magonzalez112

I really appreciate your reply. Thank you. I guessed it was something related to that, because it mentions the whole time, macvlan and netfilter it's time to deploy vlans in my network. It´s something i always had pending. I think my network hardware is compatible. I've got an HP Procurve J9028B as my homelab switch and a Mikrotik router and a tp-link switch for the house rooms. I'm not an expert on vlans and I wouldn't like to lose connectivity, especially on the server and my workstation where I configure everything. Do you recommend any guide/book to start with ? Muchas gracias Jorge.

Hello I've been running Unraid 1 year rock solid, a few updates in between, no major issues. Some flaws with containers but I always got it working back using backups, but not this time. I can't figure out what's going on. Every couple of days my server freezes and I have to hard reset using button. At first I thought it was because I added 3 new disks and an HBA (LSI 9201-16e) but I removed and the sympthoms persisted. So I added them again. I didn't find anything rare in the logs until yesterday that I enabled mirror to the flash drive and today the problem appeared but it doesn't have hang yet. Feb 9 05:46:07 caronte kernel: ------------[ cut here ]------------ Feb 9 05:46:07 caronte kernel: WARNING: CPU: 3 PID: 30466 at net/netfilter/nf_conntrack_core.c:1120 __nf_conntrack_confirm+0x99/0x1e1 Feb 9 05:46:07 caronte kernel: Modules linked in: macvlan xt_CHECKSUM ipt_REJECT ip6table_mangle ip6table_nat iptable_mangle ip6table_filter ip6_tables vhost_net tun vhost vhost_iotlb tap veth xt_nat iptable_filter xfs nfsd lockd grace sunrpc md_mod nct6775 hwmon_vid iptable_nat xt_MASQUERADE nf_nat ip_tables wireguard curve25519_x86_64 libcurve25519_generic libchacha20poly1305 chacha_x86_64 poly1305_x86_64 ip6_udp_tunnel udp_tunnel libblake2s blake2s_x86_64 libblake2s_generic libchacha bonding mlx4_en mlx4_core e1000e x86_pkg_temp_thermal intel_powerclamp coretemp kvm_intel kvm btusb crct10dif_pclmul crc32_pclmul btrtl crc32c_intel btbcm ghash_clmulni_intel btintel aesni_intel bluetooth crypto_simd cryptd glue_helper mpt3sas rapl i2c_i801 video ecdh_generic ahci raid_class i2c_smbus backlight intel_cstate i2c_core scsi_transport_sas intel_uncore ecc libahci thermal button fan [last unloaded: mlx4_core] Feb 9 05:46:07 caronte kernel: CPU: 3 PID: 30466 Comm: kworker/3:8 Not tainted 5.10.1-Unraid #1 Feb 9 05:46:07 caronte kernel: Hardware name: OEGStone DQ77MK/DQ77MK, BIOS MKQ7710H.86A.0074.2018.1025.1727 10/25/2018 Feb 9 05:46:07 caronte kernel: Workqueue: events macvlan_process_broadcast [macvlan] Feb 9 05:46:07 caronte kernel: RIP: 0010:__nf_conntrack_confirm+0x99/0x1e1 Feb 9 05:46:07 caronte kernel: Code: e4 e3 ff ff 8b 54 24 14 89 c6 41 89 c4 48 c1 eb 20 89 df 41 89 de e8 54 e1 ff ff 84 c0 75 b8 48 8b 85 80 00 00 00 a8 08 74 18 <0f> 0b 89 df 44 89 e6 31 db e8 89 de ff ff e8 af e0 ff ff e9 1f 01 Feb 9 05:46:07 caronte kernel: RSP: 0018:ffffc90000138dd8 EFLAGS: 00010202 Feb 9 05:46:07 caronte kernel: RAX: 0000000000000188 RBX: 000000000000c741 RCX: 000000001c455466 Feb 9 05:46:07 caronte kernel: RDX: 0000000000000000 RSI: 0000000000000000 RDI: ffffffff8200a544 Feb 9 05:46:07 caronte kernel: RBP: ffff8882a9c30b40 R08: 0000000095c44e4d R09: ffff888071397780 Feb 9 05:46:07 caronte kernel: R10: 0000000000000000 R11: ffff88810d9e7c00 R12: 000000000000c4cd Feb 9 05:46:07 caronte kernel: R13: ffffffff8210da40 R14: 000000000000c741 R15: ffff8882a9c30b4c Feb 9 05:46:07 caronte kernel: FS: 0000000000000000(0000) GS:ffff88840dcc0000(0000) knlGS:0000000000000000 Feb 9 05:46:07 caronte kernel: CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 Feb 9 05:46:07 caronte kernel: CR2: 00001527e5ee8020 CR3: 000000000500c001 CR4: 00000000000606e0 Feb 9 05:46:07 caronte kernel: Call Trace: Feb 9 05:46:07 caronte kernel: <IRQ> Feb 9 05:46:07 caronte kernel: nf_conntrack_confirm+0x2f/0x36 Feb 9 05:46:07 caronte kernel: nf_hook_slow+0x39/0x8e Feb 9 05:46:07 caronte kernel: nf_hook.constprop.0+0xb1/0xd8 Feb 9 05:46:07 caronte kernel: ? ip_protocol_deliver_rcu+0xfe/0xfe Feb 9 05:46:07 caronte kernel: ip_local_deliver+0x49/0x75 Feb 9 05:46:07 caronte kernel: __netif_receive_skb_one_core+0x74/0x95 Feb 9 05:46:07 caronte kernel: process_backlog+0xa3/0x13b Feb 9 05:46:07 caronte kernel: net_rx_action+0xf4/0x29d Feb 9 05:46:07 caronte kernel: __do_softirq+0xc4/0x1c2 Feb 9 05:46:07 caronte kernel: asm_call_irq_on_stack+0xf/0x20 Feb 9 05:46:07 caronte kernel: </IRQ> Feb 9 05:46:07 caronte kernel: do_softirq_own_stack+0x2c/0x39 Feb 9 05:46:07 caronte kernel: do_softirq+0x3a/0x44 Feb 9 05:46:07 caronte kernel: netif_rx_ni+0x1c/0x22 Feb 9 05:46:07 caronte kernel: macvlan_broadcast+0x10e/0x13c [macvlan] Feb 9 05:46:07 caronte kernel: macvlan_process_broadcast+0xf8/0x143 [macvlan] Feb 9 05:46:07 caronte kernel: process_one_work+0x13c/0x1d5 Feb 9 05:46:07 caronte kernel: worker_thread+0x18b/0x22f Feb 9 05:46:07 caronte kernel: ? process_scheduled_works+0x27/0x27 Feb 9 05:46:07 caronte kernel: kthread+0xe5/0xea Feb 9 05:46:07 caronte kernel: ? kthread_unpark+0x52/0x52 Feb 9 05:46:07 caronte kernel: ret_from_fork+0x1f/0x30 Feb 9 05:46:07 caronte kernel: ---[ end trace e5dca96e95407d59 ]--- I attach the diagnostics zip and a more_logs.txt file where you can see errors similar to this trace in a loop. Until I pushed the button. Thank you in advance for your help. EDIT: Even this time I lost my install of nextcloud when this happened and I'm not able to get it running again using backups. At least I have a backup of the files. I get a connection refused when I try to access the frontend when I restore the database and nextcloud to a couple of weeks ago. caronte-diagnostics-20210209-2003.zip more_logs.txt

