dedi Posted September 22, 2020 Share Posted September 22, 2020 On 9/9/2020 at 4:31 AM, David Puziol Prata said: I have the same problem. Have you found a solution? I was reading about fake CSR and that it was necessary to recompile the Linux source code module. I can't give an UP on hci0 and it just stays on DOWN with the error Can't init device hci0: Operation not supported (95) Didn't found any solution, gave up Quote Link to comment
softdrinker Posted November 11, 2020 Share Posted November 11, 2020 (edited) Hi Same problem here With CSR dongle Bluetooth, Impossible to turn up the hci [email protected]:/# hciconfig hci0: Type: Primary Bus: USB BD Address: XX:XX:XX:XX:XX:XX ACL MTU: 679:9 SCO MTU: 48:16 DOWN RX bytes:87248 acl:0 sco:0 events:4560 errors:0 TX bytes:55566 acl:0 sco:0 commands:4560 errors:37 [email protected]:/# hciconfig hci0 up Can't init device hci0: Operation not supported (95) I was happy to use unraid with docker containers to my domotics.... Impossible without the bluetooth integration. Any solution on this topic? Edited November 11, 2020 by softdrinker Quote Link to comment
Ghostman_132 Posted November 17, 2020 Share Posted November 17, 2020 Can we have this firmware also? Asus USB-BT400 Mini Bluetooth Dongle 4.0 LE. Seems to be most common nowdays that supports LE. Nov 17 08:43:24 HPMicroServer10 kernel: usb 2-4: new full-speed USB device number 6 using xhci_hcd Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: Core ver 2.22 Nov 17 08:43:24 HPMicroServer10 kernel: NET: Registered protocol family 31 Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: HCI device and connection manager initialized Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: HCI socket layer initialized Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: L2CAP socket layer initialized Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: SCO socket layer initialized Nov 17 08:43:24 HPMicroServer10 kernel: usbcore: registered new interface driver btusb Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: hci0: BCM: chip id 63 Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: hci0: BCM: features 0x07 Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: hci0: BCM20702A Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: hci0: BCM20702A1 (001.002.014) build 0000 Nov 17 08:43:24 HPMicroServer10 kernel: bluetooth hci0: Direct firmware load for brcm/BCM20702A1-0b05-17cb.hcd failed with error -2 Nov 17 08:43:24 HPMicroServer10 kernel: Bluetooth: hci0: BCM: Patch brcm/BCM20702A1-0b05-17cb.hcd not found Quote Link to comment
L0rdRaiden Posted January 2, 2021 Share Posted January 2, 2021 @limetech Hello, could you please add the firmware of this Bluetooth chip https://linuxreviews.org/Realtek_RTL8761B https://aur.archlinux.org/packages/rtl8761b-fw/ It is probably the most (if not the only one) bluetooth chip used in usb dongles that supports bluetooth 5.0 Quote Link to comment
L0rdRaiden Posted January 2, 2021 Share Posted January 2, 2021 On 5/29/2020 at 5:24 AM, dedi said: I have a CSR Bluetooth dongle (Cambridge Silicon Radio Bluetooth Dongle) that I want to pass trough to a Home Assistant VM, I can select it in the VM config but hassos does not find the device there, Is that because firmware for CSR BT dongles are missing? On 9/9/2020 at 4:31 AM, David Puziol Prata said: I have the same problem. Have you found a solution? I was reading about fake CSR and that it was necessary to recompile the Linux source code module. I can't give an UP on hci0 and it just stays on DOWN with the error Can't init device hci0: Operation not supported (95) The problem is hassio, it doesn't support bluetooh usb stick, the only bluetooth that supports is the on in raspberry pi. Quote Link to comment
