Unable to mount drive

xchan04
in General Support

Featured Replies

I am a newbie for this server, for some reason, I am unable to mount my drives. Whenever i try to start the array, i have a message below saying mounting disks but the page just loads forever. This is the first time this happened and this happened after a powerloss.



Sep 18 00:35:22 Alpha kernel: WARNING: CPU: 1 PID: 10346 at fs/xfs/xfs_buf.c:472 _xfs_buf_find+0x7f/0x28c()

Sep 18 00:35:22 Alpha kernel: Modules linked in: md_mod bonding ax88179_178a usbnet r8169 mii x86_pkg_temp_thermal coretemp kvm i2c_i801 i2c_core ahci libahci wmi [last unloaded: md_mod]

Sep 18 00:35:22 Alpha kernel: CPU: 1 PID: 10346 Comm: mount Tainted: G W 4.4.19-unRAID #1

Sep 18 00:35:22 Alpha kernel: Hardware name: ASUS All Series/B85M-G R2.0, BIOS 2201 06/25/2015

Sep 18 00:35:22 Alpha kernel: 0000000000000000 ffff8800d23e3950 ffffffff8136a68e 0000000000000000

Sep 18 00:35:22 Alpha kernel: 00000000000001d8 ffff8800d23e3988 ffffffff8104a39a ffffffff8127341f

Sep 18 00:35:22 Alpha kernel: 0000000000000000 ffff880214223e40 ffff880214223e40 ffff8802156e5500

Sep 18 00:35:22 Alpha kernel: Call Trace:

Sep 18 00:35:22 Alpha kernel: [<ffffffff8136a68e>] dump_stack+0x61/0x7e

Sep 18 00:35:22 Alpha kernel: [<ffffffff8104a39a>] warn_slowpath_common+0x8f/0xa8

Sep 18 00:35:22 Alpha kernel: [<ffffffff8127341f>] ? _xfs_buf_find+0x7f/0x28c

Sep 18 00:35:22 Alpha kernel: [<ffffffff8104a457>] warn_slowpath_null+0x15/0x17

Sep 18 00:35:22 Alpha kernel: [<ffffffff8127341f>] _xfs_buf_find+0x7f/0x28c

Sep 18 00:35:22 Alpha kernel: [<ffffffff812724f4>] ? xfs_buf_allocate_memory+0x161/0x299

Sep 18 00:35:22 Alpha kernel: [<ffffffff8127369c>] xfs_buf_get_map+0x70/0x12b

Sep 18 00:35:22 Alpha kernel: [<ffffffff81294ff1>] xfs_trans_get_buf_map+0x80/0xa7

Sep 18 00:35:22 Alpha kernel: [<ffffffff8125563c>] xfs_btree_get_bufs+0x4b/0x4d

Sep 18 00:35:22 Alpha kernel: [<ffffffff81246032>] xfs_alloc_fix_freelist+0x174/0x2de

Sep 18 00:35:22 Alpha kernel: [<ffffffff81065255>] ? wake_up_q+0x51/0x51

Sep 18 00:35:22 Alpha kernel: [<ffffffff81273239>] ? xfs_buf_rele+0x3d/0xe9

Sep 18 00:35:22 Alpha kernel: [<ffffffff812465c5>] xfs_free_extent+0x86/0xed

Sep 18 00:35:22 Alpha kernel: [<ffffffff8129550a>] xfs_trans_free_extent+0x21/0x58

Sep 18 00:35:22 Alpha kernel: [<ffffffff81290ee1>] xlog_recover_process_efi+0x125/0x155

Sep 18 00:35:22 Alpha kernel: [<ffffffff81290f82>] xlog_recover_process_efis+0x71/0xb5

