  1. I was on 6.9.2 so I just upgraded to 6.10.3 and tried adding the URLs again. The icons updated and then survived a force update and a server restart so it looks like that fixed it. Thanks for the help, I can't believe it was that easy in the end! I should have upgraded sooner.
  2. Hi, can anyone help me fix the icons on a couple of my docker containers? They are always reverting to a question mark no matter what I seem to do. After looking for solutions in the forums and google etc. I have tried: Changing the icon URL in the container template to a URL that contains the icon I want. This will work for a bit, and then revert back to a question mark after a couple of hours. Deleting the images from /var/local/emhttp/plugins/dynamix.docker.manager/images, adding the URL back to the container template, and force updating. Deleting the images from /var/lib/docker/unraid/images and copying the correct image into that folder, then deleting the old image from /var/local/emhttp/plugins/dynamix.docker.manager/images. After refreshing my browser the image appeared, but then after force updating the container it went back to a question mark. Deleting the images from /boot/config/plugins/dockerman/images. (There is no image in here for one of the containers). Restarting Unraid after trying the above steps. Clearing cache in browser and also viewing the docker page from a different browser. Using images at different URLs. If it matters, the problem containers are snipe/snipe-it and atribe/apcupsd-influxdb-exporter. The icons I am trying to use are snipe-it and apcupsd-influxdb-exporter. I have been having this problem for nearly a year and every time I look at my dockers I see the question marks begging to be fixed, but every time I sit down determined to fix it I come away with nothing. I'm at a loss - does anyone have any ideas on what to try?
  3. That Memory is Registered (RDIMM) but your board requires Unbuffered (UDIMM). I had the same trouble - it's hard to find unbuffered memory in 32GB sticks at 2400MHz speed. You could either look for 2x16GB sticks, or look for something faster than 2400MHz if you can't find exactly what you want. I ended up going with these 2x16GB sticks - https://www.amazon.com.au/dp/B07NQ1KW9H/ref=cm_sw_em_r_mt_dp_0XFAJQGX9B12ZVZFYA1A?_encoding=UTF8&psc=1 (Australian link sorry).
  4. It may be more powerful than you think. This is one of the threads that convinced me: He's transcoding 4x4k streams on an i3-8100 which is the equivalent of the i3-9100 in the previous generation, and has the same graphics processor (Intel UHD Graphics 630). I also remember reading a comment in a forum somewhere where someone was saying the i3-9100 "slays" 4k streams. I can't find it again though.
  5. Ha, didn't even think of that. I suppose that would work. May resort to that if needed. Interesting. I assume that would be something like this, or this? Are there other benefits of using an add on sata controller, apart from being easier to plug in?
  6. I am about to start putting my new build together, and I came across a blog where someone used the same case as me. They had an issue where the sata ports on the motherboard were angled sideways which made it difficult to plug in the sata cables due to being really close to the wall of the case. This is how tight it was for them: https://lanoc.org/review/pc-hardware/8346-project-data-hoarder-truenas-core-build-part-4-psu-rails-and-installation?start=2 My motherboard also has sideways facing sata ports and the sata ports are in the same location on the board, so I think I will have the same problem - especially since the cables I will be using look like they have bigger ends than those used in the blog. So, I am thinking this could be solved with some angled adapters or similar. I have found some online such as this: However, since the sata ports are stacked one on top of the other, I would only be able to use one of these for each column of ports (4 in total). I was thinking I could get 4 short adapters and 4 long adapters (which reach over the short ones), but I haven't been able to find any long ones. Does anyone have any other ideas for solutions to this problem?
  7. I just designed a new system and went down a similar path to you (here's my thread). I also wanted ECC RAM and also landed on the Intel Core i3 9100. I haven't built my server yet but it seems like a good CPU for NAS duties and some transcoding. The Motherboard I picked was the Gigabyte C246M-WU4 Micro ATX. I needed Micro ATX for my case, but you may prefer an ATX board since it will fit in your case. You said you found a Gigabyte board but the link was to an Asus board? You will need to be careful with your Memory selection. The Asus board you linked (and my board, for what it's worth) only supports Un-buffered/Un-registered (UDIMM) memory. The memory you linked is Registered (RDIMM) so it won't work. The i3 9100 supports 2400MHz memory so a suggestion would be to look for memory of at least that speed to take advantage of that extra capability.
