dr4g0n

I really didnt look into the DHCP, I just set it manually. Meh, it works now. If i run into a problem with another device I'll check the router.

GUYS I SOLVED IT. It was the friggen MTU. Some guy at my work suggested checking that. Sure enough. The default of 1500.. Is too big for my PPPoE stupid Century Link internet. 1492. Yup PPPoE Will Not accept anything over that. EVERYTHINGS WORKING Thanks for trying guys And here, have some cookies! *hands out cookies*

I only have it /16 because I'm too lazy to make it a /24 and make Actual subnets, so yeah. But when I'm home ill check out broadcast stuff.

That's all I have right now. I pulled the two other Nics out to figure out what was up.

root@Horde:~# ip addr 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 inet 127.0.0.1/32 scope host lo valid_lft forever preferred_lft forever inet 127.0.0.1/8 scope host lo valid_lft forever preferred_lft forever 2: tunl0@NONE: <NOARP> mtu 1480 qdisc noop state DOWN group default qlen 1 link/ipip 0.0.0.0 brd 0.0.0.0 3: gre0@NONE: <NOARP> mtu 1476 qdisc noop state DOWN group default qlen 1 link/gre 0.0.0.0 brd 0.0.0.0 4: gretap0@NONE: <BROADCAST,MULTICAST> mtu 1462 qdisc noop state DOWN group default qlen 1000 link/ether 00:00:00:00:00:00 brd ff:ff:ff:ff:ff:ff 5: ip_vti0@NONE: <NOARP> mtu 1364 qdisc noop state DOWN group default qlen 1 link/ipip 0.0.0.0 brd 0.0.0.0 6: eth0: <BROADCAST,MULTICAST,PROMISC,UP,LOWER_UP> mtu 1500 qdisc pfifo_fast master br0 state UP group default qlen 1000 link/ether d0:50:99:ac:5e:6e brd ff:ff:ff:ff:ff:ff 58: br0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default qlen 1000 link/ether d0:50:99:ac:5e:6e brd ff:ff:ff:ff:ff:ff inet 10.10.1.3/16 brd 10.10.255.255 scope global br0 valid_lft forever preferred_lft forever root@Horde:~# ip route default via 10.10.0.1 dev br0 metric 258 10.10.0.0/16 dev br0 proto kernel scope link src 10.10.1.3 metric 258 127.0.0.0/8 dev lo scope link root@Horde:~# Well the thing is that this is how Ive had my network set up for over a year, and its worked for every device so far. I also had the server running fine with three NICs and two IPs, one through the br0 with two NICs and the other as sort of a management port via the mobo NIC. it was only after I switched motherboards that I started having this problem. Im using a NETGEAR ProSafe 8 Port VPN Firewall FVS318Gv2 as a router.

Guess so. Bypassed my router and plugged directly into my modem. connects fine..

Alright so. I just removed the add in card. I assume my problem is because both the mobo and card are realtek chips. I have an Intel card in the mail. But, now with only one interface.. I can pick up the DHCP address fine, and the local network works great. I can access samba and the webgui fine. But. Im getting 100% dropped packets when trying to connect outside my LAN. So.. yeah, not fun.

Oh yeah, thats on a different page. But even with no reserved address, the bond wont pick up an ip from the 10.10.3.100-254 range. Ill go ahead and try removing the bridge and bond, see if that works.

I have a Rasberry Pi running Pi-Hole as an ad blocking DNS server, that's what 10.10.1.222 is. It forwards valid DNS to OpenDNS's servers. I have the router (10.10.0.1) as the other just in case the Pi doesn't pick up a local device .local name.

Yeah, it's on purpose. I have quasi-subnets, I guess. just using the 3rd octate to designate what the clients are, ie. server, user, guest, etc. Sure. Zip is attached, heres the DHCP: http://puu.sh/s5nSu.png Well, the card worked fine with the other motherboard, same config. and all the other devices I have currently have no problem with it. horde-diagnostics-20161102-2036.zip

Hello, unRAID peoples. I just switched my motherboard out for one with a couple more PCIe slots, for some VM fun, but after reinstalling everything and booting up, my add-in, two-port NIC wont grab an DHCP address, it just pulls an APIPA. I (foolishly) deleted the network.cfg, rebooted, and tried to configure my dual-nic as the bond (eth0 and eth1), wich does the APIPA thing, and the onboard NIC (eth2) as a "management port" (DHCP reserved IP assians correctly) ...which worked.. and works through reboots. Heres the current ifconfig: Pastebin cause character limit; http://pastebin.com/uPeHb6wH and heres the network.cfg (I could Not find anything online/here that tells me how to use this to fix the problem..) root@Horde:~# cat /boot/config/network.cfg # Generated settings: IFNAME[0]="br0" BONDNAME[0]="bond0" BONDNICS[0]="eth0 eth1" BONDING_MODE[0]="1" BONDING_MIIMON[0]="100" DHCP_KEEPRESOLV="no" BRNAME[0]="br0" BRNICS[0]="bond0" BRSTP[0]="no" BRFD[0]="0" DESCRIPTION[0]="" USE_DHCP[0]="yes" NETMASK[0]="255.255.0.0" GATEWAY="10.10.0.1" MTU[0]="" IFNAME[1]="eth2" DESCRIPTION[1]="" USE_DHCP[1]="yes" MTU[1]="" SYSNICS="2" My network is thus: Router: 10.10.0.1 Netmask: 255.255.0.0 DNS: 10.10.1.222, 10.10.0.1 Desired IP for the bond: 10.10.1.1 Current IP for the onboard NIC: 10.10.1.2 Servers are in the (sudoish) subnet of 10.10.1.0 Infrastructure (Router, APs) are 10.10.0.0 Clients (my PC, phone, etc; all DHPC reserved) are 10.10.2.0 DHPC guests are 10.10.3.0 Ive got the diag zip if someone needs it, let me know. Hope I can get some help. PS: after the upgrade, everything else works; array, docker, VMs..
