redQs

Hey Guys, i read now nearly every post about this subject... it still dont want to work for me... I got swag as a docker with a custom proxi network for bitwareden, nextcloud and vpn. i got access to my homeassistant remotlie at ha.xxxx.de:8123 i dont get it to work with https:// home assistant configuration.yaml: http: use_x_forwarded_for: true trusted_proxies: - 192.168.3.210 #unraid ip-adress - 172.18.0.2 #swag ip-adress and of corse i renamed the proxy-config file in swag: homeassistant.subdomain.conf server { listen 443 ssl; listen [::]:443 ssl; server_name ha.*; include /config/nginx/ssl.conf; client_max_body_size 0; location / { include /config/nginx/proxy.conf; include /config/nginx/resolver.conf; set $upstream_app 192.168.3.10; set $upstream_port 8123; set $upstream_proto http; proxy_pass $upstream_proto://$upstream_app:$upstream_port; } location ~ ^/(api|local|media)/ { include /config/nginx/proxy.conf; include /config/nginx/resolver.conf; set $upstream_app 192.168.3.10; set $upstream_port 8123; set $upstream_proto http; proxy_pass $upstream_proto://$upstream_app:$upstream_port; } } as i said i can conect remot to ha.xxxx.de:8123 so the port forwarding is working. What could it be?.. thanks for your reading this!

oh wow.. you are right.. i was just confused becaus the 3. disk is missing by me but i dont even need it... realy thank you

hey, does anybody know why the base system partition dont show up?..

i got problems with the openvpn-as since i upgradet to 6.7 I was on network host. It works all fine since update. I read that i have to change to bridge. Than the openvpn Server startes normal. The think is i cant connect anymore to my vpn. i using port tcp 8080 Portforworting works. i just got the messing: Transport Error: TCP connect error on "mydomain.de:8080" ([myhomeipadress]:8080/tcp): System/Connection refused i just test my old linux vm with openvpn. There it works normal. sad that the docker dont work anymore for me..

thanks for your answer. Thats all i want to know So i need to buy an PCI SSD or i go for a card like this: https://www.asus.com/Motherboard-Accessories/HYPER-M-2-X16-CARD-V2/ and buy an NVMe ssd. thanks a lot!

its my old OCZ-VERTEX3. So you think its the writing speed of the ssd. So i need new one. but why is the cpu at 100%? Is once a week triming enough? Wich one can sutain like 500mb/s the hole copy prozess?

Hello, i installed an Mellanox ConnectX - 2 10gbit NIC at my Unraid and my PC. I just use it directly between my Unraid and my windows PC. If 1 datei is on my ssd cach i can copy it over the 10gig to my pc ssd with full speed. it works just normal / fine. The problem is if i try to write to my share / ssd cache it starts good but than it drops after some sec like you can see in the picture. I saw that my CPU is going to but some cores to 100%. but it change the cores the hole time till the copy is finish. Do you know why my copy to the share is droping like this? Is my CPU singel core speed to bad? Its an I7 3770k. Do you think my ssd is broken? I got 18 retired blocks. Thanks for your answer right now. redQs

So i can let it run like this? why did i got like that high counter on some other interrupts. Is this normal?

