Hello, I am sorry to post again, didn't know what happen, my rebuild is failed after retrying couple of times, to provide context this is continuance from my post before: here
this is the latest diagnostics..
So I want to retry with another harddrive but awhile ago I bought a 12TB hdd, so currently my plan are (and in progress):

1.  clone 10TB disks parity into 12 TB (done)

2. 10TB previously will reformatted and plug in to replace disk C..

however, after I clone 10TB to 12 TB (using clonezilla), when I put it into array, it is not recognized as a new parity. so if i started the array, it will build new parity which all data from disk 3 will be lost. That is why I cloned it first.
is it okay if I follow this guide ? Thanks in advance


tower-diagnostics-20250407-2321.zip

Edited April 7, 20251 yr by jolma
typo

You would need to do a new config, but I'm not familiar with Cloneziel, since parity should not be recognized with a valid filesystem, I assume it was a bit by bit copy like dd, parity won't be valid if it wasn't.



Assuming the new parity is valid, you can try this:



-Tools -> New Config -> Retain current configuration: All -> Apply
-Check all assignments and assign any missing disk(s) if needed, including the new disk3 and new parity, replacement disk3 should be same size or larger than the old one
-IMPORTANT - Check both "parity is already valid" and "maintenance mode" and start the array (note that the GUI will still show that data on parity disk(s) will be overwritten, this is normal as it doesn't account for the checkbox, but it won't be as long as it's checked)
-Stop array
-Unassign disk3
-Start array (in normal mode now), and post new diagnostics

Thank you, "
here is the new diagnostics after following steps above,

After this, if all is alright, next step will be replacing disk 3?

tower-diagnostics-20250408-0125.zip

Edited April 7, 20251 yr by jolma
Typo

31 minutes ago, jolma said:

if all is alright

All is NOT alright.



Emulated disk3 is unmountable. If you rebuild all you will get is an unmountable disk3.



Usually we do check filesystem before rebuilding to make the emulated disk mountable before rebuild.



No idea whether parity is valid enough to allow you to fix the filesystem, but not much else we can try.

start array in maintenance mode and then running check filesystem in disk3 but it keeps loading for long time,

if I just replace disk 3 with another harddrive I will lost all of the data, or return the 10TB original parity disk and try rebuild it with another disk?

I haven't reviewed that other thread. Why did you think cloning parity would be a good idea?

At first I wanted to upgrade my array, I bought a 12TB HDD, because my parity drive is 10TB, so my plan is to set the new 12 TB as a new parity drive formatted the 10TB, then replace one of the array with 10TB array, however while in shipping disk3 (at first size is 1TB) failing, so I replace it with spare 2TB harddrive (my previous thread) and rebuilding failing too, so I want to create parity 12TB (thus cloning) and make sure it is everything ok, then replacing disk3 with 10TB (current plan)

so what is the best plan?

1. put 10TB original parity in new config with "old configuration", then replace disk3 with another harddrive? less risks of losing data but have to buy another drive
2. format 10TB original parity and put it in disks3 with the risks of parity in 12TB is not valid and lost all content in disk3?
Thank you

Sounds like you should have used parity swap. Was sde original disk3? That disk is bad.





1 hour ago, jolma said:

start array in maintenance mode and then running check filesystem in disk3 but it keeps loading for long time

Are you doing this from the webUI and not the command line? Easy to get the command wrong, webUI will get it right.

42 minutes ago, trurl said:

Sounds like you should have used parity swap. Was sde original disk3? That disk is bad.





Are you doing this from the webUI and not the command line? Easy to get the command wrong, webUI will get it right.

I am using web UI, I started the array and rebuilding in progress, but the speed is very slow, only around 800KB/s
here is diagnostic

tower-diagnostics-20250408-0907.zip

52 minutes ago, trurl said:

Was sde original disk3? That disk is bad.

Why are you trying to reuse that very bad disk for rebuild?

I don't have spare drive, so from this, 12TB parity drive is valid?, is it okay now I reformatted 10TB (original parity) then swap it to disk3? If not I have to buy another drive...

Emulated disk3 is mounted so rebuild should be OK, but not on the original disk.



Do not format 10TB. Just assign it as disk3 and start the array to begin rebuild.

9 minutes ago, trurl said:

Emulated disk3 is mounted so rebuild should be OK, but not on the original disk.



Do not format 10TB. Just assign it as disk3 and start the array to begin rebuild.

Okay, I decide to buy another drive, I'll keep 10TB original parity for backup if something happen, so I will assign new drive to disk3 and start the array?

While waiting for new drive, should I put it no device and start the array, just start the array, or just shutdown the unraid and start after new disk arrive?

Edited April 8, 20251 yr by jolma
typo

6 minutes ago, jolma said:

keep 10TB original parity for backup if something happen

Can't simply put that back in as parity if that's what you had in mind. At least, not without following some detailed instructions. If something does happen please ask for advice before doing anything.



8 minutes ago, jolma said:

just shutdown the unraid

That would be safest. You have no redundancy until disk3 is rebuilt.

8 minutes ago, trurl said:

Can't simply put that back in as parity if that's what you had in mind. At least, not without following some detailed instructions. If something does happen please ask for advice before doing anything.



That would be safest. You have no redundancy until disk3 is rebuilt.

Thank you, I will do both of that

so far is good rebuilding parity, will update in 12 hours...

2 hours ago, jolma said:

so far is good rebuilding parity, will update in 12 hours...

I assume you mean "rebuilding disk3"

4 hours ago, trurl said:

I assume you mean "rebuilding disk3"

my bad, yes it is, rebuilding disk3, and it faster than my expectation. but my disk replacement is 4TB and it shows capacity 2TB, is that normal?



Once the rebuild finishes, stop and restart the array and post new diags.

13 hours ago, JorgeB said:

Once the rebuild finishes, stop and restart the array and post new diags.

Sorry got caught at work
Here is the diagnostic and it is weird, I stopped the array, and disk3 is missing, I select the WD4 (newly and finished rebuilding) and wrong volume and started rebuilding again, and wrong file system/unmountable...

tower-diagnostics-20250410-0325.zip

Looks like you rebooted after that, syslog resets when you reboot, so can't see what happened before reboot.



Check filesystem on disk3 from the webUI, post the output.





So do I need to stop rebuilding process? Or wait for it to finished first?

So you are rebuilding an unmountable filesystem onto disk3 and the result will be an unmountable filesystem. Usually we try to repair before rebuilding on top of the same disk. That gives us more options.



I guess you might as well let it complete and hope for the best when we repair the rebuilt filesystem.

32 minutes ago, trurl said:

So you are rebuilding an unmountable filesystem onto disk3 and the result will be an unmountable filesystem. Usually we try to repair before rebuilding on top of the same disk. That gives us more options.



I guess you might as well let it complete and hope for the best when we repair the rebuilt filesystem.

Sori it keeps loading for a long time, here is the file system check


Quote

Phase 1 - find and verify superblock... bad primary superblock - bad magic number !!! attempting to find secondary superblock... .......................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................Sorry, could not find valid secondary superblock Exiting now.



Edited April 9, 20251 yr by jolma
here is the picture below

1 hour ago, jolma said:

Sori it keeps loading for a long time, here is the file system check

Were you running the check from the GUI or the command line?   If the command line what was the exact command you used as it is easy to get it wrong?
