  1. This is a super cool idea! I am unable to get output for my AX1500i. I'm happy to help test and would appreciate some support. This is the USB Bus 001 Device 005:ID 1b1c:1c02 Corsair Corsair Link TM USB Dongle Unplugging and replugging hot = kernel: usb 1-13: USB disconnect, device number 5 kernel: usb 1-13: new full-speed USB device number 8 using xhci_hcd Now it is listed as: USB Devices Bus 001 Device 001:ID 1d6b:0002 Linux Foundation 2.0 root hub Bus 001 Device 002:ID 0764:0501 Cyber Power System, Inc. CP1500 AVR UPS Bus 001 Device 003:ID 0781:5583 SanDisk Corp. Ultra Fit Bus 001 Device 007:ID 046d:c52b Logitech, Inc. Unifying Receiver Bus 001 Device 008:ID 1b1c:1c02 Corsair Corsair Link TM USB Dongle Bus 002 Device 001:ID 1d6b:0003 Linux Foundation 3.0 root hub
  2. And the top HTOP user PPIDs and other info: ps -ef output: root 14044 1 33 Feb13 ? 04:40:13 /usr/sbin/libvirtd -d -l -f /etc/libvirt/libvirtd.conf -p /var/run/libvirt/libvirtd.pid root 20191 20188 99 Feb13 ? 08:31:31 /usr/lib64/sa/sadc -F -L 1 1 /var/sa root 4464 4460 99 05:33 ? 02:32:21 sadc 1 2 -Z -S A_NULL A_CPU A_IO A_MEMORY A_NET_DEV root 4566 4525 99 05:33 ? 02:33:02 sadc 1 2 -Z -S A_NULL A_CPU A_IO A_MEMORY A_NET_DEV Other strange thing PID 14176 shows as active in htop but it doesn't show in the ps output? I'm learning, but maybe I'm not understanding something.
  3. Digging around in other terminal stuff for high CPU items: From PS -f -aux root 20413 96.3 0.0 0 0 ? R Feb13 505:32 \_ [kworker/u24:3+events_power_efficient] and root 2184 0.0 0.0 2532 1636 ? Ss Feb13 0:00 /usr/sbin/crond root 20187 0.0 0.0 3748 2860 ? S Feb13 0:00 \_ /bin/sh -c /usr/local/emhttp/plugins/dynamix.local.master/scripts/localmaster &> /dev/null root 20190 0.0 0.0 104628 26088 ? SL Feb13 0:00 | \_ /usr/bin/php -q /usr/local/emhttp/plugins/dynamix.local.master/scripts/localmaster root 20196 0.0 0.0 3748 2904 ? S Feb13 0:00 | \_ sh -c nmblookup -M -- - 2>/dev/null|grep -Pom1 '^\S+' root 20197 0.0 0.0 34044 11728 ? D Feb13 0:00 | \_ nmblookup -M -- - root 20198 0.0 0.0 3332 1700 ? S Feb13 0:00 | \_ grep -Pom1 ^\S+ root 20188 0.0 0.0 3748 2756 ? S Feb13 0:00 \_ /bin/sh -c /usr/local/emhttp/plugins/dynamix.system.stats/scripts/sa1 1 1 &> /dev/null root 20191 99.8 0.0 4016 2080 ? R Feb13 501:07 | \_ /usr/lib64/sa/sadc -F -L 1 1 /var/sa and root 14044 31.8 0.0 1269016 19428 ? Rl Feb13 259:21 /usr/sbin/libvirtd -d -l -f /etc/libvirt/libvirtd.conf -p /var/run/libvirt/libvirtd.pid nobody 14158 0.0 0.0 7028 1956 ? S Feb13 0:00 /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/default.