 3.64 TiB, 4000787030016 bytes, 7814037168 sectors /dev/nvme1n1p1 4096 7814035456 7814031361 3.6T Solaris /usr & Apple ZFS Disk /dev/nvme2n1: 3.64 TiB, 4000787030016 bytes, 7814037168 sectors /dev/nvme2n1p1 4096 7814035456 7814031361 3.6T Solaris /usr & Apple ZFS Disk /dev/nvme3n1: 3.64 TiB, 4000787030016 bytes, 7814037168 sectors /dev/nvme3n1p1 4096 7814035456 7814031361 3.6T Solaris /usr & Apple ZFS Disk /dev/nvme4n1: 3.64 TiB, 4000787030016 bytes, 7814037168 sectors /dev/nvme4n1p1 4096 7814035456 7814031361 3.6T Solaris /usr & Apple ZFS So these pools should be importable directly into unraid? Edited March 12, 20242 yr by studjohey
March 12, 20242 yr Community Expert 31 minutes ago, studjohey said: So these pools should be importable directly into unraid? Yep, just create new pools, assign all devices, leave the filesystem set to auto, and start the array, if they don't import post the diagnostics.
March 31, 20242 yr Getting error message "The pool cannot be imported due to damaged devices or data." Works fine on truenas scale. Showing single partition. 4 hard drives, 3 8tb and 1 4tb. All 4 showing online but cannot import pool. Is there a way to take 2 drives off the pool in Truenas, and format them to be able to mount them in both? I cannot find anything online.
March 31, 20242 yr 2 minutes ago, Skysec said: Getting error message "The pool cannot be imported due to damaged devices or data." Works fine on truenas scale. Showing single partition. 4 hard drives, 3 8tb and 1 4tb. All 4 showing online but cannot import pool. Is there a way to take 2 drives off the pool in Truenas, and format them to be able to mount them in both? I cannot find anything online. "This pool uses the following feature(s) not supported by this system: com.klarasystems:vdev_zaps_v2" ah....
March 31, 20242 yr Community Expert If the pool was formatted with a recent Truenas Scala release it won't work with Unriad 6.12, because it was formatted with openzfs 2.2, it will work with Unraid 6.13 currently in beta.
August 8, 20241 yr Successfully tried this in a virtual environment and on my main server. If your pool is upgraded to the latest openzfs version in TrueNas you can switch to unraid 7.x beta. Strangely you can import the pool from cli only webUI has trouble mounting those pools with SWAP partiontion (1). Anyway removing the SWAP partitions and moving the ZFS partitions to place 1 fixes this problem. Big thank you!
September 18, 20241 yr On 2/13/2024 at 2:33 AM, JorgeB said: I've been meaning to take a look at this, since you are not the first to ask about it, just did a quick test and everything worked correctly, in case you want to try, this should be perfectly safe to do but cannot guarantee an unforeseen issue. This would need to be done with Unraid (Linux), list partitions of one of the pool devices: root@Tower15:~# fdisk -l /dev/sde Disk /dev/sde: 223.57 GiB, 240057409536 bytes, 468862128 sectors Disk model: KINGSTON SA400S3 Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: gpt Disk identifier: 22B20B36-C9D0-11EE-A9A9-F079595F9D0F Device Start End Sectors Size Type /dev/sde1 128 4194431 4194304 2G FreeBSD swap /dev/sde2 4194432 468862087 464667656 221.6G FreeBSD ZFS Use fdisk to delete partition 1 and make partition 2 > partition 1 Commands used: d - to delete a partition 1 - to delete partition 1 x - to enter expert mode f - to fix order, in this case make part2 > part1 r - go back to main menu w - to write changes (any mistakes abort before w) root@Tower15:~# fdisk /dev/sde Welcome to fdisk (util-linux 2.38.1). Changes will remain in memory only, until you decide to write them. Be careful before using the write command. Command (m for help): d Partition number (1,2, default 2): 1 Partition 1 has been deleted. Command (m for help): x Expert command (m for help): f Partitions order fixed. Expert command (m for help): r Command (m for help): w The partition table has been altered. Calling ioctl() to re-read partition table. Syncing disks. Confirm new partition layout: root@Tower15:~# fdisk -l /dev/sde Disk /dev/sde: 223.57 GiB, 240057409536 bytes, 468862128 sectors Disk model: KINGSTON SA400S3 Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 