[Support] Nginx Proxy Manager (NPM) Official

[Braulio Dias Ribeiro]

17 hours ago, blaine07 said:

Woah, figured mine out, finally. Not sure what should or shouldn't be on to be honest...Recently, a few weeks ago? Converted from Tailscale DOCKER to Tailscale PLUGIN.

This, Tailscale DNS, was set to "YES." Once I changed it to "NO" and restarted NPM it updates and does as should correctly. Do I need DNS on or off or is that going to break what I am doing with Tailscale plugin or?

This DNS can be turned off.
It is related to guiding the devices in your VPN.
This is interesting for advanced configurations. It has no bearing on your case.

You will use this to create routes in your VPN.
Example: when you want to access nextcloud.yourdomain.com.br and want to open nextcloud only for those on your VPN

Edited Friday at 04:08 PM by Braulio Dias Ribeiro

[Braulio Dias Ribeiro]

17 hours ago, blaine07 said:

Woah, figured mine out, finally. Not sure what should or shouldn't be on to be honest...Recently, a few weeks ago? Converted from Tailscale DOCKER to Tailscale PLUGIN.

This, Tailscale DNS, was set to "YES." Once I changed it to "NO" and restarted NPM it updates and does as should correctly. Do I need DNS on or off or is that going to break what I am doing with Tailscale plugin or?

Uallll....thank you very much
This was my problem too....now everything is working perfectly

[Braulio Dias Ribeiro]

My final configuration to help others peoples.



Settings -> Tailscale -> Settings - Advanced view
Use Tailscale Subnets: no
Use Tailscale DNS settings: no



Settings -> Dockers
Docker custom network type: ipvlan
Host access to custom networks: Enabled



Settings -> Network Settings -> Routing Table
I created a network only to docker (bdrtec)

All the containers (dockers) are installed on this network (bdrtec).
Only “AdGuard” and "NPM" containers are installed on network “br0” with fixed IP.



On my router I've added the AdGuard IP (192.168.10.239) as primary DNS (first in line). This way all network traffic goes through AdGuard.

When the traffic arrives at AdGuard, it checks the domains I have registered (nextcloud.mydomain.com.br, n8n.mydomain.com.br, among others) and redirects them to the NGINX Proxy Manager (192.168.10.238).


The NGINX Proxy Manager redirects to the configured local IPs.
nextcloud.mydomain.com.br = 192.168.10.254:Port
n8n.mydomain.com.br = 192.168.10.254:Port
