TheImmatureAdmin Posted March 25 Share Posted March 25 First time Unraid user, and so far have loved the product. With the issues I have right now though, the server is all but unusable. I'm currently running Unraid 6.12.8, but this problem seems to have started before upgrading. After building this machine in January, it ran for nearly 1 month without any crashes or restarts. Slowly it started having issues where it would crash/hang every week to every few days. It started getting worse and worse. Now, the only way the machine will run is if I do not start Docker. Almost immediately after starting Docker and my containers start spinning up, the system will crash. When this happens, it doesn't restart - it is just frozen and is not accessible from the network. About a month ago, I enabled persistence of the syslog so I could see what is going on. It seems like mostly there are segfaults and "unable to access opcode bytes at [HEX ADDRESS]". Based on the countless reboots, changing of BIOS settings, and google searches, I've come to the conclusion that there is most likely a hardware issue with the CPU or MOBO. I should mention that I ran memtest for 24+ hours with multiple passes and there were no errors. Before setting up my pool of HDDs, I ran the SMART test on each and they all passed without issues. Will someone please take a look at my logs/diagnostics and see if anything stands out? I'm hoping that there is something I'm missing that'll fix this issue, but if all signs are pointing to CPU/motherboard failure then I will start replacing those. Please let me know if there are any questions, logs, or other info I can provide to help. ligma-diagnostics-20240325-1144.zip syslog-192.168.3.93 (1).log Quote Link to comment
JorgeB Posted March 25 Share Posted March 25 Based on the errors, and since memtest is only definitive if it finds an error, I would run the server with just one stick of RAM, if the same try the other one, that will basically rule out a RAM issue, and board/CPU would be the next suspects. 1 Quote Link to comment
TheImmatureAdmin Posted March 25 Author Share Posted March 25 (edited) 3 hours ago, JorgeB said: Based on the errors, and since memtest is only definitive if it finds an error, I would run the server with just one stick of RAM, if the same try the other one, that will basically rule out a RAM issue, and board/CPU would be the next suspects. Thank you for the feedback! I tested with each stick of memory by itself and reproduced the same results both times. I actually tried the first stick by itself yesterday, but never tried the second stick by itself until today. Both times, however, the server locks up almost immediately after Docker is enabled and my containers start running. If there is anything new in the logs I'll post them here. Sometimes it seems like there isn't a segfault or error at all in the logs. All I see are normal log messages and then log messages from after I press the restart button. From what I've read, that can happen when a hardware failure is the root cause. EDIT: I have attached the latest syslog. For reference, below is a snippet of the log which I believe captures when I enabled docker until the server hung up (tried to remove some lines so it wasn't too long). Mar 25 16:41:58 Ligma ool www[24269]: /usr/local/emhttp/plugins/dynamix/scripts/emcmd 'cmdStatus=Apply' ... ...**applying settings to enable docker** ... Mar 25 16:42:01 Ligma emhttpd: shcmd (961): /etc/rc.d/rc.docker start Mar 25 16:42:01 Ligma root: starting dockerd ... Mar 25 16:42:01 Ligma avahi-daemon[31534]: Server startup complete. Host name is Ligma.local. Local service cookie is 335134691. ... ...