May 31, 20179 yr Great Deal. Did you checked the jumper? Maybe the Port is even just disabled. ? Edited June 2, 20179 yr by Diggewuff
May 31, 20179 yr 1 hour ago, Diggewuff said: Great Deal. Did you checken the jumper? Maybe the Port is even just disabled. ? I checked at the time, it's not , although there's no visible damage so I could try to RMA it, but like I said I don't really need it so not worth the bother
May 31, 20179 yr Author well if I can connect a monitor to the vga port and don't need to add a pci video card, then I'm happy to go with the kaby lake cpu. The tech said this won't work because it doesn't have the needed power, so I'm confused by the replies here. I will need to cancel the kaby lake today or not all all, as it will ship out tomorrow. Please confirm if this will work without adding a video card. Edited May 31, 20179 yr by Switchblade
May 31, 20179 yr 4 minutes ago, Switchblade said: well if I can connect a monitor to the vga port and don't need to add a pci video card, then I'm happy to go with the kaby lake cpu. The tech said this won't work because it doesn't have the needed power, so I'm confused by the replies here. I will need to cancel the kaby lake today or not all all, as it will ship out tomorrow. Please confirm if this will work without adding a video card. THIS MOTHERBOARD HAS A VIDEO CARD BUILT IN.
May 31, 20179 yr 16 minutes ago, Switchblade said: The tech said this won't work because it doesn't have the needed power What the tech said is that it can't use a iGPU.
May 31, 20179 yr Seems video card is supported based on feedback. Doesn't make sense the CPU feature would impact the video chip on the motherboard, and you have some confirmation that it should work. If that was only consideration for going kaby vs skylake, seems you have your answer.
May 31, 20179 yr Author Thanks everyone! I'm going to stay with the Katy lake. I got confused with igpu vs onboard video. Even though the Kaby lake CPU has integrated graphics that I cannot use, I want the 73w and faster clock speeds. I can always change the mb later if I don't like this one. Again, thank you all! Edited May 31, 20179 yr by Switchblade
June 7, 20179 yr Author On 5/29/2017 at 7:36 AM, johnnie.black said: The 9300 will only link at 12Gbps with SAS3 disks, SATA disks are still 6gbps max, but as long as someone can confirm it works with unRAID buy that one, I know the 9207 works as I have one. @ Johnnie - did you have to do anything to get the 9207 to work, flash it or change any settings? I didn't see on the hardware compatibility list.
June 7, 20179 yr 2 hours ago, Switchblade said: did you have to do anything to get the 9207 to work, flash it or change any settings? No, it's plug and play.
June 8, 20179 yr Author 8 hours ago, johnnie.black said: No, it's plug and play. cool, thank you! I read that some cards need to be flashed. All of my parts came in so I'm building it this weekend. Should be running memtest by Sunday.
June 14, 20179 yr Author Server is running memtest with no errors, so far My mb did come with the current bios, so booted right up. I did run into a issue, where I goofed up and ordered the wrong cables. I accidentally ordered LSI LSI00411 1m Internal Cable SFF8643 to x4 SATA HDD (mini SAS HD to SATA data port)--Avago Technologies, which has the 8643 internal connector and not the 8087 connector I need to use with my LSI 9207. For these memtest runs, I did not connect power or data to any of my unraid hard drives. This time I ordered Tripp Lite Model S508-003 3 ft. Internal SAS Cable, 4-Lane mini-SAS (SFF-8087) to 4xSATA 7pin (SFF-8482). I hope these work with my SATA III 6 Gb/s drives. I read that the 8482 7pin SATA connectors are for both data and power, but I will only use them for data, as I already have power run to all of my drives. Newegg didn't have that much to offer for 8087 to regular SATA 7 pin. Oh well, I will let memtest run for a few days, until the new sata cables are here. Oh, and on the PWM fans, I ran into the same issue as others reported, where the fans will drop to very low rpm's and then after a few seconds they will go to 100% for about 1 second and back to low again, keeps doing this, while I'm running Memtest. I hope it doesn't do this when booted into unraid. I guess I need a PWM fan controller. It takes a while to get through POST, especially with the LSI sata controller. Then again, all server boards take longer too fully post than a regular desktop mb. Edited June 14, 20179 yr by Switchblade
June 14, 20179 yr I had the Same issue with my Fans. They are to Slow on low PWM value. They will keep doing this. But maybe there will be a workaround soon. Have a Look at page 23 Edited June 14, 20179 yr by Diggewuff
June 14, 20179 yr 6 hours ago, Switchblade said: I hope it doesn't do this when booted into unraid. It will do the same, but you can lower the threshold values or use ipmi raw commands to increase the fans speed.
