Tibbar Posted June 21, 2008 Share Posted June 21, 2008 Hi. I'm either blind or just can't find any info on setting up rsync between unraid and windows xp. Keep in mind that I'm complete noob when it come to Linux. Any info highly appreciated. Thanks. Quote Link to comment
brain:proxy Posted June 25, 2008 Share Posted June 25, 2008 I tried this many moons ago and it was a PAIN to find a suitable Windows rsync solution. Â I'll look around and see what I can find. Quote Link to comment
brain:proxy Posted June 25, 2008 Share Posted June 25, 2008 This seemed promising:  http://www.aboutmyip.com/AboutMyXApp/DeltaCopy.jsp  Also, you could install cygwin. Quote Link to comment
Tibbar Posted June 25, 2008 Author Share Posted June 25, 2008 Thanks for replying. I've tried Deltacopy with freenas server and it works fine. My problem is I do not know how to configure rsync on unraid system. Freenas has a nice graphical interface so for some one like me who knows squat about linux it was easy to configure. Did anybody ever written a guide how to do rsync on unraid? Thanks. Quote Link to comment
WeeboTech Posted June 25, 2008 Share Posted June 25, 2008 What are you trying to do with rsync on the unraid system?  Here's an example of my /etc/rsyncd.conf file it gets put in place from /boot/custom/etc/rsyncd.conf to /etc/rsyncd.conf  uid      = root gid      = root use chroot   = no max connections = 4 pid file    = /var/run/rsyncd.pid timeout    = 600 [backups]   path = /mnt/user/backups   comment = Backups   read only = FALSE [vmware]   path = /mnt/user/backups/vmware   comment = VMWare Backups   read only = FALSE [music]   path = /mnt/user/music   comment = Music   read only = FALSE [pub]   path = /mnt/user/pub   comment = Public Files   read only = FALSE [boot]   path = /boot   comment = /boot files   read only = FALSE [mnt]   path = /mnt   comment = /mnt files   read only = FALSE [Videos]   path = /mnt/user/Videos   comment = VIDEOS   read only = FALSE [bittorrent]   path = /mnt/user/bittorrent   comment = BITTORRENT   read only = FALSE   Here is a script I use to update /etc/inetd.conf so that it runs rsync when an rsync connection comes in.  It goes in /boot/custom/etc/rc.d/S20-init.rsyncd The call it from your /boot/config/go script.    #!/bin/bash if ! grep ^rsync /etc/inetd.conf > /dev/null ; then cat <<-EOF >> /etc/inetd.conf rsync stream tcp  nowait root  /usr/sbin/tcpd /usr/bin/rsync --daemon EOF read PID < /var/run/inetd.pid kill -1 ${PID} fi Quote Link to comment
WeeboTech Posted June 25, 2008 Share Posted June 25, 2008 You might want to look at unison http://www.cis.upenn.edu/~bcpierce/unison/index.html Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 Hi. Sorry for late reply. I would like to run rsync server on unraid system so I can run rsync clients to do backups to unraid. So : 1.Do I create file "rsyncd.conf" similar to yours and place it in /etc/rsyncd.conf 2.Create a file "S20-init.rsyncd" looking like this : #!/bin/bash  if ! grep ^rsync /etc/inetd.conf > /dev/null ; then cat <<-EOF >> /etc/inetd.conf rsync stream tcp  nowait root  /usr/sbin/tcpd /usr/bin/rsync --daemon EOF read PID < /var/run/inetd.pid kill -1 ${PID} fi and plce it in /boot/custom/etc/rc.d/ 3.What do you mean call it from /boot/config/go script Excuse my ignorance but linux is something completely new to me. Thanks   Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 >> 1. Do I create file "rsyncd.conf" similar to yours and place it in /etc/rsyncd.conf  Yes, but you will also need to copy and save this file somewhere on your flash drive. We recommend /boot/custom/etc. So you should have /etc/rsyncd.conf and /boot/custom/etc/rsyncd.conf which should be the same.  2 .Create a file "S20-init.rsyncd" looking like thi Yes. Create it as /boot/custom/etc/rc.d/S20-init.rsyncd  #!/bin/bash if ! grep ^rsync /etc/inetd.conf > /dev/null ; then cat <<-EOF >> /etc/inetd.conf rsync stream tcp  nowait root  /usr/sbin/tcpd /usr/bin/rsync --daemon EOF read PID < /var/run/inetd.pid kill -1 ${PID} fi cp /boot/custom/etc/rsyncd.conf /etc/rsyncd.conf  Notice the last line which copies the saved version of rsyncd.conf to the /etc directory.  >> 3.What do you mean call it from /boot/config/go script  THere is a script in the /boot/config directory called "go" Modify this script with your editor. Add the following line at the end of it to call S20-init.rsyncd  /boot/custom/etc/rc.d/S20-init.rsyncd  1 Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 Hi. Thanks for quick reply. I'm still missing something. Here is my rsyncd.config file gid = root uid = root use chroot = 4 max connections = 4 pid file = /var/run/rsyncd.pid timeout = 600 [backup]Â path = /mnt/disk1/Backup comment = Backup read only = FALSEÂ list = yes and her is my go file: #!/bin/bash # Start the Management Utility /usr/local/sbin/emhttp & /boot/init-powerdown ethtool -s eth0 wol g /boot/custom/etc/rc.d/S20-init.rsyncd but my rsync client does not communicate with rsync on unraid. I'm using unraid 4.3.1 is rsync build in or do I have to install it? Thanks Quote Link to comment
SSD Posted July 1, 2008 Share Posted July 1, 2008 A link to this thread has been added to the Best of the Forums (see link in my sig). Thanks to Tibbar and WeeboTech for providing a great "How To" that will benefit many other users!  We now return to the regularly scheduled thread ... 1 Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 User error I've mistyped a host name. Now I have established a connection in DeltaCopy client with rsync on "UNRAID" but for "Virtual directory name" I'm getting weird stuff like a text of a readme file. Any ideas? Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 I've no experience with Deltacopy. I know when using rsync it has a URI type interface as in  rsync://hostname/myshare/filename  myshare is the block defined as  [myshare] path = /mnt/disk1/myshare comment = Backup read only = FALSE list = yes  Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 Hi. What I mean by "Virtual directory name" is when I click the button to "Fetch virtual directories from the remote server" I thought I suppose to get a "backup" but 'm getting a text that looks like an rsync readme file. Thanks  Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 I've noticed something else. >> 1. Do I create file "rsyncd.conf" similar to yours and place it in /etc/rsyncd.conf  Yes, but you will also need to copy and save this file somewhere on your flash drive. We recommend /boot/custom/etc Do both locations of rsyncd.conf suppose to be on flash : /etc/rsyncd.conf /boot/custom/etc/rsyncd.conf because that is what I have. It seams that rsync is ignoring my rsyncd.conf . Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 >> Do both locations of rsyncd.conf suppose to be on flash :  no /etc is on the root filesystem /boot/custom/etc is on the flash.  if you edit the file in /etc then that's where it will exist. if you edit it in /boot/custom/etc. that's where it will exist.  Perhaps better to edit as /boot/custom/etc/rsyncd.conf then cp /boot/custom/etc/rsyncd.conf /etc/rsyncd.conf  Where and how are you doing the edit? Are you telneting in and editing with vi or doing it via windows? Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 I'm telneting with putty and then use mc. My rsyncd.conf file exists in both locations: /boot/custom/etc /etc To begin with I used mc within putty but I did not know how to create a new file so i just opened some file and edited it to look like rsyncd.conf and saved it as rsyncd.conf, was that OK? Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 What is a rsyncd.pid file. When I look inside /var/run that file does not exist. Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 Hi. Me again Am I supposed to make any entry to /etc/inetd.conf file ? Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 >> Am I supposed to make any entry to /etc/inetd.conf file ? Â The script S20-init.rsyncd does that for you. (or you could do it manually) Â >> What is a rsyncd.pid file. It's a semaphore file to signal the daemon is running. It will contact the active pid when rsync is running in daemon mode from inetd. it will only be there when you have an active rsync running. Â Â >> i just opened some file and edited it to look like rsyncd.conf and saved it as rsyncd.conf, was that OK? As long as it was saved as rsyncd.conf, that is fine. Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 Hi. Weebotech thanks for all the help and patience. Well I do not know what to do next. An error message I get from Deltacopy client is: Executing: rsync.exe -v -rlt -z --delete "/cygdrive/D/MKV/" "/tower::backup/MKV/" building file list ... done rsync: mkdir "/tower::backup/MKV" failed: No such file or directory (2) rsync error: error in file IO (code 11) at /home/lapo/packaging/tmp/rsync-2.6.6/main.c(422) rsync: connection unexpectedly closed (8 bytes received so far) [sender] rsync error: error in rsync protocol data stream (code 12) at /home/lapo/packaging/tmp/rsync-2.6.6/io.c(434) Error in rsync protocol data stream Rsync.exe returned an error. Will try again. This is retry number 1 of 5 My rsyncd.conf file has an entry like: [backup] path = /mnt/disk1/Backup comment = Backup read only = FALSE I've created a directory called "Backup" on disk1 and I'm trying to backup directory called MKV with Deltacopy client on Windows XP machine. Any ideas what to do next? Thanks.  Quote Link to comment
RobJ Posted July 1, 2008 Share Posted July 1, 2008 WeeboTech will probably be here soon with the more expert answer, and I haven't actually used rsync (!), but apart from that, wouldn't you want to use the UNC paths here? //tower/disk1/Backup/MKV Or if you have set up a User Share for Backup, then //tower/Backup/MKV Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 I do not define these paths. The way I understand it. I define the paths to the target directory with rsyncd.conf file and then deltacopy client fetches it from the server by the name whatever you call it ex. "myshare" [myshare] path = /mnt/disk1/myshare comment = Backup read only = FALSE list = yes but in my case communication with rsync server works but I can not fetch "myshare". Then again I might be wrong  Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 WeeboTech will probably be here soon with the more expert answer, and I haven't actually used rsync (!), but apart from that, wouldn't you want to use the UNC paths here? //tower/disk1/Backup/MKV Or if you have set up a User Share for Backup, then //tower/Backup/MKV  Proper syntax is  rsync://hostname/myshare/filename  Where Hostname is the destination Host (like http) Where myshare is the section defined in the /etc/rsyncd.conf file as in [myshare] Everything after myshare/ refers the the location appended to the path = /mnt/disk1/myshare  So If I had a section called /mnt  [mnt] path = /mnt  Then you could do a  rsync file... rsync://Tower/mnt/disk1/somedirectory/ Quote Link to comment
WeeboTech Posted July 1, 2008 Share Posted July 1, 2008 I do not define these paths. The way I understand it. I define the paths to the target directory with rsyncd.conf file and then deltacopy client fetches it from the server by the name whatever you call it ex. "myshare" [myshare] path = /mnt/disk1/myshare comment = Backup read only = FALSE list = yes but in my case communication with rsync server works but I can not fetch "myshare". Then again I might be wrong   On your Tower server type rsync://Tower Where Tower is equal to your real hostname.  On mine it is as follows  root@Atlas:/mnt/disk2/bittorrent# rsync rsync://Atlas backups    Backups vmware     VMWare Backups music     Music pub      Public Files boot      /boot files mnt      /mnt files Videos     VIDEOS bittorrent   BITTORRENT Quote Link to comment
Tibbar Posted July 1, 2008 Author Share Posted July 1, 2008 When I type at commend prompt on a server rsync://Tower I get a message: -bash: rsync://Tower: No such file or directory Tower is my UNRAID server name Quote Link to comment
