[Support] cmccambridge - ocrmypdf-auto

18 posts in this topic Last Reply

Recommended Posts




Application: ocrmypdf-auto

Overview: Automatic OCR of image PDFs from an input directory to an output directory using ocrmypdf and the latest tesseract.

Docker: https://quay.io/repository/cmccambridge/ocrmypdf-auto

Application GitHub: https://github.com/cmccambridge/ocrmypdf-auto



This container automates one stage in a "paperless" document processing pipeline: Take all the PDFs in some input folder, run OCR on them, and save the output to an output folder.  It combines the excellent tools ocrmypdf and tesseract with file-monitoring and some new configurability.



For example, you could configure a wireless document scanner to save all images to one share on your unRAID server, and use this container to monitor all new incoming files, OCR them, and write the finished (searchable!) PDFs to another share:




For details on how to configure the container and ocrmypdf to tweak OCR behavior, please see the README on GitHub! You can configure:

  • What options (per-folder) to pass to ocrmypdf
    • e.g. one folder for clean, normal page size grayscale scans from the document scanner
    • e.g. a separate folder for skewed, poor contrast receipts from a phone app
    • e.g. a separate folder for multi-language scans
  • What to do with original files after OCR
    • Archive them to a 2nd output folder?
    • Delete them?
  • Where to store temporary files
    • By default, within the container
    • Or: configure your own high-speed temporary path (cache disk, ramdisk, etc.)



Questions?

Post any other questions or issues relating to this Docker container in this thread.





Edited by cmccambridge
Better container docs

Share this post


Link to post

I see at your GitHub that the unRAID template is "TODO", so I am going to approve this new user first post, but will not move it to Docker Containers until that is "DONE".





Share this post


Link to post

Great catch @trurl, thanks! The unRAID template is already up and running here, but I had forgotten to go back and tidy up my TODO list.



There is now unRAID-specific documentation in the project's README file that describes the recommended container settings for anybody not installing via the defaults in the unRAID template directly. https://github.com/cmccambridge/ocrmypdf-auto/blob/master/README.md#unraid-integration





(Note: At the moment, I've still got a few open questions to @Squid about that template in a DM, so I don't believe that it is live in CA just yet... feel free to wait on moving this thread until the template is live.)

Share this post


Link to post
23 hours ago, cmccambridge said:
Great catch [mention=7072]trurl[/mention], thanks! The unRAID template is already up and running here, but I had forgotten to go back and tidy up my TODO list.

There is now unRAID-specific documentation in the project's README file that describes the recommended container settings for anybody not installing via the defaults in the unRAID template directly. https://github.com/cmccambridge/ocrmypdf-auto/blob/master/README.md#unraid-integration


(Note: At the moment, I've still got a few open questions to [mention=10290]Squid[/mention] about that template in a DM, so I don't believe that it is live in CA just yet... feel free to wait on moving this thread until the template is live.)

Working out of town. I'll be looking at everything in ~12 hours  EDIT:  Its in there now

Sent via Tapatalk because I'm either at work or enjoying the summer


Edited by Squid

Share this post


Link to post
Posted (edited)

2019-01-08 16:27:42 - Processing complete in 3.820000 seconds with status 3: /input/test.pdf

There is no File

What is the problem ?

Edited by Abigel

Share this post


Link to post
10 minutes ago, Abigel said:

2019-01-08 16:27:42 - Processing complete in 3.820000 seconds with status 3: /input/test.pdf

There is no File

What is the problem ?

Any other information you can give us? Your docker run command, for example?



Share this post


Link to post
1 hour ago, trurl said:

Any other information you can give us? Your docker run command, for example?



I use no command, only install the plugin

Share this post


Link to post
3 minutes ago, Abigel said:

I use no command, only install the plugin

Did you even bother to read the link I gave you? It explains exactly how to get the information I was asking for, the docker run command.

Share this post


Link to post

Sorry, I hadn't seen it on the smartphone, looked like a signature.



root@localhost:# /usr/local/emhttp/plugins/dynamix.docker.manager/scripts/docker run -d --name='ocrmypdf-auto' --net='bridge' -e TZ="Europe/Berlin" -e HOST_OS="Unraid" -e 'OCR_OUTPUT_MODE'='MIRROR_TREE' -e 'OCR_ACTION_ON_SUCCESS'='NOTHING' -e 'OCR_PROCESS_EXISTING_ON_START'='1' -e 'OCR_LANGUAGES'='' -e 'OCR_NOTIFY_URL'='' -e 'OCR_VERBOSITY'='' -e 'USERMAP_UID'='99' -e 'USERMAP_GID'='100' -v '/mnt/user/pre/':'/input':'rw' -v '/mnt/user/after/':'/output':'rw' -v '/mnt/user/appdata/ocrmypdf-auto':'/config':'rw' 'quay.io/cmccambridge/ocrmypdf-auto'

0d96f4947c0a21a2527ecf4c484b993859d7d9ca73c1c437989167d580d50da6



Share this post


Link to post

Hi @Abigel, sorry to hear you're having issues... I'm away on vacation at the moment and so don't have access to a computer to debug, but one thing comes to mind to try. The most recent change made to the code was regarding support for multiple languages. Perhaps we introduced a bug there that didn't surface until now.



