I don't think this is specific to the specific container, but if mods want to move the thread that's fine.
Intended outcome
To be able to access Jellyfin through a reverse proxy, where the proxy and the Jellyfin container is on it's own VLAN.
The config
I currently have issues with getting my subdomain via Cloudflare (proxied) to resolve my Jellyfin container out to the internet. Here's a basic setup of my config. I am only going to specify the parts of the network that are involved in the process. Everything on Cloudflare works fine.
Router: pfSense (192.168.0.1)
Subnet Unraid server: VLAN 2 (10.0.2.10)
Subnet with containers: VLAN 20 (10.0.20.10)
pfSense has NAT firewall rules to pass HTTP and HTTPS traffic that redirect to VLAN 20 adresses (non specific). Making it specific doesn't change the outcome. VLAN 20 has access to the internet and DNS resolves fine. The VLANs have rules that ensure the required connectivity between the VLAN's for specific services.
My docker network looks like this:
NETWORK ID NAME DRIVER SCOPE
453b516b189b br0 ipvlan local
6357053a24a9 br0.20 ipvlan local
57dec04655a4 bridge bridge local
My routing table looks like this:
PROTOCOL ROUTE GATEWAY METRIC
IPv4 10.0.2.0/24 br0 1
IPv4 172.17.0.0/16 docker0 0
IPv4 172.18.0.0/16 br-800f922a0e86 0
IPv4 192.168.0.0/24 br1 1
IPv4 192.168.122.0/24 virbr0 0
The problem and my thoughts that I need help with
If I run the setup on VLAN 2 in bridge mode, i.e. on the server itself, everything works fine. As soon as I set it up on VLAN 20, I get a 522 from Cloudflare.
From what I've read from various places, there are two proposed solutions, but I don't have the networking knowhow to implement them. One is adding Split DNS in my config, which I'm not exactly sure how to configure even though I know where it is in the admin panel. And my other thought, is that the routing table is missing bridging from br0 to the specific VLAN, but I'm also lacking the required networking knowledge to do this correctly as well. I tried a lot of things yesterday and ended up having to revert to a Flash backup because the config got messed up. So I thought it's best to ask for help the second time around.
I know there are a lot of elements to this config, but I'm hoping there is a fellow Unraider and pfSense geek out there that can help me resolve this issue or give me a fresh of set ideas. Please let me know if there is missing information here. Thank you very much!
