Motherboard - Supermicro X9DR3(i)-F
CPUs - Dual Intel Xeon E5-2670 v2
RAM - 128GB
PCI-e NVMe Card - ASUS Hyper M.2 X16 PCIe 3.0 X4 Expansion Card V2
NVMe Drives - 1TB PM951 NVMe Samsung
Using the above hardware i am having issues using bifurcation to have both NVMe show up in UnRaid to be used as cache drives.
At best using another adapter, Dell dual PCIe NVMe adapter, I was able to get one to show up and even with two separate adapters only one showed up.
Currently the ASUS card is sitting in CPU1 Slot2 PCIe x16 Gen 3 slot according to the Manual i found online and the two NVMe drives are sitting in slots 1 & 2.
I've tried setting the bifurcation to x4x4x4x4, x4x4x8, x16, x4(4) as Gen 2, and am quickly running out of ideas to get this to work.
So far the furtherest I've gotten with the ASUS card is only one drive showing up while the slot was set to x16 Gen3 in the BIOS.
any other settings the slot was in resulted in neither of the drives in showing up.
I know both drives are good because drives have individually shown up in Unraid but just not together, albeit one shows up more often than the other
Maybe the one drive is not doing well or the MB has issue?
Looking to see if anyone out there has the same hardware or issue and have gotten it to work. Not sure what i am missing (it is prob right in front of my face).
There should be plenty of PCIe lanes from the dual CPUs.
Any help is great appreciated.
Thank you
X9DR3(i)-F+ Manual.pdf