512 bytes I/O size (minimum/optimal): 512 bytes / 512 bytes Disklabel type: gpt Disk identifier: 22B20B36-C9D0-11EE-A9A9-F079595F9D0F Device Start End Sectors Size Type /dev/sde1 4194432 468862087 464667656 221.6G FreeBSD ZFS Repeat the procedure for the other pool devices, after all layouts are corrected Unraid can import the pool, to do that create a new pool with the number of slots needed, leave the filesystem set to auto, assign all pool devices in the same order as the zpool status output and start the array. P.S. once v6.12.7 is out, this last step will no longer be needed, but it is with 6.12.6 or earlier v6.12 releases, the pool will fail to import the first time with a similar error to this: Feb 12 18:15:05 Tower15 root: cannot import 'tank': pool was previously in use from another system. Feb 12 18:15:05 Tower15 root: Last accessed by (hostid=46c5a671) at Mon Feb 12 18:10:11 2024 Feb 12 18:15:05 Tower15 root: The pool can be imported, use 'zpool import -f' to import the pool. Type: root@Tower15:~# zpool import -f tank root@Tower15:~# zpool export tank Replace tank with correct pool name, after that restart the array and Unraid will now be able to import the pool. If at any point you want to go back to TrueNAS you just need to boot it with the devices attached and the pool will automatically be imported, at least it was for me, note that depending on the zfs version running on TrueNAS, the pool can show that some new features are available on Unraid, if that is the case don't upgrade the pool, or it will then fail to import with TrueNAS, currently the only way to upgrade a pool with Unraid is by typing the command manually, so not something that can happen by accident. Edit to add an example: I did it with my TrueNAS CORE pool, just for testing, since I want to keep TrueNAS on this server, booted with an Unraid flash drive, pool before the changes: pool: tank id: 11986576849467638030 state: ONLINE status: The pool was last accessed by another system. action: The pool can be imported using its name or numeric identifier and the '-f' flag. see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-EY config: tank ONLINE raidz3-0 ONLINE sdk2 ONLINE sdg2 ONLINE sdc2 ONLINE sdd2 ONLINE sdf2 ONLINE sdi2 ONLINE sde2 ONLINE sdh2 ONLINE sdm2 ONLINE sdj2 ONLINE sdl2 ONLINE After running fdisk on each device to delete parttion1 and make partition2 > partition1: pool: tank id: 11986576849467638030 state: ONLINE status: The pool was last accessed by another system. action: The pool can be imported using its name or numeric identifier and the '-f' flag. see: https://openzfs.github.io/openzfs-docs/msg/ZFS-8000-EY config: tank ONLINE raidz3-0 ONLINE sdk1 ONLINE sdg1 ONLINE sdc1 ONLINE sdd1 ONLINE sdf1 ONLINE sdi1 ONLINE sde1 ONLINE sdh1 ONLINE sdm1 ONLINE sdj1 ONLINE sdl1 ONLINE After doing this, the pool imported normally with Unraid 6.12.8: Rebooted the server and booted TrueNAS, pool imported as if nothing changed: I'm currently migrating from TrueNAS Scale DragonFish to UNRAID 7.0.0-beta.2. My pool has 2 disks in mirror mode, and I've checked that both disks' zfs partitions are on partition 2: root@BorNAS:/# fdisk -l /dev/sdb Disk /dev/sdb: 7.28 TiB, 8001563222016 bytes, 15628053168 sectors Disk model: TerraMaster Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 4096 bytes I/O size (minimum/optimal): 4096 bytes / 4096 bytes Disklabel type: gpt Disk identifier: 751167D6-C434-4FA6-986B-E85F6DE4D540 Device Start End Sectors Size Type /dev/sdb1 128 4194304 4194177 2G Linux swap /dev/sdb2 4194432 15628053134 15623858703 7.3T Solaris /usr & Apple ZFS root@BorNAS:/# fdisk -l /dev/sdc Disk /dev/sdc: 7.28 TiB, 8001563222016 bytes, 15628053168 sectors Disk model: TerraMaster Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 4096 bytes I/O size (minimum/optimal): 4096 bytes / 4096 bytes Disklabel type: gpt Disk identifier: EE0D5179-15BE-43C2-AEA9-FED314BAA4EC Device Start End Sectors Size Type /dev/sdc1 128 4194304 4194177 2G Linux swap /dev/sdc2 4194432 15628053134 15623858703 7.3T Solaris /usr & Apple ZFS And the pool could be directly imported with zpool import command: root@BorNAS:/# zpool status pool: data state: ONLINE scan: scrub repaired 