  1. For anyone interested in using the MaxMinds GeoIP2 functionality, here is a phenomenal blog post that covers how to do it! Thanks @GilbN https://technicalramblings.com/blog/blocking-countries-with-geolite2-using-the-letsencrypt-docker-container/#disqus_thread
  2. Don't forget you need to map that same directory where your bitwarden log file is into your swag container. Then also make sure the path in the bitwarden_rs.conf file for fail2ban has the same "container" path. This is mine for example: Bitwarden (I manually created the dir and made it nobody:users 777 since bitwarden seems to be running/setting root for all 🙂 ) Swag: Swag fail2ban / filter.d / bitwarden_rs.conf file: # https://github.com/dani-garcia/bitwarden_rs/wiki/Fail2Ban-Setup # - Set up logging to file > https://github.com/dani-garcia/bitwarden_rs/wiki/Logging # - Set logging level to warn or error # Logged in /bitwarden-log/bitwarden.log [Definition] failregex = Username or password is incorrect\. Try again\. IP: <HOST>\. Username: .*\.$ ignoreregex = Swag / fail2ban / jail.local file entry: [bitwarden_rs] enabled = true port = http,https filter = bitwarden_rs logpath = /bitwarden-log/bitwarden.log bantime = 3600 findtime = 3600 maxretry = 3
  3. Just letting you know you're not alone 🙂, I have been seeing the same. Typically for me just a "Check for updates" reestablishes the connection. I haven't looked any further into it other than that.
  4. @ich777 I found a url from Nvidia that always displays the latest Linux x86 driver. Maybe it can come in handy for something? http://download.nvidia.com/XFree86/Linux-x86_64/latest.txt
  5. @ich777 Once again that Kernel Docker worked awesome 🙂 My notes: # Needed to enable i2cdetect modprobe i2c-dev # Detect current smbus(s) i2cdetect -l | grep smbus # Detect against all until you find 50-57 range, that is your bus (0,1,2,3, etc....) i2cdetect -y 0 0x50 0x57 # Enable the device (per module), path matches bus number echo ee1004 0x50 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x51 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x52 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x53 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x54 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x55 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x56 > /sys/bus/i2c/devices/i2c-0/new_device echo ee1004 0x57 > /sys/bus/i2c/devices/i2c-0/new_device # Display info decode-dimms # Display info side-by-side decode-dimms --side-by-side # Display DIE version (replacing 0-0050 with the i2c bus number followed by a dash then the memory bank number) od -Ax -t x1 -v /sys/bus/i2c/drivers/ee1004/0-0050/eeprom root@noah:~# decode-dimms --side-by-side # decode-dimms version i2c-tools 4.1 Memory Serial Presence Detect Decoder By Philip Edelbrock, Christian Zuckschwerdt, Burkart Lingner, Jean Delvare, Trent Piepho, Hans Geiblinger and others Decoding EEPROM 0-0050 0-0051 0-0052 0-0053 0-0054 0-0055 0-0056 0-0057 Guessing DIMM is in bank 1 bank 2 bank 3 bank 4 bank 5 bank 6 bank 7 bank 8 ---=== SPD EEPROM Information ===--- EEPROM CRC of bytes 0-125 OK (0x74DA) # of bytes written to SDRAM EEPROM 384 Total number of bytes in EEPROM 512 Fundamental Memory type DDR4 SDRAM SPD Revision 1.1 Module Type UDIMM EEPROM CRC of bytes 128-253 OK (0x05F1) ---=== Memory Characteristics ===--- Maximum module speed 2400 MHz (PC4-19200) Size 16384 MB Banks x Rows x Columns x Bits 16 x 16 x 10 x 64 SDRAM Device Width 8 bits Ranks 2 Rank Mix Symmetrical Bus Width Extension 8 bits AA-RCD-RP-RAS (cycles) 17-17-17-39 Supported CAS Latencies 18T, 17T, 16T, 15T, 14T, 13T, 12T, 11T, 10T ---=== Timings at Standard Speeds ===--- AA-RCD-RP-RAS (cycles) as DDR4-2400 17-17-17-39 AA-RCD-RP-RAS (cycles) as