L0rdRaiden Posted January 22, 2021 Share Posted January 22, 2021 (edited) On 1/2/2021 at 11:45 AM, L0rdRaiden said: @limetech Hello, could you please add the firmware of this Bluetooth chip https://linuxreviews.org/Realtek_RTL8761B https://aur.archlinux.org/packages/rtl8761b-fw/ It is probably the most (if not the only one) bluetooth chip used in usb dongles that supports bluetooth 5.0 @limetech Could you please include this binary? Is the most common chip for usb dongles with bluetooth 5 Jan 22 13:28:51 Unraid kernel: usbcore: registered new interface driver btusb Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: examining hci_ver=0a hci_rev=000b lmp_ver=0a lmp_subver=8761 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: rom_version status=0 version=1 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: loading rtl_bt/rtl8761b_fw.bin Jan 22 13:28:51 Unraid kernel: bluetooth hci0: Direct firmware load for rtl_bt/rtl8761b_fw.bin failed with error -2 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: firmware file rtl_bt/rtl8761b_fw.bin not found Edited January 22, 2021 by L0rdRaiden Quote Link to comment
Ghostman_132 Posted January 22, 2021 Share Posted January 22, 2021 4 hours ago, L0rdRaiden said: @limetech Could you please include this binary? Is the most common chip for usb dongles with bluetooth 5 Jan 22 13:28:51 Unraid kernel: usbcore: registered new interface driver btusb Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: examining hci_ver=0a hci_rev=000b lmp_ver=0a lmp_subver=8761 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: rom_version status=0 version=1 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: loading rtl_bt/rtl8761b_fw.bin Jan 22 13:28:51 Unraid kernel: bluetooth hci0: Direct firmware load for rtl_bt/rtl8761b_fw.bin failed with error -2 Jan 22 13:28:51 Unraid kernel: Bluetooth: hci0: RTL: firmware file rtl_bt/rtl8761b_fw.bin not found What products (dongle manufacturers) use this chip? Quote Link to comment
L0rdRaiden Posted January 22, 2021 Share Posted January 22, 2021 18 minutes ago, Ghostman_132 said: What products (dongle manufacturers) use this chip? I would say any usb bluetooth 5.0 in aliexpress Quote Link to comment
cracyfloyd Posted June 5, 2021 Share Posted June 5, 2021 Any chance to get it running? LOG: Jun 5 04:35:06 kernel: Bluetooth: hci0: Reading Intel version information failed (-22) Jun 5 04:35:06 kernel: Bluetooth: hci0: Intel Read version failed (-22) Jun 5 04:35:06 kernel: Bluetooth: hci0: Intel reset sent to retry FW download I use a new Intel Z590 mainboard with an Intel -5 11400 CPU. Quote Link to comment
Raesche Posted July 24, 2021 Share Posted July 24, 2021 Is there any update on getting the rtl8761b driver working on Unraid? The chipset has been out for a really long time at this point and is pretty ubiquitous. Quote Link to comment
Huge Yeti Posted July 29, 2021 Share Posted July 29, 2021 [email protected]:~# hciconfig -a hci0: Type: Primary Bus: USB BD Address: 0C:54:15:69:86:64 ACL MTU: 1021:4 SCO MTU: 96:6 DOWN RX bytes:14992 acl:0 sco:0 events:2420 errors:0 TX bytes:595696 acl:0 sco:0 commands:2418 errors:0 Features: 0xff 0xfe 0x0f 0xfe 0xdb 0xff 0x7b 0x87 Packet type: DM1 DM3 DM5 DH1 DH3 DH5 HV1 HV2 HV3 Link policy: RSWITCH HOLD SNIFF Link mode: SLAVE ACCEPT Under Tools --> System Devices --> I can't seem to find this bluetooth for my guest VM device passthrough. I've inspected every IOMMU group but nothing comes close to the above. Is my motherboard bluetooth not supported in unraid 6.9.2? https://www.gigabyte.com/Motherboard/X299-DESIGNARE-EX-rev-10/sp#sp Quote Link to comment
sothym Posted August 28, 2021 Share Posted August 28, 2021 @limetech Can you please also add the following bluetooth driver: BCM20702A1-0a5c-21e8.hcd The file is also available in this reposiroty: https://github.com/winterheart/broadcom-bt-firmware/tree/master/brcm I would also try the solution of @Chuck Claunch above but I have no idea how to pass the USB bus to a VM instead of a docker. Quote Link to comment
Kuijibo Posted September 16, 2021 Share Posted September 16, 2021 Did anyone make progress on this? I bought a long-range Bluetooth dongle and can't get it to work. I have the same issue as @L0rdRaiden. Quote Link to comment
