Hello fellow Unraid Users



I´m asking more experienced users and/or pros for help, since my journey just began a few months ago.

I would appreciate any help or hints since I don´t know if i miss sth here.



I am getting a MCE errors to above mentioned topic - on a pretty constant/daily basis. It only startet on June 10th and did not stop yet.

I did not change anything regarding software/BIOS/hardware. The server is working fluently as of now and does not have any crashes.



Jun 14 04:31:45 Jukebox kernel: mce: [Hardware Error]: Machine check events logged
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: Corrected error, no action required.
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: CPU:0 (17:60:1) MC17_STATUS[Over|CE|MiscV|AddrV|-|-|SyndV|CECC|-|-|-]: 0xdc2040000000011b
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: Error Addr: 0x000000065f50b900
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: IPID: 0x0000009600050f00, Syndrome: 0x0000019d0a400902
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: Unified Memory Controller Ext. Error Code: 0, DRAM ECC error.
Jun 14 04:31:45 Jukebox kernel: EDAC MC0: 1 CE on mc#0csrow#2channel#0 (csrow:2 channel:0 page:0x69f50b offset:0x900 grain:64 syndrome:0x19d)
Jun 14 04:31:45 Jukebox kernel: [Hardware Error]: cache level: L3/GEN, tx: GEN, mem-tx: RD



Any tests made during setup 3 months ago were perfectly fine, nothing is overclocked or whatsoever. no power surges known, nor any power outages or sth else.



as far as i can read the logs i see errors occuring related to L3 cache from the CPU. is this correct?

can i assume this CPU is damaged and should be replaced? or do i misinterpret these lines and its RAM related?



THX for any help!







syslog.txt

Edited June 17, 20242 yr by woozaa.

Looks like a CPU problem to me.

Thanks for the reply!

May I ask what leads to the decision?

Am I right with the L3 cache failure, hardware related?



Greetings

woozaa

11 hours ago, woozaa. said:

Am I right with the L3 cache failure, hardware related?

That's what it looks like to me.

Hey fellas. What turned out to be the issue here? I just got this in my syslog today.

Unraid: 7.0.1

Jun 18 12:25:03 TrouxRAID kernel: mce: [Hardware Error]: Machine check events logged

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: Corrected error, no action required.

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: CPU:0 (19:61:2) MC22_STATUS[-|CE|MiscV|AddrV|-|-|SyndV|CECC|-|-|-]: 0x9c2040000400011b

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: Error Addr: 0x00000002ffa22440

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: IPID: 0x0000009600150f00, Syndrome: 0x200020000a801202

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: Unified Memory Controller Ext. Error Code: 0, DRAM ECC error.

Jun 18 12:25:03 TrouxRAID kernel: umc_normaddr_to_sysaddr: Invalid DramBaseAddress range: 0x0.

Jun 18 12:25:03 TrouxRAID kernel: EDAC MC0: 1 CE Cannot decode normalized address on mc#0csrow#2channel#1 (csrow:2 channel:1 page:0x0 offset:0x0 grain:64 syndrome:0x2000)

Jun 18 12:25:03 TrouxRAID kernel: [Hardware Error]: cache level: L3/GEN, tx: GEN, mem-tx: RD

Edited June 18, 20251 yr by ChknNRice

13 hours ago, ChknNRice said:

DRAM ECC error.

That looks like a bad ECC RAM stick.

3 hours ago, JorgeB said:

That looks like a bad ECC RAM stick.

It passed 24 hours of mem test. And there's nothing in the IPMI logs. That last line tells me it's l3 cache erroring out.

41 minutes ago, ChknNRice said:

It passed 24 hours of mem test.

That's expected with ECC RAM, the error was corrected.

42 minutes ago, ChknNRice said:

That last line tells me it's l3 cache erroring out.

Could be, I missed that before.

On 6/19/2025 at 8:32 AM, JorgeB said:

That's expected with ECC RAM, the error was corrected.

I'm using the pro version which detects ECC corrections.

Regardless, I haven't seen this error since so I'm not going to sweat it.
