isaacery

Libvirt Service failed to start

23 posts in this topic Last Reply

Recommended Posts

Hi,

Ive upgraded to 6.6.1 and now I keep getting the following error when trying to enable VMs on the VMs tab.

Libvirt Service failed to start.

Under VM Manager settings, this is the LIBVIRT log that I have:


2018-09-27 23:31:09.873+0000: 10287: info : libvirt version: 4.6.0
2018-09-27 23:31:09.873+0000: 10287: info : hostname: Tower
2018-09-27 23:31:09.873+0000: 10287: error : virGetUserID:1043 : invalid argument: Failed to parse user 'tss'
2018-09-27 23:31:09.873+0000: 10287: error : virGetGroupID:1123 : invalid argument: Failed to parse group 'tss'
2018-09-27 23:31:10.797+0000: 10287: warning : qemuDomainObjTaint:7546 : Domain id=1 name='towerWin10' uuid=b4da61b1-3499-f15d-6f24-82ff68c33a81 is tainted: high-privileges
2018-09-27 23:31:10.797+0000: 10287: warning : qemuDomainObjTaint:7546 : Domain id=1 name='towerWin10' uuid=b4da61b1-3499-f15d-6f24-82ff68c33a81 is tainted: host-cpu
2018-09-28 02:01:07.620+0000: 10266: error : qemuMonitorIO:718 : internal error: End of file from qemu monitor



whats going on?

Share this post


Link to post

Had the same error and it disappeared after a server restart. I also used the default configuration (Flash -> Syslinux configuration -> Default button). Though, the two errors and the warnings in the log are still there. Before 6.6.x had no problems starting VMs.

Share this post


Link to post
47 minutes ago, daemon_of_chaos said:

I am encountering the same issue and my diagnostics are attached.



nasmedia-diagnostics-20180930-0914.zip



Sep 30 09:09:25 nasmedia emhttpd: shcmd (5821): /usr/local/sbin/mount_image '/mnt/cache/system/' /etc/libvirt 1
Sep 30 09:09:25 nasmedia root: /mnt/cache/system/ is not a file
IMAGE_FILE="/mnt/cache/system/"

Go to settings, VM Settings and change the libvirt image to point to the actual libvirt.img file instead of just the folder

Edited by Squid

Share this post


Link to post
31 minutes ago, Squid said:




Sep 30 09:09:25 nasmedia emhttpd: shcmd (5821): /usr/local/sbin/mount_image '/mnt/cache/system/' /etc/libvirt 1
Sep 30 09:09:25 nasmedia root: /mnt/cache/system/ is not a file

IMAGE_FILE="/mnt/cache/system/"

Go to settings, VM Settings and change the libvirt image to point to the actual libvirt.img file instead of just the folder

I do not have that option. My only options are whether to enable and what libvirt image to use via a dropdown. There is no place to specify the location of that image file. Even after I click Download for that image, I cannot find the file within /mnt/cache/



Do I really need this file if I don't plan to run Windows VMs or is the name a misnomer and has nothing to do with Windows?

Edited by daemon_of_chaos

Share this post


Link to post
5 minutes ago, daemon_of_chaos said:

Do I really need this file if I don't plan to run Windows VMs or is the name a misnomer and has nothing to do with Windows?

If you don't plan on running any VM, then just disable the service

6 minutes ago, daemon_of_chaos said:

I do not have that option. My only options are whether to enable and what libvirt image to use via a dropdown. There is no place to specify the location of that image file. Even after I click Download for that image,

You need to stop the service and switch to advanced view.  But, once again if you're not running any VMs then simply disable the service altogether.

Share this post


Link to post

I'm running into this issue now.



Quote

Libvirt Service failed to start.



Quote

Oct 4 20:34:09 SwiftServer emhttpd: shcmd (660): /usr/local/sbin/mount_image '/mnt/user0/system/libvirt/libvirt.img' /etc/libvirt 10

Oct 4 20:34:09 SwiftServer root: truncate: cannot open '/mnt/disk20/system/libvirt/libvirt.img' for writing: No such file or directory

Oct 4 20:34:09 SwiftServer root: mount: /etc/libvirt: failed to setup loop device for /mnt/disk20/system/libvirt/libvirt.img.

Oct 4 20:34:09 SwiftServer root: mount error

Oct 4 20:34:09 SwiftServer emhttpd: shcmd (660): exit status: 1

Oct 4 20:34:09 SwiftServer emhttpd: nothing to sync

Oct 4 20:35:07 SwiftServer ool www[8584]: /usr/local/emhttp/plugins/dynamix/scripts/emhttpd_update

Oct 4 20:35:07 SwiftServer emhttpd: req (2): cmdStatus=apply&csrf_token=****************

Oct 4 20:35:07 SwiftServer emhttpd: Starting services...