Sep 18 00:35:22 Alpha kernel: [<ffffffff81075fcb>] ? wake_up_bit+0x1d/0x1f

Sep 18 00:35:22 Alpha kernel: [<ffffffff8127a0bf>] ? xfs_iget+0x50f/0x54e

Sep 18 00:35:22 Alpha kernel: [<ffffffff81294324>] xlog_recover_finish+0x18/0x8b

Sep 18 00:35:22 Alpha kernel: [<ffffffff81294324>] ? xlog_recover_finish+0x18/0x8b

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128b617>] xfs_log_mount_finish+0x20/0x36

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128488c>] xfs_mountfs+0x601/0x6a8

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128718c>] xfs_fs_fill_super+0x3fd/0x489

Sep 18 00:35:22 Alpha kernel: [<ffffffff8110c0fa>] mount_bdev+0x141/0x195

Sep 18 00:35:22 Alpha kernel: [<ffffffff81286d8f>] ? xfs_parseargs+0x8c1/0x8c1

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128574a>] xfs_fs_mount+0x10/0x12

Sep 18 00:35:22 Alpha kernel: [<ffffffff8110cd6b>] mount_fs+0xf/0x84

Sep 18 00:35:22 Alpha kernel: [<ffffffff81121882>] vfs_kern_mount+0x65/0xf7

Sep 18 00:35:22 Alpha kernel: [<ffffffff811241f8>] do_mount+0x91c/0xa72

Sep 18 00:35:22 Alpha kernel: [<ffffffff810ce07d>] ? strndup_user+0x3a/0x82

Sep 18 00:35:22 Alpha kernel: [<ffffffff8112453d>] SyS_mount+0x70/0x9c

Sep 18 00:35:22 Alpha kernel: [<ffffffff81620a2e>] entry_SYSCALL_64_fastpath+0x12/0x6d

Sep 18 00:35:22 Alpha kernel: ---[ end trace 718fc4c1fb29125c ]---

Sep 18 00:35:22 Alpha kernel: BUG: unable to handle kernel NULL pointer dereference at 00000000000000f8

Sep 18 00:35:22 Alpha kernel: IP: [<ffffffff812952fb>] xfs_trans_binval+0x7/0x80

Sep 18 00:35:22 Alpha kernel: PGD d2be9067 PUD d2bb9067 PMD 0

Sep 18 00:35:22 Alpha kernel: Oops: 0000 [#1] PREEMPT SMP

Sep 18 00:35:22 Alpha kernel: Modules linked in: md_mod bonding ax88179_178a usbnet r8169 mii x86_pkg_temp_thermal coretemp kvm i2c_i801 i2c_core ahci libahci wmi [last unloaded: md_mod]

Sep 18 00:35:22 Alpha kernel: CPU: 1 PID: 10346 Comm: mount Tainted: G W 4.4.19-unRAID #1

Sep 18 00:35:22 Alpha kernel: Hardware name: ASUS All Series/B85M-G R2.0, BIOS 2201 06/25/2015

Sep 18 00:35:22 Alpha kernel: task: ffff8800d4063700 ti: ffff8800d23e0000 task.ti: ffff8800d23e0000

Sep 18 00:35:22 Alpha kernel: RIP: 0010:[<ffffffff812952fb>] [<ffffffff812952fb>] xfs_trans_binval+0x7/0x80

Sep 18 00:35:22 Alpha kernel: RSP: 0018:ffff8800d23e3a68 EFLAGS: 00010246

Sep 18 00:35:22 Alpha kernel: RAX: 0000000000000000 RBX: ffff8800d23e3b58 RCX: 00000000000d6c01

Sep 18 00:35:22 Alpha kernel: RDX: 0000000000000008 RSI: 0000000000000000 RDI: ffff8802156dd000

Sep 18 00:35:22 Alpha kernel: RBP: ffff8800d23e3a78 R08: 0000000000018ed0 R09: ffffffff81272ed5

Sep 18 00:35:22 Alpha kernel: R10: ffffea000855b900 R11: 00000000002156d5 R12: ffff8802156dd000

