Thanks! So running an user scripts seems to be the way to go 👍 Your script looks very cool! I tried the wireguard-tools/reresolve-dns.sh first, though. I cloned it to /mnt/user/system/wireguard-tools/reresolve-dns.sh and added an user script with this content (the script is running every 5 minutes): #!/bin/bash /mnt/user/system/wireguard-tools/reresolve-dns.sh /etc/wireguard/wg0.conf /mnt/user/system/wireguard-tools/reresolve-dns.sh /etc/wireguard/wg1.confWorks like a charm. Even when I restarted the router at location B the tunnel was reestablished and Krusader copy processes continue without user intervention.

Issue unRAID Server at location A is connected (as client) to a Wireguard server at location B Location B has no static IP address. DynDNS is set up to update when IP address changes. Connection times out (Settings >> VPN Manager >> "Last handshake: x hours ago"). Timeout seems to happen every night in the timeframe for receiving a new IP address set in the router at location B. Reason/ Diagnosis If my understanding of this ArchWiki documentation for Wireguard is correct, this behavior is expected because Wireguard will not re-resolve the dns for the endpoint (regardless of persistent-keepalive settings). There is a wireguard-tools/reresolve-dns which solves this issue by resetting the endpoint to the updated ip. Possible solution Since I did not find wireguard-tools on the unRAID host, I would simply copy the script somewhere and then schedule a cron job using the user scripts plugin to run /<path_to_script>/reresolve-dns.sh /etc/wireguard/wg<tunnel_no>.conf I've found the wiki entry just now so I hadn't any chance to tried it yet (reconnecting the internet at location B will give me a new IP but I'm not sure if this would be an appropriate simulation of what is happening when my ISP changes the IP). Questions Has anyone else experienced this issue and found a better/ alternative solution? Is my diagnosis correct? Would running the script via user scripts work? Are there any best practices on how to solve this issue?

Support thread for all my Docker Templates for CA. Please check issues and discussion on GitHub as well. This thread is reserved for issues with the Unraid Docker templates. For issues with an applications itself, please redirect your concern to the app's own support channels.

