I have a SATA SSD that refuses to properly display the smart data in the unraid UI. Its a 4TB 860 EVO. I purchased it used so I had considered it might be a fake, but Samsung Magician has no issues identifying it and crystaldiskinfo shows all relevant data. When at Unraids terminal I can see the smart data. root@Hyperion:~# smartctl -x /dev/sdc
smartctl 7.4 2023-08-01 r5530 [x86_64-linux-6.12.24-Unraid] (local build)
Copyright (C) 2002-23, Bruce Allen, Christian Franke, www.smartmontools.org
=== START OF INFORMATION SECTION ===
Model Family: Samsung based SSDs
Device Model: Samsung SSD 860 EVO 4TB
Serial Number: S596NE0N100749D
LU WWN Device Id: 5 002538 e101299f8
Firmware Version: RVT04B6Q
User Capacity: 4,000,787,030,016 bytes [4.00 TB]
Sector Size: 512 bytes logical/physical
Rotation Rate: Solid State Device
Form Factor: 2.5 inches
TRIM Command: Available, deterministic, zeroed
Device is: In smartctl database 7.3/5706
ATA Version is: ACS-4 T13/BSR INCITS 529 revision 5
SATA Version is: SATA 3.2, 6.0 Gb/s (current: 6.0 Gb/s)
Local Time is: Wed Oct 22 17:06:52 2025 CDT
SMART support is: Available - device has SMART capability.
SMART support is: Enabled
AAM feature is: Unavailable
APM feature is: Unavailable
Rd look-ahead is: Enabled
Write cache is: Enabled
DSN feature is: Unavailable
ATA Security is: Disabled, NOT FROZEN [SEC1]
Wt Cache Reorder: Enabled
=== START OF READ SMART DATA SECTION ===
SMART overall-health self-assessment test result: PASSED
General SMART Values:
Offline data collection status: (0x00) Offline data collection activity
was never started.
Auto Offline Data Collection: Disabled.
Self-test execution status: ( 0) The previous self-test routine completed
without error or no self-test has ever
been run.
Total time to complete Offline
data collection: ( 0) seconds.
Offline data collection
capabilities: (0x53) SMART execute Offline immediate.
Auto Offline data collection on/off support.
Suspend Offline collection upon new
command.
No Offline surface scan supported.
Self-test supported.
No Conveyance Self-test supported.
Selective Self-test supported.
SMART capabilities: (0x0003) Saves SMART data before entering
power-saving mode.
Supports SMART auto save timer.
Error logging capability: (0x01) Error logging supported.
General Purpose Logging supported.
Short self-test routine
recommended polling time: ( 2) minutes.
Extended self-test routine
recommended polling time: ( 320) minutes.
SCT capabilities: (0x003d) SCT Status supported.
SCT Error Recovery Control supported.
SCT Feature Control supported.
SCT Data Table supported.
SMART Attributes Data Structure revision number: 1
Vendor Specific SMART Attributes with Thresholds:
ID# ATTRIBUTE_NAME FLAGS VALUE WORST THRESH FAIL RAW_VALUE
5 Reallocated_Sector_Ct PO--CK 100 100 010 - 0
9 Power_On_Hours -O--CK 099 099 000 - 3243
12 Power_Cycle_Count -O--CK 095 095 000 - 4080
177 Wear_Leveling_Count PO--C- 099 099 000 - 5
179 Used_Rsvd_Blk_Cnt_Tot PO--C- 100 100 010 - 0
181 Program_Fail_Cnt_Total -O--CK 100 100 010 - 0
182 Erase_Fail_Count_Total -O--CK 100 100 010 - 0
183 Runtime_Bad_Block PO--C- 100 100 010 - 0
187 Uncorrectable_Error_Cnt -O--CK 100 100 000 - 0
190 Airflow_Temperature_Cel -O--CK 072 059 000 - 28
195 ECC_Error_Rate -O-RC- 200 200 000 - 0
199 CRC_Error_Count -OSRCK 092 092 000 - 7157
235 POR_Recovery_Count -O--C- 099 099 000 - 66
241 Total_LBAs_Written -O--CK 099 099 000 - 25176669341
||||||_ K auto-keep
|||||__ C event count
||||___ R error rate
|||____ S speed/performance
||_____ O updated online