**containers starting - I left the last container start message as a reference for time** ... Mar 25 16:42:12 Ligma rc.docker: vaultwarden: started succesfully! Mar 25 16:42:14 Ligma kernel: kernel tried to execute NX-protected page - exploit attempt? (uid: 99) Mar 25 16:42:14 Ligma kernel: BUG: unable to handle page fault for address: ffff88834158f000 Mar 25 16:42:14 Ligma kernel: #PF: supervisor instruction fetch in kernel mode Mar 25 16:42:14 Ligma kernel: #PF: error_code(0x0011) - permissions violation Mar 25 16:42:14 Ligma kernel: PGD 4c01067 P4D 4c01067 PUD 80000003400001e3 Mar 25 16:42:14 Ligma kernel: Oops: 0011 [#1] PREEMPT SMP NOPTI Mar 25 16:42:14 Ligma kernel: CPU: 12 PID: 9735 Comm: python3 Tainted: P O 6.1.74-Unraid #1 Mar 25 16:42:14 Ligma kernel: Hardware name: Micro-Star International Co., Ltd. MS-7D91/MAG Z790 TOMAHAWK WIFI (MS-7D91), BIOS H.B3 03/13/2024 Mar 25 16:42:14 Ligma kernel: RIP: 0010:0xffff88834158f000 Mar 25 16:42:14 Ligma kernel: Code: 7a 99 32 d3 32 f3 9d fa 9d fa 6c fa 7c fa 36 e6 36 e6 f2 02 f2 02 a7 54 ed 44 19 60 09 70 b8 64 d2 b5 90 9f 84 9f b9 af b1 af <00> 00 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 0c 00 Mar 25 16:42:14 Ligma kernel: RSP: 0018:ffffc9000c723e90 EFLAGS: 00010046 Mar 25 16:42:14 Ligma kernel: RAX: 0000000000000000 RBX: ffff88834158f000 RCX: 0000000000000000 Mar 25 16:42:14 Ligma kernel: RDX: 0000000000000000 RSI: ffffffff8214ded8 RDI: ffffffff82102b9a Mar 25 16:42:14 Ligma kernel: RBP: ffff88885f32e200 R08: 0000000000000000 R09: 00001543e7fd8b80 Mar 25 16:42:14 Ligma kernel: R10: 00000000000002db R11: 0000000000000000 R12: ffff88834158f000 Mar 25 16:42:14 Ligma kernel: R13: 0000000000000000 R14: 0000000000000000 R15: 0000000000000000 Mar 25 16:42:14 Ligma kernel: FS: 00001543e5ffe6c0(0000) GS:ffff88885f300000(0000) knlGS:0000000000000000 Mar 25 16:42:14 Ligma kernel: CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 Mar 25 16:42:14 Ligma kernel: CR2: ffff88834158f000 CR3: 0000000314402000 CR4: 0000000000750ee0 Mar 25 16:42:14 Ligma kernel: PKRU: 55555554 Mar 25 16:42:14 Ligma kernel: Call Trace: Mar 25 16:42:14 Ligma kernel: <TASK> Mar 25 16:42:14 Ligma kernel: ? __die_body+0x1a/0x5c Mar 25 16:42:14 Ligma kernel: ? page_fault_oops+0x329/0x376 Mar 25 16:42:14 Ligma kernel: ? exc_page_fault+0xf4/0x11d Mar 25 16:42:14 Ligma kernel: ? asm_exc_page_fault+0x22/0x30 Mar 25 16:42:14 Ligma kernel: ? __schedule+0xa9/0x612 Mar 25 16:42:14 Ligma kernel: ? _raw_spin_lock+0x13/0x1c Mar 25 16:42:14 Ligma kernel: ? schedule+0x8e/0xcc Mar 25 16:42:14 Ligma kernel: ? __do_sys_sched_yield+0xa/0x11 Mar 25 16:42:14 Ligma kernel: ? do_syscall_64+0x68/0x81 Mar 25 16:42:14 Ligma kernel: ? entry_SYSCALL_64_after_hwframe+0x64/0xce Mar 25 16:42:14 Ligma kernel: </TASK> Mar 25 16:42:14 Ligma kernel: Modules linked in: ipvlan veth xt_nat nf_conntrack_netlink nfnetlink xfrm_user xfrm_algo xt_addrtype br_netfilter xt_CHECKSUM xt_MASQUERADE xt_conntrack ipt_REJECT nf_reject_ipv4 xt_tcpudp ip6table_mangle ip6table_nat iptable_mangle iptable_nat nf_nat nf_conntrack nf_defrag_ipv6 nf_defrag_ipv4 vhost_net tun vhost vhost_iotlb tap md_mod ip6table_filter ip6_tables iptable_filter ip_tables x_tables efivarfs af_packet 8021q garp mrp bridge stp llc bonding tls i915 zfs(PO) intel_rapl_msr intel_rapl_common x86_pkg_temp_thermal intel_powerclamp coretemp input_leds iosf_mbi drm_buddy i2c_algo_bit kvm_intel ttm zunicode(PO) btusb drm_display_helper btrtl btbcm kvm btintel drm_kms_helper zzstd(O) bluetooth drm crct10dif_pclmul crc32_pclmul crc32c_intel ghash_clmulni_intel sha512_ssse3 sha256_ssse3 sha1_ssse3 zlua(O) aesni_intel hid_apple crypto_simd ecdh_generic joydev led_class zavl(PO) ecc i2c_i801 cryptd intel_gtt icp(PO) zcommon(PO) znvpair(PO) rapl spl(O) mei_hdcp mei_pxp Mar 25 16:42:14 Ligma kernel: intel_cstate wmi_bmof mxm_wmi intel_uncore agpgart i2c_smbus nvme igc mei_me i2c_core ahci nvme_core syscopyarea mei libahci sysfillrect sysimgblt thermal fb_sys_fops video fan tpm_crb tpm_tis tpm_tis_core tpm backlight wmi intel_pmc_core acpi_pad acpi_tad button unix Mar 25 16:42:14 Ligma kernel: CR2: