January 10, 20188 yr 7 hours ago, mchamplain said: Now my question, what about updates? Would updating Unraid break my VM with passthrough? I asked about this, in another thread. To answer your question, yes updating unRAID will remove this patch; this was done as a courtesy and concept testing for early-TR adopters. As of now you want to just stay put. On another note I've been playing with kernel compiling (I can feel the Linux guru's and unRAID employee's shudder) goal would be to limp along an un-official fork until the user patch is in-place working; or I get a message from the "brass" saying, "for the love of all that is holly, DON'T!" Quote What if I want to try the latest version with the Java hack, is it possible to "rollback" to my current setup if it doesn't work for me? Somewhere I did see a post or thread on how to "rollback" rc versions, and it was in relation to ThreadRipper, so some searches in the forums should produce the steps you're seeking.
January 10, 20188 yr 6 hours ago, Rhynri said: If no one else volunteers, I can try my hand at making a C version this week or next. Unless PHP is preferable? As a side note, I don't use C that often, so there are undoubtably better people on the forum than me. I'd bet general consensus would be, "go for it," if unRAID peps got multiple's they would probably be: pleased, and pick the better working solution. I don't have the skill-set to do this myself, but I'd be a willing guinea-pig if you need tester(s). I have a co-worker that could probably write a php plug-in, but he graduated College, currently on vacation, and moving away in a few months - so he may not be willing or able to be tapped for favor.
January 10, 20188 yr Author 1 hour ago, Jcloud said: On another note I've been playing with kernel compiling (I can feel the Linux guru's and unRAID employee's shudder) goal would be to limp along an un-official fork until the user patch is in-place working; or I get a message from the "brass" saying, "for the love of all that is holly, DON'T!" Maybe you can ask @CHBMB to fill you in on rebuilding unRAID kernels. He maintains "unRAID DVB Edition" and could probably be bribed, but don't tell him I suggested this! Edit: Here's the ugly patch, haven't verified it works on latest kernel: --- a/drivers/pci/pci.c 2017-12-19 08:52:34.884337821 -0800 --- b/drivers/pci/pci.c 2017-12-19 08:52:34.884337821 -0800 +++ /usr/src/linux/drivers/pci/pcix.c 2017-12-19 09:57:48.516559218 -0800 @@ -3982,6 +3982,8 @@ void pci_reset_secondary_bus(struct pci_dev *dev) { u16 ctrl; + int i; + u8 mem; pci_read_config_word(dev, PCI_BRIDGE_CONTROL, &ctrl); ctrl |= PCI_BRIDGE_CTL_BUS_RESET; @@ -3995,6 +3997,12 @@ ctrl &= ~PCI_BRIDGE_CTL_BUS_RESET; pci_write_config_word(dev, PCI_BRIDGE_CONTROL, ctrl); + // The ugly patch + for (i = 0; i < 4096; i++){ + pci_read_config_byte(dev, i, &mem); + pci_write_config_byte(dev, i, mem); + } + /* * Trhfa for conventional PCI is 2^25 clock cycles. * Assuming a minimum 33MHz clock this results in a 1s
January 10, 20188 yr 7 hours ago, limetech said: Maybe you can ask @CHBMB to fill you in on rebuilding unRAID kernels. He maintains "unRAID DVB Edition" and could probably be bribed, but don't tell him I suggested this! I have "borrowed" his script, that he posted on another thread. I thought I had managed to compile the kernel, but turns out I successfully ran CHBMB's script, but I made several errors/assumptions. Learning a lot, making plenty of errors. Managed to compile it but got seg fault with emhttp, so I did something wrong. Tinkering some more, so when I do go to bother CHBMB with my ignorance, I can hopefully keep the newb questions to a minimum -- otherwise I'd hate to see bribe be more than an arm and a leg. Unrelated to response, but related to thread, my coworker passed on coding a user driver, so I'm no help there. However, I am willing to make myself a guinea-pig tester. Edited January 11, 20188 yr by Jcloud Reality of my first attempt versus fan-fiction of my first post.
January 14, 20188 yr I'm running 6.4.0 stable with a 1950X on an Asus ROG Zenith Extreme. I get an "internal error: Unknown PCI header type '127'" message when trying to boot my Windows 10 VM with a Titan X (Pascal) passed through. It booted the first time and was accessible via RDC but there was no video output and subsequent attempts to boot give that error so I'm guessing the first boot borked it until I reboot again. I assume that the kernel with the dirty patch is now older than what comes with 6.4.0. Willing to be a Guinea pig if someone has a current fix. FWIW, this video card and this VM did previously work when I had an Intel chip.
