MammothJerk

i have an issue with my smart health overview where every drive shows up twice (and my SSD cache shows up thrice) as you can see the duplicate row only has the "health ok?" info which the other row is missing, and they both have the same device id.

awesome job on 1.6! 👍👍 Couple of comments i have: the installing of dalvany-image-panel seemed kinda strange, i had to install about 3 times before it actually started working even with restarts in-between. Not sure what was up with that The "array status" field $.['servers']['https://192.168.1.7']['serverDetails'].arrayStatus needs to be edited to match your own server ip. Or i think the entire field can safely be changed to just $.['serverDetails'].arrayStatus i did not have to login again when i changed the vm/docker base url, it just worked straight away. but since you are using SSL then that would be the difference most likely. For people running without SSL the base url should just be the unraid server ip. you should be able to grab it as a variable from the unraid api source maybe? The SSD variables are not universal and might have to be tailored to your specific SSD vendor as well. i have a kingston A400 SSD https://www.kingston.com/datasheets/SA400S37_en.pdf and i had to change the Data_Units_Reda/Written to Total_LBAs_Read/Written and then add *512 to math to get an accurate reading. I'm not sure how many people use "Anime Shows" as their plex library name, i would've thought it'd just be "Anime" that's just my opinion though. For me i had to change the regex in RAM DIMM temp to actually match mine which then became /dimm.._temp/ it's possible theres a better regex to match most dimm temps rather than just /..-dimm/ but i wouldn't know most naming schemes 🤔. Why is there a currency suffix variable that is unused? i have to enter the three UPS panels and change the Field->Unit->Currency to my locale and the top variable seems to do nothing? i suspect it was supposed to be integrated at some point but just got missed? 😂 Again, Great job @falconexe!

If i am force rechecking hundreds of torrents some of them will sometimes start downloading for a split second EVEN THOUGH theyre PAUSED. This sometimes overwrites the already correct download with a new file and i'll have to download the entire thing again any way to fix this? when force rechecking it should NEVER start downloading if the initial state is paused.

1. I'm only using the delugevpn privoxy for sonarr. 2. 192.168.1.0/24 and my server address is 192.168.1.105 3. sonarr and delugevpn are both running bridged. delugevpn settings: Sonarr settings With the latest delugevpn container sonarr can only connect to deluge download client if the host is set to 172.17.0.9. localhost or 192.168.1.105 does NOT work. Same story with the proxy under general > proxy. downgrading to the previous container i have no issues.

Wait so to clarify: for dockers to make use of the delugevpn privoxy (and even the download client for radarr/sonarr/lidarr) they must have "--net=container:Binhex-DelugeVPN" in their extra parameters?

I had to install the grafana-worldmap-panel and the grafana-piechart-panel for those specific panels to show up under my plex section. Just paste these 2 commands in the Grafana docker console and then restart the container 😁 grafana-cli plugins install grafana-worldmap-panel grafana-cli plugins install grafana-piechart-panel Great progress in 1.5!

This seems to be it. I unplugged the Commander Pro from its USB header and started the server again and it instantly connected to the APC UPS daemon with no problem. Now the only issue i have left is not getting the relevant realtime UPS load, but as you say it's a hardware limitation so i would have to upgrade my UPS in the future 😁 Thanks a lot for your help!

Whats throwing me is that other than the UPS load information not updating in realtime - NUT works without any problems. It would seem that the issue is on the software side edit: quick response 😁, ill try disconnecting iCue and get back to you

im using the same cable that came in the box with the UPS so i would assume its official. Yes it is RJ45/USB

any ideas?