ffff88834158f000 Mar 25 16:42:14 Ligma kernel: ---[ end trace 0000000000000000 ]--- Mar 25 16:42:14 Ligma kernel: RIP: 0010:0xffff88834158f000 Mar 25 16:42:14 Ligma kernel: Code: 7a 99 32 d3 32 f3 9d fa 9d fa 6c fa 7c fa 36 e6 36 e6 f2 02 f2 02 a7 54 ed 44 19 60 09 70 b8 64 d2 b5 90 9f 84 9f b9 af b1 af <08> 40 00 00 00 00 00 00 01 00 00 00 00 00 00 00 00 00 00 00 0c 00 Mar 25 16:42:14 Ligma kernel: RSP: 0018:ffffc9000c723e90 EFLAGS: 00010046 Mar 25 16:42:14 Ligma kernel: RAX: 0000000000000000 RBX: ffff88834158f000 RCX: 0000000000000000 Mar 25 16:42:14 Ligma kernel: RDX: 0000000000000000 RSI: ffffffff8214ded8 RDI: ffffffff82102b9a Mar 25 16:42:14 Ligma kernel: RBP: ffff88885f32e200 R08: 0000000000000000 R09: 00001543e7fd8b80 Mar 25 16:42:14 Ligma kernel: R10: 00000000000002db R11: 0000000000000000 R12: ffff88834158f000 Mar 25 16:42:14 Ligma kernel: R13: 0000000000000000 R14: 0000000000000000 R15: 0000000000000000 Mar 25 16:42:14 Ligma kernel: FS: 00001543e5ffe6c0(0000) GS:ffff88885f300000(0000) knlGS:0000000000000000 Mar 25 16:42:14 Ligma kernel: CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 Mar 25 16:42:14 Ligma kernel: CR2: ffff88834158f000 CR3: 0000000314402000 CR4: 0000000000750ee0 Mar 25 16:42:14 Ligma kernel: PKRU: 55555554 Mar 25 16:42:14 Ligma kernel: note: python3[9735] exited with irqs disabled Mar 25 16:42:14 Ligma kernel: note: python3[9735] exited with preempt_count 1 syslog-192.168.3.93 (2).log Edited March 25 by TheImmatureAdmin adding log snippet and latest syslog Quote Link to comment
ZarZ Posted March 26 Share Posted March 26 I have also been experiencing similar issues. hoping to see if you find resolution. I was also told to test ram, tested both together, then seperate for over 24hrs each time. No errors only passes. Did you issues start about 2-3 weeks ago? I Also have a Z-790 motherboard, but ASUS. Is your ram DDR5? 1 Quote Link to comment
TheImmatureAdmin Posted March 26 Author Share Posted March 26 I believe my issues started more than 3 weeks ago. I turned rsyslog on to start having logs saved around March 1st, and my problems started 1-2 weeks before that. In total, about 4-5 weeks ago. Yes, my RAM is DDR5. It is some cheap G.Skill RAM that runs at 5600 with XMP but 4800 with XMP turned off. I've tried with XMP enabled and without, both ways still causes the hang. Everything was working great for about 1 month straight after I initially set up the server, then it started crapping out. Quote Link to comment
JorgeB Posted March 26 Share Posted March 26 13 hours ago, TheImmatureAdmin said: Both times, however, the server locks up almost immediately after Docker is enabled and my containers start running. Try to see if it's a specific container, start them one by one and let the server run a while before starting the next one. Quote Link to comment
TheImmatureAdmin Posted March 26 Author Share Posted March 26 4 hours ago, JorgeB said: Try to see if it's a specific container, start them one by one and let the server run a while before starting the next one. Is there a way to stop containers from automatically starting first? Once I enable Docker, the containers start up and the server hangs faster than I can go in and disable/stop them. Short of deleting the docker image and clearing out templates, I haven't found a way to prevent them from starting automatically. Hopefully there is an easy way that I'm missing, but if I need to start fresh with my containers then no problem. That is easier than replacing the mobo/cpu. Quote Link to comment
JorgeB Posted March 26 Share Posted March 26 You can easily recreate the docker image and re-add the containers, they will default to autostart disabled: https://docs.unraid.net/unraid-os/manual/docker-management/#re-create-the-docker-image-file Also see below if you have any custom docker networks: https://docs.unraid.net/unraid-os/manual/docker-management/#docker-custom-networks 1 Quote Link to comment
