schpongo Posted October 23, 2015 Posted October 23, 2015 I wanted to play around with Unraid 6 so I installed it to a usb stick an let my nas boot. Wanted to play around with docker I saw that I needed to start an array. As I was not sure if Unraid6 supported the ext4 file system (I expected it to so one could transfer data, but it turns out it doesn't) I started the array (with no parity on my drive). I saw that it did not recognise my FS so I stopped the array again and booted in my old os. During the process I did not format the drive But now the file system seems to be corrupted. Is there any way to fix this?
itimpi Posted October 23, 2015 Posted October 23, 2015 If you assigned a disk that was not previously used by unRAID as a array disk, then unRAID will have rewritten the partition table to conform to unRAID standards. I am not sure how one can undo such a change. Once partitioned by unRAID you can take the disk to other systems (e.g. Linux) and they will be happy to work with the unRAID style partitioning. Unraid does not support ext4 as a file system for array disks. The supported formats are BTRFS, XFS and Reiserfs. You can use ext4 (and various other formats such as HFS, NTFS) for disks that are not part of the array. This is best done by installing the Unassigned Devices plugin. This is commonly done for transferring data to/from an unRAID system.
schpongo Posted October 23, 2015 Author Posted October 23, 2015 If you assigned a disk that was not previously used by unRAID as a array disk, then unRAID will have rewritten the partition table to conform to unRAID standards. I am not sure how one can undo such a change. Unraid does not support ext4 as a file system for array disks. The supported formats are BTRFS, XFS and Reiserfs. You can use ext4 (and various other formats such as HFS, NTFS) for disks that are not part of the array. This is best done by installing the Unassigned Devices plugin. This is commonly done for transferring data to/from an unRAID system. Ah I did not know that with the Unassigned Devices. Now I just need a way to revert my changes. EDIT: Well I tried to rebuild the Filesystem and then fix it with fsck but was unsuccessful, I assume that someone could have fixed it, but as the data on the drive wasn't of great importance I have reformatted the drive.
heyper Posted February 10, 2017 Posted February 10, 2017 hello, I wanted to move from my old setup to unRAID Pro this weekend. And while testing the demo of unRAID... ...the same happend to me Now I can't mount the ext4 filesystem on the disk. (I thought mouting the disk in unRAID as a array is read only . I did NOT write any data to the disk or reformat it.) How can I get back the data from the ext4 filesystem? I think the parition table is now full of error, right? I tried to mount it via ssh: root@unRAID:/mnt# mkdir mnt_sdd1 root@unRAID:/mnt# mount -t ext4 /dev/sdd1 /mnt/mnt_sdd1 mount: wrong fs type, bad option, bad superblock on /dev/sdd1, missing codepage or helper program, or other error In some cases useful info is found in syslog - try dmesg | tail or so. :'( edit: root@unRAID:/# fdisk -lu Disk /dev/sdd: 5.5 TiB, 6001175126016 bytes, 11721045168 Units: sectors of 1 * 512 = 512 bytes Sector size (logical/physical): 512 bytes / 4096 bytes I/O size (minimum/optimal): 4096 bytes / 4096 bytes Disklabel type: gpt Disk identifier: xxxxxxxxxxxxxxx Device Start End Sectors Size Type /dev/sdd1 64 11721045134 11721045071 5.5T Linux filesystem Disk /dev/sdd: 5.5 TiB, 6001175126016 bytes, 11721045168 Device Start End Sectors Size Type /dev/sdd1 64 11721045134 11721045071 5.5T Linux filesystem This has to be the problem. The numbers do not match. How do I fix this? Using testdisk?
itimpi Posted February 10, 2017 Posted February 10, 2017 ...the same happend to me Now I can't mount the ext4 filesystem on the disk. (I thought mouting the disk in unRAID as a array is read only . I did NOT write any data to the disk or reformat it.) Unfortunately not. Assigning a disk to the array and starting it rewrites the partition table to the unRAID standard if it is not already conformant. How can I get back the data from the ext4 filesystem? I think the parition table is now full of error, right? If you do hot know what the old settings were for the partition table then you are going to have to look for recovery software that can handle this. Not sure what to suggest you use.
heyper Posted February 10, 2017 Posted February 10, 2017 Thank you for the answer. I had some trouble with an old and dying disk in the past. The partition table was corrupt (aswell ?!). Testdisk did the job and I was able to save the data to another drive. Testdisk: http://www.cgsecurity.org/wiki/TestDisk Maybe someone can help me here.. Is this a good idea in this case? I created the disk as a ext4 filesystem via openmediavault (omv).
heyper Posted February 11, 2017 Posted February 11, 2017 Done! How to fix this: Option A) Don't try to mount ext4 as an array (Best solution ) Option B) Fix the partition table with Testdisk: e.g. https://www.linux.com/learn/how-fix-mangled-partition-table-linux
extrobe Posted April 26, 2017 Posted April 26, 2017 I did something similar (I didn't mount it as an array, but think because I went from GPT to MBR, it screwed up nonetheless) Testdisk also did the trick for me - fantastic utility (and found it far far easier to use than the gdisk utility).