|______ P prefailure warning
General Purpose Log Directory Version 1
SMART Log Directory Version 1 [multi-sector log support]
Address Access R/W Size Description
0x00 GPL,SL R/O 1 Log Directory
0x01 SL R/O 1 Summary SMART error log
0x02 SL R/O 1 Comprehensive SMART error log
0x03 GPL R/O 1 Ext. Comprehensive SMART error log
0x04 GPL,SL R/O 8 Device Statistics log
0x06 SL R/O 1 SMART self-test log
0x07 GPL R/O 1 Extended self-test log
0x09 SL R/W 1 Selective self-test log
0x10 GPL R/O 1 NCQ Command Error log
0x11 GPL R/O 1 SATA Phy Event Counters log
0x13 GPL R/O 1 SATA NCQ Send and Receive log
0x30 GPL,SL R/O 9 IDENTIFY DEVICE data log
0x80-0x9f GPL,SL R/W 16 Host vendor specific log
0xa1 SL VS 16 Device vendor specific log
0xa5 SL VS 16 Device vendor specific log
0xce SL VS 16 Device vendor specific log
0xe0 GPL,SL R/W 1 SCT Command/Status
0xe1 GPL,SL R/W 1 SCT Data Transfer
SMART Extended Comprehensive Error Log Version: 1 (1 sectors)
No Errors Logged
SMART Extended Self-test Log Version: 1 (1 sectors)
Num Test_Description Status Remaining LifeTime(hours) LBA_of_first_error
# 1 Short offline Completed without error 00% 2085 -
SMART Selective self-test log data structure revision number 1
SPAN MIN_LBA MAX_LBA CURRENT_TEST_STATUS
1 0 0 Not_testing
2 0 0 Not_testing
3 0 0 Not_testing
4 0 0 Not_testing
5 0 0 Not_testing
256 0 65535 Read_scanning was never started
Selective self-test flags (0x0):
After scanning selected spans, do NOT read-scan remainder of disk.
If Selective self-test is pending on power-up, resume after 0 minute delay.
SCT Status Version: 3
SCT Version (vendor specific): 256 (0x0100)
Device State: Active (0)
Current Temperature: 28 Celsius
Power Cycle Min/Max Temperature: 23/28 Celsius
Lifetime Min/Max Temperature: 21/41 Celsius
Specified Max Operating Temperature: 70 Celsius
Under/Over Temperature Limit Count: 0/0
SMART Status: 0xc24f (PASSED)
SCT Temperature History Version: 2
Temperature Sampling Period: 10 minutes
Temperature Logging Interval: 10 minutes
Min/Max recommended Temperature: 0/70 Celsius
Min/Max Temperature Limit: 0/70 Celsius
Temperature History Size (Index): 128 (63)
Index Estimated Time Temperature Celsius
64 2025-10-21 19:50 ? -
... ..( 3 skipped). .. -
68 2025-10-21 20:30 ? -
69 2025-10-21 20:40 29 **********
70 2025-10-21 20:50 ? -
... ..( 2 skipped). .. -
73 2025-10-21 21:20 ? -
74 2025-10-21 21:30 27 ********
75 2025-10-21 21:40 ? -
... ..( 9 skipped). .. -
85 2025-10-21 23:20 ? -
86 2025-10-21 23:30 29 **********
87 2025-10-21 23:40 25 ******
88 2025-10-21 23:50 24 *****
... ..( 3 skipped). .. *****
92 2025-10-22 00:30 24 *****
93 2025-10-22 00:40 ? -
94 2025-10-22 00:50 29 **********
95 2025-10-22 01:00 29 **********
96 2025-10-22 01:10 30 ***********
97 2025-10-22 01:20 29 **********
98 2025-10-22 01:30 30 ***********
99 2025-10-22 01:40 30 ***********
100 2025-10-22 01:50 30 ***********
101 2025-10-22 02:00 31 ************
102 2025-10-22 02:10 30 ***********
103 2025-10-22 02:20 30 ***********
104 2025-10-22 02:30 29 **********
105 2025-10-22 02:40 29 **********
106 2025-10-22 02:50 29 **********
107 2025-10-22 03:00 30 ***********
108 2025-10-22 03:10 31 ************
109 2025-10-22 03:20 30 ***********
110 2025-10-22 03:30 30 ***********
111 2025-10-22 03:40 31 ************
112 2025-10-22 03:50 30 ***********
113 2025-10-22 04:00 30 ***********
114 2025-10-22 04:10 31 ************
115 2025-10-22 04:20 30 ***********
116 2025-10-22 04:30 29 **********
117 2025-10-22 04:40 29 **********
118 2025-10-22 04:50 30 ***********