TheImmatureAdmin Posted March 27 Author Share Posted March 27 (edited) 11 hours ago, JorgeB said: You can easily recreate the docker image and re-add the containers, they will default to autostart disabled: https://docs.unraid.net/unraid-os/manual/docker-management/#re-create-the-docker-image-file Also see below if you have any custom docker networks: https://docs.unraid.net/unraid-os/manual/docker-management/#docker-custom-networks Thanks, I didn't realize that was so easy. I added back most of the containers, spacing them out a bit. The server was stable for hours until I added Plex back. The plex container caused the system to crash not longer after setting it up. For most of the containers, I kept the original template and appdata from before. For Plex, I started fresh and started re-importing the libraries again (I thought maybe some automatic media optimization I setup in Plex could have been causing it, so I wanted to be sure that was gone). Nonetheless, within about 15 minutes the server hung and was unresponsive again. This time, the syslog doesn't seem to capture any error or segfault, it just stops until the system is restarted (at Mar 26 19:46:39 in the log). I also wasn't able to get Unraid to boot until I made some minor modifications in the BIOS, saved, and restarted. That pattern has happened before, after a crash the system won't boot until I make a BIOS change. It could be just turning XMP on, or turning XMP off. Either way, the change allows me to boot back up. No idea what is going on there. I wonder if maybe this is still a hardware issue given that I started fresh with Plex, the weird BIOS boot problem, and the lack of anything in syslog. Maybe Plex is the only container triggering it because it is using more resources than the other containers (more power/memory/cpu/etc)? I have attached the most recent logs and diagnostics. Thank you again for all your help! ligma-diagnostics-20240326-2315.zip syslog-192.168.3.93 (3).log Edited March 27 by TheImmatureAdmin clarification on stability, time of restart in log Quote Link to comment
ZarZ Posted March 27 Share Posted March 27 On 3/25/2024 at 11:28 PM, TheImmatureAdmin said: I believe my issues started more than 3 weeks ago. I turned rsyslog on to start having logs saved around March 1st, and my problems started 1-2 weeks before that. In total, about 4-5 weeks ago. Yes, my RAM is DDR5. It is some cheap G.Skill RAM that runs at 5600 with XMP but 4800 with XMP turned off. I've tried with XMP enabled and without, both ways still causes the hang. Everything was working great for about 1 month straight after I initially set up the server, then it started crapping out. This is exactly how mine has been, ran great for about 2 months, maybe less. then crashes with uptimes less than 2hrs. Also using have GSkill 5600 but 2x48GB sticks, same chipset Z-790 but ASUS board, same 14900-K CPU. I also have XMP off, Multicore enhancement to enforce all limits, fast boot off, etc. Very similar hardware with exactly same crashes, freezes and even the syslogs are looking the same. as far as dockers I am only running Plex anymore. I have even tried BIOS updates. syslog-127.0.0.1 (2).log Quote Link to comment
JorgeB Posted March 27 Share Posted March 27 Plex container has been known to crash servers, could be misconfigured or showing an existing issue. Quote Link to comment
TheImmatureAdmin Posted March 27 Author Share Posted March 27 (edited) 4 hours ago, JorgeB said: Plex container has been known to crash servers, could be misconfigured or showing an existing issue. Any thoughts on why Unraid won't boot until I make a change in the BIOS after a crash like that? EDIT: I found this thread which says to disable the "fast boot" feature. This is probably my boot issue. I'll give that a shot and see if I can restart after a crash. Edited March 27 by TheImmatureAdmin found potential boot issue solution Quote Link to comment
