  1. Update. Its always a good idea to use the latest version. It could have some security updates etc. Sent from my iPhone using Tapatalk
  2. Do you have isolated the cores, to work only with the vm? Sent from my iPhone using Tapatalk
  3. No, this was certanly not was i was hoping for. I wanted each device to be in its own IOMMU group. Try another pci slot, as bastl mentioned. Sent from my iPhone using Tapatalk
  4. The gfx card is the onboard one, so you need to enable ACS override in the vm settings, to split the IOMMU group. Before you can passthrough the sound card. Sent from my iPhone using Tapatalk
  5. Could you have the unraid log-window open at the same time you shutdown or restart the vm? This was how bastl discovered my usb reset problem. Maybe yours will reveal something else. Sent from my iPhone using Tapatalk
  6. You are right, but is there not a different between a normal usb card, and the one connected to the nvidia card i was trying to passthrough? My problem with the complete lockup of unraid was also i 6.7 as i remember. But that was not a thing i used so much time on, to investigate. Sent from my iPhone using Tapatalk
  7. Yes, the actionstar is an old usb hub. I use it for the ease og passthrough the usb devices. My server sits in the basement, and i use a hdmi/usb to ethernet converter, that only have one usb port. Strange thing, even if i unplug multiple times, it shows up twice in the system list. I will do some testing, and buy a new one if this becomes a problem. Sent from my iPhone using Tapatalk
  8. I just booted windows, started a game and shutdown the vm. No issues so fare, i will test more tomorrow. I can't believe it was that easy. I've been struggling with this for so long and then it was just a fucking usb controller. I just thought it was supposed to be passthroug, because it was in the same IOMMU group and part of the NVIDIA card. You are the man bastl. Thanks for all the help, i appreciate it.
  9. bigassserver-diagnostics-20191104-2113.zip Here you go : <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm'> <name>Windows 10 NVIDIA</name> <uuid>3872329d-c795-ad63-e319-f9a42aec7665</uuid> <description>gamer</description> <metadata> <vmtemplate xmlns="unraid" name="Windows 10" icon="/mnt/cache/VM/icons/windows_teamgreen.png" os="windows10"/> </metadata> <memory unit='KiB'>12582912</memory> <currentMemory unit='KiB'>12582912</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>8</vcpu> <cputune> <vcpupin vcpu='0' cpuset='1'/> <vcpupin vcpu='1' cpuset='11'/> <vcpupin vcpu='2' cpuset='2'/> <vcpupin vcpu='3' cpuset='12'/> <vcpupin vcpu='4' cpuset='3'/> <vcpupin vcpu='5' cpuset='13'/> <vcpupin vcpu='6' cpuset='4'/> <vcpupin vcpu='7' cpuset='14'/> </cputune> <os> <type arch='x86_64' machine='pc-q35-4.0.1'>hvm</type> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none'> <topology sockets='1' cores='4' threads='2'/> </cpu> <clock offset='localtime'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/disks/KINGSTON_SA400S37120G_50026B7682823576/Windows 10/vdisk1.img'/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/iso/Win10_1903_V2_English_x64.iso'/> <target dev='hda' bus='sata'/> <readonly/> <boot order='2'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/iso/virtio-win-0.1.160-1.iso'/> <target dev='hdb' bus='sata'/> <readonly/> <address type='drive' controller='0' bus='0' target='0' unit='1'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'/> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0xa'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0xb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0xc'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0xd'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x5'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0xe'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x6'/> </controller> <controller type='pci' index='8' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='8' port='0xf'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x7'/> </controller> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <controller type='sata' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <interface type='bridge'> <mac address='52:54:00:0c:02:99'/> <source bridge='virbr0'/> <model type='virtio'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <hostdev mode='subsystem' type='pci' managed='yes' xvga='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </source> <rom file='/mnt/disks/KINGSTON_SA400S37120G_50026B7682823576/Asus.GTX1660.6144.190225.rom'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x00' function='0x1'/> </source> <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x00' function='0x2'/> </source> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x02' slot='0x00' function='0x3'/> </source> <address type='pci' domain='0x0000' bus='0x07' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x046d'/> <product id='0xc521'/> </source> <address type='usb' bus='0' port='1'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x046d'/> <product id='0xc52b'/> </source> <address type='usb' bus='0' port='2'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x2101'/> <product id='0x8501'/> </source> <address type='usb' bus='0' port='3'/> </hostdev> <memballoon model='none'/> </devices> </domain>
  10. I’am not sure which one. Is it the serial bus controller? Sent from my iPhone using Tapatalk
  11. Yeah, I can see that it look like two different things. Sorry, I was not ready in my wording [emoji4] I tried to describe that the freeze only accures on shutdown of the vm, not when using it for hours. Sent from my iPhone using Tapatalk
  12. So this is where i am right now. 1. Booted Windows with vbios. 2. NVIDIA control panel announced that there was a new driver. 3. Updated the driver. 4. Almost at the end... bang, everything frooze. I noticed that really quick, because the internet in the whole house died... and the kids went crazy :-) 5. Hard reset unraid. 6. Booted Windows again. 7. New driver defintly installed, because of new Ultra HD resolutions. 8. Started diablo 3 9. Gave me a D3D error. 10. Downloaded and installed directx, that went fine. 11. Restartet Windows without any problems. 12. Started diablo 3 again, that gave me some wired shit colors and resolution on the screen. 13. Tried another game, that worked fine. 14. Went to NVIDIA control panel and reinstalled the driver, without any issue. 15. Tried diablo again, without luck. 16. Investigated more into diablo, it seems the game has taken the higest accessible solution and used that as standard. 17. Changed the settings in D3Prefs file, and now the game is running again. 18. Shutdown Windows.... bang... everything frooze within Seconds. Back to 1. :-( I was watching unraid and Windows log the whole time. The last line in unraid log, says kernel: usb 2-1-port3: cannot reset (err = -110) Sent from my iPhone using Tapatalk
  13. Okay, the whole system just now hangs, after a driver update. Damn that sucks. Sent from my iPhone using Tapatalk
  14. Sorry, i dident answer all your questions. Yes, the audio controller is also passthrough, and no usb. The vm is running now with vbios from techpowerup, so i will report back later. Sent from my iPhone using Tapatalk
  15. Thanks for letting me know Tom Sent from my iPhone using Tapatalk