  8. This is really cool. Great find. Makes the decision easier knowing this is an option. I think that makes sense. I can't see myself needing more than 96GB and starting with 2x16GB is a cheaper entry point and will give me time to see what my RAM needs really are and how it grows before jumping up to 32GB modules if need be. Just looked it up, it looks pretty decent. Can only find it in one shop here but it is a bit cheaper than the Corsair and Silverstone which makes it one to consider. Thanks for the tip!
  9. Thanks for linking those posts, interesting reading (with the help of google translate 😋). Also I saw you linked in one of those posts you have the same motherboard and the i3 8100. I see why you liked my choices Wow yeah 50% or lower would not be good. Good to see these two PSUs are much better than that! Hmm ok that's interesting. Opens up options a bit. That Kingston module seems to be pretty available locally (Australia), although it is about $120 more expensive, I guess because of the higher density and higher speed. I think the Samsung M391A4G43MB1-CTD would be good but I can't find it for sale in Australia. I did find some Crucial ones though - 3200MHz and 2666MHz (that one says REG in the title but I'm pretty sure it's not, according to Crucial's website). Now I just need to convince myself it's worth paying a little extra to get expandability to 128GB in case I need it one day. And then decide between 3200MHz and 2666MHz.
  10. Yeah good point. 6 cores would be nice but I was thinking it might be overkill for my applications at the moment - using more power and costing more initially. I thought ECC memory would be a decent upgrade as people often recommend it for servers and I like the sound of better stability, but I guess it might also be overkill for a small server such as this. Hmm this is interesting.... I just had a look at other cables on that store. Would this one be the correct cable? They look the same but look to be in opposite directions. However the one I picked has "Re" in the name - does that not mean reverse? Also the image on the page in the one I picked has SFF-8087 side going to the HDD backplane and the SATA 7-pin going to the motherboard sata ports. I thought that's how it would work, since my backplane has an 8087 port and the motherboard has sata ports? Why doesn't that work? Sorry if these are stupid questions, I'm new to SAS.
  11. I've looked up some data on the Corsair, and it does seem to be really efficient at low power. However comparing to the Silverstone I think it seems pretty similar? (Not trying to prove you wrong, or defend the Silverstone - just trying to make sure I'm not missing anything). https://www.corsair.com/corsairmedia/sys_master/productcontent/WW_RMx_Series_2021_QSG_AA.pdf https://www.anandtech.com/show/10207/the-silverstone-strider-platinum-550w-psu-review/4 Corsair RM550x: https://www.tomshardware.com/reviews/corsair-rm550x-power-supply,4484-5.html Silverstone 550w: https://pcper.com/2016/10/silverstone-strider-platinum-550w-power-supply-review/5/#ftoc-heading-6 Seems like at 55w they are both around 84-88% efficient and at 20w they are around 75-78% efficient. It's kind of hard to tell exactly without precise markings on the graphs, but they seem pretty close. Do you have any other links about the Corsair's low power efficiency vs others? Or is the Corsair just better at going down even below 20W which isn't measured by these charts or something? Yeah I agree 32GB is plenty for the time being. I was originally looking for a single 32GB stick to leave upgrade options open (and saving power would be nice too), but I couldn't find any 32GB sticks at 2400MHz that were unbuffered - they all seemed to be buffered/registered. Like you said - availability really limits choices.
  12. Thanks so much for taking the time on this. I'll look into the Corsair RMx 550. I assumed the platinum rating on the Silverstone would make it more efficient than a gold one but I guess not necessarily... It looks like the Corsair is a bit longer which puts it at the 160mm stated limit of the case. It should still fit, but you're right - it might be tight. Sorry, that 2.5 HDD is actually 3.5. I must have selected the wrong one in PC Part Picker and didn't notice. I thought the CPU only supported 64GB RAM so that's why I was planning for expandability up to 64GB. This is from the Intel spec sheet: Unless that doesn't mean what I think it does?