June 14, 20179 yr 50 minutes ago, johnnie.black said: It will do the same, but you can lower the threshold values or use ipmi raw commands to increase the fans speed. Lowering thresholds doesn't work anymore for x11 boards.
June 14, 20179 yr 9 minutes ago, Diggewuff said: Lowering thresholds doesn't work anymore for x11 boards. It works for my X11SSM-F
June 14, 20179 yr I have a x11ssi-ln4f and it didn't worked. I lowered the Fan 1234 and Fan A thresholds in the ipmi frontend. Whitch exact thresholds did you lowered? And whitch method did you have used?
June 14, 20179 yr This one was changed with ipmitool, but it's the same with freeipmi, I changed FAN4 since it's got a two fan spliter and the RPMs reported are not accurate: CPU Temp | 37.000 | degrees C | ok | 0.000 | 0.000 | 0.000 | 95.000 | 100.000 | 100.000 PCH Temp | 43.000 | degrees C | ok | -11.000 | -8.000 | -5.000 | 90.000 | 95.000 | 100.000 System Temp | 35.000 | degrees C | ok | -9.000 | -7.000 | -5.000 | 80.000 | 85.000 | 90.000 Peripheral Temp | 39.000 | degrees C | ok | -13.000 | -11.000 | -9.000 | 76.000 | 81.000 | 86.000 VcpuVRM Temp | 36.000 | degrees C | ok | -9.000 | -7.000 | -5.000 | 95.000 | 100.000 | 105.000 DIMMA1 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMA2 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMB1 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMB2 Temp | 33.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 FAN1 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN2 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN3 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN4 | 300.000 | RPM | ok | 0.000 | 100.000 | 200.000 | 25300.000 | 25400.000 | 25500.000 FANA | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 12V | 12.128 | Volts | ok | 10.144 | 10.272 | 10.784 | 12.960 | 13.280 | 13.408 5VCC | 4.974 | Volts | ok | 4.246 | 4.298 | 4.480 | 5.390 | 5.546 | 5.598 3.3VCC | 3.333 | Volts | ok | 2.789 | 2.823 | 2.959 | 3.554 | 3.656 | 3.690 VBAT | 3.056 | Volts | ok | 2.384 | 2.496 | 2.580 | 3.476 | 3.588 | 3.672 VCPU | 0.697 | Volts | ok | 0.076 | 0.076 | 0.076 | 1.516 | 1.516 | 1.516 VDIMMAB | 1.191 | Volts | ok | 0.948 | 0.975 | 1.047 | 1.344 | 1.425 | 1.443 5VSB | 4.974 | Volts | ok | 4.246 | 4.376 | 4.480 | 5.390 | 5.546 | 5.598 3.3VSB | 3.248 | Volts | ok | 2.789 | 2.891 | 2.959 | 3.554 | 3.656 | 3.690 VBMC 1.2V | 1.209 | Volts | ok | 1.020 | 1.047 | 1.092 | 1.344 | 1.371 | 1.398 VPCH 1.0V | 1.007 | Volts | ok | 0.872 | 0.890 | 0.917 | 1.043 | 1.052 | 1.070 Chassis Intru | 0x1 | discrete | 0x0100| na | na | na | na | na | na
June 15, 20179 yr Well okay then. I'm going to go right ahead and copy your purchase for my build. Thanks for your research! I will blame you of course if things go bad. Edited June 16, 20179 yr by andyb216
June 19, 20179 yr Author New cables are here and I can confirm that the Tripp Lite Model S508-003 is correct for the LSI 9207-8i. https://www.newegg.com/Product/Product.aspx?Item=9SIA24G28M5864 memtest ran several times with no errors so hardware seems good. I want to test a few more things with the 9207 before I connect my data drives and boot to my production unraid image. Good so far
June 19, 20179 yr 10 hours ago, Switchblade said: Hi johnnie black - which fan header are you using for CPU fan? This board has 2 fan control zones, FANA and FAN1/2/3/4, so I have the CPU on FANA so I can change speed of the CPU and all other fans independently.
