October 13, 20241 yr Hi everyone, after upgrading to Unraid 7 beta, my Home Assistant VM is not able to connect/pair with matter devices. Everything is smooth if I downgrade my server to Unraid 6.xx. Is anyone aware about any issues? Checking out my Matter logs on HA, I notice that it is something related to network stuff but honestly I cannot find anything more than that.
October 13, 20241 yr Community Expert 9 minutes ago, heyelly said: Hi everyone, after upgrading to Unraid 7 beta, my Home Assistant VM is not able to connect/pair with matter devices. Everything is smooth if I downgrade my server to Unraid 6.xx. Is anyone aware about any issues? Checking out my Matter logs on HA, I notice that it is something related to network stuff but honestly I cannot find anything more than that. How are they connected? Are you running beta 7?
October 13, 20241 yr Author I use a Sonoff dongle with a flashed firmware passed through the VM. They are connected to that dongle. I am running beta 7, everything works with Unraid 6.
October 13, 20241 yr Community Expert Just now, heyelly said: I use a Sonoff dongle with a flashed firmware passed through the VM. They are connected to that dongle. I am running beta 7, everything works with Unraid 6. Is that 7 beta 3? Can you provide any logs and the xml? Is the 6 6.12.x or earlier?
October 13, 20241 yr Author <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='1'> <name>HAOS</name> <uuid>0dacb239-943b-6067-9c9a-e653567d42e1</uuid> <metadata> <vmtemplate xmlns="unraid" name="Linux" icon="default.png" os="linux" webui="https://****" storage="default"/> </metadata> <memory unit='KiB'>8388608</memory> <currentMemory unit='KiB'>1048576</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='3'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-i440fx-7.2'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/0dacb239-943b-6067-9c9a-e653567d42e1_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' clusters='1' cores='2' threads='1'/> <cache mode='passthrough'/> </cpu> <clock offset='utc'> <timer name='hpet' present='no'/> <timer name='hypervclock' present='no'/> <timer name='pit' tickpolicy='delay'/> <timer name='rtc' tickpolicy='catchup'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback' discard='ignore'/> <source file='/mnt/user/domains/haos_ova-11.5.qcow2' index='1'/> <backingStore/> <target dev='hdc' bus='virtio'/> <serial>vdisk1</serial> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </disk> <controller type='pci' index='0' model='pci-root'> <alias name='pci.0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </controller> <controller type='usb' index='0' model='qemu-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:5d:dd:c3'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='virtio-net'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/run/libvirt/qemu/channel/1-HAOS/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='connected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='2'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <graphics type='vnc' port='5900' autoport='yes' websocket='5700' listen='0.0.0.0' keymap='it' sharePolicy='ignore'> <listen type='address' address='0.0.0.0'/> </graphics> <audio id='1' type='none'/> <video> <model type='qxl' ram='65536' vram='65536' vgamem='16384' heads='1' primary='yes'/> <alias name='video0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1e' function='0x0'/> </video> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1a86'/> <product id='0x55d4'/> <address bus='1' device='2'/> </source> <alias name='hostdev0'/> <address type='usb' bus='0' port='1'/> </hostdev> <memballoon model='virtio'> <alias name='balloon0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </memballoon> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain> That is the VM xml, what logs are you asking for? The 6 is 6.12 but it worked even with the old versions. Edited October 13, 20241 yr by heyelly
October 13, 20241 yr Community Expert 5 minutes ago, heyelly said: <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='1'> <name>HAOS</name> <uuid>0dacb239-943b-6067-9c9a-e653567d42e1</uuid> <metadata> <vmtemplate xmlns="unraid" name="Linux" icon="default.png" os="linux" webui="https://home.eliatonelli.com" storage="default"/> </metadata> <memory unit='KiB'>8388608</memory> <currentMemory unit='KiB'>1048576</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='3'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-i440fx-7.2'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/0dacb239-943b-6067-9c9a-e653567d42e1_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' clusters='1' cores='2' threads='1'/> <cache mode='passthrough'/> </cpu> <clock offset='utc'> <timer name='hpet' present='no'/> <timer name='hypervclock' present='no'/> <timer name='pit' tickpolicy='delay'/> <timer name='rtc' tickpolicy='catchup'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback' discard='ignore'/> <source file='/mnt/user/domains/haos_ova-11.5.qcow2' index='1'/> <backingStore/> <target dev='hdc' bus='virtio'/> <serial>vdisk1</serial> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x04' function='0x0'/> </disk> <controller type='pci' index='0' model='pci-root'> <alias name='pci.0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x03' function='0x0'/> </controller> <controller type='usb' index='0' model='qemu-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:5d:dd:c3'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='virtio-net'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/run/libvirt/qemu/channel/1-HAOS/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='connected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='2'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <graphics type='vnc' port='5900' autoport='yes' websocket='5700' listen='0.0.0.0' keymap='it' sharePolicy='ignore'> <listen type='address' address='0.0.0.0'/> </graphics> <audio id='1' type='none'/> <video> <model type='qxl' ram='65536' vram='65536' vgamem='16384' heads='1' primary='yes'/> <alias name='video0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1e' function='0x0'/> </video> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1a86'/> <product id='0x55d4'/> <address bus='1' device='2'/> </source> <alias name='hostdev0'/> <address type='usb' bus='0' port='1'/> </hostdev> <memballoon model='virtio'> <alias name='balloon0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x05' function='0x0'/> </memballoon> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain> That is the VM xml, what logs are you asking for? The 6 is 6.12 but it worked even with the old versions. Syslog and qemu logs. Or post diagnostics as will include both
October 13, 20241 yr Community Expert Not seeing anything jumping out, whats does the HA logs show for the adapter?
