EArroyo Posted November 19, 2021 Posted November 19, 2021 (edited) My onbaord nic just died. I tried to use a TPLink USB 3.0 to Ethernet adapter but it did not work after booting it never shows MAC address. I returned the TPLink and got the UGREEN. Problem is, it will not get IP or DNS from DHCP server. I tried setting static IP but I get "No route to host." And I can't just slap on a PCIe because I am using them all... HORRIBLE USB Nic support.... UGH! BTW my router sees the USB Nic and shows the correct IP address I statically assigned to it. It's the "in-betweens" like routing and gateway stuff that's not allowing me to use my unRAID online. This is getting frustrating.... No dhclient, no systemctl, no nmcli, what can I do here? /etc/rc.d/rc.inet1 says RTNETLINK ansers: File exists / dhcpd already running. rc.inet1 restart doesn't work either, always gets a 169.254 ip address. 😤 I just tried a 10/100 USB 2.0 with same results. This does not seem to be hardware related. Can we get USB Nic support fixed? Edited November 19, 2021 by EArroyo Quote
EArroyo Posted November 20, 2021 Author Posted November 20, 2021 (edited) Can someone please tell me I did something wrong here so I can fix it? ifconfig (no bridge to simplify things) root@MMPC1:~# ifconfig eth0: flags=4163<UP,BROADCAST,RUNNING,MULTICAST> mtu 1500 inet 192.168.25.1 netmask 255.255.255.0 broadcast 192.168.25.255 ether 00:0e:c6:30:64:be txqueuelen 1000 (Ethernet) RX packets 21 bytes 4045 (3.9 KiB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 14531 bytes 835997 (816.4 KiB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 lo: flags=73<UP,LOOPBACK,RUNNING> mtu 65536 inet 127.0.0.1 netmask 255.0.0.0 inet6 ::1 prefixlen 128 scopeid 0x10<host> loop txqueuelen 1000 (Local Loopback) RX packets 77277 bytes 28890364 (27.5 MiB) RX errors 0 dropped 0 overruns 0 frame 0 TX packets 77277 bytes 28890364 (27.5 MiB) TX errors 0 dropped 0 overruns 0 carrier 0 collisions 0 route table root@MMPC1:~# route Kernel IP routing table Destination Gateway Genmask Flags Metric Ref Use Iface default 192.168.25.254 0.0.0.0 UG 209 0 0 eth0 192.168.25.0 0.0.0.0 255.255.255.0 U 209 0 0 eth0 ping gateway/router root@MMPC1:~# ping 192.168.25.254 PING 192.168.25.254 (192.168.25.254) 56(84) bytes of data. From 192.168.25.1 icmp_seq=1 Destination Host Unreachable From 192.168.25.1 icmp_seq=2 Destination Host Unreachable From 192.168.25.1 icmp_seq=5 Destination Host Unreachable From 192.168.25.1 icmp_seq=6 Destination Host Unreachable ^C --- 192.168.25.254 ping statistics --- 7 packets transmitted, 0 received, +4 errors, 100% packet loss, time 6175ms pipe 4 ping local IP root@MMPC1:~# ping 192.168.25.1 PING 192.168.25.1 (192.168.25.1) 56(84) bytes of data. 64 bytes from 192.168.25.1: icmp_seq=1 ttl=64 time=0.019 ms 64 bytes from 192.168.25.1: icmp_seq=2 ttl=64 time=0.050 ms 64 bytes from 192.168.25.1: icmp_seq=3 ttl=64 time=0.049 ms ^C --- 192.168.25.1 ping statistics --- 3 packets transmitted, 3 received, 0% packet loss, time 2053ms rtt min/avg/max/mdev = 0.019/0.039/0.050/0.014 ms Edited November 20, 2021 by EArroyo Quote
trurl Posted November 20, 2021 Posted November 20, 2021 33 minutes ago, EArroyo said: Can someone please tell me I did something wrong here so I can fix it? Is that after giving up on USB NIC and using a real NIC? Quote
EArroyo Posted November 20, 2021 Author Posted November 20, 2021 (edited) 12 minutes ago, trurl said: Is that after giving up on USB NIC and using a real NIC? No, can't give up on USB NIC, I don't have PCIe available on machine and both VM's are legit Windows 10 (now Windows 11) and Server 2019 licenses I paid money for and don't want to replace MB and have to purchase licenses again. This is with USB NIC. Is there something I should know about USB NICs and unRAID? I read UGREEN were compatible, but not sure if that is true with unRAID v6? Edited November 20, 2021 by EArroyo Quote
EArroyo Posted November 20, 2021 Author Posted November 20, 2021 (edited) ethtool root@MMPC1:/etc/rc.d# ethtool eth0 Settings for eth0: Supported ports: [ TP MII ] Supported link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Half 1000baseT/Full Supported pause frame use: No Supports auto-negotiation: Yes Supported FEC modes: Not reported Advertised link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Advertised pause frame use: No Advertised auto-negotiation: Yes Advertised FEC modes: Not reported Link partner advertised link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Link partner advertised pause frame use: Symmetric Receive-only Link partner advertised auto-negotiation: Yes Link partner advertised FEC modes: Not reported Speed: 1000Mb/s Duplex: Full Auto-negotiation: on Port: MII PHYAD: 3 Transceiver: internal Supports Wake-on: pg Wake-on: g Current message level: 0x00000007 (7) drv probe link Link detected: yes arp -a root@MMPC1:~# arp -a ? (192.168.25.254) at <incomplete> on eth0 What's very intriguing is from VM I can actually access 192.168.25 network, but not from outside... Is there a firewall block maybe??? I'm out of ideas.... UGH! EDIT: BTW, I just tried bridged (br0) and I get same results... Edited November 20, 2021 by EArroyo Quote
SimonF Posted November 20, 2021 Posted November 20, 2021 (edited) 3 hours ago, EArroyo said: BTW, I just tried bridged (br0) and I get same results... Do you have bonding enabled as my Qnap usb device doesnt like bonding being enabled for the ethx device Edited November 20, 2021 by SimonF Quote
EArroyo Posted November 21, 2021 Author Posted November 21, 2021 On 11/20/2021 at 1:15 PM, SimonF said: Do you have bonding enabled as my Qnap usb device doesnt like bonding being enabled for the ethx device No, I don't. Quote
EArroyo Posted November 21, 2021 Author Posted November 21, 2021 (edited) Is there a list of compatible PCI (not PCI-e) adapter? I found 3 on Amazon: https://www.amazon.com/gp/product/B0000XKBQU D-Link DGE-530T (unknown M-TEK chipset) https://www.amazon.com/gp/product/B0000TO0BQ StarTech ST1000BT32 (RTL8110SC chipset) https://www.amazon.com/gp/product/B00YSNWLAC X-MEDIA XM-NA3500 (RTL8169SC chipset) I am not using any PCI cards, so hopefully I get the 1000 speed... It's an ASUS MSA97 R2.0 motherboard. Haven't even checked specs of bridges... EDIT: Ordered the StarTech, I've had good results with StarTech and RealTek products before... We shall see... BUT this USB 3.0 NIC support really stinks... Edited November 21, 2021 by EArroyo Quote