root@tower:~# cat /var/log/syslog | grep "apcupsd" Oct 30 21:18:51 tower root: Starting apcupsd power management: /sbin/apcupsd Oct 30 21:18:51 tower apcupsd[12378]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 30 21:18:51 tower apcupsd[12378]: NIS server startup succeeded Oct 30 21:20:54 tower apcupsd[12378]: apcupsd exiting, signal 15 Oct 30 21:20:54 tower apcupsd[12378]: apcupsd shutdown succeeded Oct 30 21:20:56 tower apcupsd[24185]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 30 21:20:56 tower apcupsd[24185]: NIS server startup succeeded Oct 30 21:25:33 tower apcupsd[24185]: apcupsd exiting, signal 15 Oct 30 21:25:33 tower apcupsd[24185]: apcupsd shutdown succeeded Oct 30 21:25:33 tower apcupsd[5352]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 30 21:25:33 tower apcupsd[5352]: NIS server startup succeeded Oct 30 21:25:39 tower apcupsd[5352]: apcupsd exiting, signal 15 Oct 30 21:25:39 tower apcupsd[5352]: apcupsd shutdown succeeded Oct 30 21:25:39 tower apcupsd[5594]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 30 21:25:39 tower apcupsd[5594]: NIS server startup succeeded Oct 31 10:52:34 tower apcupsd[5594]: apcupsd exiting, signal 15 Oct 31 10:52:34 tower apcupsd[5594]: apcupsd shutdown succeeded Oct 31 10:52:41 tower apcupsd[30126]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 10:52:41 tower apcupsd[30126]: NIS server startup succeeded root@tower:~# cat /var/log/syslog | grep "APCUPSD" root@tower:~# Nothing to indicate anything going wrong here... I tried removing the USB cable, using a different slot, even using a 3.0 header and no change at all. I found a new issue now though, with the USB cable COMPLETELY DISCONNECTED i still get the same behavior in the UPS settings, UPS status set to refreshing... and nothing else happening. so theres definitely SOMETHING wrong. Oct 31 10:52:34 tower apcupsd[5594]: apcupsd exiting, signal 15 Oct 31 10:52:34 tower apcupsd[5594]: apcupsd shutdown succeeded Oct 31 10:52:41 tower apcupsd[30126]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 10:52:41 tower apcupsd[30126]: NIS server startup succeeded Oct 31 10:52:41 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (deluged) Oct 31 10:53:12 tower login[32238]: ROOT LOGIN on '/dev/pts/0' Oct 31 11:09:56 tower kernel: usb 3-9: USB disconnect, device number 7 Oct 31 11:10:11 tower apcupsd[30126]: apcupsd exiting, signal 15 Oct 31 11:10:11 tower apcupsd[30126]: apcupsd shutdown succeeded Oct 31 11:10:19 tower apcupsd[1422]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:10:19 tower apcupsd[1422]: NIS server startup succeeded Oct 31 11:10:19 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:10:47 tower kernel: usb 3-2: new low-speed USB device number 10 using xhci_hcd Oct 31 11:10:47 tower kernel: hid-generic 0003:051D:0002.0009: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-2/input0 Oct 31 11:10:58 tower apcupsd[1422]: apcupsd exiting, signal 15 Oct 31 11:10:58 tower apcupsd[1422]: apcupsd shutdown succeeded Oct 31 11:11:02 tower apcupsd[4551]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:11:02 tower apcupsd[4551]: NIS server startup succeeded Oct 31 11:11:02 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:12:04 tower apcupsd[4551]: apcupsd exiting, signal 15 Oct 31 11:12:04 tower apcupsd[4551]: apcupsd shutdown succeeded Oct 31 11:12:09 tower apcupsd[8977]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:12:09 tower apcupsd[8977]: NIS server startup succeeded Oct 31 11:12:09 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:12:30 tower kernel: usb 3-2: USB disconnect, device number 10 Oct 31 11:12:38 tower apcupsd[8977]: apcupsd exiting, signal 15 Oct 31 11:12:38 tower apcupsd[8977]: apcupsd shutdown succeeded Oct 31 11:12:41 tower apcupsd[11059]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:12:41 tower apcupsd[11059]: NIS server startup succeeded Oct 31 11:12:42 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:13:18 tower kernel: usb 3-3: new low-speed USB device number 11 using xhci_hcd Oct 31 11:13:18 tower kernel: hid-generic 0003:051D:0002.000A: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-3/input0 Oct 31 11:14:08 tower apcupsd[11059]: apcupsd exiting, signal 15 Oct 31 11:14:08 tower apcupsd[11059]: apcupsd shutdown succeeded Oct 31 11:14:13 tower apcupsd[18360]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:14:13 tower apcupsd[18360]: NIS server startup succeeded Oct 31 11:14:13 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:17:58 tower kernel: usb 3-3: USB disconnect, device number 11 Oct 31 11:18:01 tower kernel: usb 3-4: new low-speed USB device number 12 using xhci_hcd Oct 31 11:18:01 tower kernel: hid-generic 0003:051D:0002.000B: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-4/input0 Oct 31 11:18:15 tower apcupsd[18360]: apcupsd exiting, signal 15 Oct 31 11:18:15 tower apcupsd[18360]: apcupsd shutdown succeeded Oct 31 11:18:18 tower apcupsd[2009]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:18:18 tower apcupsd[2009]: NIS server startup succeeded Oct 31 11:18:19 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:18:25 tower kernel: usb 3-4: USB disconnect, device number 12 Oct 31 11:18:34 tower kernel: usb 3-2: new low-speed USB device number 13 using xhci_hcd Oct 31 11:18:34 tower kernel: hid-generic 0003:051D:0002.000C: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-2/input0 Oct 31 11:18:42 tower apcupsd[2009]: apcupsd exiting, signal 15 Oct 31 11:18:42 tower apcupsd[2009]: apcupsd shutdown succeeded Oct 31 11:18:46 tower apcupsd[3970]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:18:46 tower apcupsd[3970]: NIS server startup succeeded Oct 31 11:18:46 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:25:04 tower kernel: usb 3-2: USB disconnect, device number 13 Oct 31 11:25:09 tower apcupsd[3970]: apcupsd exiting, signal 15 Oct 31 11:25:09 tower apcupsd[3970]: apcupsd shutdown succeeded Oct 31 11:25:14 tower apcupsd[29666]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:25:14 tower apcupsd[29666]: NIS server startup succeeded Oct 31 11:25:14 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5) Oct 31 11:26:05 tower apcupsd[29666]: apcupsd exiting, signal 15 Oct 31 11:26:05 tower apcupsd[29666]: apcupsd shutdown succeeded Oct 31 11:26:11 tower kernel: usb 3-2: new low-speed USB device number 14 using xhci_hcd Oct 31 11:26:11 tower kernel: hid-generic 0003:051D:0002.000D: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-2/input0 Oct 31 11:26:20 tower apcupsd[1371]: apcupsd 3.14.14 (31 May 2016) slackware startup succeeded Oct 31 11:26:20 tower apcupsd[1371]: NIS server startup succeeded Oct 31 11:26:20 tower kernel: hid-generic 0003:1B1C:0C10.0001: hid_field_extract() called with n (128) > 32! (swapper/5)