Oct 4 20:35:38 SwiftServer ool www[8871]: /usr/local/emhttp/plugins/dynamix/scripts/emhttpd_update

Oct 4 20:35:38 SwiftServer emhttpd: req (3): cmdStatus=apply&csrf_token=****************

Oct 4 20:35:38 SwiftServer emhttpd: Starting services...

Oct 4 20:35:38 SwiftServer emhttpd: shcmd (694): /usr/local/sbin/mount_image '/mnt/user0/system/libvirt/libvirt.img' /etc/libvirt 10

Oct 4 20:35:38 SwiftServer root: truncate: cannot open '/mnt/disk20/system/libvirt/libvirt.img' for writing: No such file or directory

Oct 4 20:35:38 SwiftServer root: mount: /etc/libvirt: failed to setup loop device for /mnt/disk20/system/libvirt/libvirt.img.

Oct 4 20:35:38 SwiftServer root: mount error

Oct 4 20:35:38 SwiftServer emhttpd: shcmd (694): exit status: 1

Obviously getting a Mount Error.  Any Ideas?

Share this post


Link to post
3 hours ago, nexusjosh said:

Any Ideas?



3 hours ago, nexusjosh said:

cannot open '/mnt/disk20/system/libvirt/libvirt.img' for writing: No such file or directory

It might be related to you using user0 for the path, specify the correct location /mnt/cache or /mnt/diskX

Edited by johnnie.black

Share this post


Link to post
Quote

Oct 5 00:07:33 Tower emhttpd: shcmd (1750): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:07:33 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 00:07:33 Tower root: mount error

Oct 5 00:07:33 Tower emhttpd: shcmd (1750): exit status: 1

Oct 5 00:07:33 Tower emhttpd: Starting services...

Oct 5 00:07:33 Tower emhttpd: shcmd (1771): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:07:33 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 00:07:33 Tower root: mount error

Oct 5 00:07:33 Tower emhttpd: shcmd (1771): exit status: 1

Oct 5 00:07:33 Tower emhttpd: nothing to sync

Oct 5 00:07:57 Tower emhttpd: req (8): shareNameOrig=isos&shareName=isos&shareComment=&shareAllocator=highwater&shareFloor=0&shareSplitLevel=&shareInclude=&shareExclude=&shareUseCache=no&confirmDelete=on&cmdEditShare=Delete&csrf_token=****************

Oct 5 00:07:57 Tower emhttpd: shcmd (1773): rmdir '/mnt/user/isos'

Oct 5 00:07:57 Tower emhttpd: shcmd (1774): rm '/boot/config/shares/isos.cfg'

Oct 5 00:07:57 Tower emhttpd: Starting services...

Oct 5 00:07:57 Tower emhttpd: shcmd (1776): chmod 0777 '/mnt/user/domains'

Oct 5 00:07:57 Tower emhttpd: shcmd (1777): chown 'nobody':'users' '/mnt/user/domains'

Oct 5 00:07:57 Tower emhttpd: shcmd (1797): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:07:58 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 00:07:58 Tower root: mount error

Oct 5 00:07:58 Tower emhttpd: shcmd (1797): exit status: 1

Oct 5 00:07:58 Tower emhttpd: Starting services...

Oct 5 00:07:58 Tower emhttpd: shcmd (1818): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:07:58 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error.

Oct 5 00:07:58 Tower root: mount error

Oct 5 00:07:58 Tower emhttpd: shcmd (1818): exit status: 1

Oct 5 00:08:06 Tower emhttpd: req (9): shareNameOrig=isos&shareName=isos&shareComment=&shareAllocator=highwater&shareFloor=0&shareSplitLevel=&shareInclude=&shareExclude=&shareUseCache=no&confirmDelete=on&cmdEditShare=Delete&csrf_token=****************

Oct 5 00:08:06 Tower emhttpd: shcmd (1819): rmdir '/mnt/user/isos'

Oct 5 00:08:06 Tower emhttpd: shcmd (1820): rm '/boot/config/shares/isos.cfg'

Oct 5 00:08:06 Tower emhttpd: Starting services...

Oct 5 00:08:06 Tower emhttpd: shcmd (1841): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:08:06 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 00:08:06 Tower root: mount error

Oct 5 00:08:06 Tower emhttpd: shcmd (1841): exit status: 1

Oct 5 00:08:06 Tower emhttpd: Starting services...

Oct 5 00:08:06 Tower emhttpd: shcmd (1862): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 00:08:06 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error.

Oct 5 00:08:06 Tower root: mount error

Oct 5 00:08:06 Tower emhttpd: shcmd (1862): exit status: 1

Oct 5 00:08:20 Tower ool www[7575]: /usr/local/emhttp/plugins/dynamix/scripts/notify 'cron-init'

Oct 5 03:09:43 Tower ool www[3102]: /usr/local/emhttp/plugins/dynamix/scripts/emhttpd_update

Oct 5 03:09:43 Tower emhttpd: req (10): cmdStatus=apply&csrf_token=****************

Oct 5 03:09:43 Tower emhttpd: Starting services...