Solution ZarZ Posted March 27 Solution Share Posted March 27 Found this last night after I found out it was also crashing Windows. Appears to be a plex issue. https://forums.plex.tv/t/end-credits-detection-causing-windows-crash-bsod/870270/4 Quote Link to comment
TheImmatureAdmin Posted March 29 Author Share Posted March 29 Much appreciation to @JorgeB and @ZarZ. The problem was narrowed down to Plex and the link above isolated the configuration causing the problem. I turned off End Credit Detection for my libraries and have now been running for 24 hours without a crash. If anything changes, I'll update here. This may still partly have to do with hardware since most, if not all, of the people experiencing issues with credit detection were running Core i9 K-series processors, e.g. Core i9-14900K. Apparently there is some instability with those processors and issues may also be resolved by changing power limit and voltage settings to keep the processor stable under higher loads. So far I haven't touched those settings in the BIOS, but that'll be my next step if the problems start back up. 1 Quote Link to comment
ZarZ Posted March 29 Share Posted March 29 2 hours ago, TheImmatureAdmin said: Much appreciation to @JorgeB and @ZarZ. The problem was narrowed down to Plex and the link above isolated the configuration causing the problem. I turned off End Credit Detection for my libraries and have now been running for 24 hours without a crash. If anything changes, I'll update here. This may still partly have to do with hardware since most, if not all, of the people experiencing issues with credit detection were running Core i9 K-series processors, e.g. Core i9-14900K. Apparently there is some instability with those processors and issues may also be resolved by changing power limit and voltage settings to keep the processor stable under higher loads. So far I haven't touched those settings in the BIOS, but that'll be my next step if the problems start back up. I am glad I was able to help, If you dont mind, Curious on your temps and cooler for your 14900k. Also more info about our issues. I'm actually thinking of downgrading sadly till they resolve all this. I'm just glad i was able to help both of us know its not Unraid or hardware failures per say. https://www.tomshardware.com/video-games/pc-gaming/outpost-infinity-siege-devs-ask-13900k-14900k-owners-to-downclock-their-chips-to-prevent-crashing Quote Link to comment
TheImmatureAdmin Posted April 1 Author Share Posted April 1 On 3/29/2024 at 7:23 PM, ZarZ said: I am glad I was able to help, If you dont mind, Curious on your temps and cooler for your 14900k. Also more info about our issues. I'm actually thinking of downgrading sadly till they resolve all this. I'm just glad i was able to help both of us know its not Unraid or hardware failures per say. https://www.tomshardware.com/video-games/pc-gaming/outpost-infinity-siege-devs-ask-13900k-14900k-owners-to-downclock-their-chips-to-prevent-crashing I just installed the Dynamix System Temp plugin, so I don't know what my temps look like under load. Right now at idle, it looks like my CPU is at 40 C. My cooler is the Noctua NH-D12L which is one of the few air coolers that fit in my 4U case (RSV-L4411). I also have three 120mm intake and two 80mm exhaust case fans. Quote Link to comment
ZarZ Posted April 2 Share Posted April 2 On 4/1/2024 at 11:44 AM, TheImmatureAdmin said: I just installed the Dynamix System Temp plugin, so I don't know what my temps look like under load. Right now at idle, it looks like my CPU is at 40 C. My cooler is the Noctua NH-D12L which is one of the few air coolers that fit in my 4U case (RSV-L4411). I also have three 120mm intake and two 80mm exhaust case fans. WOW, even the same cooler as me lol. I have a HL-15, its a mini-storinator, but otherwise almost identical builds. I am temped to try and squeeze an AIO cooler in there somehow. Quote Link to comment