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper root 14159 0.0 0.0 6896 240 ? S Feb13 0:00 \_ /usr/sbin/dnsmasq --conf-file=/var/lib/libvirt/dnsmasq/default.conf --leasefile-ro --dhcp-script=/usr/libexec/libvirt_leaseshelper root 14861 0.0 0.0 101920 11684 ? Ss Feb13 0:00 php-fpm: master process (/etc/php-fpm/php-fpm.conf) root 2901 0.0 0.0 105016 13160 ? S 05:29 0:00 \_ php-fpm: pool www root 2939 0.0 0.0 3840 2816 ? S 05:29 0:00 | \_ sh -c /usr/bin/timeout 5 /usr/bin/lsof '/mnt/disks/downloads' 2>/dev/null | /bin/sort -k8 | /bin/uniq -f7 | /bin/grep -c -e REG root 2940 0.0 0.0 2644 816 ? S 05:29 0:00 | \_ /usr/bin/timeout 5 /usr/bin/lsof /mnt/disks/downloads root 2944 0.0 0.0 2748 1864 ? D 05:29 0:00 | | \_ /usr/bin/lsof /mnt/disks/downloads root 2951 0.0 0.0 0 0 ? Z 05:29 0:00 | | \_ [lsof] <defunct> root 2941 0.0 0.0 19188 800 ? S 05:29 0:00 | \_ /bin/sort -k8 root 2942 0.0 0.0 2456 760 ? S 05:29 0:00 | \_ /bin/uniq -f7 root 2943 0.0 0.0 3268 1716 ? S 05:29 0:00 | \_ /bin/grep -c -e REG root 3261 0.0 0.0 105276 13804 ? S 05:30 0:00 \_ php-fpm: pool www root 4459 0.0 0.0 3840 2920 ? S 05:33 0:00 | \_ sh -c sar 1 1 -u -b -r -n DEV|grep -a '^A'|tr -d '\0'|awk '$2=="all" {u=$3;n=$4;s=$5;}; $2=="tps" {getline;r=$5;w=$6;}; $2=="kbmemfree" {getline;f=$2;c=$6+$7;d=$4;}; $2=="eth0" {x=$5;y=$6;} END{pri root 4460 0.0 0.0 2564 768 ? S 05:33 0:00 | \_ sar 1 1 -u -b -r -n DEV root 4464 99.5 0.0 4016 2196 ? R 05:33 141:57 | | \_ sadc 1 2 -Z -S A_NULL A_CPU A_IO A_MEMORY A_NET_DEV root 4461 0.0 0.0 3268 1696 ? S 05:33 0:00 | \_ grep -a ^A root 4462 0.0 0.0 2472 696 ? S 05:33 0:00 | \_ tr -d \0 root 4463 0.0 0.0 10032 2736 ? S 05:33 0:00 | \_ awk $2=="all" {u=$3;n=$4;s=$5;}; $2=="tps" {getline;r=$5;w=$6;}; $2=="kbmemfree" {getline;f=$2;c=$6+$7;d=$4;}; $2=="eth0" {x=$5;y=$6;} END{print u,n,s"\n"r,w"\n"f,c,d"\n"x,y} root 3509 0.0 0.0 105016 13556 ? S 05:31 0:00 \_ php-fpm: pool www root 3857 0.0 0.0 3840 2920 ? S 05:32 0:00 | \_ sh -c /usr/bin/timeout 5 /usr/bin/lsof '/mnt/disks/downloads' 2>/dev/null | /bin/sort -k8 | /bin/uniq -f7 | /bin/grep -c -e REG root 3860 0.0 0.0 2644 748 ? S 05:32 0:00 | \_ /usr/bin/timeout 5 /usr/bin/lsof /mnt/disks/downloads root 3864 0.0 0.0 2748 1740 ? D 05:32 0:00 | | \_ /usr/bin/lsof /mnt/disks/downloads root 3865 0.0 0.0 0 0 ? Z 05:32 0:00 | | \_ [lsof] <defunct> root 3861 0.0 0.0 19188 800 ? S 05:32 0:00 | \_ /bin/sort -k8 root 3862 0.0 0.0 2456 760 ? S 05:32 0:00 | \_ /bin/uniq -f7 root 3863 0.0 0.0 3268 1684 ? S 05:32 0:00 | \_ /bin/grep -c -e REG root 4419 0.0 0.0 105276 13748 ? S 05:33 0:00 \_ php-fpm: pool www root 4523 0.0 0.0 3840 2968 ? S 05:33 0:00 | \_ sh -c sar 1 1 -u -b -r -n DEV|grep -a '^A'|tr -d '\0'|awk '$2=="all" {u=$3;n=$4;s=$5;}; $2=="tps" {getline;r=$5;w=$6;}; $2=="kbmemfree" {getline;f=$2;c=$6+$7;d=$4;}; $2=="eth0" {x=$5;y=$6;} END{pri root 4525 0.0 0.0 2564 764 ? S 05:33 0:00 | \_ sar 1 1 -u -b -r -n DEV root 4566 99.9 0.0 4016 2272 ? R 05:33 142:34 | | \_ sadc 1 2 -Z -S A_NULL A_CPU A_IO A_MEMORY A_NET_DEV
