Unraid Docker API


frakman1

8 posts in this topic Last Reply

Recommended Posts

@Squid

Can you please tell me what docker command I could run that returns the values in the table that gets displayed when I click on "Container SIze"?




I want to be able to graph the output of this data over time to see which containers are growing. I've already used the "limit-log-files" extra parameter trick but still see the docker.img file growing over time.



I've tried using "docker system df -v" among others but nothing has displayed a similar table as the "Container Size" one.



Edited by frakman1
Link to post
10 minutes ago, frakman1 said:

@Squid

Can you please tell me what docker command I could run that returns the values in the table that gets displayed when I click on "Container SIze"?




I want to be able to graph the output of this data over time to see which containers are growing. I've already used the "limit-log-files" extra parameter trick but still see the docker file growing over time.



I've tried using "docker system df -v" among others but nothing has displayed a similar table as the "Container Size" one.



You can do this (its a bit slow on my system, be patient)

docker container ls -sa --format 'table {{.Names}}\t{{.Size}}'



If you want the full data you can drop the --format part.  -s means size, -a means all (so that it will show both active and inactive containers)

Link to post

Multiple commands are needed to get the info.  And it's not always 100% reliable due to how docker sometimes works, along with other overhead which is present in the docker.img file



But, you're looking at

 docker ps -sa --format='{{.Names}}|{{.Size}}'

and

docker inspect --format='{{.LogPath}}' NAME_OF_CONTAINER_HERE|xargs du -b 2>/dev/null |cut -f1



Link to post

I found the following ports using netstat but they don't look like the standard port numbers mentioned in the documentation (port 2375) and they are all ipv6.

@Squid Any ideas how to access the REST API remotely?





# netstat -tulpn | grep LISTEN | grep docker
tcp6       0      0 :::6090                 :::*                    LISTEN      20241/docker-proxy
tcp6       0      0 :::8112                 :::*                    LISTEN      19128/docker-proxy
tcp6       0      0 :::8118                 :::*                    LISTEN      19115/docker-proxy
tcp6       0      0 :::58846                :::*                    LISTEN      19102/docker-proxy
tcp6       0      0 :::6080                 :::*                    LISTEN      20255/docker-proxy
tcp6       0      0 :::58946                :::*                    LISTEN      19074/docker-proxy



Link to post

I read that the docker daemon has to be bound to an IP/port socket like this:



/usr/bin/dockerd -H fd:// -H tcp://0.0.0.0:2376



Can someone point me to where the docker config/startup files are?

Edited by frakman1
Link to post

I found a different workaround. Rather than trying to enable the HTTP REST API by changing the dockerd statup option, I decided to use the built-in feature of the docker client to use the ssh protocol to access a remote docker server. This requires that you've already setup public/private key ssh access to your UnRAID server (details here)



Once that is working, I can just run this from my client:



$docker -H ssh://root@tower:22 ps
CONTAINER ID        IMAGE                   COMMAND                  CREATED             STATUS                PORTS           blahh blah



Edited by frakman1
Link to post
