December 18, 201213 yr Hi Guys, I'm having serious problems with my unRaid server. I had a drive come up red, and somehow did something to screw it up pretty badly. Now all the drives are green but I'm getting errors when I start the array. On boot I'm seeing messages like: sas: Enter sas_scsi_recover_host busy: 0 failed: 0 sdb: sdb1 sas: ata5: end_device-0:0: dev error handler sas: ata6: end_device-0:1: dev error handler sas: ata7: end_device-0:2: dev error handler ata7.00: ATA-8: WDC WD20EARS-00MVWB0, 51.0AB51, max UDMA/133 ata7.00: 3907029168 sectors, multi 0: LBA48 NCQ (depth 31/32) ata7.00: configured for UDMA/133 sas: --- Exit sas_scsi_recover_host: busy: 0 failed: 0 sd 0:0:0:0: [sdb] Attached SCSI disk scsi 0:0:2:0: Direct-Access ATA WDC WD20EARS-00M 51.0 PQ: 0 ANSI: 5 sd 0:0:2:0: Attached scsi generic sg3 type 0 sd 0:0:2:0: [sdd] 3907029168 512-byte logical blocks: (2.00 TB/1.81 TiB) sd 0:0:2:0: [sdd] Write Protect is off sd 0:0:2:0: [sdd] Mode Sense: 00 3a 00 00 sd 0:0:2:0: [sdd] Write cache: enabled, read cache: enabled, doesn't support DPO or FUA sdc: sdc1 sas: Enter sas_scsi_recover_host busy: 0 failed: 0 sdd: sdd1 sas: ata5: end_device-0:0: dev error handler sas: ata6: end_device-0:1: dev error handler sas: ata7: end_device-0:2: dev error handler sas: ata8: end_device-0:3: dev error handler ata8.00: ATA-8: WDC WD20EARS-00MVWB0, 51.0AB51, max UDMA/133 ata8.00: 3907029168 sectors, multi 0: LBA48 NCQ (depth 31/32) ata8.00: configured for UDMA/133 sas: --- Exit sas_scsi_recover_host: busy: 0 failed: 0 When I start the array I'm seeing things like: REISERFS warning: reiserfs-5090 is_tree_node: node level 14796 does not match to the expected one 3 REISERFS error (device md4): vs-5150 search_by_key: invalid format found in block 449079810. Fsck? REISERFS (device md4): Remounting filesystem read-only In terms of hardware replacements, I've tried replacing just about everything from the SAS cables, backplane, SAS controller, etc. I followed the instructions on the http://lime-technology.com/wiki/index.php?title=Check_Disk_Filesystems wiki and each drive (I didn't check the parity as instructed) seems to give me the same --rebuild-sb problem. root@Tower2:~# reiserfsck --check /dev/sdg reiserfsck 3.6.21 (2009 www.namesys.com) ************************************************************* ** If you are using the latest reiserfsprogs and it fails ** ** please email bug reports to [email protected], ** ** providing as much information as possible -- your ** ** hardware, kernel, patches, settings, all reiserfsck ** ** messages (including version), the reiserfsck logfile, ** ** check the syslog file for any related information. ** ** If you would like advice on using this program, support ** ** is available for $25 at www.namesys.com/support.html. ** ************************************************************* Will read-only check consistency of the filesystem on /dev/sdg Will put log info to 'stdout' Do you want to run this program?[N/Yes] (note need to type Yes if you do):Yes reiserfs_open: the reiserfs superblock cannot be found on /dev/sdg. Failed to open the filesystem. If the partition table has not been changed, and the partition is valid and it really contains a reiserfs partition, then the superblock is corrupted and you need to run this utility with --rebuild-sb. Do I need to run rebuild SB? If so what options should I use? I'm running the latest unraid 5.0-rc8a. The hardware is from a "recommended" build: ASRock 880GM-LE AM3 AMD 880G Micro ATX AMD Motherboard AMD Athlon II X2 250 Regor 3.0GHz Socket AM3 65W Dual-Core Desktop Processor ADX250OCGMBOX Antec Nine Hundred Two V3 Black Steel ATX Mid Tower Gaming Case CORSAIR Enthusiast Series TX650 V2 650W ATX12V v2.31/ EPS12V v2.92 80 PLUS BRONZE Certified Active PFC High Performance Power Supply Kingston ValueRAM 2GB 240-Pin DDR3 SDRAM DDR3 1333 (PC3 10600) Desktop Memory Model KVR1333D3N9/2G SUPERMICRO AOC-SASLP-MV8 PCI-Express x4 Low Profile SAS RAID Controller CORSAIR Enthusiast Series TX650 V2 650W ATX12V v2.31/ EPS12V v2.92 80 PLUS BRONZE Certified Active PFC High Performance Power Supply Here is the dmesg: http://pastebin.com/TB6bA9r8
December 18, 201213 yr DO NOT RUN reiserfsck on the /dev/sdg device. The raw device DOES NOT HAVE THE FILE SYSTEM, IT IS ON THE FIRST PARTITION. (/dev/sdg1 ... note the trailing 1 in the name to denote the first partition ) You will cause massive corruption if you attempt to run it on the raw device and force it to use that as the start of the file-system superblock. Furthermore, you should access and fix the file-system, if at all possible through the affiliated /dev/mdX device. If you do not, parity will be incorrect after you fix the file-system errors and will be useless until it is brought back into sync. run reiserfsck on the /dev/md4 device. It will keep parity in sync as the fixes are applied. reiserfsck --check /dev/md4 Joe L.
