raidserver

beta30 fixed devmapper SSD passthrough issue for me. Thank you

My original issue with the PCIE x4 port which i use for the HBA card/HDD`s never gave me any issues other than spamming the log with errors. Its a power management issue with the HBA trying to save power. Turning the pcie aspm off for the x4 socket solved the log errors. Hope new motherboard swap fixes your issue @Muath Edit Switched off aspm via BIOS

Not sure about nVidia 670, can you test a newer card? 980 + 1060 successful with Supermicro motherboard. Nothing needed other than choosing it within the template. Enter server BIOS and select iGPU onboard graphics to boot first which hands off the GPU for passthrough. No video output if you havent done this, windows starts loading then black screen. I couldnt be happier with Win10 VM`s. Easily passthrough SSD`s & USB devices ie: XBOX wireless for gaming 15metres away from the server

Thanks Enabling write cache manually worked but the changes were not persistent through reboots on AMD server. Working perfectly now.

Uneventful update to x2 unRaid servers. Thanks LimeTech👍

Solid update. Thanks for the hardwork Limetech

EDIT: Thanks but i have sent it back for a different drive. Will try again in the future.

With a good dose of patience windows has made it to desktop via VNC i see the NVME drive. Performance is terrible though it takes forever to boot & shutdown. the VM log is showing 2019-05-09T16:48:18.233068Z qemu-system-x86_64: warning: guest updated active QH spamming the log tail

thanks cybernook, after a bit of fumbling around with the xml iam now at the stage of booting windows which is hanging on boot loading window. I no longer receive the error stated. heres my xml, maybe i have overlooked something. Reinstalled 6.7 rc8 EDIT: added vm log which shows an error near end. win8.1 xml.txt vm log.txt

Struggling to passthrough nvme drive too. Crucial CT1000P1SSD8 P1 1 TB [c0a9:2263] 07:00.0 Non-Volatile memory controller: Micron/Crucial Technology Device 2263 (rev 03) internal error: qemu unexpectedly closed the monitor: 2019-05-08T16:39:22.718254Z qemu-system-x86_64: -device vfio-pci,host=07:00.0,id=hostdev3,bus=pci.0,addr=0x9: vfio 0000:07:00.0: failed to add PCI capability 0x11[0x50]@0xb0: table & pba overlap, or they don't fit in BARs, or don't align Unraid 6.7.0-rc8 I have tried adding the alias line to my xml but that doesnt change anything, as the qemu code is also need. Is there anything i must do or should i be patient? EDIT: While i wait patiently i have rolled back to rc7 and all is well.

I have updated the newer 2.2b BIOS. The same errors started to spam the log file continuously again. It is occupied by my RocketRAID 640L. Before i decided to occupy the only other PCIE slot (x16) i read THIS bug report thread which has a few fixes to try. I have turned off/disabled pcie aspm on the x4 currently used slot. This power management option has fixed this issue. No more error logs.

Quick follow up about this because its been bugging me since i flashed the BIOS. When i revisited supermicro i found only an older BIOS which once flashed has been fine and i have no syslog errors now. I reached out to supermicro for an answer, they said. "The BIOS 2.2 we had on our website had fixes for the Spectre vulnerabilities. However, the fixes had issues and Intel has asked all Vendors to revoke the updates until new Micro codes can be released. So it's possible the new BIOS had the issues you saw, and our current advise would be to use the 2.0c BIOS version from our website."

thanks i was getting a bit worried as i thought the error was spamming the logs when i booted the server up, but that is not the case and the errors have not returned.

Ever since i have updated my supermicro motherboard BIOS i have been receiving these errors in the system log. Feb 1 15:47:48 Tower kernel: pcieport 0000:00:1c.0: AER: Corrected error received: id=00e0 Feb 1 15:47:48 Tower kernel: pcieport 0000:00:1c.0: PCIe Bus Error: severity=Corrected, type=Data Link Layer, id=00e0(Transmitter ID) Feb 1 15:47:48 Tower kernel: pcieport 0000:00:1c.0: device [8086:a110] error status/mask=00003000/00002000 Feb 1 15:47:48 Tower kernel: pcieport 0000:00:1c.0: [12] Replay Timer Timeout After BIOS flash i have cleared CMOS and set up the server as "i think" i had it prior to the update. 8086:a110 is 8086:a110] 00:1c.0 PCI bridge: Intel Corporation Sunrise Point-H PCI Express Root Port #1 (rev f1) Would appreciate any input many thanks tower-syslog-20180201-1550.zip

since i have upgraded my very poor ISP bundled router/firewall/wifi box to a pfsense minipc(somewhat overkill) i have seen very stable VPN torrents. Before i found that it would peak then drop for awhile. Iam almost certain it was the poor devices lack of power to route the encrypted traffic consistently. AES-256-CBC with multiple connections @ 20mbit/s troughput.
