N47H4N Posted June 4 Posted June 4 Hi everyone, I've a question regarding my setup. You can see my full setup here: My question will be related to my motherboard (Asus P12R-E/10G-2T) and my HBA (Lsi Sas 9305-24i) Â For the moment, all my disks are connected on my HBA though my PCI-E x8. Do you think I can improve my performance (data rebuild / parity check) if I connect my 2 parity disks directly on my motherboard ? Or the opposite, my perfs will decrease. I would appreciate any advice here thx Quote
N47H4N Posted June 5 Author Posted June 5 ok thx @JorgeB, so no benefits to move my parity disk. Do you know if moving my HBA from pci-e 3 to pci-e 4 can improve the performance ? Quote
JorgeB Posted June 5 Posted June 5 Do you mean different slots on the board or PCIe 3.0 to 4.0? Quote
N47H4N Posted June 5 Author Posted June 5 My HBA is in PCIe v3 but my moterboard is PCIe v4. If I change my HBA for the version eHBA 9600-24i for example, will I have a significant performance improvement ? Quote
_cjd_ Posted June 5 Posted June 5 If you are using an HBA card, actual drive speed should be the bottleneck. You can verify performance with the DiskSpeed application if you're curious. Rather than asking vague theory type questions: what's your current parity check time / drive size / speed results? Are you asking because you think something is wrong? Quote
N47H4N Posted June 6 Author Posted June 6 Hi @_cjd_, You will probably say that my parity check time is fine and it's on average. but the reality is that I have to stop all my VMs and all my Docker containers during parity check or rebuild to reach that average speed. and even with everything stopped, my unraid server is useless 2days per month I'm just checking if I can optimize something Quote
N47H4N Posted June 6 Author Posted June 6 (edited) @JorgeB sure, here is my diagnostics file  Edited June 19 by N47H4N Quote
JorgeB Posted June 6 Posted June 6 I missed before that it was a 24 port HBA, and I see you have 20 disks connected, still if it's on a x8 PCIe 3.0 slot, it should have just enough bandwidth, run the diskspeed docker controller test and post the results. Quote
_cjd_ Posted June 6 Posted June 6 Oof, yeah that's a lot and certainly all over the place on time. I usually see 22hr for a 16tb array where daytime use slows things down, but also a total of 5 drives in the array (mobo or asm1166 card connected). Time machine is the killer. No need for me to stop docker (no VMs any more). It's probably not even parity drives specifically, if you're saturating the card/slot. Are your VMs/docker running off the array? Curious what you have there with sufficient io to slow parity check. Quote
N47H4N Posted June 7 Author Posted June 7 @JorgeBÂ here is the result of the benchmark @_cjd_Â both my MVs and Containers are running on my nvme SSD but they are reading/writing stuff on my array of hard drives Quote
JorgeB Posted June 7 Posted June 7 Those are the disk results, and already show some interesting info, multiple disks are under-performing, but also would like to see the controller test, looks like this: Â Â Â Quote
JorgeB Posted June 7 Posted June 7 That indicates a big controller bottleneck, though the previous individual test also didn't look goof for several disks, post the output of:  lspci -d 1000: -vv  Quote