December 18, 201213 yr Author Thanks for the help. I ran --check on /dev/md4 and it's telling me to rebuild-tree root@Tower2:~# reiserfsck --check /dev/md4 reiserfsck 3.6.21 (2009 www.namesys.com) ************************************************************* ** If you are using the latest reiserfsprogs and it fails ** ** please email bug reports to [email protected], ** ** providing as much information as possible -- your ** ** hardware, kernel, patches, settings, all reiserfsck ** ** messages (including version), the reiserfsck logfile, ** ** check the syslog file for any related information. ** ** If you would like advice on using this program, support ** ** is available for $25 at www.namesys.com/support.html. ** ************************************************************* Will read-only check consistency of the filesystem on /dev/md4 Will put log info to 'stdout' Do you want to run this program?[N/Yes] (note need to type Yes if you do):Yes ########### reiserfsck --check started at Wed Dec 19 04:50:43 2012 ########### Replaying journal: Trans replayed: mountid 36, transid 141377, desc 2869, len 1, commit 2871, next trans offset 2854 Trans replayed: mountid 36, transid 141378, desc 2872, len 1, commit 2874, next trans offset 2857 Trans replayed: mountid 36, transid 141379, desc 2875, len 1, commit 2877, next trans offset 2860 Trans replayed: mountid 36, transid 141380, desc 2878, len 5, commit 2884, next trans offset 2867 Replaying journal: Done. Reiserfs journal '/dev/md4' in blocks [18..8211]: 4 transactions replayed Checking internal tree.. \/ 6 (of 19\/106 (of 170\/126 (of 170/block 325565163: The level of the node (21764) is not correct, (1) expected the problem in the internal node occured (325565163), whole subtree is skipped /107 (of 170-block 325610751: The level of the node (57557) is not correct, (2) expected the problem in the internal node occured (325610751), whole subtree is skipped / 7 (of 19\block 336632440: The level of the node (14251) is not correct, (3) expected the problem in the internal node occured (336632440), whole subtree is skipped finished Comparing bitmaps..vpf-10640: The on-disk and the correct bitmaps differs. Bad nodes were found, Semantic pass skipped 3 found corruptions can be fixed only when running with --rebuild-tree ########### reiserfsck finished at Wed Dec 19 05:20:32 2012 ########### Should I run --rebuild-tree?
December 19, 201213 yr Author I ran the reiserfsck with --rebuild-tree. The GUI now shows drive 4 with a red ball and 2 errors. I tried to run smartctl and It's just giving me errors attempting to run it. root@Tower2:/mnt# smartctl -l error /dev/sdc smartctl 5.40 2010-10-16 r3189 [i486-slackware-linux-gnu] (local build) Copyright © 2002-10 by Bruce Allen, http://smartmontools.sourceforge.net Short INQUIRY response, skip product id A mandatory SMART command failed: exiting. To continue, add one or more '-T permissive' options. Is it safe to assume it's actually the drive? I found I was able to run smartctl against the other drives in the array. Is it safe to unassign the drive and start the array?
December 19, 201213 yr Author I wanted to add the new dmesg log http://pastebin.com/VzGHQite Lots of bad looking stuff at the bottom.
December 19, 201213 yr First power cycle the system and see if disk 4 will provide a SMART report. Un-assign the drive and start the array. You may need to run reiserfsck --check /dev/md4 at this point. If disk4 does not respond to smartctl it will need to be replaced.