119 2025-10-22 05:00 30 ***********
120 2025-10-22 05:10 29 **********
... ..( 3 skipped). .. **********
124 2025-10-22 05:50 29 **********
125 2025-10-22 06:00 ? -
126 2025-10-22 06:10 25 ******
127 2025-10-22 06:20 26 *******
0 2025-10-22 06:30 26 *******
1 2025-10-22 06:40 26 *******
2 2025-10-22 06:50 23 ****
3 2025-10-22 07:00 20 *
... ..( 9 skipped). .. *
13 2025-10-22 08:40 20 *
14 2025-10-22 08:50 21 **
... ..( 13 skipped). .. **
28 2025-10-22 11:10 21 **
29 2025-10-22 11:20 22 ***
... ..( 8 skipped). .. ***
38 2025-10-22 12:50 22 ***
39 2025-10-22 13:00 23 ****
... ..( 7 skipped). .. ****
47 2025-10-22 14:20 23 ****
48 2025-10-22 14:30 24 *****
... ..( 3 skipped). .. *****
52 2025-10-22 15:10 24 *****
53 2025-10-22 15:20 23 ****
... ..( 5 skipped). .. ****
59 2025-10-22 16:20 23 ****
60 2025-10-22 16:30 ? -
61 2025-10-22 16:40 28 *********
62 2025-10-22 16:50 24 *****
63 2025-10-22 17:00 23 ****
SCT Error Recovery Control:
Read: Disabled
Write: Disabled
Device Statistics (GP Log 0x04)
Page Offset Size Value Flags Description
0x01 ===== = = === == General Statistics (rev 1) ==
0x01 0x008 4 4080 --- Lifetime Power-On Resets
0x01 0x010 4 3243 --- Power-on Hours
0x01 0x018 6 25176669341 --- Logical Sectors Written
0x01 0x020 6 266257243 --- Number of Write Commands
0x01 0x028 6 54624281204 --- Logical Sectors Read
0x01 0x030 6 819765091 --- Number of Read Commands
0x01 0x038 6 622000 --- Date and Time TimeStamp
0x04 ===== = = === == General Errors Statistics (rev 1) ==
0x04 0x008 4 0 --- Number of Reported Uncorrectable Errors
0x04 0x010 4 1596 --- Resets Between Cmd Acceptance and Completion
0x05 ===== = = === == Temperature Statistics (rev 1) ==
0x05 0x008 1 28 --- Current Temperature
0x05 0x020 1 41 --- Highest Temperature
0x05 0x028 1 21 --- Lowest Temperature
0x05 0x058 1 70 --- Specified Maximum Operating Temperature
0x06 ===== = = === == Transport Statistics (rev 1) ==
0x06 0x008 4 13009 --- Number of Hardware Resets
0x06 0x010 4 0 --- Number of ASR Events
0x06 0x018 4 7157 --- Number of Interface CRC Errors
0x07 ===== = = === == Solid State Device Statistics (rev 1) ==
0x07 0x008 1 0 N-- Percentage Used Endurance Indicator
|||_ C monitored condition met
||__ D supports DSN
|___ N normalized value
Pending Defects log (GP Log 0x0c) not supported
SATA Phy Event Counters (GP Log 0x11)
ID Size Value Description
0x0001 2 0 Command failed due to ICRC error
0x0002 2 0 R_ERR response for data FIS
0x0003 2 0 R_ERR response for device-to-host data FIS
0x0004 2 0 R_ERR response for host-to-device data FIS
0x0005 2 0 R_ERR response for non-data FIS
0x0006 2 0 R_ERR response for device-to-host non-data FIS
0x0007 2 0 R_ERR response for host-to-device non-data FIS
0x0008 2 0 Device-to-host non-data FIS retries
0x0009 2 2 Transition from drive PhyRdy to drive PhyNRdy
0x000a 2 2 Device-to-host register FISes sent due to a COMRESET
0x000b 2 0 CRC errors within host-to-device FIS
0x000d 2 0 Non-CRC errors within host-to-device FIS
0x000f 2 0 R_ERR response for host-to-device data FIS, CRC
0x0010 2 0 R_ERR response for host-to-device data FIS, non-CRC
0x0012 2 0 R_ERR response for host-to-device non-data FIS, CRC
0x0013 2 0 R_ERR response for host-to-device non-data FIS, non-CRC
I dont see anything wrong with the drive. Yes it has quite a few CRC errors but those have not changed in any meaningful way since I have begun to use it. I have rebooted, and tried different spots in the hot swap bays. Has anyone seen anything like this before?
hyperion-diagnostics-20251022-1718.zip
