[SOLVED] BTRFS issues

[tcharron]

I just saw a huge amount of errors logged.  I never got a warning or error from unraid about this, and the web interface shows nothing concerning.



This is just a small portion of what I'm seeing flood my logs...



Jul 13 14:26:42 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 323772515, rd 238527220, flush 476552, corrupt 0, gen 0
Jul 13 14:26:42 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 323772515, rd 238527221, flush 476552, corrupt 0, gen 0
Jul 13 14:26:42 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 323772515, rd 238527222, flush 476552, corrupt 0, gen 0
Jul 13 14:26:42 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 323772515, rd 238527223, flush 476552, corrupt 0, gen 0
Jul 13 14:26:42 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 323772515, rd 238527224, flush 476552, corrupt 0, gen 0
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS warning (device sdk1): lost page write due to IO error on /dev/sdm1
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4
Jul 13 14:26:43 Tower kernel: BTRFS error (device sdk1): error writing primary super block to device 4

Here is the relevant drive information:

DEVICE	IDENTIFICATION	TEMP.	READS	WRITES	ERRORS	FS	SIZE	USED	FREE	VIEW
Cache	KINGSTON_SV300S37A240G_50026B726706EDE1 - 240 GB (sdk)	25 C	41,038,636	27,137,657	0	btrfs	496 GB	210 GB 286 GB Browse /mnt/cache
Cache 2	INTEL_SSDSC2KW512G8_PHLA8222024A512DGN - 512 GB (sdm)	*	41,038,636	27,137,657	0	Device is part of cache pool
Cache 3	KINGSTON_SV300S37A240G_50026B776407138B - 240 GB (sdn)	22 C	36,990,993	20,943,909	0	Device is part of cache pool

This seems like a failing (failed?) drive, but I don't know if it is sdk or sdm, or if it is something else entirely.  Any ideas?



[JorgeB]

1 minute ago, tcharron said:

Any ideas?

Not without the full diagnostics: Tools -> Diagnostics, please.

[tcharron]

tower-diagnostics-20200713-1449.zip

[JorgeB]

Syslog doesn't show the beginning of the problem, but it shows that one of your cache devices (sdm) dropped offline:

Jul 11 04:40:37 Tower kernel: BTRFS error (device sdk1): bdev /dev/sdm1 errs: wr 279461563, rd 207240495, flush 384145, corrupt 0, gen 0



And by the number of errors it happened some time ago or multiple times, see here for more info.

[tcharron]

So a run of 'btrfs scrub /mnt/cache' has found about a million uncorrectable errors within 30 seconds.



Does this mean that my entire cache drive is toast, and now I need to rebuild it?  Given it is a pool, I would have expected to be able to rebuild (much like when array drives fail), should any single drive have errors.  Is there any way to do this?  Can I just remove sdm and replace it?



[tcharron]

2 minutes ago, tcharron said:

So a run of 'btrfs scrub /mnt/cache' has found about a million uncorrectable errors within 30 seconds.



Does this mean that my entire cache drive is toast, and now I need to rebuild it?  Given it is a pool, I would have expected to be able to rebuild (much like when array drives fail), should any single drive have errors.  Is there any way to do this?  Can I just remove sdm and replace it?



Actually.. When I try to get a smart report for sdm, it tells me that the drive is offline!  This may be good news!



Why doesn't the unraid interface show anywhere that the drive is gone??  I get (from the link you provided) that the error count is wrong, but a red ball on this page would go a long way...



[JorgeB]

4 hours ago, tcharron said:

Actually.. When I try to get a smart report for sdm, it tells me that the drive is offline!

I already mentioned that:

11 hours ago, johnnie.black said:

but it shows that one of your cache devices (sdm) dropped offline:

The link I posted also says what you should do.

[tcharron]

So checked the cables and the device seems stable now.  I was able to rebuild the drive.

root@Tower:~#
btrfs scrub status /mnt/cache
UUID:             100735db-0e88-4450-a406-40f3efdd2bb7
Scrub started:    Tue Jul 14 20:31:42 2020
Status:           finished
Duration:         0:16:16
Total to scrub:   434.15GiB
Rate:             455.50MiB/s
Error summary:    verify=17806 csum=6157411
  Corrected:      6175217
  Uncorrectable:  0
  Unverified:     0
root@Tower:~#

Thanks for your help!

[JorgeB]

As long as there are no uncorrectable errors all should be fine.

[tcharron]

My docker.img was somehow corrupted.  I deleted it and restored my dockers using CA, and all seems well.



[JorgeB]

That's normal if you're using the default system share, since it doesn't checksum the data, so also no way to verify or fix it, that's also mentioned in the FAQ link.
