  1. Thanks for sharing. I just installed it. Now to figure out how to use it, lol.
  2. Thanks for the guidance. I'll do the update later tonight. I've been running 6.8.0-rc4 as soon as it came out and this issue just now popped up.
  3. Recently been notified that something is filling my log file. Which file do I go about looking at it to determine what is eating it up? Attached are the system diagnostics. TIA tower-diagnostics-20200113-1751.zip
  4. Happy Birthday UnRAID! I love using UnRAID. It's great that it can run VMs and Docker. Great community helping those that want to learn.
  5. Just reporting that this worked great for me on my headless ThinkServer TS140 server with a Xeon CPU E3-1245 v3. Thanks again.
  6. A minor update. I recently tried using Prime OS, a branch Android X86, and the mouse navigation in VNC is no longer an issue. I'm installing some Amcrest and Wyze apps in the PrimeOS VM to give it a try.
  7. I've moved to a HASSIO VM. Takes more resources but seems to be working for me.
  8. The 64 bit VMDK worked for me as well as the internet & Play Store. I was interested in running TinyCAM Pro to act as a web server for my WyzeCam on the Android VM. After playing around with it though I didn't want to allocate the RAM and CPU resources for one program.
  9. Forewarning: I don't know if this is the best way, but this is how I got it running. I downloaded the 64bit VMDK from here: https://www.osboxes.org/android-x86/#android-x86-8-vmware I then extracted the VMDK, moved it to my domains folder and converted it through Terminal: qemu-img convert -f vmdk /mnt/user/domains/Android/Android-x86_8.1.vmdk -O qcow2 /mnt/user/domains/Android/Android-x86_8.1.qcow2 sudo qemu-img resize /mnt/user/domains/Android/Android-x86_8.1.qcow2 +20G I set up the VM as a Win7 box with the following settings: The Primary vDisk Location points to the above /mnt/user/domains/Android/Android-x86_8.1.qcow2 Again, not really sure if this is the best way. I just applied what I learned installing HASS.io to a VM to this. Mouse control in noVNC is still a pain. I'm still trying to find something else I can use to control it. You can navigate with the keyboard pretty well using the commands found here: http://paperlined.org/apps/android/hardware_keyboard.html
  10. My HA container started acting weird after one of the recent updates. I have it so I can access it through nginix and letsencrypt as detailed by SpaceInvaderOne. For some reason the Port Mapping and port config went missing: The other containers in the "proxynet" network, NodeRed & Bitwarden, are working as intended. I've tried uninstalling, removing, re-installing the HA container multiple times. Any ideas?
  11. I've got a VM running Ubuntu 16.04 LTS in UnRaid 6.5.1 and I cannot get the sound to work in VNC Remote or Chrome Remote Desktop. XML <domain type='kvm' id='7'> <name>Ubuntu_16</name> <uuid>3853e36c-c43e-f4f6-1f09-1f6e7aab7165</uuid> <metadata> <vmtemplate xmlns="unraid" name="Ubuntu" icon="ubuntu.png" os="ubuntu"/> </metadata> <memory unit='KiB'>4194304</memory> <currentMemory unit='KiB'>4194304</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>2</vcpu> <cputune> <vcpupin vcpu='0' cpuset='3'/> <vcpupin vcpu='1' cpuset='7'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-2.11'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/3853e36c-c43e-f4f6-1f09-1f6e7aab7165_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='1' threads='2'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/domains/Ubuntu_16/vdisk1.img'/> <backingStore/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/ubuntu-16.04.3-desktop-amd64.iso'/> <backingStore/> <target dev='hda' bus='sata'/> <readonly/> <boot order='2'/> <alias name='sata0-0-0'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <alias name='usb'/> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <alias name='usb'/> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <alias name='usb'/> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x10'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x11'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0x12'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0x13'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0x14'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/> </controller> <controller type='pci' index='6' model='dmi-to-pci-bridge'> <model name='i82801b11-bridge'/> <alias name='pci.6'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1e' function='0x0'/> </controller> <controller type='pci' index='7' model='pci-bridge'> <model name='pci-bridge'/> <target chassisNr='7'/> <alias name='pci.7'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:ff:ac:31'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='virtio'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-7-Ubuntu_16/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='disconnected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <graphics type='vnc' port='5900' autoport='yes' websocket='5700' listen='0.0.0.0' keymap='en-us'> <listen