TheImmatureAdmin Posted April 18 Author Share Posted April 18 One more update! I started having issues again, but this time not with Plex. I added Immich to my server and the CPU load was high enough while running Face Detection to cause the same type of crashing. The issue is 100% with the Core i9-14900k. Ultimately, I resolved it by changing the "Loadline Calibration Control" in the BIOS to mode 7. Depending on the motherboard, this setting may be called "LLC" or "LCC". The value may be called "Mode 7", "L7", or similar. Effectively, it adjusts the voltage curve for the CPU when under load. Other values may work as well, but that value increases the voltage curve high enough so the voltage drop under load doesn't destabilize the CPU. After changing that, I have had zero issues. I was able to run face detection on 30k+ photos and videos. I am contemplating turning Credit Detection back on in Plex now as well, I'm sure it will not cause the server to crash anymore (at least, not because of the CPU). Thanks again to @ZarZ for finding this thread. It had the first mention of LLC as being a solution that I saw. https://forums.plex.tv/t/end-credits-detection-causing-windows-crash-bsod/870270/8 I also found helpful information here: https://community.intel.com/t5/Processors/Solved-Stability-issue-with-proc-I9-14900K-crash-BSOD/td-p/1574516 1 Quote Link to comment
ZarZ Posted April 20 Share Posted April 20 On 4/18/2024 at 10:13 AM, TheImmatureAdmin said: Thanks again to @ZarZ for finding this thread. I'm just glad I was about to save at least one person the stress i had while figuring it out. When I was trying to figure it out, it was VERY frustrating. Quote Link to comment
ZarZ Posted Tuesday at 06:41 AM Share Posted Tuesday at 06:41 AM On 4/18/2024 at 10:13 AM, TheImmatureAdmin said: One more update! I started having issues again, but this time not with Plex. I added Immich to my server and the CPU load was high enough while running Face Detection to cause the same type of crashing. The issue is 100% with the Core i9-14900k. Ultimately, I resolved it by changing the "Loadline Calibration Control" in the BIOS to mode 7. Depending on the motherboard, this setting may be called "LLC" or "LCC". The value may be called "Mode 7", "L7", or similar. Effectively, it adjusts the voltage curve for the CPU when under load. Other values may work as well, but that value increases the voltage curve high enough so the voltage drop under load doesn't destabilize the CPU. After changing that, I have had zero issues. I was able to run face detection on 30k+ photos and videos. I am contemplating turning Credit Detection back on in Plex now as well, I'm sure it will not cause the server to crash anymore (at least, not because of the CPU). Thanks again to @ZarZ for finding this thread. It had the first mention of LLC as being a solution that I saw. https://forums.plex.tv/t/end-credits-detection-causing-windows-crash-bsod/870270/8 I also found helpful information here: https://community.intel.com/t5/Processors/Solved-Stability-issue-with-proc-I9-14900K-crash-BSOD/td-p/1574516 So for my motherboard ASUS just released a BIOS update that added some Intel Stability toggle for our CPUs, it changed a bunch of BIOS settings, I then did the Plex update with the credits and loudness fix, and also deleted the contents of my plex/drivers folder, and also deleted the contents of the plex/codecs folder, except the .device_id file. the files in those folders were data from around the time the problems started, and pre this last update so i wanted fresh ones pulled down. Restarted the plex docker, it pulled new drivers and codevs and its been solid ever since, even with all the scanner options on. Hope this helps further. Quote Link to comment