0B in 15:17:25 with 0 errors on Sun Sep 8 00:17:26 2024 config: NAME STATE READ WRITE CKSUM data ONLINE 0 0 0 mirror-0 ONLINE 0 0 0 6dfc8125-2607-4d1e-9c63-8c9ca226bd1a ONLINE 0 0 0 be28ba4e-8773-4043-b506-919cbdbb9a31 ONLINE 0 0 0 errors: No known data errors But however, create a Pool in WebGUI and add both disks still result in "Unmountable: unsupported or no file system" I want to follow the above instruction, but found this warning when trying to remove partition 1: root@BorNAS:/# fdisk /dev/sdb Welcome to fdisk (util-linux 2.40.2). Changes will remain in memory only, until you decide to write them. Be careful before using the write command. The device contains 'zfs_member' signature and it will be removed by a write command. See fdisk(8) man page and --wipe option for more details. Command (m for help): Will the partion removing action result in my data lost? Or it's safe to remove partition 1?
September 18, 20241 yr Community Expert 5 hours ago, Borealin said: The device contains 'zfs_member' signature and it will be removed by a write command. That suggests the whole device, not a partition, was used with zfs before, I never tested that config, but should be OK if you only delete partition #1
September 18, 20241 yr 7 hours ago, JorgeB said: That suggests the whole device, not a partition, was used with zfs before, I never tested that config, but should be OK if you only delete partition #1 Thanks a lot, removing partition 1 will not affect partition 2, my data is kept and the pool could be import in Web GUI
October 27, 20241 yr I followed this guide on Unraid7.beta4, which i had to upgrade to because my pool had a zfs feature flag unraid 6 can't handle. When i try executing zpool export backup i get "cannot export 'backup': pool is busy" and if i ignore this for now and try starting this pool i get: "Unmountable: no file system" Oct 27 15:46:54 bastion emhttpd: mounting /mnt/backup Oct 27 15:46:54 bastion emhttpd: backup: mount error: no file system What could i try ?
October 28, 20241 yr Community Expert 10 hours ago, marvinosswald said: and if i ignore this for now and try starting this pool i get: "Unmountable: no file system" This is normal, Unraid can't mount an already imported pool, if the export is not working it suggests something is using the pool, if you don't know or can find what, try forcing a reboot.
November 2, 20241 yr On 10/28/2024 at 10:01 AM, JorgeB said: This is normal, Unraid can't mount an already imported pool, if the export is not working it suggests something is using the pool, if you don't know or can find what, try forcing a reboot. a reboot didn't really fix the problem for me, i tried: - reboot and no manual import just starting the array and get: "Unmountable: wrong or no file system" still no luck tho.
November 2, 20241 yr Community Expert 1 hour ago, marvinosswald said: a reboot didn't really fix the problem for me, i tried: Please post the diagnostics and the output from zpool import
November 2, 20241 yr 47 minutes ago, JorgeB said: Please post the diagnostics and the output from zpool import thanks for looking into this! zpool import: Quote root@bastion:~# zpool import pool: backup id: 2668180816646062420 state: ONLINE action: The pool can be imported using its name or numeric identifier. config: backup ONLINE mirror-0 ONLINE sde1 ONLINE sdc1 ONLINE pool: freenas-boot id: 12326919044613836689 state: ONLINE status: Some supported features are not enabled on the pool. (Note that they may be intentionally disabled if the 'compatibility' property is set.) action: The pool can be imported using its name or numeric identifier, though some features will not be available without an explicit 'zpool upgrade'. config: freenas-boot ONLINE ata-Crucial_CT120M500SSD1_1352095FFBA1 ONLINE and please find the diagnostics attached bastion-diagnostics-20241102-1238.zip
November 2, 20241 yr Community Expert 8 minutes ago, marvinosswald said: and please find the diagnostics attached Diags after array start please.
November 2, 20241 yr it just worked now.. sorry to have wasted your time. i've done nothing different but after another reboot and array start, just now to get the diagnostics, the pool just came online.