June 20, 20179 yr Author cool, thanks! BTW, how did you get the report you posted? On 6/14/2017 at 1:22 AM, johnnie.black said: This one was changed with ipmitool, but it's the same with freeipmi, I changed FAN4 since it's got a two fan spliter and the RPMs reported are not accurate: CPU Temp | 37.000 | degrees C | ok | 0.000 | 0.000 | 0.000 | 95.000 | 100.000 | 100.000 PCH Temp | 43.000 | degrees C | ok | -11.000 | -8.000 | -5.000 | 90.000 | 95.000 | 100.000 System Temp | 35.000 | degrees C | ok | -9.000 | -7.000 | -5.000 | 80.000 | 85.000 | 90.000 Peripheral Temp | 39.000 | degrees C | ok | -13.000 | -11.000 | -9.000 | 76.000 | 81.000 | 86.000 VcpuVRM Temp | 36.000 | degrees C | ok | -9.000 | -7.000 | -5.000 | 95.000 | 100.000 | 105.000 DIMMA1 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMA2 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMB1 Temp | 34.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 DIMMB2 Temp | 33.000 | degrees C | ok | 1.000 | 2.000 | 4.000 | 80.000 | 85.000 | 90.000 FAN1 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN2 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN3 | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 FAN4 | 300.000 | RPM | ok | 0.000 | 100.000 | 200.000 | 25300.000 | 25400.000 | 25500.000 FANA | 1000.000 | RPM | ok | 300.000 | 500.000 | 700.000 | 25300.000 | 25400.000 | 25500.000 12V | 12.128 | Volts | ok | 10.144 | 10.272 | 10.784 | 12.960 | 13.280 | 13.408 5VCC | 4.974 | Volts | ok | 4.246 | 4.298 | 4.480 | 5.390 | 5.546 | 5.598 3.3VCC | 3.333 | Volts | ok | 2.789 | 2.823 | 2.959 | 3.554 | 3.656 | 3.690 VBAT | 3.056 | Volts | ok | 2.384 | 2.496 | 2.580 | 3.476 | 3.588 | 3.672 VCPU | 0.697 | Volts | ok | 0.076 | 0.076 | 0.076 | 1.516 | 1.516 | 1.516 VDIMMAB | 1.191 | Volts | ok | 0.948 | 0.975 | 1.047 | 1.344 | 1.425 | 1.443 5VSB | 4.974 | Volts | ok | 4.246 | 4.376 | 4.480 | 5.390 | 5.546 | 5.598 3.3VSB | 3.248 | Volts | ok | 2.789 | 2.891 | 2.959 | 3.554 | 3.656 | 3.690 VBMC 1.2V | 1.209 | Volts | ok | 1.020 | 1.047 | 1.092 | 1.344 | 1.371 | 1.398 VPCH 1.0V | 1.007 | Volts | ok | 0.872 | 0.890 | 0.917 | 1.043 | 1.052 | 1.070 Chassis Intru | 0x1 | discrete | 0x0100| na | na | na | na | na | na Thanks!
June 20, 20179 yr 6 hours ago, Switchblade said: cool, thanks! BTW, how did you get the report you posted? Install the IPMI plugin:
June 21, 20179 yr On 6/18/2017 at 11:38 PM, Switchblade said: New cables are here and I can confirm that the Tripp Lite Model S508-003 is correct for the LSI 9207-8i. https://www.newegg.com/Product/Product.aspx?Item=9SIA24G28M5864 memtest ran several times with no errors so hardware seems good. I want to test a few more things with the 9207 before I connect my data drives and boot to my production unraid image. Good so far Any power consumption numbers? I'm considering the same build but am hoping for a lowish idle watts.
