  1. Dear all I'm really struggling to get good performance on W10 machine. It is used mainly for gaming. But always lagging in games. Syslinux: kernel /bzimage append isolcpus=4,5,6,7,8,9,10,11,12,13,14,15,20,21,22,23,24,25,26,27,28,29,30,31 pcie_acs_override=downstream vfio_iommu_type1.allow_unsafe_interrupts=1 initrd=/bzroot W10 machine : 16GB assigned. -------- <type arch='x86_64' machine='pc-q35-3.1'>hvm</type> -------- <vcpu placement='static'>8</vcpu> <cputune> <vcpupin vcpu='0' cpuset='12'/> <vcpupin vcpu='1' cpuset='28'/> <vcpupin vcpu='2' cpuset='13'/> <vcpupin vcpu='3' cpuset='29'/> <vcpupin vcpu='4' cpuset='14'/> <vcpupin vcpu='5' cpuset='30'/> <vcpupin vcpu='6' cpuset='15'/> <vcpupin vcpu='7' cpuset='31'/> <emulatorpin cpuset='0,16'/> </cputune> System is on SSD : <disk type='block' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source dev='/dev/disk/by-id/ata-CT1000MX500SSD1_1902E1E1D374'/> <backingStore/> <target dev='hdc' bus='virtio'/> Nvidia 960 : Please, any help is really appreciated, I thought should be better...But is not as good as expected in terms of performance.
  2. Hi All. I'm struggling to get good performance. I noticed micro stuttering with mouse in Windows, doing circles it stops for half a second. Same when watching something in Chrome, video stops for half second. CPU utilization seems low. Below all settings. It is driving me crazy, even tried to enable/disable Hyper-V. label unRAID OS menu default kernel /bzimage append isolcpus=4,5,6,7,8,9,10,11,12,13,14,15,20,21,22,23,24,25,26,27,28,29,30,31 pcie_acs_override=downstream,multifunction initrd=/bzroot <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='2'> <name>Windows 10 Maxi</name> <uuid>577ec135-5ff4-b3eb-c804-e50aa20c1506</uuid> <metadata> <vmtemplate xmlns="unraid" name="Windows 10" icon="windows.png" os="windows10"/> </metadata> <memory unit='KiB'>8388608</memory> <currentMemory unit='KiB'>8388608</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>8</vcpu> <cputune> <vcpupin vcpu='0' cpuset='4'/> <vcpupin vcpu='1' cpuset='20'/> <vcpupin vcpu='2' cpuset='5'/> <vcpupin vcpu='3' cpuset='21'/> <vcpupin vcpu='4' cpuset='6'/> <vcpupin vcpu='5' cpuset='22'/> <vcpupin vcpu='6' cpuset='7'/> <vcpupin vcpu='7' cpuset='23'/> <emulatorpin cpuset='8-9,24-25'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-i440fx-3.0'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/577ec135-5ff4-b3eb-c804-e50aa20c1506_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> <hyperv> <relaxed state='on'/> <vapic state='on'/> <spinlocks state='on' retries='8191'/> <vendor_id state='on' value='none'/> </hyperv> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='4' threads='2'/> </cpu> <clock offset='localtime'> <timer name='hypervclock' present='yes'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='block' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source dev='/dev/disk/by-id/ata-Crucial_CT500MX200SSD1_162212D41B36'/> <backingStore/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </disk> <controller type='usb' index='0' model='nec-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <controller type='pci' index='0' model='pci-root'> <alias name='pci.0'/> </controller> <controller type='sata' index='0'> <alias name='sata0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:30:e0:8f'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='virtio'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-2-Windows 10 Maxi/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='connected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='mouse' bus='ps2'> <alias name='input0'/> </input> <input type='keyboard' bus='ps2'> <alias name='input1'/> </input> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x06' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x04' slot='0x00' function='0x1'/> </source> <alias name='hostdev1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x08' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </source> <alias name='hostdev2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x09' function='0x0'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain> Appreciate all help.
