rottenpotatoes

I have put in a bug report as recommended. The person helping me there is requesting: Could you get a backtrace of qemu crashing - this might be easiest if your distro records core dumps somewhere. I dont know how to do this. Can someone help me figure out 1)what this is and 2) how to do it so i can get this info to the bug report? also fyi for anyone interested, my bug report and conversation: https://bugs.launchpad.net/qemu/+bug/1821054

here is a copy of the syslog. The repeated lines delineate the lines written during the latest trial. Mar 20 12:17:19 unraid kernel: vfio-pci 0000:05:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 20 12:22:55 unraid kernel: vfio-pci 0000:05:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 20 12:22:55 unraid kernel: vfio-pci 0000:05:05.0: Refused to change power state, currently in D0 Mar 20 12:22:55 unraid kernel: vfio-pci 0000:05:05.1: Refused to change power state, currently in D0 Mar 20 12:22:55 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 20 12:22:55 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 20 12:22:55 unraid kernel: device vnet0 entered promiscuous mode Mar 20 12:22:55 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 20 12:22:55 unraid kernel: br0: port 2(vnet0) entered forwarding state Mar 20 12:22:57 unraid avahi-daemon[8902]: Joining mDNS multicast group on interface vnet0.IPv6 with address fe80::fc54:ff:fee9:40aa. Mar 20 12:22:57 unraid avahi-daemon[8902]: New relevant interface vnet0.IPv6 for mDNS. Mar 20 12:22:57 unraid avahi-daemon[8902]: Registering new address record for fe80::fc54:ff:fee9:40aa on vnet0.*. Mar 20 12:22:58 unraid kernel: qemu-system-x86[14591]: segfault at a8 ip 0000561f5568437a sp 00007fff097b28e0 error 4 in qemu-system-x86_64[561f5536d000+af2000] Mar 20 12:22:58 unraid kernel: Code: f9 ff 0f 1f 40 00 66 2e 0f 1f 84 00 00 00 00 00 55 53 48 89 fb 48 83 ec 08 48 8b 6f 58 e8 3e df ff ff 48 89 df e8 e6 e9 ff ff <48> 8b 85 a8 00 00 00 48 85 c0 74 2e 8b 93 a0 00 00 00 39 90 a0 00 Mar 20 12:22:58 unraid avahi-daemon[8902]: Interface vnet0.IPv6 no longer relevant for mDNS. Mar 20 12:22:58 unraid avahi-daemon[8902]: Leaving mDNS multicast group on interface vnet0.IPv6 with address fe80::fc54:ff:fee9:40aa. Mar 20 12:22:58 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 20 12:22:58 unraid kernel: device vnet0 left promiscuous mode Mar 20 12:22:58 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 20 12:22:58 unraid avahi-daemon[8902]: Withdrawing address record for fe80::fc54:ff:fee9:40aa on vnet0. Mar 20 12:22:59 unraid kernel: vfio-pci 0000:05:05.1: Refused to change power state, currently in D0 Mar 20 12:22:59 unraid kernel: vfio-pci 0000:05:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none

In reply to your second message, this is the error i get when i try to attach the pci bridge you specify.

in reply to your first message, the below is the only message i get.