October 13, 20241 yr Author 2024-10-13 19:49:58.409 (Dummy-2) CHIP_ERROR [chip.native.-] src/inet/UDPEndPointImplSockets.cpp:416: OS Error 0x02000065: Network is unreachable at src/app/OperationalSessionSetup.cpp:246 It seems something network related but I tried almost everything. I know that Matter requires ipv6 so it could be something related to this but I cannot understand what's going on. It seems that something between Unraid 6 and 7 has changed but I cannot figure out what.
October 13, 20241 yr Author Default: mDNSPlatformSendUDP got error 99 (Cannot assign requested address) sending packet to ff02::fb on interface fe80::5ce8:67ff:fedc:284e/veth239cc13/23 That is the log of Silicon Labs Multiprotocol
October 13, 20241 yr Community Expert 7 minutes ago, heyelly said: Default: mDNSPlatformSendUDP got error 99 (Cannot assign requested address) sending packet to ff02::fb on interface fe80::5ce8:67ff:fedc:284e/veth239cc13/23 That is the log of Silicon Labs Multiprotocol May not be related, but have you tried disbaling tailscale to see if that makes a difference?
October 15, 20241 yr Author Quick update: it seems that the matter network is unreachable from the VM and the dongle is unnecessary as I can use the network provided by my Apple TV. It looks like something weird about ipv6 is happening here.
October 15, 20241 yr Can I help test? I'm using HAOS in Unraid 7 beta 3. My Aqara door lock (via hub) is connected with Matter to HA - however I believe it's using WiFi and not Thread. Edited October 15, 20241 yr by Espressomatic
October 16, 20241 yr Community Expert please see form thread: there was a user script and these item ran to fix come ipv connections.
October 16, 20241 yr Author 5 hours ago, bmartino1 said: please see form thread: there was a user script and these item ran to fix come ipv connections. I tried with those commands with no luck.
October 16, 20241 yr Community Expert ok, i need to know a bit more about your setup then. 1 are you using the HA VM and have matter installed in the vm? or are you using VM and matter docker? or HA docker and matter docker? 2. Docker and potential Vm settings. I also have bridgin off and bond on to help with previous macvlan bug... -I use macvlan for dockers, as a separate mac for connection is required for matter server and HA..., ipvlan will not worker with HA and Matter dockers... -you need docker host access to custom network enabled also if matter docker please see there support on this forum the matter server Matter Server Docker networking MUST BE HOST!... HA must be set to a different IP address. and a user script with the sysctl -w net.ipv6.conf.wlan0.accept_ra=1 sysctl -w net.ipv6.conf.wlan0.accept_ra_rt_info_max_plen=64 #if ra1 dind't work you may need to use ra=2 *Note wlan0 may need to become eth0, br0, bon0 eth1.... etc... VM: Be sure that you followed HA setup for unraid: https://www.home-assistant.io/installation/linux#:~:text=VirtualBox-,Unraid,-KVM (virt-manager and follow there instructions for a matter server: Docker: https://github.com/home-assistant-libs/python-matter-server Blog install steps:https://blog.matterxiaomi.com/blog/matter-home-assistant-part1/ HA beta info for matter:https://www.home-assistant.io/integrations/matter/ confirm your settings for network source: You may also need other XML vm setting for the docker netwrok... <interface type='direct' trustGuestRxFilters='yes'> <mac address='52:54:00:89:1f:91'/> <source dev='vhost0' mode='bridge'/> <model type='virtio'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> Edited October 20, 20241 yr by bmartino1
October 16, 20241 yr Author 1. HAos in its own VM with Matter installed inside 2. Disabling the bridging between eth0 and eth1 seems actually to solve the issue in Unraid 7. Btw, I can't understand why everything works (bridging eth0 and eth1) on the older Unraid versions. Actually I cannot disabling it as I need my two ethernet ports to be bridged together. Any ideas?