  4. I have had 2 Hard Crashes and 1 Soft crash in the last two weeks. I have had 100% reliability over the last year with no crashes. There have been no hardware changes in months. The most recent change was added Deluge docker. It doesn't run 24/7. ShinobiCCTV docker was the addition prior to that. There were no crashes before Deluge, but I'd prefer to actually learn something than just guess. I experienced a hard crash while connected via Wireguard yesterday. When I got home, the fans were blowing hard, there was no web access, no SSH, no WinSCP. I had to hard reset. I restarted everything, Shinobi and Deluge (for testing) and watched plex. I started the syslog to Cache before bed, no issues. I woke up this morning - WebGUI is semi-responsive. The UNraid animation is present over some sections and won't finish it's job. Unassigned devices doesn't show me anything. WinSCP doesn't work. SSH doesn't work. Docker section shows Unraid animation. I only left Plex, Shinobi and Deluge running over night. VM section won't populate, but nothing was running. Terminal from inside the GUI does appear to work! I want to reboot it, but I'll wait to see if there are any other terminal commands you want me to run. The syslog is attached. I'm new to this - your help is appreciated I may not know much, but the sections below are repeated almost every minute and doesn't seem necessary - is this a hint? If you are curious about my pinning: I currently have 12 CPU threads. Six are isolated and reserved for my Win10Gaming VM. The other six are available to Unraid. Shinobi is pinned to 2 and 7. Feb 13 23:52:08 GLADOS kernel: ? cpuidle_enter_state+0xbf/0x141 Feb 13 23:52:08 GLADOS kernel: do_idle+0x17e/0x1fc Feb 13 23:52:08 GLADOS kernel: cpu_startup_entry+0x6a/0x6c Feb 13 23:52:08 GLADOS kernel: start_secondary+0x197/0x1b2 Feb 13 23:52:08 GLADOS kernel: secondary_startup_64+0xa4/0xb0 Feb 13 23:55:05 GLADOS kernel: rcu: INFO: rcu_sched detected expedited stalls on CPUs/tasks: { 0-... 11-... } 1322496 jiffies s: 721 root: 0x801/. Feb 13 23:55:05 GLADOS kernel: rcu: blocking rcu_node structures: Feb 13 23:55:05 GLADOS kernel: Task dump for CPU 0: Feb 13 23:55:05 GLADOS kernel: kworker/u24:3 R running task 0 20413 2 0x80000008 Feb 13 23:55:05 GLADOS kernel: Workqueue: events_power_efficient gc_worker Feb 13 23:55:05 GLADOS kernel: Call Trace: Feb 13 23:55:05 GLADOS kernel: ? process_one_work+0x16e/0x24f Feb 13 23:55:05 GLADOS