My Synology NAS is almost at its capacity and I do not want to buy any of their products anymore. Same goes for QNAP. The UniFi UNAS Pro has no option for SSD caching. Since I always wanted a home lab server anyway I thought what the heck - let's try it. This will be my first build, so I do not have any spare parts laying around. Requirements:Run Unraid - obviously. I want to start with at least 30TB storage and be able to extend this later. SSD caching storage. I want to run Home Assistant (probably running HA OS as a VM and not in a Docker container), Voice Assistant for Home Assistant locally (so Text-to-Speech model like Piper, a Speech-to-Text model like Whisper and a LLM for the conversation pipeline). At this point, I’m not sure whether this can be accomplished using only Docker containers or if a full Linux VM is required. 1x Windows 11 Desktop VM and Linux VM (probably not running at the same time), Docker containers for nginx, a web server and a git server, Time Machine Backups on multiple devices. Transcode video so I can stream from the NAS in the network (like once a month - so it would be ok if it takes a while). Run Stable Diffusion triggered by Home Assistant (at the moment I'm using the OpenAI integration). For the AI stuff I will need to add a graphics card sooner or later. I'd rather build it now without a GPU (mainly as a NAS) and add a powerful graphics card later than get a lower gpu now. So expandability for a graphics card is important. Mounted in server rack. General QuestionsAre there any flaws in how I’ve translated my requirements into specific search criteria? Do the selected components — especially the motherboard, CPU, and GPU — make sense for my intended use case? Are they potentially overkill or not powerful enough? Are there better or more cost-effective alternatives I should be considering? Am I overlooking anything important, such as compatibility issues or missing features? Right now, I’m unsure whether it’s better to build a dedicated NAS and handle everything else — LLMs, Home Assistant, AI tasks, VMs — on a separate machine, or try to consolidate everything into a single build. Any thoughts? This is what I came up with based on my requirements:MainboardSupermicro X13SAE-F (530 €) Search criteria ECC support 8+ SATA Ports Intel CPU compatible (I feel like there is less need of tinkering with Intel instead of AMD - maybe this is just imagination) Questions The manual only mentions VT-d support. Is VT-x support from the board needed as well? CPUIntel Core i5-14600K (210 €) Search criteria ECC Support VT-x and VT-d Support Derived from chosen Mainboard: Socket 1700 TDP up to 150 W DDR 5 PCIe 5 Questions I could save 40 € (80 €) buying a new or (used) Core i5-12600K. Should I? MemoryAlternative 1 (used): Crucial 32GB DDR5-4800 UDIMM CT32G48C40U5 CL40 1.1V Desktop RAM (2x 70 €) Alternative 2 (new): Mushkin Redline PRO DIMM 32GB, DDR5-4800, CL40-39-39, ECC (2x 125 €) Search criteria ECC support Derived from chosen Mainboard: DDR 5 Unbuffered Memory 32 GB (so I can max out the boards memory in the future) Questions How important is name brand RAM? Should I go for the used ones? Should I use an even number of memory sticks like it is recommended in the boards manual (the board also supports using just 1 memory stick)? Cach DrivesGIGABYTE AORUS Gen4 7300 SSD 2TB (2x 130 €) Search criteria: M.2 2 TB 2 GB DRAM-Cache Derived from chosen Mainboard: PCIe 4.0 x4 M.2 2280 Questions: Is 1 GB DRAM per TB size a good rule of thumb? Is the kind of DRAM important? Are the speeds (7.300 MB/s read and 6.850 MB/s write) enough/ good? Is TBW of 1.4PB (700TB per TB) enough/ good? One M.2 Slot directly connects to the CPU, the other 2 connect to the chipset. Does it matter which slots I use? Should I use the two connecting to the chipset? Parity Array??? Search criteria: Seagate or WD (TrueNAS 'FreeNAS Quick Hardware Guide R2a' recommends those) NAS-Drives SATA 6GB/s 3.5'' >16 TB Questions: Should I go with one big (like Seagate Exos 24TB) parity drive and then maybe 2x Seagate Exos X X16 16TB (32 TB would be enough for starters)? This would be 810 € Or any other configuration? Graphics Cardsome NVIDIA RTX 3090 (I'm trying to get one used for 500-600 € some day in the near future) Search criteria: NVIDIA (because tools for Stable Diffusion and LLM stuff are most of the times optimized for NVIDIA CPUs) 24GB+ VRAM Questions: Will I be even able to use this in Unraid and pass it to VMs? Is this enough for the use case? Power SupplyCooler Master MWE Gold V2 (150 €) Search criteria (derived from Mainboard and CPU): 80 PLUS gold or higher ATX 2.02 or higher 20/24 PIN 8-Pin EPS12V 1.000W or more SATA 8x or more 3x 6/8 PIN PCIe 1 12 PIN PCIe Questions: Most PSU calculators don't ask for the number of SATA devices, so I guessed the 1.000W. Is this enough/ too much? Will I be able to connect any RTX 3090 to these connectors? CaseFantec SG-4700 Search criteria: Server rack case Has to fit the fan ATX 8+ 3.5'' slots 1+ full height PCI slot(s) Questions: Should I install extra fans on the back? CPU-Coolerbe quiet! Dark Rock Slim (55 €) Search criteria derived from Mainboard and CPU: Socket 1700 TDP 125-180W 4-PIN PWN Questions: Is this overkill and a cooler for TDP 125W is enough? A cooler like the TOUGHAIR 110 CPU Cooler has a lower profile (45mm less height). Does this even make any sense in a server rack case? Will any of those fit when the RTX 3090 is plugged into the PCIe x16 slot (which is the one nearest to the CPU)? Closing remarksI know this is a lot, and I’ve tried to structure this post as clearly as possible while keeping my thought process concise. I hope some of you will still take the time to read it and help answer my questions. I don’t have a strict budget — mainly because I believe budgets are often used to justify a purchase rather than guide it. That said, the current build sits at around €2,900, which is a significant amount. I’d be comfortable going +/- €300 from that. As mentioned earlier, I’m planning to start with just the Unraid NAS setup and add a GPU later.