Sep 18 00:35:22 Alpha kernel: R13: ffff88021433e840 R14: ffff8800d4191000 R15: 0000000000000006

Sep 18 00:35:22 Alpha kernel: FS: 00002af1f8c3ad80(0000) GS:ffff88021fb00000(0000) knlGS:0000000000000000

Sep 18 00:35:22 Alpha kernel: CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033

Sep 18 00:35:22 Alpha kernel: CR2: 00000000000000f8 CR3: 00000000d23a9000 CR4: 00000000000406e0

Sep 18 00:35:22 Alpha kernel: Stack:

Sep 18 00:35:22 Alpha kernel: ffff8800d23e3b58 ffff8802156dd000 ffff8800d23e3b48 ffffffff8124603d

Sep 18 00:35:22 Alpha kernel: 0000000200000002 ffffffffd23e3b08 ffff880216153c80 0000000000000000

Sep 18 00:35:22 Alpha kernel: ffff8800d4063700 00000000d23e3ab0 0000000000000001 ffff8800d4063700

Sep 18 00:35:22 Alpha kernel: Call Trace:

Sep 18 00:35:22 Alpha kernel: [<ffffffff8124603d>] xfs_alloc_fix_freelist+0x17f/0x2de

Sep 18 00:35:22 Alpha kernel: [<ffffffff81065255>] ? wake_up_q+0x51/0x51

Sep 18 00:35:22 Alpha kernel: [<ffffffff81273239>] ? xfs_buf_rele+0x3d/0xe9

Sep 18 00:35:22 Alpha kernel: [<ffffffff812465c5>] xfs_free_extent+0x86/0xed

Sep 18 00:35:22 Alpha kernel: [<ffffffff8129550a>] xfs_trans_free_extent+0x21/0x58

Sep 18 00:35:22 Alpha kernel: [<ffffffff81290ee1>] xlog_recover_process_efi+0x125/0x155

Sep 18 00:35:22 Alpha kernel: [<ffffffff81290f82>] xlog_recover_process_efis+0x71/0xb5

Sep 18 00:35:22 Alpha kernel: [<ffffffff81075fcb>] ? wake_up_bit+0x1d/0x1f

Sep 18 00:35:22 Alpha kernel: [<ffffffff8127a0bf>] ? xfs_iget+0x50f/0x54e

Sep 18 00:35:22 Alpha kernel: [<ffffffff81294324>] xlog_recover_finish+0x18/0x8b

Sep 18 00:35:22 Alpha kernel: [<ffffffff81294324>] ? xlog_recover_finish+0x18/0x8b

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128b617>] xfs_log_mount_finish+0x20/0x36

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128488c>] xfs_mountfs+0x601/0x6a8

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128718c>] xfs_fs_fill_super+0x3fd/0x489

Sep 18 00:35:22 Alpha kernel: [<ffffffff8110c0fa>] mount_bdev+0x141/0x195

Sep 18 00:35:22 Alpha kernel: [<ffffffff81286d8f>] ? xfs_parseargs+0x8c1/0x8c1

Sep 18 00:35:22 Alpha kernel: [<ffffffff8128574a>] xfs_fs_mount+0x10/0x12

Sep 18 00:35:22 Alpha kernel: [<ffffffff8110cd6b>] mount_fs+0xf/0x84

Sep 18 00:35:22 Alpha kernel: [<ffffffff81121882>] vfs_kern_mount+0x65/0xf7

Sep 18 00:35:22 Alpha kernel: [<ffffffff811241f8>] do_mount+0x91c/0xa72

Sep 18 00:35:22 Alpha kernel: [<ffffffff810ce07d>] ? strndup_user+0x3a/0x82

Sep 18 00:35:22 Alpha kernel: [<ffffffff8112453d>] SyS_mount+0x70/0x9c

Sep 18 00:35:22 Alpha kernel: [<ffffffff81620a2e>] entry_SYSCALL_64_fastpath+0x12/0x6d

