March 3, 20179 yr Try as I may I cannot get my optical drives assigned to a Windows 10 VM. Using some old posts I was able to get ONE drive working once but subsequent recabling of my drives to add the second optical and further messing with the XML code has left me with no optical drive no matter how hard I try. Can someome take a look at my system/settings and point me in a direction to try? Is it even possible to have TWO optical drives assigned to a VM? Here is my mainboard Groups: IOMMU group 0 [8086:0150] 00:00.0 Host bridge: Intel Corporation Xeon E3-1200 v2/3rd Gen Core processor DRAM Controller (rev 09) IOMMU group 1 [8086:0151] 00:01.0 PCI bridge: Intel Corporation Xeon E3-1200 v2/3rd Gen Core processor PCI Express Root Port (rev 09) [8086:0155] 00:01.1 PCI bridge: Intel Corporation Xeon E3-1200 v2/3rd Gen Core processor PCI Express Root Port (rev 09) [10de:0f01] 01:00.0 VGA compatible controller: NVIDIA Corporation GF108 [GeForce GT 620] (rev a1) [10de:0bea] 01:00.1 Audio device: NVIDIA Corporation GF108 High Definition Audio Controller (rev a1) [10b5:8604] 02:00.0 PCI bridge: PLX Technology, Inc. PEX 8604 4-lane, 4-Port PCI Express Gen 2 (5.0 GT/s) Switch (rev ba) [10b5:8604] 03:01.0 PCI bridge: PLX Technology, Inc. PEX 8604 4-lane, 4-Port PCI Express Gen 2 (5.0 GT/s) Switch (rev ba) [10b5:8604] 03:05.0 PCI bridge: PLX Technology, Inc. PEX 8604 4-lane, 4-Port PCI Express Gen 2 (5.0 GT/s) Switch (rev ba) [1b4b:9123] 04:00.0 SATA controller: Marvell Technology Group Ltd. 88SE9123 PCIe SATA 6.0 Gb/s controller (rev 11) [1b4b:9123] 05:00.0 SATA controller: Marvell Technology Group Ltd. 88SE9123 PCIe SATA 6.0 Gb/s controller (rev 11) IOMMU group 2 [8086:0162] 00:02.0 Display controller: Intel Corporation Xeon E3-1200 v2/3rd Gen Core processor Graphics Controller (rev 09) IOMMU group 3 [8086:1e31] 00:14.0 USB controller: Intel Corporation 7 Series/C210 Series Chipset Family USB xHCI Host Controller (rev 04) IOMMU group 4 [8086:1e3a] 00:16.0 Communication controller: Intel Corporation 7 Series/C216 Chipset Family MEI Controller #1 (rev 04) IOMMU group 5 [8086:1e2d] 00:1a.0 USB controller: Intel Corporation 7 Series/C216 Chipset Family USB Enhanced Host Controller #2 (rev 04) IOMMU group 6 [8086:1e20] 00:1b.0 Audio device: Intel Corporation 7 Series/C216 Chipset Family High Definition Audio Controller (rev 04) IOMMU group 7 [8086:1e10] 00:1c.0 PCI bridge: Intel Corporation 7 Series/C216 Chipset Family PCI Express Root Port 1 (rev c4) IOMMU group 8 [8086:1e16] 00:1c.3 PCI bridge: Intel Corporation 7 Series/C216 Chipset Family PCI Express Root Port 4 (rev c4) IOMMU group 9 [8086:1e18] 00:1c.4 PCI bridge: Intel Corporation 7 Series/C210 Series Chipset Family PCI Express Root Port 5 (rev c4) IOMMU group 10 [8086:1e1a] 00:1c.5 PCI bridge: Intel Corporation 7 Series/C210 Series Chipset Family PCI Express Root Port 6 (rev c4) IOMMU group 11 [8086:1e1c] 00:1c.6 PCI bridge: Intel Corporation 7 Series/C210 Series Chipset Family PCI Express Root Port 7 (rev c4) IOMMU group 12 [8086:1e1e] 00:1c.7 PCI bridge: Intel Corporation 7 Series/C210 Series Chipset Family PCI Express Root Port 8 (rev c4) IOMMU group 13 [8086:1e26] 00:1d.0 USB controller: Intel Corporation 7 Series/C216 Chipset Family USB Enhanced Host Controller #1 (rev 04) IOMMU group 14 [8086:1e44] 00:1f.0 ISA bridge: Intel Corporation Z77 Express Chipset LPC Controller (rev 04) [8086:1e02] 00:1f.2 SATA controller: Intel Corporation 7 Series/C210 Series Chipset Family 6-port SATA Controller [AHCI mode] (rev 04) [8086:1e22] 00:1f.3 SMBus: Intel