kernel: ? worker_thread+0x1e2/0x2b8 Feb 13 23:55:05 GLADOS kernel: ? rescuer_thread+0x2a7/0x2a7 Feb 13 23:55:05 GLADOS kernel: ? kthread+0x10c/0x114 Feb 13 23:55:05 GLADOS kernel: ? kthread_park+0x89/0x89 Feb 13 23:55:05 GLADOS kernel: ? ret_from_fork+0x35/0x40 Feb 13 23:55:05 GLADOS kernel: Task dump for CPU 11:\ What is this? Feb 14 04:20:09 GLADOS kernel: RIP: 0010:nf_conntrack_tuple_taken+0x7f/0x221 Feb 14 04:20:09 GLADOS kernel: Code: fb 49 c1 ef 20 4b 8d 04 fe 49 c7 c6 f0 ff ff ff 48 8b 18 f6 c3 01 0f 85 8a 01 00 00 0f b6 43 37 4c 89 f7 48 89 c1 48 6b c0 38 <48> 29 c7 48 01 df 48 39 ef 0f 84 65 01 00 00 48 8b 05 12 f2 88 00 Feb 14 04:20:09 GLADOS kernel: RSP: 0000:ffff88903bac3a08 EFLAGS: 00000202 Feb 14 04:20:09 GLADOS kernel: RAX: 0000000000000038 RBX: ffff888dbb62c7c8 RCX: 0000000000000001 Feb 14 04:20:09 GLADOS kernel: RDX: 00000000000f020a RSI: 0000000000000000 RDI: fffffffffffffff0 Feb 14 04:20:09 GLADOS kernel: RBP: ffff888dbb62d2c0 R08: 0000000000000003 R09: ffffffff81c8a9c0 Feb 14 04:20:09 GLADOS kernel: R10: 0000000000000001 R11: ffff888ffdec4400 R12: ffff88903bac3a48 Feb 14 04:20:09 GLADOS kernel: R13: ffffffff81e91140 R14: fffffffffffffff0 R15: 000000000000cddc Feb 14 04:20:09 GLADOS kernel: FS: 0000000000000000(0000) GS:ffff88903bac0000(0000) knlGS:0000000000000000 Feb 14 04:20:09 GLADOS kernel: CS: 0010 DS: 0000 ES: 0000 CR0: 0000000080050033 Feb 14 04:20:09 GLADOS kernel: CR2: 0000000000000000 CR3: 0000000001e0a001 CR4: 00000000003606e0 Feb 14 04:20:09 GLADOS kernel: DR0: 0000000000000000 DR1: 0000000000000000 DR2: 0000000000000000 Feb 14 04:20:09 GLADOS kernel: DR3: 0000000000000000 DR6: 00000000fffe0ff0 DR7: 0000000000000400 Feb 14 04:20:09 GLADOS kernel: Call Trace: Whats next? 🔎 syslog.log
  5. Try setting the system log up and then post your logs - https://forums.unraid.net/topic/46802-faq-for-unraid-v6/?do=findComment&comment=781601
  6. I've had two crashes in the last month - and none in the last year - .... I'm following your post. I haven't been able to catch logs. Fully unresponsive. I have started the syslog to a cache SSD as of tonight. I'll see if I catch anything.
  7. Did you figure out the " Failed to add multicast for WSDD: Address already in use" warning?
  8. I had that feeling, and I definitely don't blame Unraid. I just don't know if I'm doing it improperly, or, if the card seems to be presenting itself to VFIO in a strange manner. Is there a way to show it as something else to the guest OS? Its a shame it won't easily work - I don't believe there are any other bitperfect VM/Docker media player options to output audio from my server. Everything else I could find is a separate physical unit.