January 15, 20188 yr I would love to see an 6.40 bzImage! Would be awesome if @limetech could build a new one Edited January 15, 20188 yr by Xstasy
January 15, 20188 yr 9 hours ago, Xstasy said: I would love to see an 6.40 bzImage! Would be awesome if @limetech could build a new one Not Limetech, but working on it. This is in the hobby and I'm no Linux expert categories, so it happens when/if it happens (on my end ).
January 16, 20188 yr 58 minutes ago, Jcloud said: Not Limetech, but working on it. This is in the hobby and I'm no Linux expert categories, so it happens when/if it happens (on my end ). If I'm reading the OP correctly then he built the first bzImage for rc17b, which means he could make it happen a bit faster. Would have compiled it myself if I knew the way on unRaid. Also, the build script you're talking about, may I have a peek? Edited January 16, 20188 yr by Xstasy
January 16, 20188 yr 1 hour ago, Xstasy said: If I'm reading the OP correctly then he built the first bzImage for rc17b, which means he could make it happen a bit faster. More than likely some truth, but I think Limetech crew would rather work on their product. Especially since the patch is more of a proof of concept hack, rather than a tested and clean fix. A conundrum in all forms of support and customer service, "can't please 100% of customer base a 100% of the time." 1 hour ago, Xstasy said: Also, the build script you're talking about, may I have a peek? Sure, the script I'm borrowing came from here: https://lime-technology.com/messenger/39030/?tab=comments#comment-603927 His CHBMB's script, in the form above doesn't cover patch files, but I imagine if you have some experience with kernel compiles on other systems then everything in there should familiar. As a side note in the script you'll see a reference for 3rd-party scsi drivers, yes you do need these. I got my set of first questions answered, but didn't have time to tinker with it yesterday. Probably put in a hour or two after work tonight. If I make something I think is worth the communities time I'll post it. Edited January 16, 20188 yr by Jcloud foo
January 16, 20188 yr Author If you look at the ugly patch reddit thread: https://www.reddit.com/r/Amd/comments/7gp1z7/threadripper_kvm_gpu_passthru_testers_needed/ The latest update provides a user-space tool that others report works (scroll all the way to bottom for latest comments). This tool is written in Java of all things, but it might be easier for someone to examine what it's really doing and re-write the critical stuff in php or bash or even C. I just don't have time to dive into this atm. Of course whole thing would be moot of AMD just fixed their damn microcode.
January 16, 20188 yr 12 minutes ago, limetech said: Of course whole thing would be moot of AMD just fixed their damn microcode. LOL Who could blame some AMD engineers for something they built on their own time versus being paid to do it in R&D labs? (Well that's me at least.) But you're not wrong either. Edited January 16, 20188 yr by Jcloud the last sentence.
January 16, 20188 yr Got the java version running on my unraid box right now! root@raid:/boot/custom # /usr/lib64/java/bin/java ZenBridgeBaconRecovery ------------------------------------------- Zen PCIe-Bridge BAR/Config Recovery Tool, rev 1, 2018, HyenaCheeseHeads ------------------------------------------- Tue Jan 16 06:41:14 CET 2018: Detecting VFIO-PCI devices Tue Jan 16 06:41:14 CET 2018: Device: /sys/devices/pci0000:00/0000:00:03.1/0000:09:00.1 Tue Jan 16 06:41:14 CET 2018: Bridge: /sys/devices/pci0000:00/0000:00:03.1 Tue Jan 16 06:41:14 CET 2018: Device: /sys/devices/pci0000:00/0000:00:03.1/0000:09:00.0 Tue Jan 16 06:41:14 CET 2018: Bridge: /sys/devices/pci0000:00/0000:00:03.1 Tue Jan 16 06:41:14 CET 2018: Monitoring 2 device(s)... Tue Jan 16 06:41:14 CET 2018: Lost contact with /sys/devices/pci0000:00/0000:00:03.1/0000:09:00.1 Tue Jan 16 06:41:14 CET 2018: Recovering 512 bytes Tue Jan 16 06:41:14 CET 2018: Bridge config write complete Tue Jan 16 06:41:14 CET 2018: Recovered bridge secondary bus Tue Jan 16 06:41:14 CET 2018: Re-acquired contact with /sys/devices/pci0000:00/0000:00:03.1/0000:09:00.1
January 16, 20188 yr Author 2 minutes ago, Xstasy said: Got the java version running on my unraid box right now! Nice! Does it work?