L0rdRaiden Posted December 28, 2021 Share Posted December 28, 2021 (edited) On 9/16/2021 at 9:51 PM, Kuijibo said: Did anyone make progress on this? I bought a long-range Bluetooth dongle and can't get it to work. I have the same issue as @L0rdRaiden. I haven't solve it yet, it would be nice to have some official support for bluetooth devices @limetech I guess the solution is here, but even if it works, the driver will disappear after a reboot https://linuxreviews.org/Realtek_RTL8761B There is already a folder for realtek devices, just need to add the new files https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_config https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_fw Download and rename to *.bin Edited December 28, 2021 by L0rdRaiden Quote Link to comment
L0rdRaiden Posted December 28, 2021 Share Posted December 28, 2021 It worked, apparently Quote Link to comment
ensnare Posted January 7, 2022 Share Posted January 7, 2022 (edited) That worked, I adde the below to my /boot/config/go: sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_config -o /tmp/rtl8761bu_config.bin sudo mv /tmp/rtl8761bu_config.bin /lib/firmware/rtl_bt/rtl8761bu_config.bin sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_fw -o /tmp/rtl8761bu_fw.bin sudo mv /tmp/rtl8761bu_fw.bin /lib/firmware/rtl_bt/rtl8761bu_fw.bin However, I have to manually unplug and plug-in the usb dongle so the module reloads. Any way to do this programmatically? Also, where does the device appear? Trying to pass this through to a Home Assistant container, but can't find it! Edited January 7, 2022 by ensnare 4 Quote Link to comment
L0rdRaiden Posted January 7, 2022 Share Posted January 7, 2022 (edited) 45 minutes ago, ensnare said: That worked, I adde the below to my /boot/config/go: sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_config -o /tmp/rtl8761bu_config.bin sudo mv /tmp/rtl8761bu_config.bin /lib/firmware/rtl_bt/rtl8761bu_config.bin sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_fw -o /tmp/rtl8761bu_fw.bin sudo mv /tmp/rtl8761bu_fw.bin /lib/firmware/rtl_bt/rtl8761bu_fw.bin However, I have to manually unplug and plug-in the usb dongle so the module reloads. Any way to do this programmatically? Also, where does the device appear? Trying to pass this through to a Home Assistant container, but can't find it! You can run this to see the status of the device "dmesg | grep -i blue" You can run this to see the tty and do the passthrough in the container "ls -ltr /dev/tty*|tail -n 1" Both in the unraid command line console Then you create the passthrough in HA container like this. I tried to make it work but I couldn't for some reason the integrations in Home Assistant that uses the bluetooth gave me errors. If you manage to make it work, please, please, post the solution here. Thanks Edited January 7, 2022 by L0rdRaiden Quote Link to comment
L0rdRaiden Posted January 7, 2022 Share Posted January 7, 2022 55 minutes ago, ensnare said: That worked, I adde the below to my /boot/config/go: sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_config -o /tmp/rtl8761bu_config.bin sudo mv /tmp/rtl8761bu_config.bin /lib/firmware/rtl_bt/rtl8761bu_config.bin sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_fw -o /tmp/rtl8761bu_fw.bin sudo mv /tmp/rtl8761bu_fw.bin /lib/firmware/rtl_bt/rtl8761bu_fw.bin However, I have to manually unplug and plug-in the usb dongle so the module reloads. Any way to do this programmatically? Also, where does the device appear? Trying to pass this through to a Home Assistant container, but can't find it! I think your script is wrong, why do you rename from rtl8761b_config to rtl8761bu_config.bin ? Quote Link to comment
L0rdRaiden Posted January 7, 2022 Share Posted January 7, 2022 Check this posts maybe you understand it better than me to make it work https://community.home-assistant.io/t/trying-to-get-usb-bluetooth-tracker-working-with-ha-docker/65004/4 http://hintshop.ludvig.co.nz/show/persistent-names-usb-serial-devices/ Quote Link to comment