  9. I plug a HDMI into my MOBO HDMI, the BIOS post and UNRAID boot go through that. I have a preamp input dedicated to the 1080ti hdmi out and a preamp hdmi input dedicated to the GT710 hdmi out. By both test good, Yes - The 710 and the 1080 will both run great in my windows VM when I select either one for passthrough. No bugs, no errors. I don't think the 710 is "broken". It appears both Passthroughs are successful, moving the hardware to the vfio driver:
  10. This XML doesn't work with = No ROM, My rom Dump and an internet downloaded rom version.... I'm guessing it isn't a ROM issue? <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm'> <name>gt710 Volumio</name> <uuid>a2cad0ce-e67f-de37-8481-433641c8146b</uuid> <metadata> <vmtemplate xmlns="unraid" name="Debian" icon="debian.png" os="debian"/> </metadata> <memory unit='KiB'>4194304</memory> <currentMemory unit='KiB'>4194304</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='8'/> </cputune> <os> <type arch='x86_64' machine='pc-q35-4.2'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/a2cad0ce-e67f-de37-8481-433641c8146b_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='1' threads='2'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/disks/nongamingvm/710viotest/Volumio-buster-kernel.rc3-2019-12-02-x86.img'/> <target dev='hdc' bus='sata'/> <boot order='1'/> <address type='drive' controller='0' bus='0' target='0' unit='2'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='sata' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'/> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0xa'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0xb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0xc'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:e9:6a:de'/> <source bridge='br0'/> <model type='e1000-82545em'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </source> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x06' slot='0x00' function='0x1'/> </source> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </hostdev> <memballoon model='none'/> </devices> </domain>
  11. This is the XML and boot log from the currently working 1080ti volumio VM. <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='2'> <name>1080ti Volumio</name> <uuid>15df200f-3a9e-03a5-9d05-62f31c4f95d0</uuid> <metadata> <vmtemplate xmlns="unraid" name="Debian" icon="debian.png" os="debian"/> </metadata> <memory unit='KiB'>4194304</memory> <currentMemory unit='KiB'>4194304</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='8'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-4.2'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/15df200f-3a9e-03a5-9d05-62f31c4f95d0_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='1' threads='2'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/disks/nongamingvm/1080viotest/Volumio-buster-kernel.rc3-2019-12-02-x86.img' index='1'/> <backingStore/> <target dev='hdc' bus='sata'/> <boot order='1'/> <alias name='sata0-0-2'/> <address type='drive' controller='0' bus='0' target='0' unit='2'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <alias name='usb'/> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <alias name='usb'/> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <alias name='usb'/> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x8'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x9'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0xa'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0xb'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0xc'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:f8:60:08'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='e1000-82545em'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-2-1080ti Volumio/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='disconnected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='mouse' bus='ps2'> <alias name='input0'/> </input> <input type='keyboard' bus='ps2'> <alias name='input1'/> </input> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x01' slot='0x00' function='0x1'/> </source> <alias name='hostdev1'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain>