type='address' address='0.0.0.0'/> </graphics> <sound model='ac97'> <alias name='sound0'/> <address type='pci' domain='0x0000' bus='0x07' slot='0x01' function='0x0'/> </sound> <video> <model type='qxl' ram='65536' vram='65536' vgamem='16384' heads='1' primary='yes'/> <alias name='video0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0'/> </video> <memballoon model='virtio'> <alias name='balloon0'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </memballoon> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain> I previously tried using one of the on-board sound cards too: Here are the IOMMU Groups: IOMMU group 0: [8086:0c08] 00:00.0 Host bridge: Intel Corporation Xeon E3-1200 v3 Processor DRAM Controller (rev 06) IOMMU group 1: [8086:041a] 00:02.0 VGA compatible controller: Intel Corporation Xeon E3-1200 v3 Processor Integrated Graphics Controller (rev 06) IOMMU group 2: [8086:0c0c] 00:03.0 Audio device: Intel Corporation Xeon E3-1200 v3/4th Gen Core Processor HD Audio Controller (rev 06) IOMMU group 3: [8086:8c31] 00:14.0 USB controller: Intel Corporation 8 Series/C220 Series Chipset Family USB xHCI (rev 04) IOMMU group 4: [8086:8c3a] 00:16.0 Communication controller: Intel Corporation 8 Series/C220 Series Chipset Family MEI Controller #1 (rev 04) [8086:8c3d] 00:16.3 Serial controller: Intel Corporation 8 Series/C220 Series Chipset Family KT Controller (rev 04) IOMMU group 5: [8086:153a] 00:19.0 Ethernet controller: Intel Corporation Ethernet Connection I217-LM (rev 04) IOMMU group 6: [8086:8c2d] 00:1a.0 USB controller: Intel Corporation 8 Series/C220 Series Chipset Family USB EHCI #2 (rev 04) IOMMU group 7: [8086:8c20] 00:1b.0 Audio device: Intel Corporation 8 Series/C220 Series Chipset High Definition Audio Controller (rev 04) IOMMU group 8: [8086:8c10] 00:1c.0 PCI bridge: Intel Corporation 8 Series/C220 Series Chipset Family PCI Express Root Port #1 (rev d4) IOMMU group 9: [8086:8c16] 00:1c.3 PCI bridge: Intel Corporation 8 Series/C220 Series Chipset Family PCI Express Root Port #4 (rev d4) IOMMU group 10: [8086:8c26] 00:1d.0 USB controller: Intel Corporation 8 Series/C220 Series Chipset Family USB EHCI #1 (rev 04) IOMMU group 11: [8086:8c56] 00:1f.0 ISA bridge: Intel Corporation C226 Series Chipset Family Server Advanced SKU LPC Controller (rev 04) [8086:8c02] 00:1f.2 SATA controller: Intel Corporation 8 Series/C220 Series Chipset Family 6-port SATA Controller 1 [AHCI mode] (rev 04) [8086:8c22] 00:1f.3 SMBus: Intel Corporation 8 Series/C220 Series Chipset Family SMBus Controller (rev 04) IOMMU group 12: [1283:8893] 02:00.0 PCI bridge: Integrated Technology Express, Inc. IT8893E PCIe to PCI Bridge (rev 41) My System Info: Will audio work at all in VNC or Chrome Remote Desktop? I use CRD as I can't port forward into my home internet connection (4G Wireless via T-Mobile) but it seems to punch through.
  12. Thanks. I got tunnel vision on using $SERIAL. I'll tinker around to see if I can get $DEVICE to work.
  13. I tried a couple things and have hacked something together with my limited knowledge. I'm not a programmer and wasn't sure how to use the environment variables found in the default script in the User Scripts section. I used info I found on the UnRaid wiki and googling leading to more googling. This solution seems to be working... so far ?. I'm learning as I go but maybe someone else may find this approach useful. #!/bin/bash # DRIVE_DEV lists all disks that have My_Passport in the name (although you can use the disk serial number too) # ignores the results with part1 in it # and then outputs the last 3 characters DRIVE_DEV=$(ls -l /dev/disk/by-id/*My_Passport* | grep -v part1 | grep -o '...$') echo "The HDD is located at " $DRIVE_DEV # Mount the drive with the built-in UD script echo "Mounting External HDD" /usr/local/sbin/rc.unassigned mount /dev/$DRIVE_DEV echo "External HDD Mounted" # copy files via rclone to the mounted UD drive echo "Starting to copy files via rclone" rclone copy -v --exclude "*.Squid*" /mnt/user/backup /mnt/disks/My_Passport/BU echo "rclone process complete" # UnMount the drive with the built-in UD script echo "Unmounting External HDD" /usr/local/sbin/rc.unassigned umount /dev/$DRIVE_DEV echo "External HDD Unmounted"
  14. I am running a script to mount and unmount a drive in UAD via User Scripts before and after it copies files. #!/bin/bash /usr/local/sbin/rc.unassigned mount /dev/sdg rclone copy -v /mnt/user/backup /mnt/disks/My_Passport/BU /usr/local/sbin/rc.unassigned umount /dev/sdg When I first wrote the script the /dev/sdg was a USB HDD, but then I started having an Array Undefined issues after a while. I then realized the device designator for the USB HDD is no longer /dev/sdg but changed to /dev/sda, and /dev/sdg is now one of the disks in my array. Is there a way to query what the Device Designator is for the USB HDD prior to mounting so that it mount/unmounts the USB HDD? Or mount it by it's SERIAL # as shown in the sample scripts?