As far as I've been using it, a few months, I'm very happy. Easy to setup, easy to use, easy to maintain, there is a lot of applicantions ready to use (just fill the docker form)... Something that can be improved is the way you automate tasks. I mean, you can do it using the user scripts plugin, but it should be a better gui to do it, not everyone knows cron. I think it should be better integrated into the system with a fancy gui, some kind of enhanced scheduler where you can select a default/pre-created task from a list (parity-check, mover, ssd trim, speedtest, check for updates, check for problems ), and a custom task loading an script (check database integrity in a docker container, execute rclone to do a copy to a remote server... ). Everything in a single place and easy to see in the blink of an eye, similar to the docker table. So I expect to see a better scheduler.

For all those having problems and everything seems to be well configured. I figured out a dumb solution, I was hitting my head with the table (figuratively speaking) at the moment I got it working. Disable data saving on your android phone or iphone. Invite me a coffee I've been 2 hours trying different ports, different settings, removing tunnels, creating them again, reinstalling wireguard. All was fine... it was the damn phone. I hate this feeling.

I figured it out by myself... and I think I found some kind of bug on how Unraid manages NIC's. I just disabled secundary on board interface in the BIOS (My motherboard has 2 Gigabit on board), I did a reboot and voila. it's working I don't know really why, but I think, it is related to this: DOCKER_ENABLED="yes" DOCKER_IMAGE_FILE="/mnt/cache/docker.img" DOCKER_IMAGE_SIZE="25" DOCKER_APP_CONFIG_PATH="/mnt/cache/appdata" DOCKER_APP_UNRAID_PATH="" DOCKER_CUSTOM_NETWORKS="eth1 " DOCKER_LOG_ROTATION="yes" DOCKER_LOG_SIZE="50m" DOCKER_LOG_FILES="2" DOCKER_AUTHORING_MODE="no" DOCKER_USER_NETWORKS="remove" DOCKER_DHCP_BR0="192.168.1.128/25" That's my docker.cfg. Look at line 6: DOCKER_CUSTOM_NETWORKS="eth1 " With bonding enabled it was blank (it wasn't able to pull any data neither) and it filled itself with that value at the moment I disabled bonding, but it wasn't working, then I noticed that Unraid manages physical interfaces as eth0, eth1... Maybe that parameter was in conflict with my secundary NIC... So I think that there is a bug related to that, maybe Unraid is not prepared properly to handle multiple NIC's and docker... I would like to use the secundary NIC in a future, maybe I should experiment with that parameter, maybe setting it to eth2 does the trick. I expect this info is useful to someone. Unraid doesn't like dual NIC 😜 Now I will keep testing the system, I like pretty much all till now. I'll probably buy one license when trial mode ends.

Stopped docker and vm services, disabled bonding, restarted docker and vm, reboot, and there is no difference, I get the same error caronte-diagnostics-20190911-1642.zip

Hello I didnt want to open a thread about this but I'm getting mad trying to resolve it, more than a day reading the forum faq and other external forums. I installed Unraid a couple of days ago, it is on trial mode, I've not purchased it yet, but I think that's not the problem. My Unraid can't pull any docker image from Community Applications (I can install plugins) Neither from terminal (docker pull hello-world) I know what you are telling me...'"Change DNS to 8.8.8.8"", I already did on Unraid, on my router... Same error result, but instead 1.1.1.1:53 it says 8.8.8.8:53 I thought maybe it's not my network, so I tried docker on a windows desktop, and it was working in less than 20 minutes, then I thought maybe it's a problem with the server itself, so I run a debian vm, I installed docker and it was working ok. So I'm missing something and I don't know what. I tried Unraid 6.7.2 and 6.7.3rc2, same result. I don't know what else to do. caronte-diagnostics-20190911-1356.zip
