Good day,



I decided to reinstall my unraid since i was having issues with wireguard. Now that all that i fixed i used to have aroudn 5 vm's (windows7,10 ubuntu, macos, centos). i only started 1 each at a time with my monitor + keyboard and mice passed through.



My keyboard works perfectly in unraid's typable ui, yet when i pass it through to my VM the keyboard just stops working. I've tried the following:



 * Delete any plugin related to usb passthrough VFIO-PCI CFG & Libvirt Hotplug USB.

* changed the USB bus of the VM (before the full restart all the busses worked)



Note that this is the set i used to install unraid with. Once i connect my roccat keyboard + mice from my other room it works in the VM. Hopefully somoene could help me figure this out

hpunraid-diagnostics-20200727-2151.zip

I just started up my VM and it did say Logitech unifying receiver installed. but no buttons are working.

libusb: error [_open_sysfs_attr] open /sys/bus/usb/devices/1-6/bConfigurationValue failed ret=-1 errno=2
libusb: error [udev_hotplug_event] ignoring udev action bind
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle
libusb: error [do_close] Device handle closed while transfer was still being processed, but the device is still connected as far as we know
libusb: warning [do_close] A cancellation for an in-flight transfer hasn't completed but closing the device handle



found these errors in the VM log



Also when i hot plug it using the plugin Libvirt Hotplug USB i even see Logitech options software and i hear a connect sound

Now al of the sudden it works:



Jul 27 22:19:26 HPUnraid kernel: input: Logitech MX Keys as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0032/0003:046D:408A.0033/input/input87
Jul 27 22:19:26 HPUnraid kernel: logitech-hidpp-device 0003:046D:408A.0033: input,hidraw2: USB HID v1.11 Keyboard [Logitech MX Keys] on usb-0000:00:14.0-6:1
Jul 27 22:19:27 HPUnraid kernel: input: Logitech MX Master 2S as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0032/0003:046D:4069.0034/input/input88
Jul 27 22:19:27 HPUnraid kernel: logitech-hidpp-device 0003:046D:4069.0034: input,hidraw3: USB HID v1.11 Keyboard [Logitech MX Master 2S] on usb-0000:00:14.0-6:2
Jul 27 22:19:27 HPUnraid kernel: input: Logitech MX Vertical as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0032/0003:046D:407B.0035/input/input89
Jul 27 22:19:27 HPUnraid kernel: logitech-hidpp-device 0003:046D:407B.0035: input,hidraw4: USB HID v1.11 Keyboard [Logitech MX Vertical] on usb-0000:00:14.0-6:3
Jul 27 22:19:33 HPUnraid acpid: input device has been disconnected, fd 6
Jul 27 22:19:33 HPUnraid acpid: input device has been disconnected, fd 7
Jul 27 22:19:33 HPUnraid acpid: input device has been disconnected, fd 11
Jul 27 22:21:13 HPUnraid kernel: usb 1-8.1: reset full-speed USB device number 12 using xhci_hcd
Jul 27 22:21:14 HPUnraid kernel: usb 1-8.3: reset full-speed USB device number 14 using xhci_hcd
Jul 27 22:21:14 HPUnraid kernel: usb 1-6: reset full-speed USB device number 17 using xhci_hcd
Jul 27 22:21:19 HPUnraid kernel: usb 1-8.1: reset full-speed USB device number 12 using xhci_hcd
Jul 27 22:21:19 HPUnraid kernel: usb 1-8.3: reset full-speed USB device number 14 using xhci_hcd
Jul 27 22:21:19 HPUnraid kernel: usb 1-6: reset full-speed USB device number 17 using xhci_hcd
Jul 27 22:22:15 HPUnraid kernel: usb 1-8: USB disconnect, device number 11
Jul 27 22:22:15 HPUnraid kernel: usb 1-8.1: USB disconnect, device number 12
Jul 27 22:22:15 HPUnraid kernel: usb 1-8.3: USB disconnect, device number 14
Jul 27 22:22:20 HPUnraid kernel: usb 1-8: new full-speed USB device number 18 using xhci_hcd
Jul 27 22:22:20 HPUnraid kernel: input: Corsair Corsair M65 RGB Gaming Mouse Mouse as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8:1.0/0003:1B1C:1B12.0036/input/input90
Jul 27 22:22:20 HPUnraid kernel: input: Corsair Corsair M65 RGB Gaming Mouse as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8:1.0/0003:1B1C:1B12.0036/input/input91
Jul 27 22:22:20 HPUnraid kernel: input: Corsair Corsair M65 RGB Gaming Mouse as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8:1.0/0003:1B1C:1B12.0036/input/input92
Jul 27 22:22:20 HPUnraid kernel: hid-generic 0003:1B1C:1B12.0036: input,hiddev97,hidraw1: USB HID v1.11 Mouse [Corsair Corsair M65 RGB Gaming Mouse] on usb-0000:00:14.0-8/input0
Jul 27 22:22:20 HPUnraid kernel: hid-generic 0003:1B1C:1B12.0037: hiddev98,hidraw2: USB HID v1.11 Device [Corsair Corsair M65 RGB Gaming Mouse] on usb-0000:00:14.0-8/input1



Restarting now to see if this still keeps working

looks like the windows 10 VM is now working. Yet creating a new VM just breaks it again..