DDR4-2133 15-15-15-35 AA-RCD-RP-RAS (cycles) as DDR4-1866 13-13-13-30 AA-RCD-RP-RAS (cycles) as DDR4-1600 11-11-11-26 ---=== Timing Parameters ===--- Minimum Cycle Time (tCKmin) 0.833 ns Maximum Cycle Time (tCKmax) 1.600 ns Minimum CAS Latency Time (tAA) 13.750 ns Minimum RAS to CAS Delay (tRCD) 13.750 ns Minimum Row Precharge Delay (tRP) 13.750 ns Minimum Active to Precharge Delay (tRAS) 32.000 ns Minimum Active to Auto-Refresh Delay (tRC) 45.750 ns Minimum Recovery Delay (tRFC1) 350.000 ns Minimum Recovery Delay (tRFC2) 260.000 ns Minimum Recovery Delay (tRFC4) 160.000 ns Minimum Four Activate Window Delay (tFAW) 21.000 ns Minimum Row Active to Row Active Delay (tRRD_S) 3.300 ns Minimum Row Active to Row Active Delay (tRRD_L) 4.900 ns Minimum CAS to CAS Delay (tCCD_L) 5.000 ns Minimum Write Recovery Time (tWR) 15.000 ns Minimum Write to Read Time (tWTR_S) 2.500 ns Minimum Write to Read Time (tWTR_L) 7.500 ns ---=== Other Information ===--- Package Type Monolithic Maximum Activate Count Unlimited Post Package Repair One row per bank group Soft PPR Supported Module Nominal Voltage 1.2 V Thermal Sensor TSE2004 compliant ---=== Physical Characteristics ===--- Module Height 19 mm Module Thickness 2 mm front, 2 mm back Module Reference Card ZZ ---=== Manufacturer Data ===--- Module Manufacturer SK Hynix DRAM Manufacturer SK Hynix Manufacturing Location Code 0x01 Manufacturing Date 2018-W28 2018-W28 2018-W28 2018-W28 2018-W16 2018-W28 2018-W28 2018-W28 Assembly Serial Number 0x72446CE5 0x72446C05 0x72446AE9 0x72446A98 0x72189C5D 0x72446CE7 0x72446B14 0x72446C0A Part Number HMA82GU8AFR8N-UH Number of SDRAM DIMMs detected and decoded: 8 root@noah:~# od -Ax -t x1 -v /sys/bus/i2c/drivers/ee1004/0-0050/eeprom 000000 23 11 0c 02 85 21 00 08 00 60 00 03 09 0b 80 00 000010 00 00 07 0d f8 0f 00 00 6e 6e 6e 11 00 6e f0 0a 000020 20 08 00 05 00 a8 1b 28 28 00 78 00 14 3c 00 00 000030 00 00 00 00 00 00 00 00 00 00 00 00 0c 2c 15 35 000040 15 35 0b 2c 15 35 0b 35 0b 2c 0b 35 15 36 00 00 000050 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000060 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000070 00 00 00 00 00 00 9c b5 00 00 00 00 e7 d6 da 74 000080 04 11 1f 01 00 00 00 00 00 00 00 00 00 00 00 00 000090 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000a0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000b0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000c0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000d0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0000f0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 f1 05 000100 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000110 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000120 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000130 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000140 80 ad 01 18 28 72 44 6c e5 48 4d 41 38 32 47 55 000150 38 41 46 52 38 4e 2d 55 48 20 20 20 20 00 80 ad 000160 ff 54 44 38 37 4e 35 32 32 36 49 30 31 00 00 00 000170 01 00 00 00 00 00 00 02 00 00 00 00 00 dd 00 00 000180 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000190 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001a0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001b0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001c0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001d0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0001f0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 000200 Save to a txt file and open with Thaiphoon Burner (File, Open from Clipboard/File):
  6. 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁 😁😁
  7. Oh, hey awesome. I didn't realize I could get to menuconfig (that's all I needed to know 🙂. I do lot's of work in OpenWRT). I assume this will be over a VNC connection to the container? EDIT: RTFM 🙂 "'docker exec -ti NAMEOFYOURCONTAINER /bin/bash'"
