Hi there,
my question relates to power readings from nvidia-smi. Currently, I'm running a Nvidia Quadro P620 with the newest driver from the nvidia driver plugin (great work btw). In general, it all works fine! Transcoding for Jellyfin and tdarr works and the card also enters persistence mode when idle. No complaints so far.
What bothers me a bit, is that my graphics card won't output power reading informations through nvidia-smi. I'm currently not aware if the Nvidia Quadro P620 is just not capabale of doing so, or if there's some issue going on.
To give you a better overview, I attached the NVSMI Log.
Thank you and best Regard
==============NVSMI LOG==============
Timestamp : Mon May 2 02:51:24 2022
Driver Version : 510.68.02
CUDA Version : 11.6
Attached GPUs : 1
GPU 00000000:01:00.0
Product Name : Quadro P620
Product Brand : Quadro
Product Architecture : Pascal
Display Mode : Disabled
Display Active : Disabled
Persistence Mode : Enabled
MIG Mode
Current : N/A
Pending : N/A
Accounting Mode : Disabled
Accounting Mode Buffer Size : 4000
Driver Model
Current : N/A
Pending : N/A
Serial Number : 1421020068036
GPU UUID : GPU-1bb3e78e-770d-f7a6-affe-5dcd4be0292d
Minor Number : 0
VBIOS Version : 86.07.90.00.A7
MultiGPU Board : No
Board ID : 0x100
GPU Part Number : 900-5G178-2741-000
Module ID : 0
Inforom Version
Image Version : G178.0505.00.02
OEM Object : 1.1
ECC Object : N/A
Power Management Object : N/A
GPU Operation Mode
Current : N/A
Pending : N/A
GSP Firmware Version : N/A
GPU Virtualization Mode
Virtualization Mode : None
Host VGPU Mode : N/A
IBMNPU
Relaxed Ordering Mode : N/A
PCI
Bus : 0x01
Device : 0x00
Domain : 0x0000
Device Id : 0x1CB610DE
Bus Id : 00000000:01:00.0
Sub System Id : 0x126410DE
GPU Link Info
PCIe Generation
Max : 2
Current : 1
Link Width
Max : 16x
Current : 16x
Bridge Chip
Type : N/A
Firmware : N/A
Replays Since Reset : 0
Replay Number Rollovers : 0
Tx Throughput : 0 KB/s
Rx Throughput : 0 KB/s
Fan Speed : 34 %
Performance State : P8
Clocks Throttle Reasons
Idle : Active
Applications Clocks Setting : Not Active
SW Power Cap : Not Active
HW Slowdown : Not Active
HW Thermal Slowdown : Not Active
HW Power Brake Slowdown : Not Active
Sync Boost : Not Active
SW Thermal Slowdown : Not Active
Display Clock Setting : Not Active
FB Memory Usage
Total : 2048 MiB
Reserved : 48 MiB
Used : 1 MiB
Free : 1998 MiB
BAR1 Memory Usage
Total : 256 MiB
Used : 4 MiB
Free : 252 MiB
Compute Mode : Default
Utilization
Gpu : 0 %
Memory : 0 %
Encoder : 0 %
Decoder : 0 %
Encoder Stats
Active Sessions : 0
Average FPS : 0
Average Latency : 0
FBC Stats
Active Sessions : 0
Average FPS : 0
Average Latency : 0
Ecc Mode
Current : N/A
Pending : N/A
ECC Errors
Volatile
Single Bit
Device Memory : N/A
Register File : N/A
L1 Cache : N/A
L2 Cache : N/A
Texture Memory : N/A
Texture Shared : N/A
CBU : N/A
Total : N/A
Double Bit
Device Memory : N/A
Register File : N/A
L1 Cache : N/A
L2 Cache : N/A
Texture Memory : N/A
Texture Shared : N/A
CBU : N/A
Total : N/A
Aggregate
Single Bit
Device Memory : N/A
Register File : N/A
L1 Cache : N/A
L2 Cache : N/A
Texture Memory : N/A
Texture Shared : N/A
CBU : N/A
Total : N/A
Double Bit
Device Memory : N/A
Register File : N/A
L1 Cache : N/A
L2 Cache : N/A
Texture Memory : N/A
Texture Shared : N/A
CBU : N/A
Total : N/A
Retired Pages
Single Bit ECC : N/A
Double Bit ECC : N/A
Pending Page Blacklist : N/A
Remapped Rows : N/A
Temperature
GPU Current Temp : 40 C
GPU Shutdown Temp : 103 C
GPU Slowdown Temp : 100 C
GPU Max Operating Temp : N/A
GPU Target Temperature : 83 C
Memory Current Temp : N/A
Memory Max Operating Temp : N/A
Power Readings
Power Management : N/A
Power Draw : N/A
Power Limit : N/A
Default Power Limit : N/A
Enforced Power Limit : N/A
Min Power Limit : N/A
Max Power Limit : N/A
Clocks
Graphics : 139 MHz
SM : 139 MHz
Memory : 405 MHz
Video : 544 MHz
Applications Clocks
Graphics : 1265 MHz
Memory : 2505 MHz
Default Applications Clocks
Graphics : 1265 MHz
Memory : 2505 MHz
Max Clocks
Graphics : 1354 MHz
SM : 1354 MHz
Memory : 2505 MHz
Video : 1341 MHz
Max Customer Boost Clocks
Graphics : 1354 MHz
Clock Policy
Auto Boost : N/A
Auto Boost Default : N/A
Voltage
Graphics : N/A
Processes : None