L0rdRaiden Posted January 7, 2022 Share Posted January 7, 2022 My last try is (To see de bus and device number) lsusb (To see the dev/bus route and confirm the device) udevadm info /dev/bus/usb/{BUS_NUMBER}/{DEVICE_NUMBER} (Add this to the docker container) --device=/dev/bus/usb/00X/00Y Didn't work either Quote Link to comment
PmoshBR Posted January 24, 2022 Share Posted January 24, 2022 I tryed to use Nerd Pack "bluez" pack to install hci0, and managed to start hci0 to start at unraid... but no success to pass to docker.. Any new ideia to try?? I'm trying to use hacs component "Passive BLE Monitor" at Home Assistant docker... Quote Link to comment
abuhamsa Posted May 30, 2022 Share Posted May 30, 2022 (edited) On 1/7/2022 at 2:33 PM, ensnare said: That worked, I adde the below to my /boot/config/go: sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_config -o /tmp/rtl8761bu_config.bin sudo mv /tmp/rtl8761bu_config.bin /lib/firmware/rtl_bt/rtl8761bu_config.bin sudo curl -L https://raw.githubusercontent.com/Realtek-OpenSource/android_hardware_realtek/rtk1395/bt/rtkbt/Firmware/BT/rtl8761b_fw -o /tmp/rtl8761bu_fw.bin sudo mv /tmp/rtl8761bu_fw.bin /lib/firmware/rtl_bt/rtl8761bu_fw.bin However, I have to manually unplug and plug-in the usb dongle so the module reloads. Any way to do this programmatically? Also, where does the device appear? Trying to pass this through to a Home Assistant container, but can't find it! This one was the solution for me. I upgraded from 6.9.x to 6.10.2 and my ruuvi collector stopped working. adding those drivers did the thing I needed. Have to look in to my flash-backup if I used this workaround before and just forgot about it or if it was something that changed with 6.10.x Later (if I'm not to busy) I'll make an example of a ruuvicollector container that works. Edit: so here is my solution to use a usb-bluetooth dongle in docker to read ruuvi tags: https://github.com/abuhamsa/RuuviCollector It is just https://github.com/Scrin/RuuviCollector with an extra start.sh script I also have an unraid-docker template you have to copy it to /boot/config/plugins/dockerMan/templates-user The trick is run it with privileged rights and in host networkmode Edited May 30, 2022 by abuhamsa Quote Link to comment
vcxpz Posted August 6, 2022 Share Posted August 6, 2022 Im trying to get my bluetooth 5 dongle to passthrough to docker in unraid 6.11.0-rc2, it looks like the drivers are trying to download automatically, but are failing to download [ 57.803956] Bluetooth: Core ver 2.22 [ 57.804111] NET: Registered PF_BLUETOOTH protocol family [ 57.804258] Bluetooth: HCI device and connection manager initialized [ 57.804406] Bluetooth: HCI socket layer initialized [ 57.804553] Bluetooth: L2CAP socket layer initialized [ 57.804698] Bluetooth: SCO socket layer initialized [ 58.867186] Bluetooth: hci0: RTL: examining hci_ver=0a hci_rev=000b lmp_ver=0a lmp_subver=8761 [ 58.879191] Bluetooth: hci0: RTL: rom_version status=0 version=1 [ 58.879351] Bluetooth: hci0: RTL: loading rtl_bt/rtl8761bu_fw.bin [ 58.879532] bluetooth hci0: Direct firmware load for rtl_bt/rtl8761bu_fw.bin failed with error -2 [ 58.879689] Bluetooth: hci0: RTL: firmware file rtl_bt/rtl8761bu_fw.bin not found Quote Link to comment
trurl Posted August 6, 2022 Share Posted August 6, 2022 4 hours ago, vcxpz said: looks like the drivers are trying to download automatically It tries to load them, not download them. They fail to load because they aren't installed Quote Link to comment
Jaburges Posted August 8, 2022 Share Posted August 8, 2022 (edited) @L0rdRaidenI've updated the firmware files, and the boot config - so the firmware and config files load. Added the Nerd-pack to get BlueZ and i'm able to run `hciconfig` on the host AND the docker. I'm passing the DBus & the device through /dev/bus/usb/XXX/XXX the error I get now is: Failed to start Bluetooth: [org.freedesktop.DBus.Error.ServiceUnknown] The name org.bluez was not provided by any .service files Edited August 8, 2022 by Jaburges 1 Quote Link to comment