N47H4N Posted June 7 Author Posted June 7 root@NAS01:~# lspci -d 1000: -vv 01:00.0 Serial Attached SCSI controller: Broadcom / LSI SAS3224 PCI-Express Fusion-MPT SAS-3 (rev 01) Subsystem: Broadcom / LSI SAS9305-24i Control: I/O+ Mem+ BusMaster+ SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx+ Status: Cap+ 66MHz- UDF- FastB2B- ParErr- DEVSEL=fast >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx- Latency: 0, Cache Line Size: 64 bytes Interrupt: pin A routed to IRQ 16 IOMMU group: 15 Region 0: I/O ports at 4000 [size=256] Region 1: Memory at a9100000 (64-bit, non-prefetchable) [size=64K] Expansion ROM at a9000000 [disabled] [size=1M] Capabilities: [50] Power Management version 3 Flags: PMEClk- DSI- D1+ D2+ AuxCurrent=0mA PME(D0-,D1-,D2-,D3hot-,D3cold-) Status: D0 NoSoftRst+ PME-Enable- DSel=0 DScale=0 PME- Capabilities: [68] Express (v2) Endpoint, MSI 00 DevCap: MaxPayload 4096 bytes, PhantFunc 0, Latency L0s <64ns, L1 <1us ExtTag+ AttnBtn- AttnInd- PwrInd- RBE+ FLReset+ SlotPowerLimit 75W DevCtl: CorrErr- NonFatalErr- FatalErr- UnsupReq- RlxdOrd+ ExtTag+ PhantFunc- AuxPwr- NoSnoop+ FLReset- MaxPayload 256 bytes, MaxReadReq 512 bytes DevSta: CorrErr+ NonFatalErr- FatalErr- UnsupReq+ AuxPwr- TransPend- LnkCap: Port #0, Speed 8GT/s, Width x8, ASPM not supported ClockPM- Surprise- LLActRep- BwNot- ASPMOptComp+ LnkCtl: ASPM Disabled; RCB 64 bytes, Disabled- CommClk+ ExtSynch- ClockPM- AutWidDis- BWInt- AutBWInt- LnkSta: Speed 8GT/s, Width x8 TrErr- Train- SlotClk+ DLActive- BWMgmt- ABWMgmt- DevCap2: Completion Timeout: Range BC, TimeoutDis+ NROPrPrP- LTR- 10BitTagComp- 10BitTagReq- OBFF Not Supported, ExtFmt- EETLPPrefix- EmergencyPowerReduction Not Supported, EmergencyPowerReductionInit- FRS- TPHComp- ExtTPHComp- AtomicOpsCap: 32bit- 64bit- 128bitCAS- DevCtl2: Completion Timeout: 50us to 50ms, TimeoutDis- LTR- 10BitTagReq- OBFF Disabled, AtomicOpsCtl: ReqEn- LnkCap2: Supported Link Speeds: 2.5-8GT/s, Crosslink- Retimer- 2Retimers- DRS- LnkCtl2: Target Link Speed: 8GT/s, EnterCompliance- SpeedDis- Transmit Margin: Normal Operating Range, EnterModifiedCompliance- ComplianceSOS- Compliance Preset/De-emphasis: -6dB de-emphasis, 0dB preshoot LnkSta2: Current De-emphasis Level: -6dB, EqualizationComplete+ EqualizationPhase1+ EqualizationPhase2+ EqualizationPhase3+ LinkEqualizationRequest- Retimer- 2Retimers- CrosslinkRes: unsupported Capabilities: [a8] MSI: Enable- Count=1/1 Maskable+ 64bit+ Address: 0000000000000000 Data: 0000 Masking: 00000000 Pending: 00000000 Capabilities: [c0] MSI-X: Enable+ Count=96 Masked- Vector table: BAR=1 offset=0000e000 PBA: BAR=1 offset=0000f000 Capabilities: [100 v2] Advanced Error Reporting UESta: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- UEMsk: DLP- SDES- TLP- FCP- CmpltTO- CmpltAbrt- UnxCmplt- RxOF- MalfTLP- ECRC- UnsupReq- ACSViol- UESvrt: DLP+ SDES+ TLP- FCP+ CmpltTO- CmpltAbrt- UnxCmplt- RxOF+ MalfTLP+ ECRC- UnsupReq- ACSViol- CESta: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr+ CEMsk: RxErr- BadTLP- BadDLLP- Rollover- Timeout- AdvNonFatalErr+ AERCap: First Error Pointer: 00, ECRCGenCap- ECRCGenEn- ECRCChkCap- ECRCChkEn- MultHdrRecCap- MultHdrRecEn- TLPPfxPres- HdrLogCap- HeaderLog: 04000001 0000000c 01080008 c61e2ad2 Capabilities: [1e0 v1] Secondary PCI Express LnkCtl3: LnkEquIntrruptEn- PerformEqu- LaneErrStat: 0 Capabilities: [1c0 v1] Power Budgeting <?> Capabilities: [190 v1] Dynamic Power Allocation <?> Capabilities: [148 v1] Alternative Routing-ID Interpretation (ARI) ARICap: MFVC- ACS-, Next Function: 0 ARICtl: MFVC- ACS-, Function Group: 0 Kernel driver in use: mpt3sas Kernel modules: mpt3sas  Quote
JorgeB Posted June 7 Posted June 7 54 minutes ago, N47H4N said: LnkSta: Speed 8GT/s, Width x8 This is OK, but the HBA is not performing as it should, or the disks, I would start by calling/emailing LSI with the serial number to make sure it's genuine. Quote