Sep 18 00:35:22 Alpha kernel: Code: 01 8b 50 78 89 d6 83 ce 0a 80 e2 80 89 70 78 75 12 55 89 ca 44 89 ce 48 89 c7 48 89 e5 e8 c8 94 ff ff 5d c3 55 48 89 e5 41 54 53 <48> 8b 9e f8 00 00 00 f6 43 78 04 75 67 49 89 fc 48 89 f7 e8 fd

Sep 18 00:35:22 Alpha kernel: RIP [<ffffffff812952fb>] xfs_trans_binval+0x7/0x80

Sep 18 00:35:22 Alpha kernel: RSP <ffff8800d23e3a68>

Sep 18 00:35:22 Alpha kernel: CR2: 00000000000000f8

Sep 18 00:35:22 Alpha kernel: ---[ end trace 718fc4c1fb29125d ]---

Sep 18 00:35:22 Alpha emhttp: err: shcmd: shcmd (457): exit status: -119

Sep 18 00:35:22 Alpha emhttp: mount error: No file system (-119)

Sep 18 00:35:22 Alpha emhttp: shcmd (458): umount /mnt/disk1 |& logger

Sep 18 00:35:22 Alpha root: umount: /mnt/disk1: not mounted

Sep 18 00:35:22 Alpha emhttp: shcmd (459): rmdir /mnt/disk1

Sep 18 00:35:22 Alpha emhttp: shcmd (460): mkdir -p /mnt/cache

Sep 18 00:35:22 Alpha emhttp: shcmd (461): set -o pipefail ; mount -t auto -o noatime,nodiratime /dev/sdb1 /mnt/cache |& logger

Sep 18 00:35:22 Alpha kernel: BTRFS info (device sdb1): disk space caching is enabled

Sep 18 00:35:22 Alpha kernel: BTRFS: has skinny extents

Sep 18 00:35:22 Alpha kernel: BTRFS: detected SSD devices, enabling SSD mode

Sep 18 00:35:22 Alpha emhttp: shcmd (462): sync

Sep 18 00:35:40 Alpha kernel: br0: received packet on bond0 with own address as source address

Sep 18 00:36:01 Alpha kernel: br0: received packet on bond0 with own address as source address

Sep 18 00:36:01 Alpha kernel: br0: received packet on bond0 with own address as source address

Sep 18 00:37:45 Alpha kernel: br0: received packet on bond0 with own address as source address



Those are the messages i can get from the logs. Please help me.


  • Quote
    • Community Expert

    You should always post the diagnostics, the snippet you posted doesn't show which disk is causing the crash, but since you only have one run xfx_repair on disk1, there's a filesystem issue and it's making unRAID crash.

  • Quote
    • Author

    Thank you, is there any way to run that via command line or is there anyway to disable disk autostart via command line?

  • Quote
    • Author

    unfortunately since it looks like the disks are automatically starting, i am unable to access the gui as it is crashing

  • Quote
    • Community Expert

    Settings -> Disk settings -> Enable auto start: No

  • Quote
    • Author

    yeah, thats the prob, i am unable to access the gui as of the moment. Is there anyway to disable autostart from terminal?

  • Quote
    • Community Expert

    If you can't get to the webGUI you have to edit the file in your flash drive:



    config\disk.cfg



    change startArray="yes" to "no"

  • Quote
    • Author

    thank you very much, im currently running the check filesystem on disk one





    Phase 1 - find and verify superblock...

    Phase 2 - using internal log

            - zero log...

            - scan filesystem freespace and inode maps...

    Metadata corruption detected at xfs_agf block 0x1/0x200

    flfirst 118 in agf 0 too large (max = 118)

    agf 118 freelist blocks bad, skipping freelist scan



    Thank you!

  • Quote
    • Author

    Thank you, i was able to fix my issue!!!