Could you try explicitly setting OCR_LANGUAGES="enu" (or your language of choice) even though it's supposed to work correctly without?



Let me know if that changes anything...

Share this post


Link to post
Posted (edited)

Hi

i have choose en OCR_LANGUAGES'='enu' but this comes:



Reading package lists...
---- Installing Tesseract Langauge: en via tesseract-ocr-en
Reading package lists...
Building dependency tree...
Reading state information...
E: Unable to locate package tesseract-ocr-en

when i choose

OCR_LANGUAGES="enu"

it works

but in the docker run command it is written like OCR_LANGUAGES'=''



thanks for your help!



Can the program recognize handwriting?

Edited by Abigel

Share this post


Link to post
3 hours ago, Abigel said:

Can the program recognize handwriting?

Depends on the penmanship.

Share this post


Link to post

I have test it with block capitals but it doesnt work.

Nothing is detectet as Word

Share this post


Link to post

I'm glad that it's working now for you, @Abigel - I believe I know what the problem was there, and will get an update posted so that other folks don't run into the same problem down the road. Thanks for reporting this!



Re: handwriting recognition... This isn't really the intended purpose for tesseract, the OCR program that ocrmypdf-auto is using internally. I have limited success with recognizing block letter handwriting, such as the attached example... you can see that it mostly recognized the block letters (mistook "IS" for "1S"), did similarly OK on mixed upper and lowercase printed letters (mistook "Hello" for "Yello" and got some capitalization wrong), and did poorly on cursive lettering. If you want to research this further, here's a link I had found regarding academic research into customizing tesseract for handwriting recognition... it sounds like the accuracy is not very good: https://stackoverflow.com/questions/39556443/using-tesseract-for-handwriting-recognition



Note: If it wasn't clear from the documentation or your experience with ocrmypdf-auto, there's one thing I should clarify: The program intentionally does not change the input image of the PDF itself, other than some minor quality enhancements like deskewing, etc. Instead, the program only adds an extra invisible "text layer" to the output PDF that lets you search for and highlight recognized text.  For example, if you highlight all the handwriting in the output sample here, you can copy and paste the following "recognized" text:

HELLO, THIS 1S AN OCR TEST.
Yello, this is an OcR test.
Alle, thin ko am OCR et.



OCR Test Input.pdf

OCR Test Output.pdf

Share this post


Link to post

Okay

My goal is to have my handwritten notes recognized by the search in the PDF document. I study and take a lot of notes. I took photos of my notes and had hoped that I could search for words in the document if I only wanted to read a certain word. Unfortunately, it doesn't work very well for me. Maybe it's my handwriting. Is it possible to train the program in my handwriting?
Could it be that I write in German?

For example the documents in the attachement.

Is there any way to get to my destination?
If necessary also with other software?



input.pdf

output.pdf

Share this post


Link to post

Hi @Abigel - couple of thoughts...



First and most important: the tesseract OCR engine that is used by ocrmypdf-auto really isn't optimized for handwriting.



It's designed for typeset / printed text which has properties that make it "easier to read" like consistent letter shapes, letter spacing, word spacing, line breaks, etc. You can read all the gory details on the tesseract homepage, or explore some of the academic research efforts to extend the engine to handwriting, but the short version to my understanding is: handwriting recognition is a lot harder than recognizing typeset text.



That said... here would be my best tips :) Sorry that I don't have any solution to this problem...

  • Your example image appears to be a cellphone photo of a page of text. This should work, but you will probably get better results the closer your image looks to a black-and-white piece of paper. Tesseract has tips on improving recognition by improving image quality.
    • For example, in your files the handwriting is blue on a tan background... this is clear to a human, but not as obvious to a computer. It will be easier for the computer to understand if all text is black on white.
    • If you have access to a scanner, I would try that instead of a phone camera, since the scanner will remove some of the artificial "room coloring" that a phone camera sees.
    • Or, convert your phone image to black and white and increase the contrast before trying to run OCR on it, so that the text versus background are very clear for the computer.
  • Since the OCR engine does try to recognize full words, not just individual letters, it's important to tell it what language(s) to expect. This is what the OCR_LANGUAGES variable is for. In your case, since you're writing in German, I would try setting OCR_LANGUAGES="deu" to install the German language data, rather than the default of English.
  • And as a side tip... the best program I've ever seen for recognizing actual handwriting is a somewhat unexpected one: Microsoft OneNote. This may not be helpful to you at all unless you have a Windows computer, but it could be worth a try :).  I am not sure whether it will do as good a job recognizing handwriting in a photo as it does recognizing direct pen input on a tablet, though...
I did a quick experiment with some of the tips above, and got slightly better results... enough that it might be worth it for you to keep experimenting? Up to you :)
  1. Converted your image to black and white.
  2. Increased the contrast until the handwriting was very black and the background was very white.
  3. Ran ocrmypdf-auto with OCR_LANGUAGES=deu
The result was partial recognition:
Das Haus ı5+ gem.

Best of luck!

input_black_white.pdf

output_black_white.pdf

Share this post


Link to post

many thanks!

it hasn't completely solved my problem because not everything is recognized and OneNote Not my solution ist. But I have come much closer to the solution, thank you very much.