So on all my VM's it doesnt work except for 1 windows 10 VM. I just can't seem to figure this one out: more photos:



<?xml version='1.0' encoding='UTF-8'?>
<domain type='kvm'>
  <name>Windows 10 GPU</name>
  <uuid>3309031e-4b70-62a0-3106-21b6390a7817</uuid>
  <metadata>
    <vmtemplate xmlns="unraid" name="Windows 10" icon="windows.png" os="windows10"/>
  </metadata>
  <memory unit='KiB'>6291456</memory>
  <currentMemory unit='KiB'>6291456</currentMemory>
  <memoryBacking>
    <nosharepages/>
  </memoryBacking>
  <vcpu placement='static'>4</vcpu>
  <cputune>
    <vcpupin vcpu='0' cpuset='2'/>
    <vcpupin vcpu='1' cpuset='6'/>
    <vcpupin vcpu='2' cpuset='3'/>
    <vcpupin vcpu='3' cpuset='7'/>
  </cputune>
  <os>
    <type arch='x86_64' machine='pc-i440fx-4.2'>hvm</type>
    <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader>
    <nvram>/etc/libvirt/qemu/nvram/3309031e-4b70-62a0-3106-21b6390a7817_VARS-pure-efi.fd</nvram>
  </os>
  <features>
    <acpi/>
    <apic/>
    <hyperv>
      <relaxed state='on'/>
      <vapic state='on'/>
      <spinlocks state='on' retries='8191'/>
      <vendor_id state='on' value='none'/>
    </hyperv>
  </features>
  <cpu mode='host-passthrough' check='none'>
    <topology sockets='1' cores='2' threads='2'/>
    <cache mode='passthrough'/>
  </cpu>
  <clock offset='localtime'>
    <timer name='hypervclock' present='yes'/>
    <timer name='hpet' present='no'/>
  </clock>
  <on_poweroff>destroy</on_poweroff>
  <on_reboot>restart</on_reboot>
  <on_crash>restart</on_crash>
  <devices>
    <emulator>/usr/local/sbin/qemu</emulator>
    <disk type='file' device='disk'>
      <driver name='qemu' type='raw' cache='writeback'/>
      <source file='/mnt/disks/SSD/VM_Data/Windows 10 GPU/vdisk1.img'/>
      <target dev='hdc' bus='virtio'/>
      <boot order='1'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/>
    </disk>
    <disk type='file' device='cdrom'>
      <driver name='qemu' type='raw'/>
      <source file='/mnt/user/isos/A_Windows10_2004_Pro_0.3.iso'/>
      <target dev='hda' bus='sata'/>
      <readonly/>
      <boot order='2'/>
      <address type='drive' controller='0' bus='0' target='0' unit='0'/>
    </disk>
    <disk type='file' device='cdrom'>
      <driver name='qemu' type='raw'/>
      <source file='/mnt/user/isos/virtio-win-0.1.173-2.iso'/>
      <target dev='hdb' bus='sata'/>
      <readonly/>
      <address type='drive' controller='0' bus='0' target='0' unit='1'/>
    </disk>
    <controller type='usb' index='0' model='qemu-xhci' ports='15'>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/>
    </controller>
    <controller type='sata' index='0'>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/>
    </controller>
    <controller type='virtio-serial' index='0'>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/>
    </controller>
    <controller type='pci' index='0' model='pci-root'/>
    <interface type='bridge'>
      <mac address='52:54:00:ee:65:e9'/>
      <source bridge='br0'/>
      <model type='virtio'/>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/>
    </interface>
    <serial type='pty'>
      <target type='isa-serial' port='0'>
        <model name='isa-serial'/>
      </target>
    </serial>
    <console type='pty'>
      <target type='serial' port='0'/>
    </console>
    <channel type='unix'>
      <target type='virtio' name='org.qemu.guest_agent.0'/>
      <address type='virtio-serial' controller='0' bus='0' port='1'/>
    </channel>
    <input type='mouse' bus='ps2'/>
    <input type='keyboard' bus='ps2'/>
    <hostdev mode='subsystem' type='usb' managed='no'>
      <source>
        <vendor id='0x1e7d'/>
        <product id='0x2cee'/>
      </source>
      <address type='usb' bus='0' port='1'/>
    </hostdev>
    <hostdev mode='subsystem' type='usb' managed='no'>
      <source>
        <vendor id='0x1e7d'/>
        <product id='0x2f76'/>
      </source>
      <address type='usb' bus='0' port='2'/>
    </hostdev>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <driver name='vfio'/>
      <source>
        <address domain='0x0000' bus='0x01' slot='0x00' function='0x0'/>
      </source>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0'/>
    </hostdev>
    <hostdev mode='subsystem' type='pci' managed='yes'>
      <driver name='vfio'/>
      <source>
        <address domain='0x0000' bus='0x01' slot='0x00' function='0x1'/>
      </source>
      <address type='pci' domain='0x0000' bus='0x00' slot='0x08' function='0x0'/>
    </hostdev>
    <hostdev mode='subsystem' type='usb' managed='no'>
      <source>
        <vendor id='0x046d'/>
        <product id='0xc52b'/>
      </source>
      <address type='usb' bus='0' port='3'/>
    </hostdev>
    <hostdev mode='subsystem' type='usb' managed='no'>
      <source>
        <vendor id='0x1b1c'/>
        <product id='0x1b12'/>
      </source>
      <address type='usb' bus='0' port='4'/>
    </hostdev>
    <memballoon model='none'/>
  </devices>
</domain>