Oct 5 03:09:43 Tower emhttpd: shcmd (2227): chmod 0777 '/mnt/user/isos'

Oct 5 03:09:43 Tower emhttpd: shcmd (2228): chown 'nobody':'users' '/mnt/user/isos'

Oct 5 03:10:21 Tower ool www[6564]: /usr/local/emhttp/plugins/dynamix/scripts/emhttpd_update

Oct 5 03:10:21 Tower emhttpd: req (11): cmdStatus=apply&csrf_token=****************

Oct 5 03:10:21 Tower emhttpd: Starting services...

Oct 5 03:10:26 Tower ool www[6564]: /usr/local/emhttp/plugins/dynamix/scripts/emhttpd_update

Oct 5 03:10:26 Tower emhttpd: req (12): cmdStatus=apply&csrf_token=****************

Oct 5 03:10:26 Tower emhttpd: Starting services...

Oct 5 03:10:26 Tower emhttpd: shcmd (2270): /usr/local/sbin/mount_image '/mnt/user/system/libvirt/libvirt.img' /etc/libvirt 1

Oct 5 03:10:26 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 03:10:26 Tower root: mount error

Oct 5 03:10:26 Tower emhttpd: shcmd (2270): exit status: 1

Continuing to troubleshoot.  I reinstalled the OS.  Didn't help.  I think it might just be best to rebuild the Shares?



Quote

Oct 5 03:10:26 Tower root: mount: /etc/libvirt: wrong fs type, bad option, bad superblock on /dev/loop3, missing codepage or helper program, or other error. Oct 5 03:10:26 Tower root: mount error

According to that, something is horribly wrong.

Share this post


Link to post
10 minutes ago, nexusjosh said:

Continuing to troubleshoot.  I reinstalled the OS.  Didn't help.  I think it might just be best to rebuild the Shares?



According to that, something is horribly wrong.

That's a corrupt or invalid libvirt.img, restore form a backup or create a new image.

Share this post


Link to post
Just now, johnnie.black said:

That's a corrupt or invalid libvirt.img, restore form a backup or create a new image.

I've deleted it, and tried to re-create it a dozen times.  I can easily rebuild my VM's.



How I've done it, is Settings -> VM Manager -> Libvirt storage location -> Delete Image File



But doing that has made no difference.

Share this post


Link to post
3 minutes ago, nexusjosh said:

I've deleted it, and tried to re-create it a dozen times.  I can easily rebuild my VM's.



How I've done it, is Settings -> VM Manager -> Libvirt storage location -> Delete Image File



But doing that has made no difference.

Like I suggested earlier try:



2 hours ago, johnnie.black said:

specify the correct location /mnt/cache or /mnt/diskX

If it still doesn't work post your diagnostics: Tools -> Diagnostics

Share this post


Link to post
19 minutes ago, johnnie.black said:

Like I suggested earlier try:



If it still doesn't work post your diagnostics: Tools -> Diagnostics

I doubt that'll work, because I nuked my nuked my shares, in an attempt to just get VM's working, and go from there.






I'm still getting "Libvirt Service failed to start." even after making all custom directories in my VM Directory custom share.  For some reason it doesn't seem to be generating the Libvirt file.  And/or when it is, its corrupted?



I'm currently generating my diagnostics file.  I'll reply/edit this post when its generated, and I've uploaded it to Google Drive.

Share this post


Link to post

The storage location value is wrong.   It needs to include the name of the actual file, not just the folder that contains it.

Share this post


Link to post
3 minutes ago, itimpi said:

The storage location value is wrong.   It needs to include the name of the actual file, not just the folder that contains it.

Aha! It works now.  Thanks!  And thanks everyone, I'm very much new to UnRaid. :P  But so far I love it!  Can't wait until my 10TB Parity Drive comes in.

Edited by nexusjosh

Share this post


Link to post

Hello, I know that this thread is a bit old but I didn't want to create a new one.

I have similar problem, doesn't even try to create a libvirt.img file and the path in Settings->VM-Manager-> is  /mnt/user/system/libvirt/libvirt.img

I cannot see anything in syslog when I enable or disable the VMs

Can anyone help?

Thank you in advance.

I have attached the diagnostics files.

cup-micronas-diagnostics-20190711-1118.zip

Share this post


Link to post
10 minutes ago, ngick said:

Hello, I know that this thread is a bit old but I didn't want to create a new one.

I have similar problem, doesn't even try to create a libvirt.img file and the path in Settings->VM-Manager-> is  /mnt/user/system/libvirt/libvirt.img

I cannot see anything in syslog when I enable or disable the VMs

Can anyone help?

Thank you in advance.

I have attached the diagnostics files.

cup-micronas-diagnostics-20190711-1118.zip 79.06 kB · 0 downloads

Settings -> VM Manger -> Default ISO storage path:



Set a valid path.

Share this post


Link to post

Thank you very much Johnie.black that solved it!!!!

Sorry for the trouble, I didn't see this setting... :(



Thank you again!!!

Share this post


Link to post