it comes again. different PCI slot. but the transfer speed dont break down. cat /proc/interrupts says this. does this help you? CPU0 CPU1 CPU2 CPU3 CPU4 CPU5 CPU6 CPU7 0: 13 0 0 0 0 0 0 0 IO-APIC 2-edge timer 8: 0 0 0 0 0 0 54 0 IO-APIC 8-edge rtc0 9: 0 0 0 0 0 0 0 0 IO-APIC 9-fasteoi acpi 16: 0 0 0 100000 0 0 0 0 IO-APIC 16-fasteoi ehci_hcd:usb1 17: 0 0 0 0 1196014 0 0 0 IO-APIC 17-fasteoi mvsas 18: 0 0 0 0 0 0 0 0 IO-APIC 18-fasteoi i801_smbus 23: 0 0 0 0 96 0 0 0 IO-APIC 23-fasteoi ehci_hcd:usb2 24: 0 0 0 0 0 0 0 0 PCI-MSI 327680-edge xhci_hcd 25: 0 0 0 0 0 0 13750 0 PCI-MSI 2621440-edge xhci_hcd 26: 0 0 0 0 0 0 0 0 PCI-MSI 2621441-edge xhci_hcd 27: 0 0 0 0 0 0 0 0 PCI-MSI 2621442-edge xhci_hcd 28: 0 0 0 0 0 0 0 0 PCI-MSI 2621443-edge xhci_hcd 29: 0 0 0 0 0 0 0 0 PCI-MSI 2621444-edge xhci_hcd 30: 0 0 0 0 0 0 0 0 PCI-MSI 2621445-edge xhci_hcd 31: 0 0 0 0 0 0 0 0 PCI-MSI 2621446-edge xhci_hcd 32: 0 0 0 0 0 0 0 0 PCI-MSI 2621447-edge xhci_hcd 33: 0 0 93062 0 0 0 0 0 PCI-MSI 512000-edge ahci[0000:00:1f.2] 34: 0 0 0 0 0 0 0 0 PCI-MSI 3145728-edge ahci[0000:06:00.0] 35: 0 0 0 0 0 0 0 0 PCI-MSI 3670016-edge ahci[0000:07:00.0] 36: 0 42208229 0 0 0 0 0 0 PCI-MSI 2097152-edge eth1 37: 0 0 0 6194125 0 0 0 0 PCI-MSI 409600-edge eth0 NMI: 24 8 0 0 10 9 0 0 Non-maskable interrupts LOC: 650503 1248013 711463 982474 796734 707417 709708 705084 Local timer interrupts SPU: 0 0 0 0 0 0 0 0 Spurious interrupts PMI: 24 8 0 0 10 9 0 0 Performance monitoring interrupts IWI: 0 0 0 0 0 0 0 0 IRQ work interrupts RTR: 0 0 0 0 0 0 0 0 APIC ICR read retries RES: 188600 227830 32341 127065 15282 10074 5030 5259 Rescheduling interrupts CAL: 26297 32439 19056 17237 17020 20230 19347 18189 Function call interrupts TLB: 20984 29165 15495 13616 15124 18413 17602 16300 TLB shootdowns TRM: 0 0 0 0 0 0 0 0 Thermal event interrupts THR: 0 0 0 0 0 0 0 0 Threshold APIC interrupts DFR: 0 0 0 0 0 0 0 0 Deferred Error APIC interrupts MCE: 0 0 0 0 0 0 0 0 Machine check exceptions MCP: 33 34 34 34 34 34 34 34 Machine check polls HYP: 0 0 0 0 0 0 0 0 Hypervisor callback interrupts HRE: 0 0 0 0 0 0 0 0 Hyper-V reenlightenment interrupts HVS: 0 0 0 0 0 0 0 0 Hyper-V stimer0 interrupts ERR: 0 MIS: 0 PIN: 0 0 0 0 0 0 0 0 Posted-interrupt notification event NPI: 0 0 0 0 0 0 0 0 Nested posted-interrupt event PIW: 0 0 0 0 0 0 0 0 Posted-interrupt wakeup event

BIOS is the latest update on it. I just use this Controller: SuperMicro AOC-SASLP-MV8 I just use it for get more SATA ports so i dont use raid or anythink. Bevor i move too the new hardware it work´s all good. The think is this PCI slot must work fine. Becaus bevor i moved it intoo my unraid it was my gaming rig an in this slot was my 1080. But i started new right now and try an other PCI slot.

thanks for the fast answer. you mean a bios update for my motherboard might help also? can you tell me where you saw that SASLP uses IRQ16?

Hello, i m using Unraid since 4 month right now. I switcht last week to new hardware. New MB New CPU New RAM New Networkcard. The updating was pretty easy. All works good. I now use bonding mode balance - alb of my MB 1GB nic and my PCI 1 GB nic. It works good and i can copy with 200MB´s. On monday i tried to copy again and after some sec´s the transfer broke down to somethink like 3 mb´s. i look via Putty at the Server nothink written there. I look via monitor at the Server and there stands: Tower login : Disabling IRQ #16 i startet my server new and all work fine again. Today it comes again. all the same only 3mb´s transfer and again Tower login : Disabling IRQ #16 I m new at unraid and at linux. Do you think it´s becaus the bonding mode? Can someone help me? I read in the Form that you need the diagnostics file. Thanks for you help right now. - redQs tower-diagnostics-20190221-1559.zip