January 16, 20188 yr cane someone point me in a direction to get java installed on unraid to start with to get the patch to work. i had fount one way but the supporting files for it ar no longer on the net
January 16, 20188 yr HAHA I knew the community would beat me! Bah. Good learning experience though. I just successfully compiled and booted 6.4.0 with Ugly patch. VM's are up and running. Currently in my testing-paranoia mode Edited January 16, 20188 yr by Jcloud
January 16, 20188 yr 31 minutes ago, Jcloud said: HAHA I knew the community would beat me! Bah. Good learning experience though. I just successfully compiled and booted 6.4.0 with Ugly patch. VM's are up and running. Currently in my testing-paranoia mode Mine is running fine, but I wouldn't mind a copy of your bz* files to test. This user-land java patch is annoying and needs to be started after the VM.
January 16, 20188 yr 1 hour ago, Xstasy said: Mine is running fine, but I wouldn't mind a copy of your bz* files to test. Sure thing. It's getting late for me so give me about a day on that. one second, that's trivial doing that now. I'll also try and clean up my fugly compile algorithm of the ugly patch in case you anyone wants to just compile on your hardware for best results. Use this file at your own risk! If you read through this entire thread you'll realize I can read instructions, but I really don't know what I'm doing on fundamentals. 0201de31a1f125e240397b48c2978a58 bzImage Limetech overloards is this bad mojo with the files here my bad. Feel free to do what needs to be done. I took down the other two bz files per Limetech's suggestion, but if there's a 100% failure rate I'll put them back up. bzimage-tr6_4_0 Edited January 16, 20188 yr by Jcloud Danger! Danger Will Robinson!
January 16, 20188 yr Author 27 minutes ago, Jcloud said: Sure thing. It's getting late for me so give me about a day on that. one second, that's trivial doing that now. I'll also try and clean up my fugly compile algorithm of the ugly patch in case you anyone wants to just compile on your hardware for best results. 0201de31a1f125e240397b48c2978a58 bzImage 853423d0da99ecf5b9e86fae2026737e bzfirmware da0d28000c9b19d91bc192fd62ecbbd3 bzmodules Limetech overloards is this bad mojo with the files here my bad. Feel free to do what needs to be done. bzfirmware bzImage bzmodules You only need to post 'bzimage', with lower case 'i'. Maybe call it 'bzimage-tr'. Probably you've looked at what the patch does right? It's dirt-simple and I guarantee, if the right engineer at AMD saw a description of the problem and the code of the solution, they could tell you in 10 minutes the exact address range that must be read/written, and in such a way as at least be compatible with other bridges. Edit: might be good to add something like, "use at your own risk".
January 16, 20188 yr 1 minute ago, limetech said: Probably you've looked at what the patch does right? It's dirt-simple and I guarantee, if the right engineer at AMD saw a description of the problem and the code of the solution, they could tell you in 10 minutes the exact address range that must be read/written, and in such a way as at least be compatible with other bridges. Oh yes. I couldn't get it to work as a patch file, compiler rejected it, so I changed the file by hand, a few times... when I was figuring out how to do it, or at least make it compile ha! Lots of "firsts" for me on this one. I'll remember the file bit if there's a next time.
January 17, 20188 yr Upgraded to 6.4 stable, added jcloud's compile and so far so good. 3 vm's running, 2 with pass through, all fine. Smooth transition. Thanks, @Jcloud ! Asrock Tai Chi x399 TR 1950 2 x MSI GTX 970 4G Gaming
January 17, 20188 yr Just a quick mention to all of you using this patch, it's probably reasonable to let you all know that @Jcloud contacted me to discuss compiling this for the community and to ask for a little advice and made a very generous donation from his own pocket to linuxserver.io which is very much appreciated and will go towards our server and hosting costs. So a big thanks to him from everyone is well deserved (although I would like to point out I would have provided any help for free! ) Edited January 17, 20188 yr by CHBMB
January 17, 20188 yr 7 hours ago, CHBMB said: So a big thanks to him from everyone is well deserved (although I would like to point out I would have provided any help for free! ) I do Techsupport, customer service, and I'm a sarcastic SOB; I can appreciate the concept of being compensated for a newb's barrage of questions. Past and future Edited January 17, 20188 yr by Jcloud "phrasing" -- Archer
January 17, 20188 yr On 5/1/2018 at 10:16 AM, Jcloud said: Is yours the Prime or Strix board? I'm running the Prime, and patch been working for me. Latest bios perhaps? Caught my curiosity is all. Prime, Latest bios.