Corporation 7 Series/C216 Chipset Family SMBus Controller (rev 04) IOMMU group 15 [1b21:0612] 07:00.0 SATA controller: ASMedia Technology Inc. ASM1062 Serial ATA Controller (rev 01) IOMMU group 16 [14e4:16b1] 08:00.0 Ethernet controller: Broadcom Limited NetLink BCM57781 Gigabit Ethernet PCIe (rev 10) IOMMU group 17 [1b21:1080] 09:00.0 PCI bridge: ASMedia Technology Inc. ASM1083/1085 PCIe to PCI Bridge (rev 03) [1095:3114] 0a:01.0 RAID bus controller: Silicon Image, Inc. SiI 3114 [SATALink/SATARaid] Serial ATA Controller (rev 02) IOMMU group 18 [1106:3403] 0b:00.0 FireWire (IEEE 1394): VIA Technologies, Inc. VT6315 Series Firewire Controller (rev 01) IOMMU group 19 [1b21:1042] 0c:00.0 USB controller: ASMedia Technology Inc. ASM1042 SuperSpeed USB Host Controller and here is my SCSI device list: [0:0:0:0] disk SanDisk Cruzer Fit 1.27 /dev/sda 8.00GB [1:0:0:0] cd/dvd HL-DT-ST DVDRAM GH24NSB0 LN00 /dev/sr0 - [2:0:0:0] cd/dvd HL-DT-ST DVDRAM GH24NS95 RN01 /dev/sr1 - [5:0:0:0] disk ATA WDC WD20EFRX-68E 0A82 /dev/sdb 2.00TB [6:0:0:0] disk ATA SAMSUNG HD204UI 0001 /dev/sdc 2.00TB [9:0:0:0] disk ATA ST2000DM001-9YN1 CC4H /dev/sdd 2.00TB [10:0:0:0] disk ATA ST2000DM001-9YN1 CC4H /dev/sde 2.00TB [12:0:0:0] disk ATA TOSHIBA MK5065GS 8B /dev/sdf 500GB [15:0:0:0] disk ATA WDC WD30EFRX-68E 0A82 /dev/sdg 3.00TB [16:0:0:0] disk ATA WDC WD1001FAES-7 1D05 /dev/sdh 1.00TB As well and my machine vm xml code: <domain type='kvm'> <name>Windows 10 x64</name> <uuid>6dfd0581-b5aa-23fc-c529-6d4ac55f79f3</uuid> <metadata> <vmtemplate xmlns="unraid" name="Windows 10" icon="windows.png" os="windows10"/> </metadata> <memory unit='KiB'>4194304</memory> <currentMemory unit='KiB'>4194304</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>4</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='3'/> <vcpupin vcpu='2' cpuset='6'/> <vcpupin vcpu='3' cpuset='7'/> </cputune> <os> <type arch='x86_64' machine='pc-i440fx-2.7'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/6dfd0581-b5aa-23fc-c529-6d4ac55f79f3_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> <hyperv> <relaxed state='on'/> <vapic state='on'/> <spinlocks state='on' retries='8191'/> <vendor_id state='on' value='none'/> </hyperv> </features> <cpu mode='host-passthrough'> <topology sockets='1' cores='2' threads='2'/> </cpu> <clock offset='localtime'> <timer name='hypervclock' present='yes'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/domains/Windows 10 x64/vdisk1.img'/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </disk> <controller type='usb' index='0' model='nec-xhci'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <controller type='pci' index='0' model='pci-root'/> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:ee:a6:7c'/> <source bridge='br0'/> <model type='virtio'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </interface> <serial type='pty'> <target port='0'/> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <graphics type='vnc' port='-1' autoport='yes' websocket='-1' listen='0.0.0.0' keymap='en-us'> <listen type='address' address='0.0.0.0'/> </graphics> <video> <model type='qxl' ram='65536' vram='65536' vgamem='16384' heads='1' primary='yes'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </video> <memballoon model='virtio'> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0'/> </memballoon> </devices> </domain> The VM runs good and attached is my device manager screenshot showing a scsi adapter but no optical device. This is all new to me and I would appreciate any help or comments I can get. Thanks, Dwight