December 19, 201213 yr Author I rebooted the machine and power cycled it. I was able to run the smart report, and it show's FAILING_NOW on pre-allocated sector count. root@Tower2:~# smartctl -l error /dev/sdc smartctl 5.40 2010-10-16 r3189 [i486-slackware-linux-gnu] (local build) Copyright © 2002-10 by Bruce Allen, http://smartmontools.sourceforge.net === START OF READ SMART DATA SECTION === SMART Error Log Version: 1 No Errors Logged root@Tower2:~# smartctl -i /dev/sdc smartctl 5.40 2010-10-16 r3189 [i486-slackware-linux-gnu] (local build) Copyright © 2002-10 by Bruce Allen, http://smartmontools.sourceforge.net === START OF INFORMATION SECTION === Model Family: Western Digital Caviar Green (Adv. Format) family Device Model: WDC WD20EARS-00MVWB0 Serial Number: WD-WCAZA4954073 Firmware Version: 51.0AB51 User Capacity: 2,000,398,934,016 bytes Device is: In smartctl database [for details use: -P show] ATA Version is: 8 ATA Standard is: Exact ATA specification draft version not indicated Local Time is: Thu Dec 20 01:11:24 2012 CET SMART support is: Available - device has SMART capability. SMART support is: Enabled root@Tower2:~# smartctl -a /dev/sdc smartctl 5.40 2010-10-16 r3189 [i486-slackware-linux-gnu] (local build) Copyright © 2002-10 by Bruce Allen, http://smartmontools.sourceforge.net === START OF INFORMATION SECTION === Model Family: Western Digital Caviar Green (Adv. Format) family Device Model: WDC WD20EARS-00MVWB0 Serial Number: WD-WCAZA4954073 Firmware Version: 51.0AB51 User Capacity: 2,000,398,934,016 bytes Device is: In smartctl database [for details use: -P show] ATA Version is: 8 ATA Standard is: Exact ATA specification draft version not indicated Local Time is: Thu Dec 20 01:11:56 2012 CET SMART support is: Available - device has SMART capability. SMART support is: Enabled === START OF READ SMART DATA SECTION === SMART overall-health self-assessment test result: FAILED! Drive failure expected in less than 24 hours. SAVE ALL DATA. See vendor-specific Attribute list for failed Attributes. General SMART Values: Offline data collection status: (0x84) Offline data collection activity was suspended by an interrupting command from host. Auto Offline Data Collection: Enabled. Self-test execution status: ( 0) The previous self-test routine completed without error or no self-test has ever been run. Total time to complete Offline data collection: (38400) seconds. Offline data collection capabilities: (0x7b) SMART execute Offline immediate. Auto Offline data collection on/off support. Suspend Offline collection upon new command. Offline surface scan supported. Self-test supported. Conveyance Self-test supported. Selective Self-test supported. SMART capabilities: (0x0003) Saves SMART data before entering power-saving mode. Supports SMART auto save timer. Error logging capability: (0x01) Error logging supported. General Purpose Logging supported. Short self-test routine recommended polling time: ( 2) minutes. Extended self-test routine recommended polling time: ( 255) minutes. Conveyance self-test routine recommended polling time: ( 5) minutes. SCT capabilities: (0x3035) SCT Status supported. SCT Feature Control supported. SCT Data Table supported. SMART Attributes Data Structure revision number: 16 Vendor Specific SMART Attributes with Thresholds: ID# ATTRIBUTE_NAME FLAG VALUE WORST THRESH TYPE UPDATED WHEN_FAILED RAW_VALUE 1 Raw_Read_Error_Rate 0x002f 083 083 051 Pre-fail Always - 32871 3 Spin_Up_Time 0x0027 253 253 021 Pre-fail Always - 991 4 Start_Stop_Count 0x0032 100 100 000 Old_age Always - 37 5 Reallocated_Sector_Ct 0x0033 135 135 140 Pre-fail Always FAILING_NOW 1238 7 Seek_Error_Rate 0x002e 200 200 000 Old_age Always - 0 9 Power_On_Hours 0x0032 088 088 000 Old_age Always - 8924 10 Spin_Retry_Count 0x0032 100 253 000 Old_age Always - 0 11 Calibration_Retry_Count 0x0032 100 253 000 Old_age Always - 0 12 Power_Cycle_Count 0x0032 100 100 000 Old_age Always - 35 192 Power-Off_Retract_Count 0x0032 200 200 000 Old_age Always - 21 193 Load_Cycle_Count 0x0032 198 198 000 Old_age Always - 7616 194 Temperature_Celsius 0x0022 124 116 000 Old_age Always - 26 196 Reallocated_Event_Count 0x0032 001 001 000 Old_age Always - 918 197 Current_Pending_Sector 0x0032 200 196 000 Old_age Always - 274 198 Offline_Uncorrectable 0x0030 200 199 000 Old_age Offline - 30 199 UDMA_CRC_Error_Count 0x0032 200 200 000 Old_age Always - 0 200 Multi_Zone_Error_Rate 0x0008 001 001 000 Old_age Offline - 114281 SMART Error Log Version: 1 No Errors Logged SMART Self-test log structure revision number 1 Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error # 1 Short offline Completed without error 00% 8878 - SMART Selective self-test log data structure revision number 1 SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS 1 0 0 Not_testing 2 0 0 Not_testing 3 0 0 Not_testing 4 0 0 Not_testing 5 0 0 Not_testing Selective self-test flags (0x0): After scanning selected spans, do NOT read-scan remainder of disk. If Selective self-test is pending on power-up, resume after 0 minute delay. I am going to unassign the drive and start in maint mode then run the reiserfsck on the drive?
