Guns McWar Posted November 11, 2020 Share Posted November 11, 2020 (edited) Hello all, I've been running Unraid on my QNAP TS-853A for about a month now. I intend to use Unraid full-time on this box with this as the primary file server in my home. Before switching to Unraid, I Googled if it was possible to run Unraid on a QNAP and the consensus was: "Probably, just try it." As long as you can access the BIOS and change the boot order, you should be able to boot into Unraid. Some people report not all of their drive bays working depending on which SATA controller was being used (that forum thread is from 2016, so an update may have added compatibility for those controllers). All 8 drive bays are working on my TS-853A. The rest of the hardware is working just fine. The LCD screen on the front of the QNAP constantly says "SYSTEM BOOTING >>>>>>>", but I can overlook that. One day I may try to see if I can modify that. I just want to document that it's possible -- and easy -- to run Unraid on a QNAP. My only experience with QNAP boxes is with my own, so your mileage may vary. This is my first Unraid installation, but everything was incredibly straight-forward. I had no complications getting things set up. As others have stated in the past, these NAS boxes come with 500 MB-ish of DOM flash storage. I didn't try to install Unraid on the DOM because I didn't know if it had a UID. It would be nice to use, but I don't see 500 MB being suitable in the long term. I actually removed the DOM because my BIOS would ignore my boot order and prioritize the DOM over my Unraid flash drive. I'll report back if I ever get around to booting Unraid from the DOM. The Celeron N3160 and 8 GB of DDR3 prevent me from going wild with dockers and VMs, but I had that expectation going in; my primary purpose for this box is a file server for my business. But it's running a Minecraft server for my nephews, Bitwarden, and a few other services that I use for work/play. I let my 2015 Nvidia Shield act as my Plex server pulling content from my Unraid SMB shares. Plus, boot times went from 10+ minutes to just a couple. Unraid has breathed new life into my QNAP. This was a hand-me-down of sorts, but I've always been a Synology guy. This QNAP was a clear upgrade from the hardware of the Synology, but the QNAP software experience was subjectively much worse. So far, it's been more than suitable for full-time use. If anyone else uses a QNAP for Unraid, I've attached the case model design I've made. ts-853a.svg Edited December 16, 2020 by Guns McWar 5 Quote Link to comment