Searching for "APC" in the output only shows me this line and its surrounding [ 12.676866] sda: sda1 [ 12.678857] sd 0:0:0:0: [sda] Attached SCSI removable disk [ 12.831161] usb 3-7.1: new low-speed USB device number 8 using xhci_hcd [ 12.943735] input: HID 0557:2419 as /devices/pci0000:00/0000:00:14.0/usb3/3-7/3-7.1/3-7.1:1.0/0003:0557:2419.0003/input/input1 [ 12.946475] hid-generic 0003:051D:0002.0004: hiddev98,hidraw2: USB HID v1.10 Device [APC Back-UPS ES 700G FW:871.O3 .I USB FW:O3 ] on usb-0000:00:14.0-9/input0 [ 12.996334] hid-generic 0003:0557:2419.0003: input,hidraw3: USB HID v1.00 Keyboard [HID 0557:2419] on usb-0000:00:14.0-7.1/input0 [ 12.998411] input: HID 0557:2419 as /devices/pci0000:00/0000:00:14.0/usb3/3-7/3-7.1/3-7.1:1.1/0003:0557:2419.0005/input/input2 [ 12.999323] hid-generic 0003:0557:2419.0005: input,hidraw4: USB HID v1.00 Mouse [HID 0557:2419] on usb-0000:00:14.0-7.1/input1 [ 13.061171] usb 3-10: new full-speed USB device number 9 using xhci_hcd [ 13.117035] random: fast init done under system devices -> usb devices i have this line as well if it matters Bus 003 Device 007: ID 051d:0002 American Power Conversion Uninterruptible Power Supply

I had this issue before installing NUT, and I assumed stopping the NUT UPS tools service would be sufficient to not cause a conflict, but ive removed the NUT plugin anyway. I still have the issue even after a complete server reboot and restarting the APC UPS daemon.

I'm tunneled into my network from accross the country and i'm having a weird issue trying to connect. I have 2 unraid servers on this local network both setup with a separate tunnel connection because of this specific issue. When i'm connected to server1tunnel i cannot access the deluge thinclient connection on server1, but i CAN access the deluge thinclient connection on server2. Same thing when connected to server2tunnel i cannot access the deluge thinclient connection on server2, but i CAN access it for server1. What is weird is that i can access the webUI from either of the tunnel connections, its just the thinclient that does not work. I've also noticed that i cannot use the PiHole as DNS server if i am connected to server1tunnel, but i can use it when using the server2tunnel (pihole is setup on server1). i also have some weird server1 webUIs that do not work when im connected to the server1tunnel, like soulseek, pihole, and seemingly any docker using VNC to use dockers such as mkvtoolnix, krusader, etc. I'm having none of these problems when on location at the local network so i must have something wrong with the tunnel setup. Any ideas?

I have an APC Back-UPS ES 700VA connected via RJ45/USB cable to my unraid server and i am having an issue seeing its stats. When using the built in "UPS Settings" the "UPS STATUS" is stuck showing "Refreshing..." and will never show any other information. I'm not sure if there is something broken or if the firmware is corrupted or something. The weird thing is that the NUT v2 UPS plugin works as intended and show all relevant information except for the UPS load only showing when on battery power. Any ideas?

aha i see. Seems like very strange behaviour to only report UPS load when disconnected, but atleast i know my UPS is not broken, thanks!