October 17, 20241 yr Community Expert turn bridge off use bond instead. the vm is proably trying to bridge to eth0 / eth1 and nor br0.. Not sure...
October 17, 20241 yr Author 2 hours ago, bmartino1 said: turn bridge off use bond instead. the vm is proably trying to bridge to eth0 / eth1 and nor br0.. Not sure... I cant, those interfaces need to be bridged. The VM is set to use br0, there is no reason for it to behave like that with Unraid 7 and work properly with 6.
October 17, 20241 yr Community Expert Not enouth information.... nothing of note changed in v7 from v6 in regards to how unriads Network interfaces and how br0 and bond0 operate. If anything changed its how libvirt bridges to a interface... Please notate the xml i posted above, you will need to edit vhost0 to the interface you want it on as atest... use eth0 or eth1 this will create a (virtual) veth bridge and the traffic will then be bridge tied to eth1/0 to the network in use for the VM.... Based on your information you provded atm, All signs point to you should be using bond not bridge... brdige to the best that i can describe it to you is that eth0 is you main connection to the router. eth1 is a carry upstream ot other devices that needs the same data connection as eth0 you bridge the connection to cary the data. you may need to check ipv4 system ctl rules for ip forwarding... Otherwise you scenario, I have eth0 and eth1 to the router, i want the machine to balance load the connection I bond (which actas like a bridge) depengin on your needs you chose the type of bond... Please review forum post and links here where i attempted to explain the difference and needs for bonding: xml example <interface type='direct' trustGuestRxFilters='yes'> <mac address='keep your same vm MAC'/> <source dev='eth00' mode='bridge'/> <model type='virtio'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> would need more data... ip a netstat etc...
October 20, 20241 yr It's my understanding that HA (Home Assistant) is trying, very hard, to be more stable. As of this writing, I can't make it run longer than a week on bare metal (Rpi4). HA changes very fast, as does home automation in general. Thread/Matter/IPV6... Maybe I'm wrong, but I haven't read anything to suggest that Thread/Matter require IPV6... Maybe its a MAC/iOS thing? MrGrey.
October 20, 20241 yr Just now, MrGrey said: It's my understanding that HA (Home Assistant) is trying, very hard, to be more stable. As of this writing, I can't make it run longer than a week on bare metal (Rpi4). HA changes very fast, as does home automation in general. Thread/Matter/IPV6... Maybe I'm wrong, but I haven't read anything to suggest that Thread/Matter require IPV6... Maybe its a MAC/iOS thing? MrGrey. My first HA was run in Rpi3 and stable, the only problem is the booting SD / USB will die in 2 or 3 month due to continues writing to the media. Then, the HA have migrate to Unraid VM and currently move to docker, and all stable. My first Matter device was google nest thermostat but I have return it, so no more test can make again, the test was on unraid v7beta. Due to all test in docker, so no much can advice in this post. BTW, Matter server communicate between Matter device must IPv6. But Matter service in HA to communicate Matter server was IPv4. Edited October 20, 20241 yr by Vr2Io
November 2, 20241 yr Author Solution I managed to solve my issue. That is the solution. For some reason, even after upgrading to beta4, that wasn't fixed.
November 2, 20241 yr Does your ISP assign you an IPv6 range? My IPv6 is all link-local as my ISP doesn't support IPv6 at all, and I have it turned off at my pfSense router. Unraid hosting HAOS VM is also set to IPv4 only. If ISP doesn't give out a static IPv6 range, there's no point (and can't) set IPv6 static address for the router. If router doesn't have static IPv6, you can't run a local IPv6 DHCP. If there's no IPv6DHCP, there's no point/need to turn on IPv6 on a host. None of this seems to stop or block Matter servers/devices from using link-local addresses and communicating. Matter and Thread working in HA with the single end-device I have at the moment, Aqara Hub feeding U100 lock. Every border router can also be communicated with, 3x Eero and 5x Apple devices (Homepod and AppleTV) Edited November 2, 20241 yr by Espressomatic
