Can't pass through PCI Device on TR1950X Asus X399-A

[Marshalleq]

I have been conversing in this other thread (below) but felt guilty about stealing it, especially since it is marked solved, so starting a new one.



Stubs and such like don't seem to be working.

The config I'm using is as below.



kernel /bzimage
append xen-pciback.hide=(0b:00.0)(0b:00;1),vfio_iommu_type1.allow_unsafe_interrupts=1 isolcpus=12-15,28-31 initrd=/bzroot







I have tried unsafe interrupts added to the append command also, which didn't change anything either.  Any ideas?





obi-wan-diagnostics-20190507-0155.zip

[bastl]

5 hours ago, Marshalleq said:

append xen-pciback.hide=(0b:00.0)(0b:00;1),vfio_iommu_type1.allow_unsafe_interrupts=1 isolcpus=12-15,28-31 initrd=/bzroot

Same hint as in the other thread. Be carful with the options you set in the syslinux config. They have to be separated by a space and not a comma.

[Marshalleq]

OK, I'll give it a go.  One of the guides (I think the space invader one) specifically stated to use commas, then some follow up responses stated they saw no difference with or without a comma.  Will give it a go when I put my NIC card back in shortly.

[Marshalleq]

I replaced the card.  So assuming the card reseating didn't achieve it (and I have no reason to assume it did), this seems to have worked.  Thanks for your help.  I might do some testing with commas again later just to be absolutely certain.

[guruleenyc]

On 5/7/2019 at 4:20 AM, bastl said:

Same hint as in the other thread. Be carful with the options you set in the syslinux config. They have to be separated by a space and not a comma.

Thank you for this tip!

Mine looks like this now:

append vfio_iommu_type1.allow_unsafe_interrupts=1 pcie_acs_override=downstream,multifunction iommu=pt vfio-pci.ids=8086:105e initrd=/bzroot

Edited May 17, 2019 by guruleenyc
