Joshewing02 Posted March 16, 2022 Share Posted March 16, 2022 After upgrading to 6.10.0-rc3o and following the steps here to get Windows 11 installed. Install went fine and then started some of the windows updates. After 'Restarting" I noticed the VM never booted back up. Went into UNRAID VM tab and noticed it was "Stopped". Tried starting it and per normal my first CPU "18" goes to 100% for 30 sec or so then the VM would boot appropriately. This time and every time since it seems to stall out and shut itself down. Any support would be appreciated. 2022-03-16T15:39:08.489047Z qemu-system-x86_64: terminating on signal 15 from pid 8967 (/usr/sbin/libvirtd) 2022-03-16 15:39:15.937+0000: shutting down, reason=shutdown Attached diagnostics to support the help. PC is in the middle of a Parity Check but don't see how that should impact it. VM XML below <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm'> <name>Jebidiah VM</name> <uuid>edb8a06b-058c-7379-804e-870fb99fe2fe</uuid> <description>Josh Desktop</description> <metadata> <vmtemplate xmlns="unraid" name="Windows 10" icon="windows.png" os="windows10"/> </metadata> <memory unit='KiB'>131072000</memory> <currentMemory unit='KiB'>131072000</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>36</vcpu> <cputune> <vcpupin vcpu='0' cpuset='18'/> <vcpupin vcpu='1' cpuset='54'/> <vcpupin vcpu='2' cpuset='19'/> <vcpupin vcpu='3' cpuset='55'/> <vcpupin vcpu='4' cpuset='20'/> <vcpupin vcpu='5' cpuset='56'/> <vcpupin vcpu='6' cpuset='21'/> <vcpupin vcpu='7' cpuset='57'/> <vcpupin vcpu='8' cpuset='22'/> <vcpupin vcpu='9' cpuset='58'/> <vcpupin vcpu='10' cpuset='23'/> <vcpupin vcpu='11' cpuset='59'/> <vcpupin vcpu='12' cpuset='24'/> <vcpupin vcpu='13' cpuset='60'/> <vcpupin vcpu='14' cpuset='25'/> <vcpupin vcpu='15' cpuset='61'/> <vcpupin vcpu='16' cpuset='26'/> <vcpupin vcpu='17' cpuset='62'/> <vcpupin vcpu='18' cpuset='27'/> <vcpupin vcpu='19' cpuset='63'/> <vcpupin vcpu='20' cpuset='28'/> <vcpupin vcpu='21' cpuset='64'/> <vcpupin vcpu='22' cpuset='29'/> <vcpupin vcpu='23' cpuset='65'/> <vcpupin vcpu='24' cpuset='30'/> <vcpupin vcpu='25' cpuset='66'/> <vcpupin vcpu='26' cpuset='31'/> <vcpupin vcpu='27' cpuset='67'/> <vcpupin vcpu='28' cpuset='32'/> <vcpupin vcpu='29' cpuset='68'/> <vcpupin vcpu='30' cpuset='33'/> <vcpupin vcpu='31' cpuset='69'/> <vcpupin vcpu='32' cpuset='34'/> <vcpupin vcpu='33' cpuset='70'/> <vcpupin vcpu='34' cpuset='35'/> <vcpupin vcpu='35' cpuset='71'/> </cputune> <os> <type arch='x86_64' machine='pc-i440fx-6.2'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi-tpm.fd</loader> <nvram>/etc/libvirt/qemu/nvram/edb8a06b-058c-7379-804e-870fb99fe2fe_VARS-pure-efi-tpm.fd</nvram> </os> <features> <acpi/> <apic/> <hyperv> <relaxed state='on'/> <vapic state='on'/> <spinlocks state='on' retries='8191'/> <vendor_id state='on' value='none'/> </hyperv> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' cores='18' threads='2'/> <cache mode='passthrough'/> </cpu> <clock offset='localtime'> <timer name='hypervclock' present='yes'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/VM Storage/Jebidiah VM/spaces_win_clover.img'/> <target dev='hdc' bus='sata'/> <boot order='1'/> <address type='drive' controller='0' bus='0' target='0' unit='2'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/VM Storage/Jebidiah VM/vdisk2.img'/> <target dev='hdd' bus='virtio'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/Windows10.8.26.2020.iso'/> <target dev='hda' bus='ide'/> <readonly/> <boot order='2'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/virtio-win-0.1.215-2.iso'/> <target dev='hdb' bus='ide'/> <readonly/> <address type='drive' controller='0' bus='0' target='0' unit='1'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='ide' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='0' model='pci-root'/> <controller type='sata' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:85:16:90'/> <source bridge='br0'/> <model type='virtio'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </interface> <serial type='pty'> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <tpm model='tpm-tis'> <backend type='emulator' version='2.0' persistent_state='yes'/> </tpm> <audio id='1' type='none'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xd8' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0' multifunction='on'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xd8' slot='0x00' function='0x1'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x1'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x8a' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x09' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xb1' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x0a' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xb4' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x0b' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xb5' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x0c' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xb6' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x0d' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xd8' slot='0x00' function='0x2'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x2'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0xd8' slot='0x00' function='0x3'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x3'/> </hostdev> <memballoon model='none'/> </devices> </domain> ewing-diagnostics-20220316-0856.zip Quote Link to comment
Joshewing02 Posted March 18, 2022 Author Share Posted March 18, 2022 Just messed with a few items and got it to boot. Changed Graphics Card to VNC Changed Sound Card to None Now it boots and I can at least use RDT to connect off another PC. Curious if I need to change or install something to get my GPU to pass through again. Unsure why it booted once. It did take like 3 tries and one Force Shutdown to get it to boot. Quote Link to comment