  8. Well, in case anyone is interested I have made some progress, but not quite there yet. I have been able to detect the smbus (of my board) that holds the I2C address of the SPD EEPROMs (which for me is "0", where I have all 8 x SPD EEPROMs). The catch now though is I need to have an eeprom driver baked into the kernel (namely the ee1004 eeprom driver/kmod). @ich777 you think your kernel toolbox might be up for the challenge? (https://www.spinics.net/lists/linux-i2c/msg32331.html)
  9. I want to be able to get my memory timings from CLI, but out of the box all I see is just a high level view with lshw -C memory *-bank:0 description: DIMM DDR4 Synchronous Unbuffered (Unregistered) 2934 MHz (0.3 ns) product: HMA82GU8AFR8N-UH vendor: Hynix physical id: 0 serial: 72446CE5 slot: DIMM 0 size: 16GiB width: 64 bits clock: 2934MHz (0.3ns) I want to also be able to pull the memory timings. Looking online, seems the best way to do this is using i2c-tools (namely decode-dimms). So I pulled down and installed the slackware package: https://packages.slackonly.com/pub/packages/14.2-x86_64/system/i2c-tools/i2c-tools-4.1-x86_64-1_slonly.txz But.... seems I need to be able to modprode eeprom before decode-dimms can actually read anything: (Screenshot was from an old version of i2c-tools 3.1.1, I since updated to 4.1. Needed for DDR4) Is there a way to get this information?
  10. I think you should pickup the 1920X I have 🙂 . There is nothing wrong with it, as I have been running my unraid system with it for about 6 months now. You lose 4 cores and you don't get PBO, but confirmed working on what I am running at least.
  11. @RockDawg check this out too: https://www.phoronix.com/scan.php?page=news_item&px=ECC-DRAM-Overclocking-TR Good stuff! I'm up to 2800 on my Hynix (From stock 2400), and exited to see what happens with 2nd Gen TR when it comes in since it has a better IMC.
  12. They are discontinued now, but I got 8 x sticks of this in there: https://store.supermicro.com/16gb-ddr4-2400-mem-dr416l-hv01-eu24.html MANUFACTURER Hynix MEMORY CAPACITY 16 GB MEMORY TECHNOLOGY DDR4 MEMORY SPEED 2400 MHz VOLTAGE 1.2 V ECCVLP ECC UDIMM RANK 2 rank CAS LATENCY CL17 MANUFACTURER PART NUMBER HMA82GU8AFR8N-UH WARRANTY 5 year warranty (here is the current equivelant: https://store.supermicro.com/memory/ddr4/16gb-ddr4-mem-dr416l-cv02-eu26.html) Also, if you need a TR for cheap, let me know. I jumped on the 2950X deal, so want to sell off my 1920X for about $220 shipped. (I'm in SE Michigan, seemingly right above you)
  13. Been running it for a few months now and love it, it's been super stable (disabled C states and set power supply idle control to typical in BIOS). Both Intel NIC's work out the box and register as 10Gb and the IOMMU groupings are nice as well. Details of my system are in my signature. I am on the latest 6.9.0Beta25 using a recompiled Kernel to add Nvidia Drivers from @ich777 's nice docker tool - Here For BIOS and BMC: BMC Version - 1.30.00 - Download BIOS Version - L1.37 (BETA BIOS I requested from Support) - Download For the BETA BIOS, it's been rock solid. The difference with this one is not only (current release bios doesn't even have bifurcation) does it allow you to set bifurcation, but it does so on a per PCIe slot basis. BETA BIOS prior had PCIe slots setup in groups. So if you wanted to set one slot to x4x4x4x4, then you got two slots as x4x4x4x4, I didn't like that. I am posting it in my onedrive for you since I find it a requirement.
  14. Are you on a clean IOMMU grouping, meaning you are not trying to pass through a grouping with multiple GPU's or something?