I am trying to setup a XP vm with hardware passthrough of an old radeon 9250 and creative labs sound blaster card. I have the cards hooked to my unraid server via a pcie to dual pci adapter (example can be found here: https://www.aliexpress.com/item/Desktop-PCI-Express-PCI-e-to-PCI-Adapter-Card-PCIe-to-Dual-Pci-Slot-Expansion-Card/32849431927.html ). My IOMMU groups show the adapter, sound card and what i believe to be the two outputs of the graphics card all in the same group. I think this is fine as all the devices are to be passed to my vm. IOMMU group 15:[12d8:e111] 01:00.0 PCI bridge: Pericom Semiconductor PI7C9X111SL PCIe-to-PCI Reversible Bridge (rev 02) [1274:5880] 02:04.0 Multimedia audio controller: Ensoniq 5880B / Creative Labs CT5880 (rev 02) [1002:5960] 02:05.0 VGA compatible controller: Advanced Micro Devices, Inc. [AMD/ATI] RV280 [Radeon 9200 PRO] (rev 01) [1002:5940] 02:05.1 Display controller: Advanced Micro Devices, Inc. [AMD/ATI] RV280 [Radeon 9200 PRO] (Secondary) (rev 01) however when i try to start the vm im greeted with a popup and the message in the title: "internal error: qemu unexpectedly closed the monitor" the syslog isnt much help either. I tried to start several times in succession so that the errors would be evident in the logs: Mar 7 20:57:52 unraid kernel: vfio-pci 0000:02:05.0: Refused to change power state, currently in D0 Mar 7 20:57:52 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 20:57:52 unraid kernel: device vnet0 entered promiscuous mode Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered forwarding state Mar 7 20:57:52 unraid kernel: qemu-system-x86[11275]: segfault at a8 ip 000055f57ce3237a sp 00007ffea39fb520 error 4 in qemu-system-x86_64[55f57cb1b000+af2000] Mar 7 20:57:52 unraid kernel: Code: f9 ff 0f 1f 40 00 66 2e 0f 1f 84 00 00 00 00 00 55 53 48 89 fb 48 83 ec 08 48 8b 6f 58 e8 3e df ff ff 48 89 df e8 e6 e9 ff ff <48> 8b 85 a8 00 00 00 48 85 c0 74 2e 8b 93 a0 00 00 00 39 90 a0 00 Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 20:57:52 unraid kernel: device vnet0 left promiscuous mode Mar 7 20:57:52 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 20:57:53 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 20:57:53 unraid kernel: vfio-pci 0000:02:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 7 21:08:20 unraid kernel: vfio-pci 0000:02:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 7 21:08:20 unraid kernel: vfio-pci 0000:02:05.0: Refused to change power state, currently in D0 Mar 7 21:08:20 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 21:08:20 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 21:08:20 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:08:20 unraid kernel: device vnet0 entered promiscuous mode Mar 7 21:08:20 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 21:08:20 unraid kernel: br0: port 2(vnet0) entered forwarding state Mar 7 21:08:21 unraid kernel: qemu-system-x86[7453]: segfault at a8 ip 00005590982c637a sp 00007fff8132e7b0 error 4 in qemu-system-x86_64[559097faf000+af2000] Mar 7 21:08:21 unraid kernel: Code: f9 ff 0f 1f 40 00 66 2e 0f 1f 84 00 00 00 00 00 55 53 48 89 fb 48 83 ec 08 48 8b 6f 58 e8 3e df ff ff 48 89 df e8 e6 e9 ff ff <48> 8b 85 a8 00 00 00 48 85 c0 74 2e 8b 93 a0 00 00 00 39 90 a0 00 Mar 7 21:08:21 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:08:21 unraid kernel: device vnet0 left promiscuous mode Mar 7 21:08:21 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:08:22 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 21:08:22 unraid kernel: vfio-pci 0000:02:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 7 21:15:46 unraid kernel: vfio-pci 0000:02:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none Mar 7 21:15:46 unraid kernel: vfio-pci 0000:02:05.0: Refused to change power state, currently in D0 Mar 7 21:15:46 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:15:46 unraid kernel: device vnet0 entered promiscuous mode Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered blocking state Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered forwarding state Mar 7 21:15:46 unraid kernel: qemu-system-x86[27299]: segfault at a8 ip 000055982823137a sp 00007ffd38193ae0 error 4 in qemu-system-x86_64[559827f1a000+af2000] Mar 7 21:15:46 unraid kernel: Code: f9 ff 0f 1f 40 00 66 2e 0f 1f 84 00 00 00 00 00 55 53 48 89 fb 48 83 ec 08 48 8b 6f 58 e8 3e df ff ff 48 89 df e8 e6 e9 ff ff <48> 8b 85 a8 00 00 00 48 85 c0 74 2e 8b 93 a0 00 00 00 39 90 a0 00 Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:15:46 unraid kernel: device vnet0 left promiscuous mode Mar 7 21:15:46 unraid kernel: br0: port 2(vnet0) entered disabled state Mar 7 21:15:47 unraid kernel: vfio-pci 0000:02:05.1: Refused to change power state, currently in D0 Mar 7 21:15:47 unraid kernel: vfio-pci 0000:02:05.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none vm xml below: <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm'> <name>Windows XP</name> <uuid>91230a79-b145-678a-dc42-52195269234d</uuid> <description>XP</description> <metadata> <vmtemplate xmlns="unraid" name="Windows XP" icon="windowsxp.png" os="windowsxp"/> </metadata> <memory unit='KiB'>3145728</memory> <currentMemory unit='KiB'>3145728</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='1'/> <vcpupin vcpu='1' cpuset='5'/> </cputune> <os> <type arch='x86_64' machine='pc-i440fx-3.0'>hvm</type> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='1' threads='2'/> </cpu> <clock offset='localtime'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/en_windows_xp_professional_with_service_pack_3_x86_cd_x14-80428.iso'/> <target dev='hda' bus='ide'/> <readonly/> <boot order='2'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/domains/Windows XP/vdisk1.img'/> <target dev='hdc' bus='ide'/> <boot order='1'/> <address type='drive' controller='0' bus='1' target='0' unit='0'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='pci' index='0' model='pci-root'/> <controller type='ide' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:e9:40:aa'/> <source bridge='br0'/> <model type='rtl8139'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </interface> <serial type='pty'> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <hostdev mode='subsystem' type='pci' managed='yes' xvga='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x05' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x05' function='0x1'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x04' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x0461'/> <product id='0x4d17'/> </source> <address type='usb' bus='0' port='2'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x062a'/> <product id='0x0201'/> </source> <address type='usb' bus='0' port='3'/> </hostdev> <memballoon model='none'/> </devices> </domain> Also in case its needed, here's my syslinux config: default menu.c32 menu title Lime Technology, Inc. prompt 0 timeout 50 label unRAID OS menu default kernel /bzimage append pcie_acs_override=downstream,multifunction initrd=/bzroot vfio_iommu_type1.allow_unsafe_interrupts=1 label unRAID OS GUI Mode kernel /bzimage append pcie_acs_override=downstream,multifunction vfio_iommu_type1.allow_unsafe_interrupts=1 initrd=/bzroot,/bzroot-gui label unRAID OS Safe Mode (no plugins, no GUI) kernel /bzimage append pcie_acs_override=downstream initrd=/bzroot unraidsafemode label unRAID OS GUI Safe Mode (no plugins) kernel /bzimage append pcie_acs_override=downstream initrd=/bzroot,/bzroot-gui unraidsafemode label Memtest86+ kernel /memtest Any ideas on how to get this to boot?