  3. Done. Mounted and unmounted fine. Diagnostics file attached. echidna-diagnostics-20181123-1625.zip
  4. root@echidna:~# mount proc on /proc type proc (rw) sysfs on /sys type sysfs (rw) tmpfs on /dev/shm type tmpfs (rw) tmpfs on /var/log type tmpfs (rw,size=128m,mode=0755) /dev/sda1 on /boot type vfat (rw,noatime,nodiratime,umask=0,shortname=mixed) /boot/bzmodules on /lib/modules type squashfs (ro) /boot/bzfirmware on /lib/firmware type squashfs (ro) /mnt on /mnt type none (rw,bind) /dev/md1 on /mnt/disk1 type xfs (rw,noatime,nodiratime) /dev/md2 on /mnt/disk2 type xfs (rw,noatime,nodiratime) /dev/md3 on /mnt/disk3 type xfs (rw,noatime,nodiratime) /dev/md4 on /mnt/disk4 type xfs (rw,noatime,nodiratime) /dev/sdc1 on /mnt/cache type btrfs (rw,noatime,nodiratime) shfs on /mnt/user0 type fuse.shfs (rw,nosuid,nodev,noatime,allow_other) shfs on /mnt/user type fuse.shfs (rw,nosuid,nodev,noatime,allow_other) //SLOTH/Backup on /mnt/disks/SLOTH_Backup type cifs (rw) //SLOTH/Multimedia on /mnt/disks/SLOTH_Multimedia type cifs (rw) //SLOTH/Private on /mnt/disks/SLOTH_Private type cifs (rw) //SLOTH/AG-NET on /mnt/disks/SLOTH_AG-NET type cifs (rw) //SLOTH/NFS on /mnt/disks/SLOTH_NFS type cifs (rw) /mnt/disk2/system/docker/docker.img on /var/lib/docker type btrfs (rw) /mnt/disk2/system/libvirt/libvirt.img on /etc/libvirt type btrfs (rw) root@echidna:~#
  5. Probably browser on VM. I just killed it. echidna-syslog-20181123-1351.zip
  6. .cfg file is empty -rwxrwxrwx 1 root root 1 Nov 23 13:05 unassigned.devices.cfg*
  7. I did all 3 steps, unfortunatelly situation is stil the same. SSD is mounted, and cannot be unmounted. Attached diagnose file. echidna-diagnostics-20181123-1310.zip
  8. Hi all. I have problem with one SSD (of two, passed-through to Windows VM's). Where it shows always as mounted, and cannot be unmounted. Nov 21 14:24:01 echidna unassigned.devices: Disk '' could not be unmounted... Nov 21 14:38:03 echidna unassigned.devices: Disk with serial 'Crucial_CT500MX200SSD1_162212D41B36', mountpoint 'Wiederherstellung' is not mounted and cannot be unmounted... Nov 21 14:38:03 echidna unassigned.devices: Disk with serial 'Crucial_CT500MX200SSD1_162212D41B36', mountpoint 'Crucial_CT500MX200SSD1_162212D41B36-part2' is not mounted and cannot be unmounted... Nov 21 14:38:03 echidna unassigned.devices: Disk with serial 'Crucial_CT500MX200SSD1_162212D41B36', mountpoint 'Crucial_CT500MX200SSD1_162212D41B36-part3' is not mounted and cannot be unmounted... Nov 21 14:38:03 echidna unassigned.devices: Device '' script file not found. 'REMOVE' script not executed. Nov 21 14:38:03 echidna unassigned.devices: Unmounting disk ''... Nov 21 14:38:03 echidna unassigned.devices: Unmounting ''... Nov 21 14:38:03 echidna unassigned.devices: Unmount cmd: /bin/umount '' 2>&1 Nov 21 14:38:03 echidna unassigned.devices: Unmount of '' failed. Error message: umount: : no mount point specified. Nov 21 14:38:04 echidna unassigned.devices: Since there aren't open files, will force unmount. Nov 21 14:38:04 echidna unassigned.devices: Unmounting ''... Nov 21 14:38:04 echidna unassigned.devices: Unmount cmd: /bin/umount -f -l '' 2>&1 Nov 21 14:38:04 echidna unassigned.devices: Unmount of '' failed. Error message: umount: : no mount point specified. Nov 21 14:38:05 echidna unassigned.devices: Disk '' could not be unmounted... How I can unmount it ?
  9. I just need advise, how to separate GPU, to have them on separate CPU. It seems, as I understand, everything landed on NUMANode P0. I have 2 VM's and two GPU's. On other hand, I took Mainboard manual and I see this : 54 PCI Express 3.0 x16 Slot (PCIE2, Blue) from CPU_BSP1 56 PCI Express 3.0 x16 Slot (PCIE3, Blue) from CPU_BSP1 57 PCI Express 3.0 x16 Slot (PCIE4, Blue) from CPU_BSP1 58 PCI Express 3.0 x16 Slot (PCIE5, Blue) from CPU_AP1 60 PCI Express 3.0 x 4 Slot (PCIE6, White) from CPU_BSP1 Am I correct saying, CPU_AP1 have only one PCI Express bus ? And did some PCI cards shuffling, now it looks like this. Main VM is on NUMANode 0. Just curious what affect have all other devices on performance, like eth etc.
  10. New firmware for BMC http://asrock.pc.cdn.bitgravity.com/BIOS/Server/EP2C602-4LD16(00.19.00)BMC.zip Right now after update I see I lost reading from CPU_AP1 Temp : N/A . After reboot, works well. Changelog: 1.Improve JAVA compatibility 2.Improve WebUI interface Java works just fine finaly.
