xfs on raid device showing I/O error, /dev/sd?1 device xfs shows fine

Recommended Posts

So I have has some cabling and controller issues, kept on losing parity, so disabled parity (i know I know) until I could get my replacement card in.

Re-cabled with new cables, had an issue with md1 (And the physical drive as well), rechecked power connections, same, then changed out whole new power connection for 4 drives and md1 came back fine, but now somewhere in the ups and downs the md4 device began having I/O errors, but the device (currently /dev/sdg1) xfs checks looks fine (-n so it wouldn't change anything).

I did the 'shrink array' method of rebuilding the array with new config, keep data, to see if that would 'fix' the error. Still no.

Since I do not have a parity right now, I am guessing it is safe to xfs_repair the non-md device (ie /dev/sdg1), and recover what I can, then just make a new config - keep files, and go from there?

Output from xfs_repair


root@media:~# xfs_repair -vn /dev/sdg1
Phase 1 - find and verify superblock...
        - block cache size set to 6157048 entries
Phase 2 - using internal log
        - zero log...
zero_log: head block 1233498 tail block 1233498
        - scan filesystem freespace and inode maps...
        - found root inode chunk
Phase 3 - for each AG...
        - scan (but don't clear) agi unlinked lists...
        - process known inodes and perform inode discovery...
        - agno = 0
        - agno = 1
        - agno = 2
        - agno = 3
        - process newly discovered inodes...
Phase 4 - check for duplicate blocks...
        - setting up duplicate extent list...
        - check for inodes claiming duplicate blocks...
        - agno = 0
        - agno = 2
        - agno = 1
        - agno = 3
No modify flag set, skipping phase 5
Phase 6 - check inode connectivity...
        - traversing filesystem ...
        - agno = 0
        - agno = 1
        - agno = 2
        - agno = 3
        - traversal finished ...
        - moving disconnected inodes to lost+found ...
Phase 7 - verify link counts...
No modify flag set, skipping filesystem flush and exiting.

        XFS_REPAIR Summary    Thu Apr  8 01:18:04 2021

Phase           Start           End             Duration
Phase 1:        04/08 01:17:39  04/08 01:17:39
Phase 2:        04/08 01:17:39  04/08 01:17:40  1 second
Phase 3:        04/08 01:17:40  04/08 01:17:56  16 seconds
Phase 4:        04/08 01:17:56  04/08 01:17:57  1 second
Phase 5:        Skipped
Phase 6:        04/08 01:17:57  04/08 01:18:04  7 seconds
Phase 7:        04/08 01:18:04  04/08 01:18:04

Total run time: 25 seconds
root@media:~# xfs_repair -vn /dev/md4
Phase 1 - find and verify superblock...
superblock read failed, offset 0, size 524288, ag 0, rval -1

fatal error -- Input/output error



Link to comment

The drives with read errors are on separate sas cables and different power segments, so I am thinking it is a mix of old drives and funkyness from my old controller.

My plan atm is removing the drives with the read errors from the drive pool, making a new config with the remaining drives, then mount -o ro,norecovery the other drives and moving the data over to the array. I have some spare drives to throw in to make more space so that should work out space wise. I know I may have some file corruption, anything of importance, like I said, is backed up already so I may just restore those shares that are important and worry about the rest on a case by case basis.

I am still open to feedback though, as that process will take a while and I wont start on it for a few days :D

Link to comment

I just took the faulty drives out of the array, rebuilt the new config, and copied over the data. Everything looked good, Once I get my new drives in for double parity and everything is good I will pre-clear the 'faulty' drives and see how that goes.


If I have issues with them I will make a new post, thanks for doing your awesome jobs! Very much appreciate everyone who helps out here in the community!

Much love!