Jul 27 22:37:14 HPUnraid kernel: device vnet0 left promiscuous mode
Jul 27 22:37:14 HPUnraid kernel: br0: port 2(vnet0) entered disabled state
Jul 27 22:37:14 HPUnraid avahi-daemon[4204]: Withdrawing address record for fe80::fc54:ff:fe9e:db27 on vnet0.
Jul 27 22:37:14 HPUnraid kernel: usb 1-8.1: reset full-speed USB device number 24 using xhci_hcd
Jul 27 22:37:14 HPUnraid kernel: input: ROCCAT ROCCAT Kova Mouse as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8.1/1-8.1:1.0/0003:1E7D:2CEE.0084/input/input178
Jul 27 22:37:14 HPUnraid kernel: input: ROCCAT ROCCAT Kova Consumer Control as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8.1/1-8.1:1.0/0003:1E7D:2CEE.0084/input/input179
Jul 27 22:37:14 HPUnraid kernel: input: ROCCAT ROCCAT Kova as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8.1/1-8.1:1.0/0003:1E7D:2CEE.0084/input/input180
Jul 27 22:37:14 HPUnraid kernel: hid-generic 0003:1E7D:2CEE.0084: input,hiddev97,hidraw3: USB HID v1.11 Mouse [ROCCAT ROCCAT Kova] on usb-0000:00:14.0-8.1/input0
Jul 27 22:37:14 HPUnraid kernel: input: ROCCAT ROCCAT Kova as /devices/pci0000:00/0000:00:14.0/usb1/1-8/1-8.1/1-8.1:1.1/0003:1E7D:2CEE.0085/input/input181
Jul 27 22:37:14 HPUnraid kernel: hid-generic 0003:1E7D:2CEE.0085: input,hidraw5: USB HID v1.11 Keyboard [ROCCAT ROCCAT Kova] on usb-0000:00:14.0-8.1/input1
Jul 27 22:37:14 HPUnraid kernel: usb 1-6: reset full-speed USB device number 17 using xhci_hcd
Jul 27 22:37:14 HPUnraid kernel: logitech-djreceiver 0003:046D:C52B.0088: hiddev98,hidraw6: USB HID v1.11 Device [Logitech USB Receiver] on usb-0000:00:14.0-6/input2
Jul 27 22:37:14 HPUnraid kernel: input: Logitech MX Keys as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0088/0003:046D:408A.0089/input/input182
Jul 27 22:37:14 HPUnraid kernel: logitech-hidpp-device 0003:046D:408A.0089: input,hidraw7: USB HID v1.11 Keyboard [Logitech MX Keys] on usb-0000:00:14.0-6:1
Jul 27 22:37:15 HPUnraid kernel: input: Logitech MX Master 2S as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0088/0003:046D:4069.008A/input/input183
Jul 27 22:37:15 HPUnraid kernel: logitech-hidpp-device 0003:046D:4069.008A: input,hidraw8: USB HID v1.11 Keyboard [Logitech MX Master 2S] on usb-0000:00:14.0-6:2
Jul 27 22:37:15 HPUnraid kernel: input: Logitech MX Vertical as /devices/pci0000:00/0000:00:14.0/usb1/1-6/1-6:1.2/0003:046D:C52B.0088/0003:046D:407B.008B/input/input184
Jul 27 22:37:15 HPUnraid kernel: logitech-hidpp-device 0003:046D:407B.008B: input,hidraw9: USB HID v1.11 Keyboard [Logitech MX Vertical] on usb-0000:00:14.0-6:3
Jul 27 22:37:16 HPUnraid kernel: vfio-pci 0000:01:00.0: vgaarb: changed VGA decodes: olddecodes=io+mem,decodes=io+mem:owns=none
Jul 27 22:37:17 HPUnraid kernel: usb 1-8: USB disconnect, device number 23
Jul 27 22:37:17 HPUnraid kernel: usb 1-8.1: USB disconnect, device number 24
Jul 27 22:37:17 HPUnraid acpid: input device has been disconnected, fd 17
Jul 27 22:37:17 HPUnraid kernel: usb 1-8.3: USB disconnect, device number 25
Jul 27 22:37:17 HPUnraid acpid: input device has been disconnected, fd 5
Jul 27 22:37:17 HPUnraid acpid: input device has been disconnected, fd 7
Jul 27 22:37:17 HPUnraid acpid: input device has been disconnected, fd 11
Jul 27 22:37:17 HPUnraid acpid: input device has been disconnected, fd 16