  12. My system overview is: System Overview TITLE INFORMATION System Overview unRAID system: unRAID server Plus, version 6.8.2 Model: Motherboard: ASUSTeK COMPUTER INC. - WS C246 PRO Processor: Intel® Xeon® E-2176G CPU @ 3.70GHz HVM: Enabled IOMMU: Enabled Cache: L1 Cache = 384 kB (max. capacity 384 kB) L2 Cache = 1536 kB (max. capacity 1536 kB) L3 Cache = 12288 kB (max. capacity 12288 kB) Memory: 64 GB (max. installable capacity 64 GB) ChannelA-DIMM1 = 16384 MB, 2666 MT/s ChannelA-DIMM2 = 16384 MB, 2666 MT/s ChannelB-DIMM1 = 16384 MB, 2666 MT/s ChannelB-DIMM2 = 16384 MB, 2666 MT/s Network: eth0: 1000Mb/s, full duplex, mtu 1500 eth1: 1000Mb/s, full duplex, mtu 1500 Kernel: Linux 4.19.98-Unraid x86_64 OpenSSL: 1.1.1d P + Q algorithm: 22287 MB/s + 33066 MB/s Uptime: 0 days, 1 hours, 50 minutes, 32 seconds BIOS TITLE INFORMATION BIOS Information Vendor: American Megatrends Inc. Version: 1102 Release Date: 11/08/2019 Address: 0xF0000 Runtime Size: 64 kB ROM Size: 32 MB Characteristics: PCI is supported APM is supported BIOS is upgradeable BIOS shadowing is allowed Boot from CD is supported Selectable boot is supported BIOS ROM is socketed EDD is supported 5.25"/1.2 MB floppy services are supported (int 13h) 3.5"/720 kB floppy services are supported (int 13h) 3.5"/2.88 MB floppy services are supported (int 13h) Print screen service is supported (int 5h) 8042 keyboard services are supported (int 9h) Serial services are supported (int 14h) Printer services are supported (int 17h) ACPI is supported USB legacy is supported BIOS boot specification is supported Targeted content distribution is supported UEFI is supported BIOS Revision: 5.13 Motherboard TITLE INFORMATION Base Board Information Manufacturer: ASUSTeK COMPUTER INC. Product Name: WS C246 PRO Version: Rev 1.xx Serial Number: Asset Tag: Default string Features: Board is a hosting board Board is replaceable Location In Chassis: Default string Type: Motherboard Processor TITLE INFORMATION Processor Information Socket Designation: LGA1151 Type: Central Family: Xeon Manufacturer: Intel® Corporation ID: Signature: Type 0, Family 6, Model 158, Stepping 10 Flags: FPU (Floating-point unit on-chip) VME (Virtual mode extension) DE (Debugging extension) PSE (Page size extension) TSC (Time stamp counter) MSR (Model specific registers) PAE (Physical address extension) MCE (Machine check exception) CX8 (CMPXCHG8 instruction supported) APIC (On-chip APIC hardware supported) SEP (Fast system call) MTRR (Memory type range registers) PGE (Page global enable) MCA (Machine check architecture) CMOV (Conditional move instruction supported) PAT (Page attribute table) PSE-36 (36-bit page size extension) CLFSH (CLFLUSH instruction supported) DS (Debug store) ACPI (ACPI supported) MMX (MMX technology supported) FXSR (FXSAVE and FXSTOR instructions supported) SSE (Streaming SIMD extensions) SSE2 (Streaming SIMD extensions 2) SS (Self-snoop) HTT (Multi-threading) TM (Thermal monitor supported) PBE (Pending break enabled) Version: Intel® Xeon® E-2176G CPU @ 3.70GHz Voltage: 1.1 V External Clock: 100 MHz Max Speed: 8300 MHz Current Speed: 3663 MHz Status: Populated, Enabled Upgrade: Socket LGA1151 Serial Number: To Be Filled By O.E.M. Asset Tag: To Be Filled By O.E.M. Part Number: To Be Filled By O.E.M. Core Count: 6 Core Enabled: 6 Thread Count: 12 Characteristics: 64-bit capable Multi-Core Hardware Thread Execute Protection Enhanced Virtualization Power/Performance Control Cache Memory TITLE INFORMATION Cache Information Socket Designation: L1 Cache Configuration: Enabled, Not Socketed, Level 1 Operational Mode: Write Back Location: Internal Installed Size: 384 kB Maximum Size: 384 kB Supported SRAM Types: Synchronous Installed SRAM Type: Synchronous Speed: Unknown Error Correction Type: Parity System Type: Unified Associativity: 8-way Set-associative Cache Information Socket Designation: L2 Cache Configuration: Enabled, Not Socketed, Level 2 Operational Mode: Write Back Location: Internal Installed Size: 1536 kB Maximum Size: 1536 kB Supported SRAM Types: Synchronous Installed SRAM Type: Synchronous Speed: Unknown Error Correction Type: Single-bit ECC System Type: Unified Associativity: 4-way Set-associative Cache Information Socket Designation: L3 Cache Configuration: Enabled, Not Socketed, Level 3 Operational Mode: Write Back Location: Internal Installed Size: 12288 kB Maximum Size: 12288 kB Supported SRAM Types: Synchronous Installed SRAM Type: Synchronous Speed: Unknown Error Correction Type: Multi-bit ECC System Type: Unified Associativity: 16-way Set-associative Memory Summary TITLE INFORMATION Physical Memory Array Location: System Board Or Motherboard Use: System Memory Error Correction Type: Single-bit ECC Maximum Capacity: 64 GB Number Of Devices: 4 Memory Devices Configured Memory Speed: 2666 MT/s Minimum Voltage: Unknown Maximum Voltage: Unknown Configured Voltage: 1.2 V Ethernet TITLE INFORMATION Port eth0 Information Supported ports: [ TP ] Supported link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Supported pause frame use: Symmetric Supports auto-negotiation: Yes Supported FEC modes: Not reported Advertised link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Advertised pause frame use: No Advertised auto-negotiation: Yes Advertised FEC modes: Not reported Speed: 1000Mb/s Duplex: Full Port: Twisted Pair PHYAD: 1 Transceiver: internal Auto-negotiation: on MDI-X: on (auto) Supports Wake-on: pumbg Wake-on: g Current message level: 0x00000007 (7) drv probe link Link detected: yes MTU size: 1500 bytes Port eth1 Information Supported ports: [ TP ] Supported link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Supported pause frame use: No Supports auto-negotiation: Yes Supported FEC modes: Not reported Advertised link modes: 10baseT/Half 10baseT/Full 100baseT/Half 100baseT/Full 1000baseT/Full Advertised pause frame use: No Advertised auto-negotiation: Yes Advertised FEC modes: Not reported Speed: 1000Mb/s Duplex: Full Port: Twisted Pair PHYAD: 1 Transceiver: internal Auto-negotiation: on MDI-X: on (auto) Supports Wake-on: pumbg Wake-on: g Current message level: 0x00000007 (7) drv probe link Link detected: yes MTU size: 1500 bytes I followed the @SpaceInvaderOne Win10 Gaming VM video on Youtube. I had my PCIe ACS Override set to - Downstream. I have onboard HDMI, a Nvidia 1080ti and an NVidia GT710. I can change the passthrough graphics card in my Win10 gaming config and it boots fine, audio switches over and both cards run well. So - VM works, passthrough works and both cards test good. The 1080ti is a great gaming card, so that one I want to leave paried with the Win10 machine. Problem: I want to run a second, full time VM with the GT710. This VM is based on Debian, and the image file is here: https://volumio.org/get-started/ This will be a hifi, efficient media player that is in the Unraid box and will output audio via HDMI to my preamp. If I load the video as VNC, it boots and runs fine and I can get to the web gui, but of course there is no sound output. If I pass through ONLY the GT710, it fails to boot. I have tried a downloaded Rom, a dump of my ROM and No ROM attached. All configurations fail to fully boot. There are no obvious errors (to me) in the log, it just stops here: I tried setting my PCIe ACS Override to - Downsteam/multi or "both" in the gui. My current IOMMU output (set to "both") is: I can use the exact same xml and put the 1080ti into it and it boots and runs fine. I can play audio. This isn't a satisfactory resolution, I don't need a 1080ti for an audio card The next two posts will be the XML from the working 1080ti version and the XML from the not working GT710 version. I can't figure this out 😫
  13. Upgrade 6.8.1 to 6.8.2 - No present issues. Additionally, you fixed my Wireguard issue I had been chasing and wondering if it was my network - Solved, thanks to this update. I think it must have been the "host access to custom networks" you listed? Much appreciated.
  14. *** SOLVED - 6.8.2 Fixed this problem. My dockers are able to be reached over WG. No change to any of my settings necessary other than upgrade to 6.8.2. Thank you! ***
