Greetings,
I am trying to get my two 6TB Exos SAS drives to be recognized in unRAID. My other two drives (1 SSD, 1 1TB HDD), both SATA, are recognized and set up in my array. My SSD is my Cache drive, and the 1TB drive is just in my array. I need to have one of my 6TB drives set as my parity drive, and the other one in my array.
I have 4 SAS bays in my case, and have my drives set as follows: 1: SSD SATA, 2: 1TB SATA, 3: 6TB SAS, 4: 6TB SAS. The first diagnostics file I uploaded (valhalla-diagnostics-20220130-1650) was with this setup.
I tried changing to: 1: SSD SATA, 2: 6TB SAS, 3: 6TB SAS, 4: 1TB SATA. The second diagnostics file I uploaded (valhalla-diagnostics-20220130-1831) was with this setup.
I have my SATA controller set up as HP Dynamic Smart Array B320i Raid Controller in the BIOS. I have also tried the other option as well (SATA AHCII Controller or something), but that didn't work either.
I have read that I need an HP Smart Array SAS License Key installed to provide support for SAS Hard Drives? Any ProLiant MS Gen8 users out there that might be able to confirm and help me if this is true?
Lastly, on bootup I receive a "SATA3: COMRESET failed (errno=-32)" error that retries like 6 times before moving on. I am thinking this error might possibly have something to do with why my SAS drives aren't showing up?
My setup is in my signature. I also attached my syslog in case that might help as well.
Any help would be much appreciated!
Thanks!
valhalla-diagnostics-20220130-1650.zip
valhalla-diagnostics-20220130-1831.zip
valhalla-syslog-20220130-2354.zip