Disconnecting the mains from my ups for about a minute did indeed change the shown UPS load to now 182 watts while the charge decreased to 93% any steps where to go from here? sorry for the long delay, i haven't had physical access for some time edit: When the server is on UPS power the UPS load will update in realtime together with the battery percentage this is how my grafana graph looks like to show how useless it is when i dont get the updated correct information lol, the last fluctiations are after disconnecting the mains While the UPS is charging the UPS load does not seem to update again, it will only update if the mains is disconnected..

I'm having an issue where UPS load is not updating at all. It starts out at 162W and sits there stuck even with load changes and parity checking etc. it never changes. Any idea why i'm having this problem? I would use the built-in unraid APC UPS plugin but that doesnt give me any info whatsoever, its just stuck when starting for some reason.

My UPS is a bit finicky with the apcups plugin and does not always work correctly, NUT however always works and i created a small edit to the UPS section if you would like to add the option for NUT. Firstly you need the "NUT Network UPS Tools" plugin for unraid and then the "maihai/nut-influxdb-exporter" docker to get the data to the influxdb database. then all you need to do is change the variables around a bit and it works just the same as the apcups option Attached is the UPS section of the main dashboard edited to work with NUT :). NUT UPS Dashboard for falconexe-1601050759513.json

I liked this dashboard so much i decided to install it on my other unraid box as well :), but i'm having an issue with CPU temp :(. I cannot get my CPU temp from IPMI since this is an unraid box made from spare parts and lacks IPMI support, i can see the CPU temp in the unraid dashboard so i assume it should be possible to send that reading through telegraf, the question is how? the telegraf [[inputs.cpu]] seem to only take care of usage, not temperature. the guide also seems to be missing [[inputs.net]] and [[inputs.docker]], i had to uncomment both of these to get any readings for network and docker on this other box. Lastly just a minor thing, i run both my dashboards on the same grafana instance and i would like to be able to switch between them seamlessly in kiosk mode. Currently i have "dashboard Links" setup on each dashboard to navigate to each-other, the problem is that this button gets hidden in kiosk mode, Is there any way to keep it on top even in kiosk mode? 😁

There we go 😁 It appears by default it is commented as "attributes = false" i had uncommented it which is probably what screwed me there, changing it to "true" has fixed my problem. Thanks for your help

I fixed the diskio tags and i see where i was missing out on that one hehe. It did not fix the POH issue though, removing the LIMIT didn't change anything either.

ah ok, it seems like there is no data so perhaps i screwed up with telegraf.conf? all i did was uncomment [[inputs.diskio]]. # Read metrics about disk IO by device [[inputs.diskio]] # By default, telegraf will gather stats for all devices including # disk partitions. # Setting devices will restrict the stats to the specified devices. #devices = ["sda", "sdb", "vd*"] # Uncomment the following line if you need disk serial numbers. #skip_serial_number = false # On systems which support it, device metadata can be added in the form of # tags. # Currently only Linux is supported via udev properties. You can view # available properties for a device by running: # 'udevadm info -q property -n /dev/sda' # Note: Most, but not all, udev properties can be accessed this way. Properties # that are currently inaccessible include DEVTYPE, DEVNAME, and DEVPATH. #device_tags = ["ID_FS_TYPE", "ID_FS_USAGE"] # Using the same metadata source as device_tags, you can also customize the # name of the device via templates. # The 'name_templates' parameter is a list of templates to try and apply to # the device. The template may contain variables in the form of '$PROPERTY' or # '${PROPERTY}'. The first template which does not contain any variables not # present for the device is used as the device name tag. # The typical use case is for LVM volumes, to get the VG/LV name instead of # the near-meaningless DM-0 name. #name_templates = ["$ID_FS_LABEL","$DM_VG_NAME/$DM_LV_NAME"] ok i just re-read the front page and noticed i missed the part about the diskio tags 😬, ill fix that and test again

quick reply 😁 here ya go { "request": { "method": "GET", "url": "api/datasources/proxy/1/query", "params": { "db": "telegraf", "q": "SELECT last(\"raw_value\") AS \"Power On Hours\" FROM \"smart_attribute\" WHERE (\"name\" = 'Power_On_Hours') AND time >= now() - 12h GROUP BY \"device\" LIMIT 10", "epoch": "ms" }, "data": null, "precision": "ms" }, "response": { "results": [ { "statement_id": 0 } ], "executedQueryString": "SELECT last(\"raw_value\") AS \"Power On Hours\" FROM \"smart_attribute\" WHERE (\"name\" = 'Power_On_Hours') AND time >= now() - 12h GROUP BY \"device\" LIMIT 10" } }
